QTLRM-947GSM/WCDMA cellular phone w/BT and WLAN

User Guide Nokia XXX Issue 1 EN Contents Safety 4 Get started 5 Keys and parts 5 Insert a SIM card, battery, and memory card 5 Charge the battery 6 Copy contacts from your old phone 7 Basics 8 Display indicators 8 Touch screen actions 8 Switch between views 10 Check your activity 10 Change settings quickly 11 Prolong battery life 11 Reorganise the apps menu 12 Personalise the lock screen 12 Change your ringtone 12 Add a full keyboard or phone keypad 13 Add a writing language 13 Keys on the keyboard 13 Write using the keyboard 13 Keys on the keypad 14 Write using the keypad 14 Use predictive text 15 Nokia Store 15 People & messaging 16 Make or answer a call 16 Save a name and phone number 16 Add social info to contacts 17 Update your status 17 Send a message 17 Mail for Exchange 18 Set up your mail account 18 Send a mail 19 Chat with your friends 19 Check your voice mail 20 Camera 21 Take a photo 21 Record a video 21 Share your photo or video 21 Maps & navigation 23 Find nearby places 23 Internet 24 Browse the web 24 Add a website to your favourites 24 Entertainment 25 Play a song 25 Listen to the radio 25 Office 26 Change the time and date 26 Set an alarm 26 Add a calendar entry 26 Phone management & connectivity 27 Share your content using Slam 27 Connect to a Wi-Fi network 27 Copy content between your phone and computer 27 Update your phone software 28 Use your phone in flight mode 28 Access codes 28 User Guide Nokia XXX © 2013 Nokia. All rights reserved. 2 Product and safety information 30 © 2013 Nokia. All rights reserved. 3 Safety We invite you to read the instructions on this guide before using the device. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. SAR This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetre (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar-tick.com. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call. © 2013 Nokia. All rights reserved. 4 Get started Get to grips with the basics, and have your phone up and running in no time. Keys and parts Explore the keys and parts of your new phone. 1Audio connector (3.5 mm AHJ) 2Earpiece 3Micro-USB connector 4Volume/Zoom keys 5Lock/Power key 6Microphone 7Back key 8Touch screen 9Camera flash 10Camera lens. Before using the camera, remove the protective tape from the lens. 11Back cover release button 12Antenna area You can set your phone to ask for the lock code that you define. The antenna area is highlighted. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation. Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels. Some of the accessories mentioned in this user guide may be sold separately. Insert a SIM card, battery, and memory card Learn how to insert a battery and SIM and memory cards. Important: This device is designed to be used with a mini-UICC SIM card, also known as a micro- SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card. © 2013 Nokia. All rights reserved. 5 1. Press the release button at the back of the phone, and carefully lift and remove the back cover. 2. If the battery is in the phone, lift it out. 3. Open the SIM holder, and slide the SIM into the holder, contact area face down. Close the holder, and lock it into place. 4. Line up the battery contacts, and put the battery in. 5. Push the memory card into the memory card slot until it locks into place. Tip: To remove the memory card, push it in until it's released, then pull it out. Important: Do not remove the memory card when an app is using it. Doing so may damage the memory card and the device and corrupt data stored on the card. 6. Replace the back cover. 7. To switch on, press and hold the power key. Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers atta…

Text truncated - open the document above for the full version.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 July 5 th , 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Xu Helen act as our agent in all FCC matters for grantee code QTL. This appointment is effective until otherwise notified by us. Sincerely, Nokia (China) Investment Co., Ltd Yao Shuo-Lisa Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 September 4, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: QTLRM-947 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Xu Helen Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 September 4, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: QTLRM- 947 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Xu Helen Product Certification Officer Beijing, PRC.

21Aug2013 External photographs FCC ID: QTLRM-947 Exhibit 3 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. EXTERNAL PHOTOGRAPHS 21Aug2013 External photographs FCC ID: QTLRM-947 Exhibit 3 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 External photographs FCC ID: QTLRM-947 Exhibit 3 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 External photographs FCC ID: QTLRM-947 Exhibit 3 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.

1 (1) 19/08/2013 Type Label FCC ID: QTLRM-947 Exhibit 01 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.  Type label for RM-947  Label location for RM-947

21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 1. INTERNAL PHOTOGRAPHS 21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. 21Aug2013 Internal photographs FCC ID: QTLRM-947 Exhibit 9 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_05 Copyright © TCC Nokia 1 (9) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-947_05.docx Date of Report: 23-Aug-2013 Number of pages: 9 Customer’s Contact person: Qiu Rain Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-947 / Battery BL-4U / AC-charger AC-20E / Headset WH-108 FCC ID: QTLRM-947 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Zou Ming, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_05 Copyright © TCC Nokia 2 (9) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 18-Jul-2013 Testing completed 29-Jul-2013 The customer's contact person Qiu Rain Test Plan referred to T:\Projects\RM-922\TestPlan\RS_Testplan_RM-922.xlsm Notes - Document name FCC15B_RM-947_05.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-922 SIM1:004402473829269;SIM2:004402473829277 0201 - 0.1326.0 53630 Battery BL-4U 4175353204B12410178;0670561 - - - 53503 AC-charger AC-20E 4868673116340515048;0675628 - - - 53510 Headset WH-108 3121M71 - - - 53505 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions PASSED GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. The test results of QTLRM-922 are re-used for certification of the QTLRM-947. The table above indicates the results, which will be re-used. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_05 Copyright © TCC Nokia 3 (9) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM850 test results, FM radio active ............................................................................................... 6 3. Test Equipment ............................................................................................................. 8 3.1. Conducted measurements ................................................................................................................ 8 3.2. Radiated measurements ................................................................................................................... 8 FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_05 Copyright © TCC Nokia 4 (9) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) EUT with DUT number RM-922, DUT 53630 Accessories with DUT numbers BL-4U, DUT 53503 ; AC-20E, DUT 53510 ; WH-108, DUT 53505 Operation Voltage [V] / [Hz] 115 / 60 Results PASSED Remarks FM radio active during GSM850 idle mode. Temp [ o C] / Humidity [%RH] / Air Pressure [kPa] 23/65/99.9 Date of measurements 29-Jul-2013 Measured by Zou Ming 2.1.1 Test setup Tower / table controller Communication Tester Receiver EUT 2.2. Test method and limit The measurement is made according to ANSI C63.4-2003as follows: The measurement is performed in the Semi-Anechoic Chamber with conducting metal floor. The measurement dist…

Text truncated - open the document above for the full version.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_06 Copyright © TCC Nokia 1 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-947_06.docx Date of Report: 23-Aug-2013 Number of pages: 11 Customer’s Contact person: Qiu Rain Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-947 / Battery BL-4U / USB data cable CA-190CD / Laptop IBM T43 / AC-Adapter 02K6749 / Printer HP C6427A / Parallel cable for printer - / Headset WH-108 FCC ID: QTLRM-947 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under “Test method and limit”. Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Zou Ming, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_06 Copyright © TCC Nokia 2 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 18-Jul-2013 Testing completed 25-Jul-2013 The customer’s contact person Qiu Rain Test Plan referred to T:\Projects\RM-922\TestPlan\RS_Testplan_RM-922.xlsm Notes - Document name FCC15B_RM-947_06.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-922 SIM1:004402473829368; SIM2:004402473829376 0201 - 0.1326.0 53496 Battery BL-4U 4175353204B12410175;0670561 - - - 53639 Laptop IBM T43 L3KXHL3 - - - 52468 AC-Adapter 02K6749 - - - - 53509 Printer HP C6427A MY15B18156JJ - - - 51838 Parallel cable for printer - - - - - 53508 Headset WH-108 3121M71 - - - 53641 Phone RM-922 SIM1:004402473829269; SIM2:004402473829277 0201 - 0.1326.0 53630 Battery BL-4U 4175353204B12410178;0670561 - - - 53503 Headset WH-108 3121M71 - - - 53505 USB data cable CA-190CD 07304572453F2F 53642 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. The test results of QTLRM-922 are re-used for certification of the QTLRM-947. The table above indicates the results, which will be re-used. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐947_06 Copyright © TCC Nokia 3 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) ................................................................................. 4 2.1. Test Setup ......................................................................................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM 1900 Test results ..................................................................................................................... 5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 6 3.2. Test method and limit ........................................................................................................................ 6 3.3. GSM1900 test results ........................................................................................................................ 8 4. Test Equipment ........................................................................................................... 10 4.1. Conducted measurements .............................................................................................................. 10 4.2. Radiated measurements ..................................................................…

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-947_09 Copyright © TCC Nokia 1 (3) RM-947 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-947_09 Copyright © TCC Nokia 2 (3) Picture 3. FCC Part 15B Radiated emissions, computer peripherals Picture 4. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-947_09 Copyright © TCC Nokia 3 (3) Picture 5. FCC Part 15B AC powerline conducted emissions, computer peripherals, measure from PC charger
