QQFPBTAG02C2Bluetooth Audio Gateway

Confidential Page 1 8/6/2003 2210 O’Toole Ave. #200, San Jose, Ca. 95131 Tel: 408-576-1770 Fax: 408-576-1790 2210 O'Toole Ave #200 San Jose, CA 95131 TEL : 408.576.1770 FAX : 408.576.1790 [email protected] http://www.windigosys.com/ Windigo Products Windigo Bluetooth(TM) Audio Gateway (Audio Only) User manual Ver.1.1 August 6, 2003 Confidential Page 3 8/6/2003 2210 O’Toole Ave. #200, San Jose, Ca. 95131 Tel: 408-576-1770 Fax: 408-576-1790 1. Introduction Bluetooth profile K-6 gives an implementation guideline for Bluetooth headset application, which includes two functions: Bluetooth headset and Bluetooth audio gateway. Generally headset profile will be implemented in headset, and audio gateway will be implemented in cellular phone, PBX or other communication devices. Windigo systems has developed a fully Bluetooth V1.1 compliant audio gateway module for these devices without embedded Bluetooth functionality. This manual will explain the basic audio gateway operation instruction to our customers. 2. A glimpse at the headset Figure 1 illustrates the reference audio gateway module design. Figure 1. Windigo Bluetooth Audio Gateway Reference Design The audio gateway (hereafter as AG) module includes a green LED, a red LED, a three-way button, an audio jack and one DC jack, these elements are illustrated in figure 2. Both green LED and red LED are used to indicate various operation status for the AG module, such as pairing, connecting, talking...etc. One push button is used to initialize various operations, such as activating the AG function, turning off the AG module, pairing, connecting, etc. Audio jack is used to connect an external microphone and speaker. Windigo Bluetooth AG module must be paired with Windigo Bluetooth headset before it is fully functional. Please refer to the Bluetooth headset user manual on how to initialize and operate the headset and its various functions. Confidential Page 4 8/6/2003 2210 O’Toole Ave. #200, San Jose, Ca. 95131 Tel: 408-576-1770 Fax: 408-576-1790 Figure 2. Key elements on Windigo Bluetooth Headset 3. Getting start Step 1: Be sure the AG module is powered up properly, and headset battery is fully charged. Step 2: Be sure the AG module is in idle state; otherwise, follow bellow procedure to put the AG module into idle state. A. If blue LED flashing, press and hold the button for 3 seconds till the blue LED is off, this will put the AG module into idle mode. Step 3: Enter into pairing mode While in this idle mode, both amber and blue LEDs are off. To enable the pairing mode, press and hold the talk button for about 3 seconds till both the blue and amber LED starts to flash alternatively, then release the button. Note: 1. AG module can only be paired with Windigo headset 2. Pairing feature is used to establish the relationship between headset and audio gateway. Any given headset can only talk with the paired audio gateway after a successful pairing session. 3. Pairing mode can be cancelled by depressing the talk button for about 3 seconds, until both blue LED and amber LED are off. Then the audio gateway is put into idle mode again. Amber LED Audio Jack Blue LED DC jack for charging Push Button Confidential Page 5 8/6/2003 2210 O’Toole Ave. #200, San Jose, Ca. 95131 Tel: 408-576-1770 Fax: 408-576-1790 4. Due to lack of display capability, so AG module will automatically paired with the first found headset. Make sure there is only one headset is in pairing mode. Step 4: If AG module is paired with headset successfully, the AG module will connect to headset automatically whenever there is active incoming call or outgoing call. If the AG module connects to headset successfully, the blue LED will flash and amber LED will be off for normal operation. If battery runs low, then the amber LED will flash, and blue LED will be off. Step 5: If the AG module has been successfully paired with headset, then AG module is ready to use. 4. Summary of the LED display No display AG module is in idle mode Flashing in blue at 3 seconds interval AG module is in standby mode Flashing in blue at 0.5 seconds interval while amber LED is off AG module is in connecting mode (master mode) Flashing alternatively for both amber and blue LED AG module is in pairing mode Flashing in blue at 1 seconds AG module is in working mode. Voice connection is up Note: When the battery runs low, all the LED indication will be displayed on amber color. 5. Summary of button operation Press and hold for 3 seconds When AG module is in idle mode, this will put AG module into pairing mode. When AG module is in pairing module, this will cancel the pairing mode and put AG into idle mode. When AG module is in standby mode, this will put AG module into idle mode. Confidential Page 6 8/6/2003 2210 O’Toole Ave. #200, San Jose, Ca. 95131 Tel: 408-576-1770 Fax: 408-576-1790 6. Summary of status transition Both blue and amber LEDs are turned off Green LED and red LED flash alternatively Red LED is turned off, and green LED flashes Red LED flashes, and green LED is turned on Red LED is turned off, and green LED is turned on Normally the AG module will stay in standby mode unless user initializes shutdown operation! Idle/Shutdown pairing Standby Talking (Cancel Pairing Mode) Depress Talk Button for 3 s Depress Talk Button for 3 s

Windigo Systems August 6, 2003 Federal Communications Commission Authorization and Evaluation Division FCC ID: QQFPBTAG02C2 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Singer Name) / (Title) Windigo Systems

Ersteller: U. Rodemeier Revision: 00 Erstelldatum: 3. August 2001 Datum: 3. August 2001 Seite 1 von 1 E:\Ready_To_Convert\Doc\375173.DOC Windigo Systems Address: 2210 O’Toole Ave,Suite 200 San Jose,CA 95313 USA. Telephone: 408 576-1779 FAX: 408 576-1790 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg To Whom It May Concern: Please be advised that Windigo Systems authorizes Interocean EMC Technology Corp to act on our behalf, until otherwise notified, for applications submitted to PHOENIX TEST-LAB GmbH (PTL). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C.862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory

Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 50 of 56 Interocean EMC Technology Corp. FCC EMC Test Report 14 Photographs of EUT Front View of Appearance (PBTAG02C2-1) Rear View of Appearance (PBTAG02C2-1) Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 51 of 56 Interocean EMC Technology Corp. FCC EMC Test Report I/O Port of EUT (PBTAG02C2-1) I/O Port of EUT (PBTAG02C2-1) Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 52 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Front View of EUT (PBTAG02C2-2) Inside View of EUT

LABEL 10mm 30mm This statement will be placed in User Manual. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 52 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Front View of EUT (PBTAG02C2-2) Inside View of EUT Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 53 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Component Side View of Main Board Solder Side View of Main Board PCB Antenna Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 54 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Front View of Power Adapter Rear View of Power Adapter Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 55 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Label of Power Adapter Inside View of Power Adapter Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 56 of 56 Interocean EMC Technology Corp. FCC EMC Test Report Component Side of Main board (Power Adapter) Solder Side of Main board (Power Adapter)

Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 1 of 57 FCC Part 15 EMI TEST REPORT of E.U.T.:Bluetooth Audio Gateway Trade Name: Windigo Systems Model Number:PBTAG02C2-XX (X=A~Z, 0~9 or Blank) Prepared for Windigo Systems 2210 O’Toole Ave Suite 200, San Jose, CA 95131, U.S.A. TEL:+408 576 1779 FAX:+408 576 1790 Prepared by Interocean EMC Technology Corp. No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 57 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test results in the report only to the tested sample. Interocean EMC Technology Corp. FCC EMC Test Report Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 3 of 57 Table of Contents 1 General Information 6 1.1 Description of Equipment Under Test 6 1.2 Supporting System Detail (For Radiation Emission Measurement) 7 1.3 Test Methodology 7 1.4 Bluetooth Approvals 7 1.5 Test Facility 7 2 PROVISIONS APPLICABLE 8 2.1 Definition 8 2.2 Requirement for Compliance 9 2.3 Restricted Bands of Operation 11 2.4 Labeling Requirement 12 2.5 User Information 12 3 SYSTEM TEST CONFIGURATION 13 3.1 Justification 13 4 Power Line Conducted Emission Measurement 14 4.1 Instrument 14 4.2 Block Diagram of Test Configuration 14 4.3 Conducted Limit (Power Line) 15 4.4 Measurement Procedure 15 4.5 Measuring Instrument 15 4.6 Test Step of EUT 15 5 RADIATED EMISSION MEASUREMENT 20 5.1 Instrument 20 5.2 Block Diagram of Test Configuration 20 5.3 Applicable Standard 21 5.4 Measurement Procedure 21 5.5 Measuring Instrument 22 5.6 Test Step of EUT 22 5.7 Radiated Emission Data 23 5.8 Field Strength Calculation 30 6 ANTENNA REQUIREMENT 31 6.1 Standard Applicable 31 6.2 Antenna Construction and Directional Gain 31 Interocean EMC Technology Corp. FCC EMC Test Report Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 4 of 57 7 HOPPING CHANNEL BANDWIDTH MEASUREMENT 32 7.1 Standard Applicable 32 7.2 Measurement Procedure 32 7.3 Measurement Equipment 32 7.4 Measurement Data 32 8 MAXIMUM OUTPUT POWER MEASUREMENT 33 8.1 Standard Applicable 33 8.2 Measurement Equipment 33 8.3 Measurement Data 33 9 100 kHz BANDWIDTH OF BAND EDGES MEASUREMENT 34 9.1 Standard Applicable 34 9.2 Measurement Procedure 34 9.3 Measurement Equipment 34 9.4 Measurement Data 34 10 HOPPING CHANNEL SEPARATION 35 10.1 Standard Applicable 35 10.2 Measurement Procedure 35 10.3 Measurement Equipment 35 10.4 Measurement Data 35 11 NUMBER OF HOPPING FREQUENCY USED 36 11.1 Standard Applicable 36 11.2 Measurement Procedure 36 11.3 Measurement Equipment 36 11.4 Measurement Data 36 12 DWELL TIME ON EACH CHANNEL 37 12.1 Standard Applicable 37 12.2 Measurement Procedure 37 12.3 Measurement Equipment 37 12.4 Bluetooth operation modes 38 12.5 Measurement Data 38 13 HOPPING SEQUENCE TEST 39 14 Receiver input bandwidth 39 A1.1 Mode 1: Charge Mode 40 A1.2 Mode 2: TX/RX Mode 41 Interocean EMC Technology Corp. FCC EMC Test Report Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 5 of 57 15 Photographs of Measurement 49 15.1 Power Line Conducted Emission Measurement 49 15.2 Radiated Emission Measurement 50 16 Photographs of EUT 51 Interocean EMC Technology Corp. FCC EMC Test Report Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 6 of 57 1 General Information 1.1 Description of Equipment Under Test Equipment Under Test : Bluetooth Audio Gateway Model Number : PBTAG02C2-XX (X=A~Z, 0~9 or Blank) Serial Number : N/A Type of Sample Tested : Proto-type Pre-Production Mass Production Applicant : Windigo Systems 2210 O’Toole Ave Suite 200, San Jose, CA 95131, U.S.A. Manufacturer : Wearnes Electronics (M) Sdn Bhd 99, Jalan Parit Masjid, 82000 Pontian, Johor, Malaysia. Power Adapter : Manufacturer: BALANCE ELECTRONICS, M/N: GPSA-0750150 Input: 100-240Vac, 50-60Hz, 0.5A Output: 7Vdc, 0.6A Power cable: Non-shielded Detachable, 1.8m Date of Receipt of Sample Aug. 18, 2003 Date of Test Aug. 18 ~ Oct. 15, 2003 Description of E.U.T. 1. The EUT is Bluetooth Audio Gateway. 2. Windigo Bluetooth Audio Gateway is battery power wireless communication device used to transfer both control command and voice between headset and audio gateway device, which is Bluetooth specification V1.1 compliant, and a single chip RF transceiver from Cambridge Silicon Radio is used. Single 16MHz crystal is used for both generating the timing for Bluetooth communication and internal micro- controller. PCB antenna is built in. The maximum antenna Gain is 2.5dBi.This Bluetooth audio gateway is major used with cellular phone as hands-free kit, but also can be used with computer, notebook, PDA and other computing and communication devices. 3. EUT Ports: 1 Audio Out Port * 1. 2 Power Port * 1. 4. The PBTAG02C2-1 is representative selected in the test and included in this report. Interocean EMC Technology Corp. FCC EMC Test Report Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 7 of 57 1.2 Supporting System Detail (For Radiation Emission Measurement) z IBM Note Book Model Number : 2655-GT1 Serial Number : 78-LRZR4 EMC Approved : FCC DoC, CE, VCCI, 檢磁 3902I050 Manufacturer : IBM Adapter : IBM AA21070, 檢磁 3892A299 Input: 100-240Vac, 1.2~0.5A, 50/60Hz Non-shielded, Detachable, 1.5m Output: 16Vdc, 4.5A Non-shielded, Un-detachable, 1.8m z Bluetooth Earphone Model Number : PBTHSTF2C2-ELC Serial Number : N/A EMC Approved : QQFPBTHSTX2C2XXX Manufacturer : Windigo 1.3 Test Methodology For Bluetooth Audio Gateway, both conducted and radiated emissions were performed according to the procedures illustrated in ANSI C63.4 (1992) and Other required measurements were illustrated in separate sections of this test report for details. 1.4 Bluetooth Approvals For Bluetooth Earphone meeting the Bluetooth Specifications in the 2.4GHz band as of February 2001 operating in the USA. 1.5 Test Facility The open area test site and conducte…

Text truncated - open the document above for the full version.

Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 48 of 56 Interocean EMC Technology Corp. FCC EMC Test Report 13 Photographs of Measurement 13.1 Power Line Conducted Emission Measurement Front View Rear View Report No.: 3A080705FR FCC ID: QQFPBTAG02C2 Page 49 of 56 Interocean EMC Technology Corp. FCC EMC Test Report 13.2 Radiated Emission Measurement Front View Rear View
