QTLRM-994GSM/WCDMA cellular phone w/BT and WLAN

Nokia Lumia 1320 Welcome to the Nokia Lumia 1320 Issue 1.0 EN Psst... This guide isn't all there is... There's a user guide in your phone – it's always with you, available when needed. On the start screen, swipe left, and tap Nokia Care. For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/support. You can also scan the code to go to the website. Press , and tap . Point the camera at the code, and tap the result. Check out the videos at www.youtube.com/ NokiaSupportVideos. For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy. First start-up Your new phone comes with great features that are installed when you start your phone for the first time. Allow some minutes while your phone sets up. 2 Quick Guide Nokia Lumia 1320 Contents Safety 4 Keys and parts 6 Get started 8 Get the basics 11 Take your friends with you 12 Browse the web 13 Help and tips 14 Product and safety information 15 NOKIA — MANUFACTURER’S LIMITED WARRANTY 23 3 Safety We invite you to read the instructions on this guide before using the device. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible. Do not connect incompatible products. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. GLASS PARTS The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or 4 attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. SAR This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar-tick.com. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call. 5 Keys and parts 1Connector for headphones and loudspeakers (3.5 mm) 2Earpiece 3Front camera 4Volume keys 5Power/Lock key 6Camera key 7Back key 8Start key 9Search key 10Microphone 11Micro-USB connector. Also used to charge the battery. 6 Do not attempt to remove the battery from the device. To replace the battery, take the device to your nearest authorised service facility. Some of the accessories mentioned in this user guide may be sold separately. 7 Get started Before you start using your phone, remove the back cover to insert the micro-SIM card. Remove the back cover Make sure your phone is switched off. At the bottom corner of the phone, put your fingernail in the seam between the screen frame and the back cover. Bend the back cover open, and remove it. Only use your fingers to open the cover. 8 Insert the SIM and memory card Important: This device is designed to be used with a mini-UICC SIM card, also known as a micro- SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. 1. Push the SIM card into the SIM card slot, contact area face down. 2. If you have a microSD card, push the card into the memory card slot until it locks into place. 9 Close the back cover Press the top edge of the back cover against the top edge of your phone, and snap the back cover into place. Charge the battery Connect the USB cable to the charger, plug the charger into a wall outlet, and connect the micro- USB end to your phone. You can also charge the phone from a computer with the USB cable. If the battery is completely discharged, it may need to charge for up to 20 minutes before you can use your phone. The charging indicator may not be displayed in this time. 10 Get the basics Make a call 1. Tap > , type in the phone number, and tap call. To type in the + character, used for international calls, tap and hold 0. The + character only works from abroad. The + character may not work in all regions. In this case, enter the international access code directly. 2. To end the call, tap end call. Lock the keys and screen Press the power key briefly. To unlock, press the power key, and drag the lock screen up. Switch between views and apps To switch between the start screen and the apps menu, simply swipe left or right. To switch between open apps, press and hold , and choose the app you want. To close an app, tap . Personalise the start screen To move a tile on the start screen, place your finger on the item for a second or two, and drag the item to a new location. 11 Take your friends with you Get in touch with your friends, family, colleagues, you na…

Text truncated - open the document above for the full version.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 April 17 th , 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Ren Shuifang act as our agent in all FCC matters for grantee code QTL. This appointment is effective until otherwise notified by us. Sincerely, Nokia (China) Investment Co., Ltd Yao Shuo-Lisa Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 November 20, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: QTLRM-994 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Ren Shuifang Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 November 20, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: QTLRM-994 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Ren Shuifang Product Certification Officer Beijing, PRC.

17-October-2013 Page 1 of 3 Exhibit 3: External Photographs FCC ID: QTLRM-994 Applicant: Nokia Corporation Copyright © 2013 Nokia Corporation EXTERNAL PHOTOS 17-October-2013 Page 2 of 3 Exhibit 3: External Photographs FCC ID: QTLRM-994 Applicant: Nokia Corporation Copyright © 2013 Nokia Corporation 17-October-2013 Page 3 of 3 Exhibit 3: External Photographs FCC ID: QTLRM-994 Applicant: Nokia Corporation Copyright © 2013 Nokia Corporation

23- September -2013 Page 1 of 1 FCC Label and location FCC ID: QTLRM-994 Exhibit 1 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. Label Location Drawing

Exhibit 9: I n Applicant: N INTERNA nternal Photo Nokia Corpor AL PHOTO ographs ration O Copyright © 17-Octob Pag FCC ID: © 2013 Nokia ber-2013 ge 1 of 3 QTLRM-994 Corporation 4 n Exhibit 9: I n Applicant: N nternal Photo Nokia Corpor ographs ration Copyright © 17-Octob Pag FCC ID: © 2013 Nokia ber-2013 ge 2 of 3 QTLRM-994 Corporation 4 n 17-October-2013 Page 3 of 3 Exhibit 9: Internal Photographs FCC ID: QTLRM-994 Applicant: Nokia Corporation Copyright © 2013 Nokia Corporation

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_14.docx Copyright © TCC Nokia 1 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-994_14.docx Date of Report: 25-Nov-2013 Number of pages: 11 Customer’s Contact person: Hu Helen Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-994 / Battery BV-4BWA(Sony) / AC-charger AC-60E / Charger CA-190CD / Headset WH-108 FCC ID: QTLRM-994 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_14.docx Copyright © TCC Nokia 2 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 01-Nov-2013 Testing completed 14-Nov-2013 The customer's contact person Hu Helen Test Plan referred to T:\Projects\RM-994\TestPlan\RS_testplan_RM-994.xlsm Notes - Document name FCC15B_RM-994_14 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-994 004402476326388 1000 - 3052.40000.1341.0000 53932 Battery BV- 4BWA(Sony) - Ver.2.0 - - 53933 AC-charger AC-60E 4868673343710301247;0675677 - - - 53949 USB data cable CA-190CD - - - - 53951 Headset WH-108 3323471 - - - 53950 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions PASSED WCDMA 850 (Band V): Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_14.docx Copyright © TCC Nokia 3 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM850 test results, FM Radio active .............................................................................................. 6 2.4. GSM1900 test results, GPS active .................................................................................................... 8 3. Test Equipment ........................................................................................................... 10 3.1. Conducted measurements .............................................................................................................. 10 3.2. Radiated measurements ................................................................................................................. 10 FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_14.docx Copyright © TCC Nokia 4 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) EUT with DUT number RM-994, DUT 53932 Accessories with DUT numbers BV-4BWA(Sony), DUT 53933 ; AC-60E, DUT 53949 ; CA-190CD, DUT 53951 ; WH-108, DUT 53950 Operation Voltage [V] / [Hz] 115/60 Results PASSED Remarks - Temp [ o C] / Humidity [%RH] / Air Pressure [kPa] 19 / 38 / 101.4 Date of measurements 14-Nov-2013 Measured by Zou Ming 2.1.1 Test setup Tower / table c…

Text truncated - open the document above for the full version.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_15.docx Copyright © TCC Nokia 1 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-994_15 Date of Report: 25-Nov-2013 Number of pages: 11 Customer’s Contact person: Hu Helen Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-994 / Battery BV-4BWA(Sony) / USB data cable CA-190CD / Headset WH-108 / Laptop IBM T43 / Printer HP C6427A / Parallel cable for printer - / AC-Adapter 02K6749 FCC ID: QTLRM-994 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_15.docx Copyright © TCC Nokia 2 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 01-Nov-2013 Testing completed 15-Nov-2013 The customer's contact person Hu Heln Test Plan referred to T:\Projects\RM-994\TestPlan\RS_testplan_RM-994.xlsm Notes - Document name FCC15B_RM-994_15 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-994 004402476326388 1000 - 3052.40000.1341.0000 53932 Battery BV-4BWA(Sony) - Ver.2.0 - - 53933 USB data cable CA-190CD 07304573013628 - - - 53970 Headset WH-108 3185D71 - - - 53782 Laptop IBM T43 L3KXHL3 - - - 52468 Printer HP C6427A MY15B18156JJ - - - 51838 Parallel cable for printer - - - - - 53508 AC-Adapter 02K6749 - - - - 53509 Phone RM-994 004402476329242 1000 - 3052.40000.1341.0000 53796 Battery BV-4BWA(Sony) - Ver.2.0 - - 53938 USB data cable CA-190CD 07304563151628 - - - 53943 Headset WH-108 3323471 - - - 53944 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP WCDMA 850 (Band V): Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐994_15.docx Copyright © TCC Nokia 3 (11) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) ................................................................................. 4 2.1. Test Setup ......................................................................................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. GSM 1900 Test results ..................................................................................................................... 5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6) ................................... 6 3.2. Test method and limit ........................................................................................................................ 6 3.3. GSM1900 test results ........................................................................................................................ 8 4. Test Equipment ........................................................................................................... 10 4.1. Conducted measurements .............................................................................................................. 10 4.2. Radiated measurements ....…

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-994_17.docx Copyright © TCC Nokia 1 (3) RM-994 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-994_17.docx Copyright © TCC Nokia 2 (3) Picture 3. FCC Part 15B Radiated emissions, computer peripherals Picture 4. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-994_17.docx Copyright © TCC Nokia 3 (3) Picture 5. FCC Part 15B AC powerline conducted emissions, computer peripherals, measure from PC charger
