FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM‐811_03.docx Copyright © TCC Nokia 1 (41) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15C Compliance Test Report Test Report no.: FCC15CBT_RM-811_03.docx Date of Report: 07-Mar-2012 Number of pages: 41 Customer’s Contact person: Xu Helen Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-811 / Battery BL-5CB / AC-Charger AC-11E / Headset WH-102 FCC ID: QTLRM-811 IC: 661AB-RM811 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards, RSS-210 (Issue 8, December 2010). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Zou Ming, Engineer, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM‐811_03.docx Copyright © TCC Nokia 2 (41) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 10-Feb-2012 Testing completed 27-Feb-2012 The customer's contact person Xu Helen Test Plan referred to T:\Projects\RM-811\TestPlan\RS_testplan_RM-811.xls Notes - Document name FCC15CBT_RM-811_03.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/Bluetooth The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Devices under tests Product Type SN HW MV SW DUT Phone RM-811 004402137800326 0202 - Ksssb1_11w48 52650 Battery BL-5CB 0670619382066R505031269871 - - - 52654 AC-Charger AC-11E 4090491411970515835;0675479 - - - 52663 Headset WH-102 06943240506D4104976 - - - 52658 Phone RM-811 004402137801167 0202 - Ksssb1_11w48 52641 Battery BL-5CB 0670619382066R126060408205 - - - 52655 AC-charger AC-11E 4090491411970515310;0675479 - - - 52656 Headset WH-102 06943240506D4103634 - - - 52657 Phone RM-811 004402137801126 0202 - Ksssb1_11w48 52642 Battery BL-5CB 0670619382066R505031269874 - - - 52664 AC-Charger AC-11E 4090491411970515837;0675479 - - - 52659 Headset WH-102 06943240506D4104976 - - - 52658 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(2)) Conducted peak output power PASSED 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions PASSED 15.247(d) A8(0.5) Spurious RF conducted emissions PASSED 15.247(d), 15.209 A8(0.5) Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions PASSED 15.247(a)(1) A8(0.1(1)) 20dB(bandwidth) PASSED 15.247(a)(1) A8(0.1(2)) Carrier frequency separation PASSED 15.247(a)(1)(iii) A8(0.1(4)) Number of hopping frequencies PASSED 15.247(a)(1)(iii) A8(0.1(4)) Time of occupancy PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM‐811_03.docx Copyright © TCC Nokia 3 (41) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Conducted peak output power (15.247(b)(1), RSS-210 A8.4 (2)) ......................................................................................... 5 2.1. Test Setup ......................................................................................................................................... 5 2.2. Test method and limit ........................................................................................................................ 5 2.3. Bluetooth Test results ....................................................................................................................... 6 3. Band edge compliance of RF emissions (FCC §15.247(d), 15.205(b), RSS-210 A8.5) ....................................................................... 9 3.2. Test method and limit ........................................................................................................................ 9 3.3. Bluetooth Test results ..................................................................................................................... 10 4. Spurious RF conducted emissions (FCC §15.247(d), RSS-210 A8.5) .......................................…

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-811_07.docx Copyright © TCC Nokia 1 (2) RM-811 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-811_07.docx Copyright © TCC Nokia 2 (2) Picture 4. FCC Part 15C AC powerline conducted emissions
