QTLBH-220Bluetooth Headset

Nokia Luna User Guide Issue 1 Introduction About your headset With the Nokia Luna Bluetooth Headset, you can handle calls hands-free, even when you are using two phones at the same time. Remove the headset from the cradle, and it's instantly ready for use. The surface of this product is nickel-free. Warning: This product may contain small parts. Keep them out of the reach of small children. Parts of the product are magnetic. Metallic materials may be attracted to the product. Do not place credit cards or other magnetic storage media near the product, because information stored on them may be erased. Read this user guide carefully before using the product. Also, read the user guide for the device that you connect to the product. For more information, go to www.nokia.com/support. About Bluetooth connectivity You can use Bluetooth to make a wireless connection to other compatible devices, such as mobile devices. Devices do not need to be in direct line-of-sight, but they must be within 10 metres (33 feet) of each other. The connection may be affected by obstructions such as walls or other electronic devices. This device is compliant with Bluetooth Specification 2.1 + EDR supporting the following profiles: Headset Profile 1.1 and Hands-Free Profile 1.5. Check with the manufacturers of other devices to determine their compatibility with this device. 2 Get started Keys and parts 8 1Microphone 2Earpiece 3Charging indicator light 4Cradle 5Charger connector 6NFC area 7Bluetooth indicator light 8Multifunction key Charge the battery Before using the headset, you must charge the battery. Warning: Use only chargers approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous. Use of unapproved chargers may present a risk of fire, explosion, or other hazard. 1Connect the charger to a wall outlet. 2Place the headset in the cradle. 3Connect the charger cable to the charger connector in the cradle. The red charging indicator light switches off when the battery is fully charged. 4Disconnect the charger from the cradle, then from the wall outlet. When you unplug a charger, hold and pull the plug, not the cord. The fully charged battery has power for up to 2 hours of talk time and up to 35 hours of standby time. If you keep the headset in the cradle, the standby time is up to 2 months. 3 When the battery charge is low, you hear a voice prompt. In addition, a red indicator light flashes and the headset beeps every 5 minutes. If you have deactivated voice prompts, the headset beeps every 5 minutes. Check the battery charge With your headset switched on and connected to your phone, press the multifunction key. A green light indicates a sufficient charge level. If the light is yellow, you may need to recharge the battery soon. If the light is red, recharge the battery. Switch the headset on or off Switch on Press the headset down to remove it from the cradle. The headset switches on, and a green indicator light flashes once. The headset connects to the last connected phone. If you have never paired the headset with a phone, or you have cleared the pairings, pairing mode is activated. Switch off Place the headset in the cradle, and press down on the headset to lock it into place. The headset switches off, and a red indicator light flashes once. All active calls and connections are ended. If not connected to a phone within 30 minutes, the headset switches off. Tip: Don't have the cradle with you? To switch the headset off, press and hold the multifunction key for 5 seconds. To switch the headset on, press the multifunction key. Wear the headset The headset comes with different sized earpads. Select the earpad that fits the best and is the most comfortable for your ear. To change the earpad, gently pull the current earpad from the earpiece, and push the new earpad into place. Gently push the earpiece into your ear. When you're not using your headset, keep it in the cradle. You can thread a wrist strap through the holes in the cradle, and carry it with you easily. Pair the device Pair and connect the headset to your phone Before using the headset, you must pair and connect it to a compatible phone. 4 You can pair your headset with 8 phones, but you can only connect it to a maximum of 2 phones at the same time. With some phones, you may need to make the connection separately after pairing. When the headset is connected to a phone, the Bluetooth indicator light flashes slowly. Pair and connect the headset using NFC With Near Field Communication (NFC), you can pair and connect your headset to your compatible phone easily. If the compatible phone supports NFC, activate its NFC feature, remove the headset from the cradle, and touch the NFC area of the cradle with the NFC area of your phone. The headset connects to the phone automatically. You can also disconnect the headset using NFC. For details on NFC, see the user guide of the phone. If the phone does not support NFC, pair the headset manually. Pair the headset manually 1Make sure your headset is switched off and your compatible phone on. 2If you have never paired the headset with a device, or you have cleared the pairings, switch the headset on. If you have previously paired your headset with another device, press and hold the multifunction key for 5 seconds. Pairing mode is activated, and a blue indicator light starts to flash quickly. Follow the voice prompts. 3Within 3 minutes, activate Bluetooth on the phone, and set it to search for Bluetooth devices. For details, see the user guide of the phone. 4On your phone, select the headset from the list of found devices. 5If required, enter the passcode 0000. In some devices, you may need to make the connection separately after pairing. 5 Pair and connect the headset to two phones When you use the headset for the first time, it automatically pairs and connects to your phone. You can also connect your headset to another phone, and manage ca…

Text truncated - open the document above for the full version.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 Nov 25 , 2010 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Liu Chunbin act as our agent in all FCC matters for grantee code QTL. This appointment is effective until otherwise notified by us. Sincerely, Nokia (China) Investment Co., Ltd Wang Yan Product Certification Officer Beijing, PRC.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

0.5  2011/09/15  Requirement of PRIMAX Green Part: 1. Comply with PRIMAX QW-5Q002 Green Product Chemical Substances Specification . 2. Follow customer's specification as required.3. Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required “ “ BH-220 LASER MARKING Junying Liu Sunger Lee Hongmin Hu THIS DRAWING MAY BE USED IN WHOLE OR PART T-RR024REVISEDJAN.95"BYTHOMASHSU 308000XXXXXX 308000XX000V05.PDF 24.2 mm 25.66 mm I C : 6 6 1 A B - B H 2 2 0 F C C I D : Q T L B H - 2 2 0 C E 0 5 6 0 S N : V V V V V V V Y W W D L F S S S S S S 1:1 LW factory code is "1", JZ factory code is “6” Model: BH-220 Made In China 7.5mm Text: Nokia Pure Text 2.8ptHeight=0.75mm 12.92 mm 7.49 mm 1:1 I C : 6 6 1 A B - B H 2 2 0 F C C I D : Q T L B H - 2 2 0 C E 0 5 6 0 S N : V V V V V V V Y W W D L F S S S S S S Model: BH-220 Made In China 9.67 mm

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: QTLBH-220 Report No.: RF110901D10 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is PIFA antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.

Report No: SA110901D10 1 Report Format Version 4.0.0 RF EXPOSURE REPORT REPORT NO.: SA110901D10 MODEL NO.: BH-220 FCC ID: QTLBH-220 VERSION: (For Bluetooth Headset) Proto: B4.0K, HW: v1.0, SW: v1.0E/v1.0C, MV: v1.0 (For Cradle) Proto: 4.0D, HW: v1.0, SW: v1.0, MV: v1.0 APPLICANT: Nokia(China) Investment Co., LTD. ADDRESS: B2, Nokia China Campus.Beijing Economic and Tech Development Area, No.5. Donghuan Zhonglu.P.O. Box 100176, Beijing, China ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City 244, Taiwan This test report consists of 5 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No: SA110901D10 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION..............................................................................................4 2. CONCLUSION.................................................................................................5 Report No: SA110901D10 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110901D10 Original release Sep. 14, 2011 Report No: SA110901D10 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Bluetooth Headset BRAND NAME: NOKIA MODEL NO.: BH-220 APPLICANT: Nokia(China) Investment Co., LTD. TESTED: Sep. 1 ~ 2, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No: SA110901D10 5 Report Format Version 4.0.0 2. CONCLUSION No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.58 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power 7.8 6.0 EIRP Power 9.2 8.3 *Note: The antenna is PIFA antenna with 1.43dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 8.3mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold ---END---

Report No.: RF110901D10 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110901D10 MODEL NO.: BH-220 FCC ID: QTLBH-220 VERSION: (For Bluetooth Headset) Proto: B4.0K, HW: v1.0, SW: v1.0E/v1.0C, MV: v1.0 (For Cradle) Proto: 4.0D, HW: v1.0, SW: v1.0, MV: v1.0 RECEIVED: Sep. 1, 2011 TESTED: Sep. 1 ~ 2, 2011 ISSUED: Sep. 14, 2011 APPLICANT: Nokia(China) Investment Co., LTD. ADDRESS: B2, Nokia China Campus.Beijing Economic and Tech Development Area, No.5. Donghuan Zhonglu.P.O. Box 100176, Beijing, China ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City 244, Taiwan This test report consists of 75 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110901D10 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD................................................................................4 1. CERTIFICATION.............................................................................................5 2. SUMMARY OF TEST RESULTS.....................................................................6 2.1 MEASUREMENT UNCERTAINTY..................................................................7 3. GENERAL INFORMATION.............................................................................8 3.1 GENERAL DESCRIPTION OF EUT................................................................8 3.2 DESCRIPTION OF TEST MODES..................................................................9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................10 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................11 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................14 3.2.4 DESCRIPTION OF SUPPORT UNITS..........................................................14 4. TEST TYPES AND RESULTS.......................................................................15 4.1 CONDUCTED EMISSION MEASUREMENT................................................15 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..............................15 4.1.2 TEST INSTRUMENTS..................................................................................15 4.1.3 TEST PROCEDURES...................................................................................16 4.1.4 DEVIATION FROM TEST STANDARD.........................................................16 4.1.5 TEST SETUP................................................................................................17 4.1.6 EUT OPERATING CONDITIONS..................................................................17 4.1.7 TEST RESULTS............................................................................................18 4.2 RADIATED EMISSION MEASUREMENT.....................................................22 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................22 4.2.2 TEST INSTRUMENTS..................................................................................23 4.2.3 TEST PROCEDURES...................................................................................24 4.2.4 DEVIATION FROM TEST STANDARD.........................................................24 4.2.5 TEST SETUP................................................................................................25 4.2.6 EUT OPERATING CONDITIONS..................................................................25 4.2.7 TEST RESULTS............................................................................................26 4.3 NUMBER OF HOPPING FREQUENCY USED.............................................35 4.3.1 LIMIT OF HOPPING FREQUENCY USED...................................................35 4.3.2 TEST INSTRUMENTS....................................................................................35 4.3.3 TEST PROCEDURES...................................................................................35 4.3.4 DEVIATION FROM TEST STANDARD.........................................................36 4.3.5 TEST SETUP................................................................................................36 4.3.6 TEST RESULTS............................................................................................36 4.4 DWELL TIME ON EACH CHANNEL.............................................................39 4.4.1 LIMIT OF DWELL TIME USED......................................................................39 4.4.2 TEST INSTRUMENTS..................................................................................39 4.4.3 TEST PROCEDURES...................................................................................39 4.4.4 DEVIATION FROM TEST STANDARD.........................................................39 4.4.5 TEST SETUP................................................................................................40 4.4.6 TEST RESULTS............................................................................................40 4.5 CHANNEL BANDWIDTH...............................................................................48 4.5.1 LIMITS OF CHANNEL BANDWIDTH............................................................48 Report No.: RF110901D10 3 Report Format Version 4.0.0 4.5.2 TEST INSTRUMENTS..................................................................................48 4.5.3 TEST PROCEDURE.....................................................................................48 4.5.4 DEVIATION FROM TEST STANDARD.........................................................49 4.5.5 TEST SETUP................................................................................................49 4…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode B) 2 CONDUCTED EMISSION TEST (Mode C) 3 RADIATED EMISSION TEST (Mode A) 4 RADIATED EMISSION TEST (Mode B) 5 RADIATED EMISSION TEST (Mode C)
