QSCTIA

Siemens Transportation Systems exclusive property New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév : 0002/00 Traduction : EN Mémo : 624480 Date : 08/02/2002 Projet / Project Arborescence / Technical number NYL Canarsie Line CBTC System Contract S-32701 CBTC/1350/DS/10 Type de document / Type of document CATALOG CUT SHEET TITRE / TITLE TRANSPONDER INTERROGATOR ANTENNAE (TIA) Mots clés descripteurs / Descriptors Rédacteur / Author Nombre de pages / Number of pages G. LEDOUX 9 APPROBATION / APPROVAL Nom / Name Fonction / Function Date / Date Signature / Signature Prepared by G. LEDOUX Checked by M. GOUVEA V. POUZOL Authorized by: D. GRIMBERT E&SW Architecture Designer Hardware Quality Engineer Hardware Technical Supervisor Siemens MTI Project Manager New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 Date : 08/02/2002 TRANSPONDER INTERROGATOR ANTENNAE (TIA) - 2 / 9 - Siemens Transportation Systems exclusive property SUIVI D’EVOLUTIONS / REVISION RECORDS Edition / Révision Version number Date Date § concernés Affected § Modification Change Justification Justification 00/00 01/00 02/00 07/09/01 09/11/01 08/02/02 All All Annexe Minor form corrections First issue FCC information New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 Date : 08/02/2002 TRANSPONDER INTERROGATOR ANTENNAE (TIA) - 3 / 9 - Siemens Transportation Systems exclusive property TABLE OF CONTENTS 1. ENVIRONMENT CLASSIFICATION ..................................................................................... 4 2. PRODUCT FUNCTION.......................................................................................................... 4 3. PRODUCT INSTALLATION CONSTRAINTS ....................................................................... 4 4. ELECTRICAL INTERFACE................................................................................................... 4 5. MECHANICAL INTERFACE ................................................................................................. 4 6. ILLUSTRATIONS ..................................................................................................................5 7. RAMS .................................................................................................................................... 6 8. ENVIRONMENTAL CHARACTERISTICS ............................................................................ 6 9. EMI / EMC ............................................................................................................................. 6 10. GLOSSARY........................................................................................................................... 7 11. REFERENCES ......................................................................................................................7 ANNEXE A : FCC INFORMATION ................................................................................................ 8 END OF DOCUMENT.................................................................................................................... 9 New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 Date : 08/02/2002 TRANSPONDER INTERROGATOR ANTENNAE (TIA) - 4 / 9 - Siemens Transportation Systems exclusive property 1. ENVIRONMENT CLASSIFICATION Environment Classification Vehicle Interior … Vehicle body Mounted … Vehicle Truck Mounted ; Wayside Outdoors … Wayside Equipment cases and Relay Rooms … Computer Rooms … 2. PRODUCT FUNCTION TIA receives signals from the transponders installed on the track. Theses data are processed by the carborne controller computer unit to verify and update the localization of the train. 3. PRODUCT INSTALLATION CONSTRAINTS Location on the train – The TIA is secured to the center of the first truck of A1-car. Positioning and mounting on the truck with reference to the TOR: 8 Nominal height: 5.5" 8 Maximum height: 5.82" 8 Minimum height: 1.98" 4. ELECTRICAL INTERFACE Input Yes Output Yes Protection None The TIA is linked to the OBCU by one specific shielded cable, made of 4 twisted shielded pairs featuring a 50 Ohms impedance at 10 MHz. The cable is connected to the TIA to a Leatton Veam socket type: CIR 07R20.11P.F80.T100.V0 by means of a plug type CIRG06SB 18-20.11S.F80.T100.V0. 5. MECHANICAL INTERFACE The transponder consist of a rectangular box, mechanically attached to the truck by means of 4 screws (3/8" grade 5) with a tied torque of 15 to 16 N.M (20.3 to 21.7 FT_LBF).. The weight of a TIA is approximately 13 pounds. New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 Date : 08/02/2002 TRANSPONDER INTERROGATOR ANTENNAE (TIA) - 5 / 9 - Siemens Transportation Systems exclusive property 6. ILLUSTRATIONS TIA Mechanical interface drawing New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 Date : 08/02/2002 TRANSPONDER INTERROGATOR ANTENNAE (TIA) - 6 / 9 - Siemens Transportation Systems exclusive property 7. RAMS Characteristic Qualification standard or equivalent Applied Level (when relevant) MTBF UTE C80 810 2 339 290 h Electrical Insulation 500 V AC 8. ENVIRONMENTAL CHARACTERISTICS Characteristic Qualification standard or equivalent Applied Level (when relevant) Operating ambient temperature MIL-STD-810F -25°C / +70°C Storage temperature MIL-STD-810F -40°C / +85°C Shock (temperature) N/A Humidity (non condensing) MIL-STD-810F 95% Sinusoidal vibration N/A Random vibration EN 61373 Shock EN 61373 30 g / 18 ms Salt Fog MIL-STD-810F Sand EN 60529 IP65 Rain EN 60529 IP65 Dust / Metallic Dust EN 60529 IP65 9. EMI / EMC Characteristic Qualification standard or equivalent Applied Level (when relevant) Operating Frequencies 128 kHz and 9,984 MHz Emission EN 50121-3-2 Immunity EN 50121-3-2 FCC Part 15 New York City Transit Réf. : DEL/NYL/39.1354.01/GLE/GLE Ed/Rév :0002/00 Trad.: EN Mémo : 624480 …

Text truncated - open the document above for the full version.

FCC ID Label and Location Label to be mounted on the side of the Transponder Interrogator Antenna chassis FCC ID:QSCTIA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Location of the label

CABAL édition du 24/03/2003 NOMENCLATURE INDUSTRIELLE Ref : 843520 ind : 04 NiveauRepères Topo.QuantitéUnitéDescription de l''articleRéférence principaleCode articleInd. 0U (Unité)CABAL8435204 1172U (Unité) COL.AUTO-VERROU.TY RAP TY 24MTY 24M40510 1100,5 U (Unité) FIL DE FRETTE NOIRGUDELACE STYLE 2060370 161U (Unité) RONDELLE M 3, NYLONNF E 25-513182300 131U (Unité) RONDELLE M 5, NYLONNF E 25-513184530 1ST1,ST2,ST32U (Unité) COMMU.DIP-FIX 8 CONNEX.C42315 A1347 A108199800 1162 U (Unité) PLOT A FOURC.BFM 13 24311 0078 0 00 53 0209490 1C131U (Unité) 10,00 PF 05% 100VCE13N227790 1C8,C92U (Unité) 1,00 NF 10% 100VCN31N230390 1181U (Unité) RHODORSILCAF 4248970 1C31 U (Unité) 150,00 PF 05% 1000VMF5277950 1C21U (Unité) 270,00 PF 05% 1000VMF5277960 1C11,C162U (Unité) 1,00 PF A 30,00 PF5601283590 1R61U (Unité) 1,00 OH 01%RS64Y287350 1C12,C14,C173 U (Unité) 150,00 PF 05% 100VCE13N292870 1C181U (Unité) 1,00 NF 20% 400VWKP303880 141U (Unité) ECROU HFR M5 NYLON PA6.650,001309460 1TB21U (Unité) BANDE DE REPERAGE"1 A 16"249-16634089 1C11 U (Unité) 1,80 NF 01% 1000VCA134099 1C41 U (Unité) 68,00 PF 05% 1000VMF534100 1C51U (Unité) 39,00 PF 05% 1000VMF534101 1C61U (Unité) 18,00 PF 05% 1000VMF534102 1C71 U (Unité) 10,00 PF 05% 1000VMF534103 1R21 U (Unité) 1,50 OH 01%RS64Y34105 1R3,R42U (Unité) 49,90 OH 01%RS64Y34106 1R51U (Unité) 0,51 OH 01%RS64Y34107 1R71 U (Unité) 2,05 OH 01%RS64Y34108 1R81 U (Unité) 4,02 OH 01%RS64Y34109 1TB11 U (Unité) BORNE 12 PLOTS POUR C.I.233-51234110 1TB11 U (Unité) BANDE DE REPERAGE"1 A 16"249-15634111 1TB21U (Unité) BORNE 4 PLOTS POUR C.I.255-40434112 121U (Unité) VIS CLS,M 5 - 20, NYLONNF E 25-12834187 171U (Unité) ECROU HFR M3 NYLON PA6.630,00134189 151 U (Unité) VIS CLS,M 3 - 12, NYLONNF E 25-12834610 1R11 U (Unité) 3,30 OH 01%RTO2034611 180,015U (Unité) RESINE EPOXIDEDP10534679 1C10,C152U (Unité) COMPOSANT NON MONTE8239160 194U (Unité) CALE EPOXY EP.2,010 X 58369830 1T1B0 U (Unité) 014.005.T52007 1F 34 128407500 111U (Unité) CIRCUIT CABAL8435214 20U (Unité) DECOUPE CIRCUIT CABAL8436221 1T21U (Unité) BOBINAGE8438021 1T1A1 U (Unité) BOBINAGE8438030 1111U (Unité) MONTAGE TO220/DISSIPATEURKIT MONTAGE N. 1628438241 242UNITE VIS CS ,M 3 - 14, INOXNF E 25-12718970 254UNITE RONDELLE ONDULEE M 3 INOXNF E 27-620141850 262UNITE ECROU HFR,M 3 , INOX A2NF E 25-409282900 221UNITE DISSIPATEUR POUR TO220TV21288340 1141 U (Unité) ETIQ. D'IDENTIFICATIONFORMAT 76,2 X 6,358443570 21UNITE ETIQUETTE 76,20 X 6,35THT-16-42334742 1151 U (Unité) ETIQ. GESTION D'INDICESFORMAT 76,2 X 6,358443580 21UNITE ETIQUETTE 76,20 X 6,35THT-16-42334742 1131U (Unité) ETIQ. SERIALISATIONFORMAT 25,4 X 12,78443590 21UNITE ETIQUETTE 25,40 X 12,7BPT-5-753634741 1121 U (Unité) ETIQUETTE DE NOM DE CARTEFORMAT 25,4 X 12,78443600 21UNITE ETIQUETTE 25,40 X 12,7BPT-5-753634741 1R91U (Unité) 9,09 OH PUIS 1,00 OH A 20,00 OH 01%RS64Y844440

Duplication of this document is only permitted for an integral photographic facsmile. It includes the number of pages referenced hereabove.. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole production to the item tested. EMITECH C129 Rév.0 RC-01-40826/1/TC E.M.C Test Report According to the standard: FCC PART 15 Edition 2002 Equipment under test: TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630 Company: SIEMENS TRANSPORTATION SYSTEMS DISTRIBUTION: Mr. ESTIEVENART (Company: SIEMENS TRANSPORTATION SYSTEMS) Number of pages: 18 + 2 annexes Ed. Date Modified pages Prepared By Name Signature Reviewed By Name signature Approved By Name signature 0 25/06/02 Creation T. COLARD RC-01-40826/1 Date : 25/06/2002 Page : 2 / 18 TEST CERTIFICATION FOR: FCC Certification NAME OF THE EQUIPMENT UNDER TEST: TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) Type: 843630 Serial number: PNYL 003 (V2) NAME OF THE MANUFACTURER: SIEMENS TRANSPORTATION SYSTEMS ADDRESS OF THE COMPANY INTRODUCING THE EQUIPMENT: Company : SIEMENS TRANSPORTATION SYSTEMS Address : 48 à 56, rue Barbès BP 531 92542 Montrouge Cedex France Person in charge : Mr. ESTIEVENART Present person during the tests : Mr. N'GUYEN and Mr. ESTIEVENART DATES OF TESTS: The 15 th March, 15 th April and 14 th June 2002 TESTS LOCATION: EMITECH open area test site in Aunainville (28) TESTS OPERATORS: T. COLARD / E. COEURET RC-01-40826/1 Date : 25/06/2002 Page : 3 / 18 TABLE OF CONTENTS 1. INTRODUCTION ________________________________________________________________ 4 2. REFERENCE DOCUMENT _______________________________________________________ 4 3. EQUIPMENT UNDER TEST (EUT) CONFIGURATION_______________________________ 4 4. SUMMARY OF TEST RESULTS ___________________________________________________ 6 5. INTENTIONAL RADIATED EMISSIONS IN THE BAND 9 KHZ – 0.49 MHZ ____________ 7 6. INTENTIONAL RADIATED EMISSIONS IN THE BAND 1.705 MHZ – 10 MHZ_________ 10 7. UNINTENTIONAL RADIATED EMISSIONS IN THE BAND 9 KHZ – 30 MHZ __________ 12 8. UNINTENTIONAL RADIATED EMISSIONS IN THE BAND 30 MHZ – 1 GHZ __________ 14 Annexes: Customer’s questionnaire. Antenna factors, insertion losses and amplifier values. RC-01-40826/1 Date : 25/06/2002 Page : 4 / 18 1. INTRODUCTION This document submits the results of Electromagnetic Compatibility tests performed on the equipment "TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630" here in referred to as the EUT, according to the document listed below. 2. REFERENCE DOCUMENT FCC PART 15 Edition 2002 Code of Federal Regulations Title 47- Telecommunication Chapter 1- Federal Communication Commission Part 15- Radio frequency devices Subpart C- Intentional Radiators 3. EQUIPMENT UNDER TEST (EUT) CONFIGURATION See photograph next page. See customer’s questionnaire in annex. See antenna factors, insertion losses and amplifier values in annex. Modification of the equipment during the tests: No RC-01-40826/1 Date : 25/06/2002 Page : 5 / 18 Photograph of the equipment under test (EUT) RC-01-40826/1 Date : 25/06/2002 Page : 6 / 18 4. SUMMARY OF TEST RESULTS The following table summarizes test results of the EUT. Test results Designation of test Pass Fail N.A. N.P. Comments Intentional radiated emissions in the band 9 kHz – 0.49 MHz 9 Section 15.209 Intentional radiated emissions in the band 1.705 MHz – 10 MHz 9 Section 15.223 Unintentional radiated emissions in the band 9 kHz - 30 MHz 9 Section 15.209 Unintentional radiated emissions in the band 30 MHz – 1 GHz 9 Section 15.209 Conducted emissions on AC mains ports 9 Section 15.207 N.A.: Not Applicable N.P.: Not Performed The tested sample "TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630" complies with the requirements of the standard: ¾ FCC PART 15 Edition 2002 according to the limits specified in the present report. RC-01-40826/1 Date : 25/06/2002 Page : 7 / 18 5. INTENTIONAL RADIATED EMISSIONS IN THE BAND 9 KHZ – 0.49 MHZ Standard : FCC PART 15 Edition 2002 Section: 15.209 Equipment under test arrangement The equipment under test (EUT) is placed on a wooden table, at 0.8 m above the ground plane (turntable). Antenna height is 1 m above the ground plane. For each frequency corresponding to an emission, EUT carried out a rotation through 360° with the aid of the turntable, with the aim to find the maximum of signal. The test antenna is oriented in two orientations (perpendicular or parallel). Only the highest level is recorded. Test configuration photographs : The equipment was studied to work below a train, so we simulate the train in placing a large plan of copper at 10 cm above the transponder. RC-01-40826/1 Date : 25/06/2002 Page : 8 / 18 The standard ANSI C63-4 authorizes to realize the measurement in an open site without ground plane under the antenna at the frequencies inferior to 30 MHz. RC-01-40826/1 Date : 25/06/2002 Page : 9 / 18 Frequency range : 9 kHz – 0.49 MHz. Detection mode : Average Resolution bandwidth : 200 Hz Measurement distance : 10 meters. Limit : Frequency range (MHz) Frequency field strength (μV/m) Frequency measurement distance (meters) 0.009-0.490 2400/F (kHz) 300 Limits in dBμV/m can be extrapolated to 10 m using 40 dB / decade. Operating mode during the test : The transponder is detecting permanently the coil antenna. Instrumentation test list : Meter Nr Emitech Category Mark Type 187 3/16/12/004 OATS Emitech Site champ libre 315 3/24/18/049 Loop antenna Rohde et Schwarz HFH2-Z2 344 5/14/00/025 Power supply Rohde et Schwarz HZ-9 2205 1/02/18/068 Spectrum analyzer Agilent E7405A Results : FREQUENCY (MHz) ANTENNA ORIENTATION AZIMUTH (degrees) MEASUREMENT (dBμV/m) LIMIT (dBμV/m) MARGIN (dB) 0.128 Perpendicular 270 59.4 85.5 26.1 Observation during the test : The equipment complies with the requirements of the standard FCC PART 15.209 Edition 2002. RC-01-40826/1 Date : 25/06/2002 Page : 10 / 18 6. INTENTIONAL RADIATED EMISSIONS IN THE BAND 1.705 MHZ …

Text truncated - open the document above for the full version.

La reproduction de ce rapport d’essais n’est autorisée que sous sa forme intégrale. Il comporte le nombre de pages référencé ci-dessus. Le présent document résulte d’essais sur un spécimen, une éprouvette ou un échantillon d’un produit. Il ne préjuge pas de la conformité de l’ensemble des produits fabriqués à l’échantillon essayé. EMITECH C114 Rév.0 RC-02-45449/GL/ST E.M.C Test Report According to the standards: EN 50121-3-2 Edition 2000 Equipment under test: TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630 Company: SIEMENS TRANSPORTATION SYSTEMS DISTRIBUTION: Mr. ESTIEVENART (Company: SIEMENS TRANSPORTATION SYSTEMS) Number of pages: 17 + 3 annexes Ed. Date Modified pages Prepared By Name Signature Reviewed By Name signature Approved By Name signature 0 17/06/02 Creation G. LAUNAY RC-02-45449 Date 17/06/02 Page : 2 / 17 NAME OF THE EQUIPMENT UNDER TEST: TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630 NAME OF THE MANUFACTURER: SIEMENS TRANSPORTATION SYSTEMS ADDRESS OF THE COMPANY INTRODUCING THE EQUIPMENT: Company : SIEMENS TRANSPORTATION SYSTEMS Address : 48 à 56, rue Barbès BP 531 92542 Montrouge Cedex France Person in charge : Mr. ESTIEVENART Present person during the tests : Mr. N'GUYEN DATE OF TESTS: The 5 th February 2002 and 12 th March 2002 TESTS LOCATION: EMITECH laboratory in Montigny le Bretonneux (78) TESTS OPERATORS: G. LAUNAY and P. COMAILLE TESTS SUPERVISOR: E. COEURET RC-02-45449 Date 17/06/02 Page : 3 / 17 TABLE OF CONTENTS 1. INTRODUCTION ________________________________________________________________ 4 2. REFERENCE DOCUMENT _______________________________________________________ 4 3. EQUIPMENT UNDER TEST (EUT) CONFIGURATION_______________________________ 4 4. SUMMARY OF TEST RESULTS ___________________________________________________ 6 5. RADIATED EMISSION IN ABSORBER-LINED SHIELDED CHAMBER (PROCEDURE E1) _______________________________________________________________ 8 6. RADIATED ELECTRIC FIELD IMMUNITY (PROCEDURE E3) ______________________ 12 7. CONDUCTED RF IMMUNITY ON INPUT-OUTPUT CABLE (PROCEDURE E6) ________ 14 8. ELECTRICAL FAST TRANSIENT/BURST IMMUNITY ON INPUT-OUTPUT CABLE (PROCEDURE E8) ______________________________________________________________ 16 Annexes Customer’s questionnaire Customer's document 1 Customer's document 2 RC-02-45449 Date 17/06/02 Page : 4 / 17 1. INTRODUCTION This document submits the results of Electromagnetic Compatibility tests performed on the equipment "TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630" here in referred to as the EUT, according to the document listed below. 2. REFERENCE DOCUMENT EN 50121-3-2 Edition 2000 Railway applications Electromagnetic Compatibility Part 3-2: Rolling stock - Apparatus HARDWARE QUALIFICATION TEST PLAN Réf.: DEL / NYL / 39.1473.01 / GLE / GLE Ed / Rév.: 0002/00 (cf. customer’s document 2) HARDWARE ENVIRONMENTAL QUALIFICATION TEST PROCEDURE Réf.: DPM / NYL / 14.1549.01 / JME / JME Ed / Rév.: 0003/00 (cf. customer’s document 1) 3. EQUIPMENT UNDER TEST (EUT) CONFIGURATION See photograph next page. See customer’s questionnaire in annex. See customer’s document in annex. Modification of the equipment during the test: No Serial number: PNLY 003 (V2) RC-02-45449 Date 17/06/02 Page : 5 / 17 Photograph of the equipment under test (EUT) RC-02-45449 Date 17/06/02 Page : 6 / 17 4. SUMMARY OF TEST RESULTS The following table summarizes test results of the EUT. Test results Designation of test Pass Fail Comments Harmonics measurement N.A. Flicker measurement N.A. Radiated emission in absorber-lined shielded chamber (procedure E1) x Conducted emission on AC mains ports N.A. Radiated electric field immunity (procedure E3) x Conducted RF immunity on AC mains ports N.A. Conducted RF immunity on input-output cable (procedure E6) x Electrical fast transient/burst immunity on AC mains ports N.A. Electrical fast transient/burst immunity on input-output cable (procedure E8) x Electrostatic discharges immunity N.A. Surge immunity on AC mains ports N.A. Voltage dips, short interruptions and voltage variation immunity N.A. N.A.: Not Applicable RC-02-45449 Date 17/06/02 Page : 7 / 17 In emission : The tested sample "TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630" complies with the requirements of the standard: ¾ EN 50121-3-2 Edition 2000 according to the limits specified in the present report. In immunity : The tested sample "TIA: TRANSPONDER INTERROGATOR ANTENNA (ANBAL) TYPE 843630" complies with the requirements of the standard: ¾ EN 50121-3-2 Edition 2000 according to criteria specified in the present report. RC-02-45449 Date 17/06/02 Page : 8 / 17 5. RADIATED EMISSION IN ABSORBER-LINED SHIELDED CHAMBER (procedure E1) Standard : EN 50121-3-2 Edition 2000 Test method : EN 55011 Edition 1998 Equipment under test arrangement Floor standing EUT is placed directly on the horizontal metal ground plane, the points of contact being consistent with normal use, but separated from metallic contact with the ground plane by up to 12 mm of insulation. Frequency range : 30 MHz - 1 GHz Detection mode : Peak Resolution : Frequency range Resolution bandwidth Video bandwidth 30 MHz to 1 GHz 100 kHz 300 kHz Measurement distance : 3 m RC-02-45449 Date 17/06/02 Page : 9 / 17 Limit : The EUT must satisfy emission requirements of the standard for class A as shown in table below. Frequency range (MHz) Limit for Class A (dBμV/m) Limit for FCC part 15 (dBμV/m) 30 to 88 50 50 88 to 216 50 53.5 216 to 230 50 56.4 230 to 960 57 56.4 960 to 1000 57 59.5 Limits of radiated disturbances of the CISPR 11 or EN 55011 are specified for a test distance of 10 meters for class A equipment. The measurement distance used for test in the present report being 3 meters, published results are obtained by a theoretical conversion of the limit (as described in the standard). Operating mode during the test: The EUT is connected and powered on by the test tool through the antenna cable. The test tool is configured in the transpon…

Text truncated - open the document above for the full version.

Test set up photos
