QTLRM-926GSM cellular phone w/BT and WLAN

Product name missing Welcome to the Product name missing Issue 1 EN Psst... For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy. 2 Contents Safety 4 Get started 6 Basics 16 People & messaging 28 Camera 42 Internet 45 Entertainment 47 Maps & navigation 50 Office 51 Phone management & connectivity 53 Help and support 62 Product and safety information 67 3 Safety We invite you to read the instructions on this guide before using the device. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products. 4 KEEP YOUR DEVICE DRY Your device is not water- resistant. Keep it dry. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. 5 1 2 7 4 5 6 3 8 11 9 10 12 13 14 Get started Keys and parts 6 1Charger connector 2Micro-USB connector 3Headset connector (3.5 mm) 4Screen 5Scroll key 6End/Power key 7Keyboard 8Shortcut keys 9Call key 10Selection keys 11Earpiece 12Camera lens. Before using the camera, remove the protective tape from the lens. 13Loudspeaker 14Antenna area The antenna area is highlighted. Tip: Lock the keys when not using your phone. Select Menu, and press the function key. To unlock, select Unlock, and press the function key. Tip: You can set your phone to ask for the lock code that you define. The default lock code is 12345. Your phone uses S40 software. Some of the accessories mentioned in this user guide may be sold separately. 7 Insert SIM card and battery 1. Switch the phone off, and remove the back cover. 2. If the battery is in the phone, lift it out. 3. Lift the SIM holder, and put the SIM in, contact area face down. 8 4. Line up the battery contacts, and put the battery in. 5. Press the back cover down until it locks into place. 6. To switch on, press and hold until the phone vibrates. 9 Insert a memory card 1. Switch the phone off, and remove the back cover. 2. If the battery is in the phone, lift it out. 3. Slide the memory card holder towards the top of the phone. 10 4. Lift the holder. 5. Put a compatible memory card in, contact area face down. 6. Lower the holder. 11 7. Slide the holder to the original position. 8. Line up the battery contacts, and put the battery in. 9. Press the back cover down until it locks into place. 12 Charge the battery 1. Plug the charger into a wall outlet. 2. Connect the charger to the phone. See 3 on page 64. When done, unplug the charger from the phone, then from the wall outlet. 13 Change the volume 1. While in a call, scroll up or down to change the volume. 2. You can also connect a compatible headset or other device to the headset connector. 123456789 In call Loudspeak. 3. To use the loudspeaker on your phone when calling, select Loudspeak.. You can also use the loudspeaker when listening to radio. 14 Copy content from your old phone Easily get your contacts, calendar entries, and other stuff to your new phone. 1. Switch Bluetooth on in both phones. To switch Bluetooth on on your new phone, select Menu > Settings > Connectivity > Bluetooth. 2. On your new phone, select Menu > Settings > Sync and backup > Copy from device. 3. Select what you want to copy, then select Done. 4. Choose your old phone from the list of found devices. 5. If asked, create a one- time passcode (such as 123), and select OK. 6. Check that the codes match on both phones. 7. Follow the instructions shown on both phones. 15 Basics Explore your phone Menu ... ... 1. To see the apps and features of your phone, press Menu. 2. To go to an app or feature, press the scroll key up, down, left, or right. ... 3. To open the app or select the feature, press Select. 16 Back 4. To go back to the previous view, press Back. 5. To go back to the home screen, press . 17 Display indicators You have unread messages. You have unsent or failed messages. The keys are locked. An alarm is set. Bluetooth is on. The phone is connected to a GSM network. All incoming calls are forwarded to another number. The phone is connected to a headset. The phone is connected to a device, such as a PC, with a USB cable. The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, , depending on your network service provider. The icons may vary depending on your region or network service provider. 18 Prolong battery life • Always charge the battery fully. • Mute unnecessary sounds, such as key press sounds. •Use wired headphones, rather than the loudspeaker. To save power, you can: 19 Lower the backlight brightnessSelect Menu > Settings > Display > Backlight, and change the setting for Backlight intensity. Set the backlight to switch off after a short time Select Menu > Settings > Display > Backlight, and change the setting for Backlight time-out. Use network connections selectively • Switch Bluetooth on only when needed. • To switch off automatic update of a mail account, select Menu > Mail > Options > Settings and an account, and switch Update my Inbox: to Manually. 20 • If you're listening to music or otherwise using your phone, but don't want to make or receive calls, switch flight mode on. S…

Text truncated - open the document above for the full version.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 April 11 th , 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Hui Xu act as our agent in all FCC matters for grantee code QTL. This appointment is effective until otherwise notified by us. Sincerely, Nokia (China) Investment Co., Ltd Yao Shuo-Lisa Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 March 27, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: QTLRM-926 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Xu Helen Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 March 27 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: QTLRM- 926 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Xu Helen Product Certification Officer Beijing, PRC.

External Photographs FCC ID: QTLRM-926 Exhibit 03 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. External Photographs FCC ID: QTLRM-926 Exhibit 03 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. External Photographs FCC ID: QTLRM-926 Exhibit 03 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.

FCC ID: QTLRM-926 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. Type label placement on the phone

Internal Photographs FCC ID: QTLRM-926 Exhibit 09 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. Internal Photographs FCC ID: QTLRM-926 Exhibit 09 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_06.docx Copyright © TCC Nokia 1 (13) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-926_06.docx Date of Report: 03-Apr-2013 Number of pages: 13 Customer’s Contact person: Wang Jason Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-926 / Battery BL-4U / AC Charger AC-11E / Headset WH-109 FCC ID: QTLRM-926 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_06.docx Copyright © TCC Nokia 2 (13) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 26-Mar-2013 Testing completed 29-Apr-2013 The customer's contact person Wang Jason Test Plan referred to T:\Projects\RM-926\TestPlan\RS_testplan_RM-926.xlsm Notes - Document name FCC15B_RM-926_06.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-926 004402471846695 0202 - snsECL_13w06 53301 Battery BL-4U 4181572473000000306;0670560 - - - 53309 AC Charger AC-11E 4868672495451408123;0675479 - - - 53352 Headset WH-109 2512I3R - - - 53282 Phone RM-926 004402471846497 0202 - snsECL_13w06 53304 Battery BL-4U 4181572473000000303;0670560 - - - 53308 AC Charger AC-11E 4868672495441407809;0675479 - - - 53311 Headset WH-109 2512I3R - - - 53284 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 (4.6) Radiated emissions PASSED GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_06.docx Copyright © TCC Nokia 3 (13) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) ................................................................................. 4 2.1. Test Setup ......................................................................................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM 850 Test results ....................................................................................................................... 5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 6 3.2. Test method and limit ........................................................................................................................ 6 3.3. GSM850 test results, FM radio on ..................................................................................................... 8 3.4. GSM1900 test results, FM radio on ................................................................................................. 10 4. Test Equipment ........................................................................................................... 12 4.1. Conducted measurements .............................................................................................................. 12 4.2. Radiated measurements ................................................................................................................. 12 FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_06.docx Copyright © TCC Nokia 4 (13) TCC Nokia Beijing Laboratory Beijing Economic an…

Text truncated - open the document above for the full version.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_07.docx Copyright © TCC Nokia 1 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-926_07.docx Date of Report: 03-Apr-2013 Number of pages: 11 Customer’s Contact person: Wang Jason Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-926 / AC Charger AC-11E / Headset WH-109 / USB data cable CA-190CD / Printer HP C6427A / Laptop IBM T43 FCC ID: QTLRM-926 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_07.docx Copyright © TCC Nokia 2 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 26-Mar-2013 Testing completed 01-Apr-2013 The customer's contact person Wang Jason Test Plan referred to T:\Projects\RM-926\TestPlan\RS_testplan_RM-926.xlsm Notes - Document name FCC15B_RM-926_07.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-926 004402471846497 0202 - snsECL_13w06 53304 Battery BL-4U 4181572473000000303;0670560 - - - 53308 AC Charger AC-11E 4868672495441407809;0675479 - - - 53311 Headset WH-109 2512I3R - - - 53284 USB data cable CA-190CD 07304562112T2F - - - 53312 Printer HP C6427A MY15B18156JJ - - - 51838 Laptop IBM T43 L3KXHL3 - - - 52468 Phone RM-926 004402471846695 0202 - snsECL_13w06 53301 Battery BL-4U 4181572473000000306;0670560 - - - 53309 AC Charger AC-11E 4868672495451408123;0675479 - - - 53352 Headset WH-109 2512I3R - - - 53282 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_07.docx Copyright © TCC Nokia 3 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) ................................................................................. 4 2.1. Test Setup ......................................................................................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM 1900 Test results ..................................................................................................................... 5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 6 3.2. Test method and limit ........................................................................................................................ 6 3.3. GSM1900 test results ........................................................................................................................ 8 4. Test Equipment ........................................................................................................... 10 4.1. Conducted measurements .............................................................................................................. 10 4.2. Radiated measurements ................................................................................................................. 10 FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐926_07.docx Copyright © TCC Nokia 4 (11) TCC Nokia …

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-926_08.docx Copyright © TCC Nokia 1 (3) RM-926 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-926_08.docx Copyright © TCC Nokia 2 (3) Picture 3. FCC Part 15B Radiated emissions, computer peripherals Picture 4. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-926_08.docx Copyright © TCC Nokia 3 (3) Picture 5. FCC Part 15B AC powerline conducted emissions, computer peripherals, measure from PC charger
