QUX-ATT-830Asset tracking transmitter

Wireless Resident Monitoring Solutions Asset Tracking Device Operational Instructions The HomeFree system is designed to monitor special needs individuals in the care center environment. The ATT (Asset Tracking Tag) is one of the many unique elements of this system. The ATT is a transmitter that is designed for installation on material assets such as computers and printers located within the monitored area. When the monitored item is in motion, the ATT transmits a signal that enables the item to be tracked. The ATT is not for use outside the monitored area. LED Indicator Activating the Asset Tracking tag: The ATT is turned off by the manufacturer before shipment and must be activated before use. To activate, install the rear tamper plate onto the item that requires tracking. Click the ATT onto the rear tamper plate; the LED indicator flashes for 3 seconds indicating that the ATT has been activated successfully. Once in active mode, the ATT sends a status message to the monitoring station (every 60 minutes) indicating the current battery status as well as the location of the ATT. This status message is sent until the ATT is deactivated. Motion Alert: When the ATT detects motion, it sends a transmission every 20 seconds. The ATT sends these transmissions until 2 minutes have expired without motion. After 2 motion-free minutes, the ATT returns to Rest mode. Tamper Alert: If the ATT is removed from the tracked item (i.e. it becomes separated from the rear tamper plate), a tamper signal shall be sent once every 20 seconds for a period of one hour. After an hour, if the ATT is still separated from the tracked item, a tamper signal shall be sent once every 60 minutes. After the ATT has been in a tamper condition for 12 hours, it shall automatically deactivate itself. Deactivating the ATT: Separate the ATT from its rear tamper plate. After 12 hours, the ATT deactivates itself automatically. FCC Notices Note: The following is applicable only to the 318MHz version of this product. FCC ID: QUX-ATT-830 FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT The equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna, 2. Increase the separation between the equipment and the receiver, 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected, 4. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Elmo Tech Ltd could void the user’s authority to operate the equipment. In case of any problems please contact your local service provider: HomeFree Systems Inc. Phone: 1-800-606-0661 Outside US call: +927-3-7671900 E-mail:[email protected] Web Site: www.homfreesys.com

ATT-830 Block diagram The following block diagram illustrates the functional areas within the ATT-830.

FCC Confidentiality Form 06.12.2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen, This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. HomeFree would like the following documents regarding this submission for FCC ID: QUX-ATT-830 to be kept confidential. • Permanent Confidentiality: Schematics • Short-term Confidentiality (180 days): Installation Manual The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want this document to be accessible to the general public. Sincerely, Gil Gemer CTO

Letter for FCC’s Drug Compliance Statement 06.12.2010 EMCCert DR. RAŠEK Boelwiese 5 91320 Ebermannstadt Germany Tel.: +49-9194-9331 Fax: +49-9194-7964-84 E-mail: [email protected] URL: http://www.emcc.de We the undersigned, hereby certify that, in the case of individual applicant, he or she is not subject to a denial of federal benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 853a or in the case of non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the applicant is subject to a denial of federal benefit pursuant to that action. Sincerely , Sincerely yours, Gil Gemer CTO

TCB Letter of Authorization 06.12.2010 To whom it may concern: We the undersigned, hereby authorize EMCCert DR. RAŠEK to act on our behalf in all manners relating to application for Transmitter (QUX-ATT-830) authorization, including signing of all documents relating to these matters. Any and all acts carried out by EMCCert DR. RAŠEK, on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice from HomeFree. Sincerely , Gil Gemer CTO

External pictures of the QUX-ATT-830 *look the same from all sides

Label location for ATT-830

Internal Pictures of the QUX-ATT-830

ATT – 830 Asset Tracking Tag Operational Description The Asset Tracking Tag is a small transmitter that shall be designed for installation on material assets such as computers and printers located within an area monitored by the TRaCE3 system. The device comprises a printed circuit board (PCB) that includes a RF transceiver module with an integral antenna and a microcontroller that controls its operation. The ATT-830 has one RF channel (318MHz, 433MHz or 868MHz) over which it communicates with its monitoring system. The unit is powered by an internal 3.6V Lithium battery. The ATT – 830 is mounted on material assets such as computers or printers through tamper mechanism. Once installed and activated the device transmit once every hour supervision signal, including data (e.g. battery ok) in order to indicate that the transmitter is functionally. The total duration of transmissions does not exceed more than one second per hour: 60 minutes X 1 transmissions per minute X 6 mSec (max.) = 0.36 seconds Any attempt to move the item upon which the ATT – 830 is installed on shall generate a "Motion" transmissions event and shall be used to track the movement path of the protected item. In this mode device transmit once every 20 seconds. If 2 minutes have not motion detection device return in standby mode. Additionally, any attempt to remove the ATT – 830 from the protected item shall generate a tamper alarm transmission event. In this mode device transmit once every 20 seconds.

DATE: 07 December 2010 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for HomeFree Systems Ltd. (An Attenti Subsidiary) Equipment under test: Asset Tracking Tag ATT-830 Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E103311.00 HomeFree Systems Ltd. Page 1 of 39 FCC ACC M Ver 1.1 05Mayl 2000 Test Report E103311.00 HomeFree Systems Ltd. Page 2 of 39 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for HomeFree Systems Ltd. Asset Tracking Tag ATT-830 FCC ID: QUX-ATT-830 This report concerns: Original Grant: x Class I change: Class II change: Equipment type: Part 15 Security/Remote Control Transceiver 47CFR15 Section 15231 (a-d) Measurement procedure used is ANSI C63.4-2003. Application for Certification: prepared by: Koby Cohen Home Free 2 Habarzel St. Tel-Aviv, 61131 Israel Tel: +972-3-647-8871 Fax: +972-3-647-8872 e-mail: [email protected] TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 5 1.3 Product Description ........................................................................................... 6 1.4 Test Methodology .............................................................................................. 6 1.5 Test Facility ....................................................................................................... 6 1.6 Measurement Uncertainty ................................................................................. 6 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 7 2.1 Justification ........................................................................................................ 7 2.2 Special Accessories .......................................................................................... 7 2.3 Equipment Modifications ................................................................................... 7 2.4 Configuration of Tested System ........................................................................ 7 3. RADIATED MEASUREMENT TEST SET-UP PHOTOS ------------------------------------------ 8 4. AVERAGE FACTOR CALCULATION ----------------------------------------------------------------- 9 4.1 Test Instrumentation Used .............................................................................. 11 5. PERIODIC OPERATION ---------------------------------------------------------------------------------12 5.1 Specification .................................................................................................... 12 5.2 Requirements .................................................................................................. 12 5.3 Results............................................................................................................. 12 5.4 Test Instrumentation Used .............................................................................. 18 6. FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------19 6.1 Test Specification ............................................................................................ 19 6.2 Test Procedure ................................................................................................ 19 6.3 Measured Data ................................................................................................ 19 6.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 23 7. RADIATED EMISSION, 9 KHZ – 30 MHZ -----------------------------------------------------------24 7.1 Test Specification ............................................................................................ 24 7.2 Test Procedure ................................................................................................ 24 7.3 Measured Data ................................................................................................ 24 7.4 Test Instrumentation Used, Radiated Measurements .................................... 25 7.5 Field Strength Calculation ............................................................................... 25 8. SPURIOUS RADIATED EMISSION, 30 – 3500 MHZ ---------------------------------------------26 8.1 Test Specification ............................................................................................ 26 8.2 Test Procedure ................................................................................................ 26 8.3 Test Data ......................................................................................................... 27 8.4 Test Instrumentation Used, Radiated Measurements .................................... 29 9. BANDWIDTH ------------------------------------------------------------------------------------------------30 9.1 Test procedure ................................................................................................ 30 9.2 Results table .................................................................................................... 31 9.3 Test Equipment Used. ..................................................................................... 32 10. 11. APPENDIX A - CORRECTION FACTORS -----------------------------------------------------33 10.1 Correction factors for CABLE ......................................................................... 33 10.2 Correction factors for CABLE ............................................................…

Text truncated - open the document above for the full version.

QUX-ATT-830 Test Setup Photographs
