QTLRM-1014GSM Cellular Phone w/BT and WLAN

Quick GuideNokia X2 Issue 1 EN RM-1014 Psst... This guide isn't all there is... There's a user guide in your phone – it's always with you, available when needed. On the start screen, swipe left, and tap . For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/ support. The instructions in this user guide are based on the latest available software version. If your device has not been updated to the latest available software, there may be differences in the availability and functionality of some features. For info about writing text on your phone, see the user guide in your phone or the online user guide. For info on Microsoft Mobile Service terms and Privacy policy, go to www.nokia.com/privacy. Contents For your safety 3 Keys and parts 5 Insert the SIM card, battery, and memory card 7 Charge the battery 9 2 Copy contacts from your old phone 10 Switch between views 11 Take better photos with Smart mode 12 Update your phone software 13 Find your model number and serial number (IMEI) 14 Product and safety information 15 For your safety Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Microsoft Mobile for use with this device. Do not connect incompatible products. 3 KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. GLASS PARTS The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. SAR This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar- tick.com. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call. 4 Keys and parts Explore the keys and parts of your new phone. 1Micro-USB connector 2Earpiece 3Audio connector (3.5 mm AHJ) 4Volume keys 5Lock/Power key 6Home key 7Back key 8Microphone 9Touch screen 5 10Camera flash 11Antenna area 12Loudspeaker 13Camera lens. Before using the camera, remove the protective tape from the lens. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation. Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels. Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately. Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic storage media near the device, because info stored on them may be erased. Keep a safe distance when using the flash. Do not use the flash on people or animals at close range. Do not cover the flash while taking a photo. 6 Insert the SIM card, battery, and memory card Learn how to get your phone ready. Important: Your device uses a micro-SIM card, also known as a mini-UICC SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card. Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached. 1. Hold your phone by the bottom corners in one hand, and with the thumb of your other hand, press the back cover, and remove it. 7 2. If the battery is in the phone, lift it out. 3. Push the SIM into the SIM1 slot, contact area face down. To remove the SIM, pull the card out. 4. Push the memory card into the memory card slot with the contact area face down. To remove the memory card, pull it out. 8 Important: Do not remove the memory card when an app is using it. Doing so may damage the memory card and the device and corrupt data stored on the card. 5. Line up the battery contacts, and put the battery in. 6. Replace the back cover. 7. To switch on, press and hold the power key. Your device has a maximum charging voltage of 4.35V. Use only batteri…

Text truncated - open the document above for the full version.

Confidential 1 (1) 2014-06-19 Confidential This material, including documentation and any related computer programs, is protected by copyright controlled by Microsoft. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Microsoft. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Microsoft. Copyright  2014 Microsoft. All rights reserved. Exhibit 10a List of Active Devices FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 June 19, 2014 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: QTLRM-1014 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Yao Shuo - Lisa Product Certification Officer

Confidential 1 (1) 2014-06-19 Confidential This material, including documentation and any related computer programs, is protected by copyright controlled by Microsoft. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Microsoft. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Microsoft. Copyright  2014 Microsoft. All rights reserved. Exhibit 10a List of Active Devices FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 June 19, 2014 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: QTLRM-1014 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Yao Shuo-Lisa Product Certification Officer

1 (5) 2014-06-19 Confidential This material, including documentation and any related computer programs, is protected by copyright controlled by Microsoft. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Microsoft. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Microsoft. Copyright  2014 Microsoft. All rights reserved. Exhibit 3: External Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile External Photographs Confidential 2 (5) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 3: External Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Right view To p v i e w Bottom view Confidential 3 (5) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 3: External Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 4 (5) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 3: External Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 5 (5) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 3: External Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile

Confidential 1 (1) 2014-06-19 Confidential This material, including documentation and any related computer programs, is protected by copyright controlled by Microsoft. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Microsoft. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Microsoft. Copyright  2014 Microsoft. All rights reserved. Exhibit01_Type_Label FCC ID: QTLRM-1014 Applicant: Microsoft Mobile

Confidential 1 (7) 2014-06-19 Confidential This material, including documentation and any related computer programs, is protected by copyright controlled by Microsoft. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Microsoft. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Microsoft. Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Internal Photographs Confidential 2 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Right view To p v i e w Bottom view Confidential 3 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 4 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 5 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 6 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile Confidential 7 (7) 2014-06-19 Confidential Copyright  2014 Microsoft. All rights reserved. Exhibit 9: Internal Photographs FCC ID: QTLRM-1014 Applicant: Microsoft Mobile

____________________________________________________________________________ SAR Report FCC_RM-1014_01 Applicant: Microsoft Mobile Type: RM-1014 Copyright  2014 TCC Microsoft 1/76 SAR Compliance Test Report Test report no.: FCC_RM-1014_01 Date of report: 2014-06-10 Template version: 19.7 Number of pages: 76 Testing laboratory: TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Client: Microsoft Mobile Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Responsible test engineer: Liu Xianchao Product contact person: Qiu Rain Measurements made by: Yuan Rui, He Ying, Xu Liping Tested device: RM-1014 FCC ID: QTLRM-1014 IC: - Supplement reports: SAR_Photo_RM-1014_02 Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC published RF exposure KDB procedures RSS-102, Issue 4 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at TCC Microsoft. Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: For the contents: ____________________________________________________________________________ SAR Report FCC_RM-1014_01 Applicant: Microsoft Mobile Type: RM-1014 Copyright  2014 TCC Microsoft 2/76 CONTENTS 1. SUMMARY OF SAR TEST REPORT ........................................................................................................................................ 4 1.1 TEST DETAILS ........................................................................................................................................................................... 4 1.2 MAXIMUM RESULTS ................................................................................................................................................................... 4 1.2.1 Head Configuration ...................................................................................................................................................... 4 1.2.2 Body Worn Configuration .......................................................................................................................................... 5 1.2.3 Wireless Router Configuration ................................................................................................................................. 5 1.2.4 Summary SAR data ....................................................................................................................................................... 6 1.2.5 Maximum Drift .............................................................................................................................................................. 6 1.2.6 Measurement Uncertainty ......................................................................................................................................... 6 2. DESCRIPTION OF THE DEVICE UNDER TEST ....................................................................................................................... 7 2.1 DESCRIPTION OF THE ANTENNA ................................................................................................................................................. 9 3. TEST CONDITIONS ............................................................................................................................................................. 12 3.1 TEMPERATURE AND HUMIDITY ................................................................................................................................................ 12 3.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER .................................................................................................................. 12 4. DESCRIPTION OF THE TEST EQUIPMENT ......................................................................................................................... 13 4.1 MEASUREMENT SYSTEM AND COMPONENTS ............................................................................................................................ 13 4.1.1 Isotropic E-field Probe Type ES3DV3 ................................................................................................................... 15 4.1.2 Isotropic E-field Probe Type EX3DV4 ................................................................................................................... 15 4.2 PHANTOMS ............................................................................................................................................................................ 16 4.3 TISSUE SIMULANTS ................................................................................................................................................................ 16 4.3.1 Tissue Simulant Recipes .......................................................................................................................................... 16 4.4 SYSTEM VALIDATION AND SYSTEM CHECKING ........................................................................................................................... 17 4.4.1 System validation status ..................................................................................................…

Text truncated - open the document above for the full version.

FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_02.docx Copyright © TCC Microsoft 1 (7) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 22/24 Compliance Test Report Test Report no.: FCC22&24_RM-1014_02.docx Date of Report: 13-Jun-2014 Number of pages: 7 Customer’s Contact person: Qiu Yu (raiqiu) Testing laboratory: TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Microsoft Mobile Oy Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-1014 / Battery BV-5S FCC ID: QTLRM-1014 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Parts 22/24, TIA-603-C-2004 and IC standards, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Microsoft. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_02.docx Copyright © TCC Microsoft 2 (7) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 22/24 Compliance Test Report Date of receipt 31-May-2014 Testing completed 03-Jun-2014 The customer's contact person Qiu Yu (raiqiu) Test Plan referred to T:\Projects\RM-1014\TestPlan\RS_testplan_RM-1014.xlsm Notes - Document name FCC22&24_RM-1014_02.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-1014 004402478720489 0342 - 0.1422.0 54368 Battery BV-5S 4955404074040105275;0670718 - - - 54316 1.2. Summary of Test Results WCDMA 1900: Section in CFR 47 Section in RSS-GEN or RSS-133 Name of the test Result §2.1046(a) 6.4 Conducted RF output power NP §24.232(b) 6.4 Radiated RF output power PASSED §2.1049(h) 4.6.1 99 % occupied bandwidth NP §24.238(a) 6.5 Band edge compliance NP §24.238(a), §2.1051 6.5 Spurious emissions at antenna terminals NP §24.238(a), §2.1053 6.5 Spurious radiated emissions NP §2.1055(a) 6.3 Frequency stability, temperature variation NP §2.1055(d) 6.3 Frequency stability, voltage variation NP WCDMA 850: Section in CFR 47 Section in RSS-GEN or RSS-132 Name of the test Result §2.1046(a), 22.913(a) 4.4 Conducted RF output power NP §22.913(a) 4.4 Radiated RF output power PASSED §2.1049(h) 4.6.1 99 % occupied bandwidth NP §22.917(a) 4.5 Band edge compliance NP §22.917(a), §2.1051 4.5 Spurious emissions at antenna terminals NP §22.917(a), §2.1053 4.5 Spurious radiated emissions NP §2.1055(a) 4.3 Frequency stability, temperature variation NP §2.1055(d) 4.3 Frequency stability, voltage variation NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Microsoft Laboratory. FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_02.docx Copyright © TCC Microsoft 3 (7) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 22/24 Compliance Test Report ........................................... 2 1.1. EUT and Accessory Information ...........................................................................................................2 1.2. Summary of Test Results .....................................................................................................................2 2. Radiated RF output power (FCC §24.232(b), §22.913(a), RSS-133 6.4, RSS-132 4.4) ................................................ 4 2.2. Test method and limit ...........................................................................................................................4 2.3. WCDMA 1900 test results ....................................................................................................................5 2.4. WCDMA 850 test results ......................................................................................................................5 3. Test Equipment ........................................................................................................... 6 3.1. Conducted measurements ...................................................................................................................6 3.2. Radiated measurements ......................................................................................................................6 FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_02.docx Copyright © TCC Microsoft 4 (7) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 2. Radiated RF output power (FCC §24.232(b), §22.913(a), RS…

Text truncated - open the document above for the full version.

FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_03.docx Copyright © TCC Microsoft 1 (14) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 22/24 Compliance Test Report Test Report no.: FCC22&24_RM-1014_03.docx Date of Report: 13-Jun-2014 Number of pages: 14 Customer’s Contact person: Qiu Yu (raiqiu) Testing laboratory: TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Microsoft Mobile Oy Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-1014 / Battery BV-5S / AC-Charger AC-20E / Headset WH-108 FCC ID: QTLRM-1014 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Parts 22/24, TIA-603-C-2004 and IC standards, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Microsoft. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_03.docx Copyright © TCC Microsoft 2 (14) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 22/24 Compliance Test Report Date of receipt 31-May-2014 Testing completed 03-Jun-2014 The customer's contact person Qiu Yu (raiqiu) Test Plan referred to T:\Projects\RM-1014\TestPlan\RS_testplan_RM-1014.xlsm Notes - Document name FCC22&24_RM-1014_03.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-1014 004402478720489 0342 - 0.1422.0 54368 Battery BV-5S 4955404074040105275;0670718 - - - 54316 AC-Charger AC-20E 4090493461550614436;0675628 - - - 54370 Headset WH-108 4125PB1 - - - 54372 Phone RM-1014 004402478720430 0342 - 0.1422.0 54366 Battery BV-5S 4955404074040105278;0670718 - - - 54318 AC-Charger AC-20E 4090493461550614048;0675628 - - - 54369 Headset WH-108 4125PB1 - - - 54371 1.2. Summary of Test Results WCDMA 1900: Section in CFR 47 Section in RSS-GEN or RSS-133 Name of the test Result §2.1046(a) 6.4 Conducted RF output power NP §24.232(b) 6.4 Radiated RF output power NP §2.1049(h) 4.6.1 99 % occupied bandwidth PASSED §24.238(a) 6.5 Band edge compliance PASSED §24.238(a), §2.1051 6.5 Spurious emissions at antenna terminals NP §24.238(a), §2.1053 6.5 Spurious radiated emissions PASSED §2.1055(a) 6.3 Frequency stability, temperature variation NP §2.1055(d) 6.3 Frequency stability, voltage variation NP WCDMA 850: Section in CFR 47 Section in RSS-GEN or RSS-132 Name of the test Result §2.1046(a), 22.913(a) 4.4 Conducted RF output power NP §22.913(a) 4.4 Radiated RF output power NP §2.1049(h) 4.6.1 99 % occupied bandwidth PASSED §22.917(a) 4.5 Band edge compliance PASSED §22.917(a), §2.1051 4.5 Spurious emissions at antenna terminals NP §22.917(a), §2.1053 4.5 Spurious radiated emissions PASSED §2.1055(a) 4.3 Frequency stability, temperature variation NP §2.1055(d) 4.3 Frequency stability, voltage variation NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_03.docx Copyright © TCC Microsoft 3 (14) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 NP The test was not performed by the TCC Microsoft Laboratory. FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-1014_03.docx Copyright © TCC Microsoft 4 (14) TCC Microsoft Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 22/24 Compliance T…

Text truncated - open the document above for the full version.
