Nokia N75 User Guide 9252943 ISSUE 1 EN R1114_en.book Page 1 Thursday, October 19, 2006 3:43 PM © 2006 Nokia. All rights reserved.Nokia, Nokia Connecting People, Xpress-on, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.Reproduction, transfer, distribution, or storag e of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.This product includes software lic ensed from Symbian Software Ltd (c) 1998-200(6). Symbian and Symbian OS ar e trademarks of Symbian Ltd. US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2006. Tegic Communications, Inc. All rights reserved.Java™ and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.This product is licensed under the MPEG -4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.Nokia operates a policy of ongoing development . Nokia reserves the right to make changes and improvements to any of th e products described in this document without prior notice.TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR A NY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.The availability of particular products and applications for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.Export controlsThis device may contain commodities, tec hnology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.FCC / INDUSTRY CANADA NOTICEYour device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your te lephone if such interference cannot be eliminated. If you require assistance, contac t your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received , including interference that may cause undesired operation. Any changes or modific ations not expressly approved by Nokia could void the user's authority to operate this equipment.Issue 1 EN, 9252943 R1114_en.book Page 2 Thursday, October 19, 2006 3:43 PM Contents ContentsFor your safety...........................................8Get connected ......................................... 11Welcome .................................................. 12Accessibility solutions ...... ........... ........... ............ ......... .......12 Find information about your device...............................12Contact your service provider ..........................................12 Your Nokia device................................... 13Keys and parts (fold open) ........... ............ ......... ......... .......13 Keys and parts (fold closed, front, back and sides)....14Insert the SmartChip card and battery .........................15Switch the device on ..........................................................15Modes .....................................................................................16 Fold closed mode ......... ........... ............ ......... ......... .......16 Fold open mode............ ........... ............ ......... ......... .......17 Essential indicators .............................................................18Useful shortcuts...................................................................18 Idle mode ............ ........... ........... ............ ......... ......... .......19 Edit text and lists.........................................................19 Keypad lock (keyguard)......................................................19Volume and loudspeaker control ....................................20 Headset .................................................................................. 20Clock ....................................................................................... 21 Clock settings ............................................................... 21World clock ................................................................... 21 Wrist strap ............................................................................ 22Settings .................................................................................. 22Memory card ........................................................................ 22 Memory card tool........................................................ 23 File manager ......................................................................... 23 View memory consumption ...................................... 24Memory low—free memory....................................... 24 Mus…

Text truncated - open the document above for the full version.

Address book 69 Address book Press , and select Addr. Book . Addr. Book holds details of your contacts, such as phone numbers and e-mail addresses. Each contact’s details are stored on a contact card, which can include a pers onal ringing tone (see "Add ringing tones for addresses," p. 70) or a thumbnail image for the contact. You can also create contact groups, which allow you to send text me ssages or e-mail to many recipients at the same time. See "Contact groups," p. 70. You can add received address information (business cards) to Addr. Book . See "Data and settings," p. 61. Address information can only be sent to or received from compatible devices. Contact cardsTo add details of a new contact in Addr. Book , select Options > New contact . To edit a contact card in Addr. Book , select it and Options > Edit . You can search for the desired contact by entering the first letters of the name to the search field. A list of contacts, starting with the letters, appears on the display. Tip! To add or edit several contact cards, use Nokia Contacts Editor available in Nokia PC Suite. To attach a small thumbnail image to a contact card, open the contact card, and select Options > Edit > Options > Add thumbnail . The thumbnail image is shown when the contact calls.To delete a contact card in Addr. Book , select a card, and press . To delete several contact cards at the same time, press and to mark the contact cards , and press to delete. Tip! 1-touch dialing is a quick way to call frequently used numbers. You can assign 1-touch dialing keys to eight phone numbers. See "1-touch dial a phone number," p. 73. Tip! To send contact information, select the contact card you want to send. Select Options > Send > Via text message , Via multimedia , Via Bluetooth , or Via infrared . See "Messaging," p. 55 and "Send data using Bluetooth connectivity," p. 114. To view the amount of a ddresses, groups, and the available memory in Addr. Book , select Options > Check memory . R1114_en.book Page 69 Thursday, October 19, 2006 3:43 PM Address book 70 Default numbers and addressesYou can assign default numbers or addresses to a contact card. In this way if a contact has several numbers or addresses, you can easily call or send a message to the contact to a certain number or address. The default number is also used in voice dialing.1 In Addr. Book , select a contact, and press . 2 Select Options > Defaults . 3 Select the number or address to which you want to add a default value, and select Assign . 4 Select a number or an address you want to set as a default. The default number or address is underlined in the contact card. Contact groupsTo create a contact group, do the following:1 In Addr. Book , press to open the groups list. 2 Select Options > New group . 3 Write a name for the group or use the default name Group %N , and select OK . 4 Open the group, and select Options > Add members . 5 Scroll to a contact, and press to mark it. To add multiple members at a time, repeat this action on all the contacts you want to add. 6 Select OK to add the contact to the group. To rename a group, select Options > Rename , enter the new name, and select OK . To add a contact to an existing contact group, select Options > Add to group: . To remove contacts from a group, do the following: 1 In the groups list, open the group you want to modify. 2 Select the contact and Options > Remove from group . 3 Select Yes to remove the contact from the group. Tip! To check to which groups a contact belongs, scroll to the contact, and select Options > Belongs to groups . Add ringing tones for addressesWhen a contact or group member calls you, the device plays the chosen ringing tone (if the caller’s telephone number is sent with the call an d your device recognizes it). 1 Press to open a contact card or go to the groups list, and select a contact group. 2 Select Options > Ringing tone . A list of ringing tones opens. 3 Select the ringing tone you want to use for the individual contact or the selected group. R1114_en.book Page 70 Thursday, October 19, 2006 3:43 PM Address book 71 You can also use a song as a ringing tone. See "Set a song as a ringing tone," p. 39.To remove the ringing tone, select Default tone from the list of ringing tones. Copy contactsTo copy names and numbers from a SmartChip to your device, press , and select Addr. Book > Options > SmartChip contacts > SmartChip directory . Select the names you want to copy and Options > Copy to Address Book . To copy addresses to your SmartChip, press , and select Addr. Book . Select the names you want to copy and Options > Copy to SChip direct. or Options > Copy > To SmartChip directory . Only the contact card fields supported by your SmartChip are copied. SChip directory an d other SmartChip services For availability and inform ation on using SmartChip services, contact your service provider.Press , and select Addr. Book > Options > SmartChip contacts > SChip directory to see the names and numbers stored on the SmartChip. In the SmartChip directory you can add, edit, or copy numbers to Addr. Book , and make calls.To view the list of fixed dialing numbers, select Options > SmartChip contacts > Fixed dialing contacts . This setting is only shown if supported by your SmartChip. To restrict calls from your device to selected phone numbers, select Options > Activ. fixed dialing . To add new numbers to the fixed dialing list, select Options > New SmartChip contact . You need the PIN2 code for these functions.When you use Fixed dialing , packet data connections are not possible, except when send ing text messages over a packet data connection. In this case, the message center number and the recipient’s phone number must be included on the fixed dialing list.When fixed dialing is activate d, calls may be possible to the official emergency num ber programmed into your device. R1114_en.book Page 71 Thursday, October 19, 2006 3:43 PM Make calls 72 Make callsVoice calls Tip! To increase or decre…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 18, 2006 RE: FCC ID: QURRM-128_ATCB004122 Attention: Esa Hakala I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that the operational description states that the GSM850 operation is from 890 – 915MHz. Please note that US operations are from 824-849MHz. Please explain and please correct as necessary. 2. Please note that the smallest resolution bandwidth allowed for making Occupied BW measurements is 1% of the OBW. Please note that for WCDMA plots on pages 14 and 15 of the part 22-24 test report shows a res BW of only 30kHz. Please note that for the projected OBW (i.e. 4.2MHz) the minimum Res BW should be 42kHz not 30kHz. Please provide a 99% bandwidth measurement for the device using the correct resolution bandwidths. Alternately, please explain in sufficient detail why the res BW on the analyzer used is adequate to meet the suggested 1% res bw. 3. Please note that it is not clear from the 15B report if data was continually being transferred between the phone and the PC during testing. As this is a computer peripheral test, data must be present during testing. Please confirm. 4. Please provide the manual for this device. Please insure that all appropriate FCC statements are located in the manual and that appropriate SAR data is also in the manual. 5. Please note that upon reception of the above information a further review of the application may be necessary. 6. Please note that it is not clear as to what type power measurements were made in the SAR report. Was the power measurement ERP/EIRP or conducted. Please be aware that the power between the SAR report and EMC report must be within +/- 0.5dB conducted and +/-3dB ERP/EIRP. 7. Please note that WCDMA testing for 3G requires certain test modes to be used. Please note that WCDMA testing must be done using 12.2kbps RMC Test Loop Mode 1. Also, all applicable physical channel configurations need to be addressed. The SAR report does not appear to address specific test modes for 3G application in sufficient detail. Please refer to the FCC required 3G test protocol found in KDB 941225 to insure all necessary test protocols have been adequately addressed. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

NOKIA CORPORATION Joensuunkatu 7 Salo, FIN-24101 Finland Tel. +358-71-8008000 Fax +358-71-8044235 (25/10/2006) American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean VA22101 Attention: Dennis Ward Correspondence: QURRM-128_ATCB004122 1. Corrected document (Updated_Exhibit12a_Theory_of_operation.pdf) uploaded to ATCB server. 2. Corrected test report (updated_Salo_FCC_0637_10.pdf) uploaded to ATCB server. 3. Updated test report (updated_Salo_FCC_0638_08.pdf) uploaded to ATCB server. 4. User guide uploaded to ATCB server. 5. information is now ready for review. 6. The power levels quoted are ERP/EIRP as indicated in the SAR summary tables in 1.2.1 and 1.2.2. 7. All WCDMA SAR tests were carried out using 12.2 kbps RMC Test Loop Mode 1. NOKIA CORPORATION Tero Huhtala

N75-3 WCDMA850/1900 GSM850/900/1800/1900 © 2006 Nokia CONFIDENTIAL Positioning Statement :”Music player meets camera meets smartphone” Key Selling Points: My Music – Play your music collection easily with the music keys on the cover . Synchronize both ways with Windows Media Player and get the music you want, more choices! Enjoy excellent 3D stereo sound quality. My Entertainment – Easy access to great mobile entertainment experiences! Instant access to Cingular Mobile Services like Cingular Video on-demand streaming, mobitv and mobiradio. Rich full screen MPEG-4 video with excellent stereo sound. My Connected Life – Browse what you like with the new Nokia Web Browser. Connect with eBay service or share your pictures on the web. Check your emails on the go! Technical Data: DIMENSIONS (with BL-5BT battery) • Volume: 93 cc • Weight: 123.5 g • Dimensions:(max) 52 x 95 x 20.2 mm KEY FEATURES MUSIC – Hear New • Digital music player : supports MP3/M4A/AAC/eAAC+/WMA with playlists and equalizer. • Dedicated music keys in cover UI • OMA DRM 1.0 support for music. • Stereo FM radio (87.5-108MHz /76-90MHz) • Stereo handsfree speakers with 3D audio • Inbox 3.5mm stereo headset adapter with integrated microphone and send/end/volume control • Nokia Stereo Headset HS-28 IMAGING – See New Capture Camera • Sensor : CMOS, 2 megapixel (1600x1200 pixels) • F number/Aperture Toshiba: F2.8 • Focal length Toshiba: 4.4 mm • Focus range Toshiba 30 cm to infinity Photo • Still Image resolutions VGA (640x480), 1 megapixel (1152x864), 2 megapixel (1600 x 1200) • Still image file format JPEG/EXIF • Fixed focus • Exposure compensation +2 ~ -2EV at 0.33 step • White balance Automatic, Daylight, Tungsten, Fluorescent • Scene Auto, User defined, Portrait, Landscape, Night, Night Portrait • Colour tone Normal, Sepia, B&W, Negative • Zoom (digital) up to 16x Video • Video resolution QCIF (176x144), CIF (352x288) • Audio recording AAC-LC • Video file format MPEG-4, 3GPP • White balance Automatic, Daylight,Tungsten, Fluorescent • Scene Normal, Night • Colour tone Normal, Sepia, B&W, Negative • Zoom (digital) up to 8x Other camera features • Intergrated flash LED Edit • On device photo editor and video editor (manual & automatic). View • Bright 2.4” QVGA (240 x 320 pixels) colour display with up to 16 million colours. Ambient light detector - used to optimize display brightness and power consumption • Display brightness up to 230 Cd/m2 • Display capable of 24 bit / up to 16 million colours • Slideshow from gallery • Cover-display – 1.36” colour display (160x128) up to 262144 colours. • Display brightness up to 100 Cd/m2 Share • Nokia XpressShare - share effortlessly from gallery or after capture via email, Bluetooth connectivity, MMS or IrDA. • Online album : image/video uploading from gallery Print • Nokia XpressPrint – direct printing via USB (PictBridge) and Bluetooth connectivity (BPP), from a compatible memory card or via online printing. Store • Nokia XpressTransfer – easy to transfer and organize photos and video between your device and compatible PC. • Comes with Adobe Photoshop Album 3.0 Starter Edition. • Nokia Lifeblog MEDIA – Watch New • Stream media files from compatible media portals Product picture to be added only after public announcement. © 2006 Nokia CONFIDENTIAL • Formats: H263, H264/ AVC • True web experience with Nokia Web Browser (HTML) PRODUCTIVITY – Do New • Messaging • E-mail (SMTP, IMAP4, POP3), MMS, SMS • Office applications • Supports viewing of common email attachments – Microsoft Word, Excel and PowerPoint, PDF, ZIP • PIM (Personal Information management) • Contacts, Calendar, To-do, Notes, Recorder, Calculator, Clock, Converter • Synchronization • Local/Remote (using SyncML) • Data: Calendar, Contacts, To-do, Notes, E-mail • PC Applications: Microsoft Outlook (98, 2000, 2002, 2003), Outlook Express, Lotus Organizer (5.0, 6.0), Lotus Notes (5.0, 6.0) • Call management • Call logs, speed dial, voice dialling (with SIND) and voice commands CONNECTIVITY • Pop-Port™ interface with USB 2.0 • Bluetooth wireless technology 2.0 • Infrared ADD-ON SOFTWARE • Operating system: Symbian OS v9.1 • User interface: S60 3 rd edition • Java™ :MIDP2.0 • C++ and Java SDKs Additional Technical specs • Vibrating alert • 3GPP Release 4 compliant • Quad band: WCDMA850/1900, GSM 850/900/1800/1900 MHz • Speech codecs supported: AMR/FR/EFR • WCDMA 850/1900 with simultaneous voice and packet data (PS max speed DL/UL= 384/384kbps, CS max speed 64kbps) • Multi slot class 11, max speed DL/UL: 177.6/118.4 kbits/s • EGPRS class B, multi slot class 11, (4 Rx + 3 Tx / Max Sum 5), max speed DL/UL= 236.8 / 177.6 kbits/s. • GPRS class B, multi slot class 11 (4 Rx + 3 Tx / Max Sum 5), max speed DL/UL= 85.6 / 64.2 kbits/s. ENHANCEMENTS • Power • Battery (BL-5BT) 800mAh • Nokia Travel Charger (AC-4) • Nokia Travel Charger (AC-5) • Nokia Compact Charger (AC-3) • Nokia Charging Adapter (CA-44) • Music • Nokia Music stand (MD-1) • Nokia Active Music Headphone (HS-62) • Nokia Music Headphone (HS-61) • Audio • Nokia Headsets (HS-20, HS-28, HS-23, HS-31, HS- 5, HS-29) • Nokia Wireless and Bluetooth Headsets (HS- 21W,HS-24W, HS-25W, HS-26W, HS-36W, HS- 50W, HS-51W, HS-57W, HS-58W, HS-59W) • Nokia Inductive Loopset ( LPS-4 ) • Nokia Audio Adapter (AD-41, AD-46, AD-15, AD-45) • Data • Nokia Connectivity Cable (CA-53) • Nokia Charging Data cable (CA-70) • Nokia TTY Adapter (HDA-10) – US market only • Nokia Wireless GPS Module ( LD-3W) • Nokia Micro-SD cards (128MB - MU-26, 256MB - MU-27, 512MB - MU-28, 1 GB - MU-22, 2GB MU- 37) • Carrying • Nokia Protective pouch (CL-1) • Nokia Wrist Strap (CP-134) • Nokia Carrying case (CP-108, CP-109, CP-110) • Messaging • Nokia Digital Pen (SU-27W) • Car • Nokia Universal Holder (CR-39) – Fold closed only • Nokia Mobile Charger (DC-4) • Nokia Wireless Plug-in Car Handsfree (HF-6W, HF- 33W) • Nokia Wireless Car Kits (CK-7W, CK-20W) • Nokia Navigation pack (LD-2) Operating Times* • ECTEL Talk time: 132 min(WC…

Text truncated - open the document above for the full version.

06 Oct 2006 Exhibit 03: External Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 06 Oct 2006 Exhibit 03: External Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 06 Oct 2006 Exhibit 03: External Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved.

09 Oct 2006 Exhibit 01: Type Label Position FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 09 Oct 2006 Exhibit 01: Type Labels FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved.

09 Oct 2006 t Exhibit 09: Internal Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 09 Oct 2006 Exhibit 09: Internal Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 09 Oct 2006 Exhibit 09: Internal Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved. 09 Oct 2006 Exhibit 09: Internal Photographs FCC ID: QURRM-128 IC: 661AC-RM128 Applicant: Nokia Corporation Copyright © 2006 Nokia. All rights reserved.

Nokia ____________________________________________________________________________ SAR Report Salo_SAR_0637_07 Applicant: Nokia Corporation Type: RM-128 Copyright © 2006 TCC Nokia 1/48 SAR Compliance Test Report Test report no.: Salo_SAR_0637_07 Date of report: 2006-09-28 Template version: 2.0 Number of pages: 48 Testing laboratory: TCC Nokia Salo Laboratory P.O.Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Client: Nokia Corporation P.O. Box 50 Mattilanniemi 6-8 FIN-40101 JYVÄSKYLÄ, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 78000 Responsible test engineer: Virpi Tuominen Product contact person: Tero Huhtala Measurements made by: Janne Hirsimäki, Virpi Tuominen Tested device: RM-128 FCC ID: QURRM-128 IC: 661AC-RM128 Supplement reports: - Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: For the contents: Nokia ____________________________________________________________________________ SAR Report Salo_SAR_0637_07 Applicant: Nokia Corporation Type: RM-128 Copyright © 2006 TCC Nokia 2/48 CONTENTS 1. SUMMARY OF SAR TEST REPORT............................................................................................................................................. 3 1.1 TEST DETAILS.............................................................................................................................................................................3 1.2 MAXIMUM RESULTS....................................................................................................................................................................3 1.2.1 Head Configuration........................................................................................................................................................ 3 1.2.2 Body Worn Configuration............................................................................................................................................ 4 1.2.3 Maximum Drift................................................................................................................................................................ 4 1.2.4 Measurement Uncertainty........................................................................................................................................... 4 2. DESCRIPTION OF THE DEVICE UNDER TEST........................................................................................................................... 4 2.1 PICTURE OF THE DEVICE..............................................................................................................................................................6 2.2 DESCRIPTION OF THE ANTENNA..................................................................................................................................................6 3. TEST CONDITIONS..................................................................................................................................................................... 6 3.1 TEMPERATURE AND HUMIDITY....................................................................................................................................................6 3.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER......................................................................................................................6 4. DESCRIPTION OF THE TEST EQUIPMENT...............................................................................................................................7 4.1 MEASUREMENT SYSTEM AND COMPONENTS................................................................................................................................7 4.1.1 Isotropic E-field Probe Type ET3DV6......................................................................................................................... 8 4.2 PHANTOMS................................................................................................................................................................................8 4.3 TISSUE SIMULANTS....................................................................................................................................................................9 4.3.1 Tissue Simulant Recipes............................................................................................................................................... 9 4.3.2 System Checking............................................................................................................................................................. 9 4.3.3 Tissue Simulants used in the Measurements....................................................................................................... 11 5. DESCRIPTION OF THE TEST PROCEDURE............................................................................................................................. 12 5.1 DEVICE HOLDER.....................…

Text truncated - open the document above for the full version.

FCC Part 22/24 Compliance Test Report FCC Part 22/24 Compliance Test Report / Template Version 7.0 T:\Projects\RM-128\EMC\Results\FCC\Salo_FCC_0637_10.doc Copyright © TCC Nokia 1 (35) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Test Report no.: 24.10.2006 Salo_FCC_0637_10.doc Date of Report: Number of pages: 35 Tero Huhtala Customer’s Contact person: Testing laboratory: TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC listing no.: IC recognition no.: 533467 5385 Nokia Corporation Customer: P.O. Box 50 Mattilanniemi 6-8 FIN-40…
