QTLRM-995GSM/WCDMA/LTE cellular phone w/BT and WLAN

Nokia Lumia 1320 Welcome to the Nokia Lumia 1320 Issue 1.0 EN 1320.1 Keys and parts 1Connector for headphones and loudspeakers (3.5 mm) 2Earpiece 3Front camera 4Volume keys 5Power/Lock key 6Camera key 7Back key 8Start key 9Search key 10Microphone 11Micro-USB connector. Also used to charge the battery. Do not attempt to remove the battery from the device. To replace the battery, take the device to your nearest authorised service facility. Some of the accessories mentioned in this user guide may be sold separately. 2 Get started Before you start using your phone, remove the back cover to insert the micro-SIM card. Remove the back cover Make sure your phone is switched off. At the bottom corner of the phone, put your fingernail in the seam between the screen frame and the back cover. Bend the back cover open, and remove it. Only use your fingers to open the cover. 3 Insert the SIM and memory card Important: Your device uses a mini-UICC SIM card, also known as a micro-SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. 1. Push the SIM card into the SIM card slot, contact area face down. 2. If you have a microSD card, push the card into the memory card slot until it locks into place. 4 Close the back cover Press the top edge of the back cover against the top edge of your phone, and snap the back cover into place. Charge the battery Connect the USB cable to the charger, plug the charger into a wall outlet, and connect the micro- USB end to your phone. You can also charge the phone from a computer with the USB cable. If the battery is completely discharged, it may need to charge for up to 20 minutes before you can use your phone. The charging indicator may not be displayed in this time. 5 Help and tips There's a user guide in your phone – it's always with you, available when needed. On the start screen, swipe left, and tap Nokia Care. For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/ support, or press , and tap . Point the camera at the code below, and tap the result. Check out the videos at www.youtube.com/ NokiaSupportVideos. If your phone freezes Press and hold the power key for about 10 seconds. The phone vibrates and restarts. 6 Product and safety information Important: For important info on the safe use of your device and battery, read “Safety” and “Product and safety info” in the device user guide at www.nokia.com/support and in the in-device user guide before you take your device into use. Select Nokia Care. For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy. You can only use your device on the LTE 700, 850, 1700–2100, 1900 MHz networks, WCDMA 850, 1900, 1700–2100, 2100 MHz networks, and GSM 850, 900, 1800, 1900 MHz networks. Use your device only with an original BV-4BWA rechargeable battery. To replace the battery, take the device to the nearest authorised service facility. Do not dispose batteries as household waste. Charge your device with AC-60U charger. Charger plug type may vary. Nokia may make additional battery or charger models available for this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may also be compatible. To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. Additional safety information Accessibility solutions Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit the Nokia website at www.nokiaaccessibility.com. Hearing Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety. Some wireless devices may interfere with some hearing aids. Information on health The U.S. Food and Drug Administration (FDA) and the U.S. Federal Communications Commission (FCC) published statements and questions and answers concerning cellular telephones and health. Nokia encourages you to visit these websites for updated information. You can access the FDA website at www.fda.gov/ Radiation-EmittingProducts/ RadiationEmittingProductsandProcedures/ HomeBusinessandEntertainment/CellPhones/default.htm and the FCC website at transition.fcc.gov/oet/rfsafety/rf-faqs.html. 7 Additional health-related information is available from the World Health Organization (WHO) at www.who.int/mediacentre/ factsheets/fs193/en/ and The National Cancer Institute ("NCI") www.cancer.gov/ncicancerbulletin/NCI_Cancer_Bulletin_092308/ page7. In the event that you are concerned about possible health effects, the FDA suggests that you limit your own or your children’s radio frequency (RF) exposure by limiting the length of calls or by using handsfree devices. Safety and texting while driving Safety should be every driver’s first priority. Drivers must obey all local laws that may include restrictions on the use of cellular telephones or accessories while driving. If use is legal, always keep your hands free to operate the vehicle while driving and use a handsfree device whenever possible. Suspend calls in heavy traffic or hazardous weather. Get to know your cellular phone and its features and make any necessary information inputs prior to driving. Do not input data or engage in text messaging while driving. Cellular telephones should not be used when use may be a distraction to the driver. The Cellular Telecommunications & Internet Association (CTIA) has published further info and tips on safe use of cellular telephones at www.ctia.org/consumer_info/safety, which we encourage you to review. Certification information (SAR) This mobile device meets international guidelines for exposure to radio waves. Your mobile device is a radio transmitter and receiver. It is designed not to exceed the l…

Text truncated - open the document above for the full version.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 April 17 th , 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Ren Shuifang act as our agent in all FCC matters for grantee code QTL. This appointment is effective until otherwise notified by us. Sincerely, Nokia (China) Investment Co., Ltd Yao Shuo-Lisa Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 December 11, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: QTLRM-995 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Ren Shuifang Product Certification Officer Beijing, PRC.

Nokia (China) Investment Co., Ltd B2, Nokia China Campus Beijing Economic and Tech Development Area, No.5 Donghuan Zhonglu Beijing, 100176 China PRC Tel. +861087118888 Fax +861087114550 December 11, 2013 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: QTLRM-995 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Ren Shuifang Product Certification Officer Beijing, PRC.

17-October-2013 Page 1 of 3 Exhibit 3: External PhotographsFCC ID: QTL RM-995 IC: 661AB-RM995 Applicant: Nokia Corporation Copyright © 2013 Nokia Corporation EXTERNAL PHOTOS 17-October-2013 Page 2 of 3 Exhibit 3: External Photographs FCC ID: QTLRM-995 IC: 661AB-RM995 Applic ant : Nokia Corporation Copyright © 2013 Nokia Corporation 17-October-2013 Page 3 of 3 Exhibit 3: External Photographs FCC ID: QTLRM-995 IC: 661AB-RM995 Applic ant : Nokia Corporation Copyright © 2013 Nokia Corporation

16-October-2013 Page 1 of 2 FCC Label and location FCC ID: QTLRM-995 IC: 661AB-RM995 Exhibit 1 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved. Label Location Drawing 16-October-2013 Page 2 of 2 FCC Label and location FCC ID: QTLRM-995 IC: 661AB-RM995 Exhibit 1 Applicant: Nokia Corporation Copyright © 2013 Nokia. All rights reserved.

Exhibit 9: I n Applicant: N INTERNA nternal Photo Nokia Corpor AL PHOTO ographs ration O Copyright © 17-Octob Pag FCC ID: IC: 66 © 2013 Nokia ber-2013 ge 1 of 3 QTLRM-995 1AB-RM995 Corporation 5 5 n Exhibit 9: I n Applicant: N nternal Photo Nokia Corpor ographs ration Copyright © 17-Octob Pag FCC ID: IC: 66 © 2013 Nokia ber-2013 ge 2 of 3 QTLRM-995 1AB-RM995 Corporation 5 5 n Exhibit 9: I n Applicant: N nternal Photo Nokia Corpor ographs ration Copyright © 17-Octob Pag FCC ID: IC: 66 © 2013 Nokia ber-2013 ge 3 of 3 QTLRM-995 1AB-RM995 Corporation 5 5 n

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_03.docx Copyright © TCC Nokia 1 (10) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-995_03.docx Date of Report: 13-Dec-2013 Number of pages: 10 Customer’s Contact person: Hu Helen Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-995 / Battery BV-4BWA(Sony) / AC-Charger AC-20U / Headset WH-108 FCC ID: QTLRM-995 IC: 661AB-RM995 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22, RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009), RSS-139 (Issue 2, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_03.docx Copyright © TCC Nokia 2 (10) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 13-Nov-2013 Testing completed 14-Nov-2013 The customer's contact person Hu Helen Test Plan referred to T:\Projects\RM-995\TestPlan\RS_testplan_RM-995.xlsm Notes - Document name FCC15B_RM-995_03.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-995 004402476460609 1000 - 3055.40000.1344.1000 53964 Battery BV-4BWA(Sony) - - - - 53967 AC-Charger AC-20U 4868673112340509970;0675629 - - - 53340 Headset WH-108 3323471 - - - 53950 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions PASSED WCDMA 850 (Band V): Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions NP GSM1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions NP WCDMA 1900 (Band II): Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions NP WCDMA 1700 (Band IV): Section in CFR 47 Section in ICES-003 (RSS-139) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions NP FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_03.docx Copyright © TCC Nokia 3 (10) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_03.docx Copyright © TCC Nokia 4 (10) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6, RSS-139 6.6) ............. 5 2.2. Test method and limit ........................................................................................................................ 5 2.3. GSM850 test results; FM radio on ..................................................................................................... 7 3. Test Equipment ............................................................................................................. 9 3.1. Conducted measurements ................................................................................................................ 9 3.2. Radiated measurements ................................................................................................................... 9 FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_03.docx Copyright © TCC Nokia 5 (10) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 …

Text truncated - open the document above for the full version.

FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_04.docx Copyright © TCC Nokia 1 (15) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-995_04.docx Date of Report: 16-Dec-2013 Number of pages: 15 Customer’s Contact person: Hu Helen Testing laboratory: TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 Customer: Nokia Corporation Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 FCC listing no.: IC recognition no.: 975940 661AH-1 Tested devices/ accessories: Phone RM-995 / Battery BV-4BWA(Sony) / USB data cable CA-190CD / Headset WH-108 / Laptop IBM T43 / Printer HP C6427A / Parallel cable for printer - / AC-Adapter 02K6749 FCC ID: QTLRM-995 IC: 661AB-RM995 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), RSS-GEN (Issue3, December 2010), CISPR 22, RSS-130 (Issue 1, October 2013), RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009), RSS-139 (Issue 2, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Gao Sherina, Engineer, EMC FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_04.docx Copyright © TCC Nokia 2 (15) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 13-Nov-2013 Testing completed 29-Nov-2013 The customer's contact person Hu Helen Test Plan referred to T:\Projects\RM-995\TestPlan\RS_testplan_RM-995.xlsm Notes - Document name FCC15B_RM-995_04.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-995 004402476460609 1000 - 3055.40000.1344.1000 53964 Battery BV-4BWA(Sony) - - - - 53967 USB data cable CA-190CD 07304573013628 - - - 53970 Headset WH-108 3185D71 - - - 53782 Laptop IBM T43 L3KXHL3 - - - 52468 Printer HP C6427A MY15B18156JJ - - - 51838 Parallel cable for printer - - - - - 53508 AC-Adapter 02K6749 - - - - 53509 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions NP 15.109, a 6.1 Radiated emissions NP WCDMA 850 (Band V): Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions NP 15.109, a 6.1 Radiated emissions NP GSM1900: Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions PASSED 15.109, a 6.1 Radiated emissions PASSED WCDMA 1900 (Band II): Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions NP 15.109, a 6.1 Radiated emissions NP FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_04.docx Copyright © TCC Nokia 3 (15) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 WCDMA 1700 (Band IV): Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions NP 15.109, a 6.1 Radiated emissions PASSED LTE700 Lower (Band 17): Section in CFR 47 Section in RSS-GEN Name of the test Result 15.107, a 7.2.4 AC powerline conducted emissions NP 15.109, a 6.1 Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15B Compliance Test Report / Template Version 15.0 FCC15B_RM‐995_04.docx Copyright © TCC Nokia 4 (15) TCC Nokia Beijing Laboratory Beijing Economic and Technological Development Area No.5 Donghuan Zhonglu Beijing PRC China 100176 Tel. +86 10 8711 8888 Fax. +86 10 8711 4550 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.107, RSS-GEN section 7.2.4) ............................................................................. 5 2.1. Test Setup ......................................................................................................................................... 5 2.2. Test method and limit ........................................................................................................................ 5 2.3. GSM 1900 Test results ..................................................................................................................... 6 3. Radiated emissions (FCC §15.109, RSS-GEN secti…

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-995_11.docx Copyright © TCC Nokia 1 (3) RM-995 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-995_11.docx Copyright © TCC Nokia 2 (3) Picture 3. FCC Part 15B Radiated emissions, computer peripherals Picture 4. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-995_11.docx Copyright © TCC Nokia 3 (3) Picture 5. FCC Part 15B AC powerline conducted emissions, computer peripherals, measure from PC charger
