Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Personal Watcher™ Operating Instructions Red Light Indicates ON/OFF Adjusts time ON/OFF Button Metal Clip secures Operating Instructions About the Personal Watcher™ Unit The Personal Watcher™ (Watch Style) is a uniquely designed wristwatch and wander-monitoring device. Lightweight and water-resistant, it is worn by the monitored individual at all times. The Wireless Monitoring Unit (WMU) network picks up its silent, continuously active signal, alerting staff members whenever a monitored individual enters or exits a restricted zone, approaches a monitored door or exit, or removes the device. The Personal Watcher TM is not for use outside of the monitored area. The Personal Watcher TM (PW) continuously sends a signal to the wireless network, indicating a resident’s current location and status. The PW has multiple sensing capabilities, including strap tamper/open, body contact, and motion sensing. Resident location – The PW transmissions are monitored at all times by the network, providing continuous, real-time resident monitoring throughout the coverage area of your facility/community. From the monitor screen, you can determine a resident's general location by selecting the resident’s name in the Residents Status area, right-clicking with the mouse, and selecting Position from the dropdown list. The map on the right side of the screen will display a 'walking person' in the general area of the WMU receiving the PW signal. Secondary layer of security – The HomeFree system notifies staff members via computer and pager if a resident wearing a PW exits the facility/community through a non-monitored exit, such as a window or a non-monitored door. The alert duration can be defined for each resident profile. PW removal alerts – The HomeFree system notifies the staff if residents remove their PWs. Resident motion monitoring – PWs are equipped with motion sensors. The HomeFree system notifies staff members if residents are in motion or motionless during a specified time period. This function needs to be activated in the resident’s profile screen in the Motion Monitoring area at the bottom of the screen. Personal Watcher Page 2 of 5 Operating Instructions Turn On PW The PW can only be turned on if the strap is completely open and the back of the PW does not detect heat. 1. Open the watchstrap. Hold the PW so that you are not touching the back of the device (body sensor) and the straps do not touch each other. Press and hold the ON/OFF button until the Red Light on the watch face turns on and off briefly. 2. IMMEDIATELY put the watch down on its side on a non-metal surface, near the central monitoring computer. The PW is automatically calibrated. 3. Do not touch or move the PW during the time it is calibrating. Look for the “Calibration Passed” message in the Events Display area of the HomeFree Monitor screen. You must wait to see this message before proceeding. 4. The PW is now ready for testing. If you do not see the “Calibration Passed“ message, or you see a “Calibration Failed” message, turn the PW off. Wait 15-20 seconds before turning the PW back on and repeating the above steps. If the PW does not calibrate, contact Technical Support for assistance. Do not place the Personal Watcher™ on a resident if calibration fails or you do not see “Calibration Passed”. Test PW You MUST test the PW before placing it on a resident. 1. Place the PW on your wrist, making sure the strap is tucked into the strap loop. You do not have to fasten the latch for testing. 2. Walk toward a HomeFree monitored door and open the door. Verify that the Wireless Monitoring Door Unit alerts appropriately, and that alarm information is sent to the pager. Close the door and reset the alarm. 3. If the door alerts appropriately, the PW is ready to place on a resident. 4. If the door does not alert appropriately, contact Technical Support for assistance. Personal Watcher Page 3 of 5 Operating Instructions Turn Off PW PWs should be turned off when not in use, for example, when a resident is in the hospital or discharged from the facility. A PW can only be turned off if its strap is completely open and the PW back does not detect heat. 1. Open the PW strap. Press and hold the ON/OFF button until the Red Light on the watch face turns on. 2. Release the ON/OFF button, and then quickly press the button twice. The Red Light turns on for 1-2 seconds and then turns off again. The message “Watch Closed” or “Watch Turned Off” appears in the Events Display area of the HomeFree Monitor screen. Putting the Personal Watcher™ on a Resident Make sure the PW has been tested. 1. Make sure that the serial number on the watch matches the serial number on the resident’s profile screen. 2. Fasten the strap around the resident’s wrist like any other watch, making sure the back of the watch touches the skin, the watch face is on the top of the wrist, and the strap is not too loose or too tight. Attach the metal clip around the strap and snap it closed. Use the hex screwdriver to tighten the screw to insure the watch cannot be removed. 3. Tuck the strap through the strap loop. 4. Set the time like any other watch. Recommendations On a regular basis (recommended at least once per shift), in the Residents Status area on the Monitor screen, check that all names/identifiers are in GREEN. Any other color (BLUE or RED) requires attention. Scroll through the entire screen or use the Filter option to check. Verify that PWs are turned OFF when not in use. This will extend battery life. Verify that PWs are removed from residents when they are transferred to the hospital or are permanently discharged from the facility. Make sure that you have extra PWs in stock for new residents. Make sure that you have longer PW straps in stock for residents with larger wrists. Make sure that you have extra strap and battery replacements in stock. Personal Watcher Page 4 of 5 Operating Instructions FCC Notices The PW-830-2 complies with Part 15 of the FCC Rules. Op…
Text truncated - open the document above for the full version.
Block Diagram The following block diagram illustrates the functional areas within the PW830-2 (VVST). Panic Button CPU PIC18F25K20 RF Transceiver CC1101 Loop Antena Body sensor Temperature sensor Volatge regulator Tilt sensor Strap Power BAT A/D Temp A/D MRD MRD comm Debug & Programming 26MHz Crystal Oscillator
FCC Confidentiality Form 13.09.2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen, This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. HomeFree would like the following documents regarding this submission for FCC ID: QUX-PW-830-2 to be kept confidential. • Permanent Confidentiality: Schematics • Short-term Confidentiality (180 days): Installation Manual The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want this document to be accessible to the general public. Sincerely, Gil Gemer CTO
External pictures of the PW-830-2
FCC ID: QUX-PW-830-2 XXXXX Personal Watcher 128 HomeFree Ltd. REV.ECO#DESCRIPTIONDATEAPPROVED A00001633FIRST RELEASE20/09/2010RonB SCALE 1:2 APPR. DESIGN DRAWN DATE DO NOT SCALE DRAWING PROJECT:VVST DESCRIPTION: SHORT STRAP "SET" VVST 433MHz FCC REV. A00 2 Habrzel St.,P.O.Box 13236,Tel Aviv 61132 ,Israel Tel:+972-3-7671700 Fax:+972-3-7671701 E-mail: engineering @ elmotech.com DWG. No.: 32000148 RonB 10/09/09 RonB NAME SIGN D E F C 1234 B A 3215 C D 4678 A B A3 SHEET 1 OF 1 ELECTRONIC MONITORING TECHNOLOGIES P/N: 32000148 Status:REL IlanB IlanB 20/09/10 10/09/09 IlanB IlanB
Label Location –QUX-PW-830-2 QUX-PW-830-2
Internal Pictures of the PW-830-2
PW-830 Bracelet Transceiver Operational Description The VVST is an AMS / EMS network transmitter that is hidden in an analog wristwatch, and is aimed for the Home free users. The VVST contains a few more sensors like "Body" sensor, "Strap open/close" sensor, temperature and battery level sensors and tilt. Includes 433.92 MHz and 318 MHz version. The Personal Watcher™ (Watch Style) is a uniquely designed wristwatch and wander- monitoring device. Lightweight and water-resistant, it is worn by the monitored individual (Alzheimer patients that can wander off and risk there own life in the process) at all times. The Wireless Monitoring Unit (WMU) network picks up its silent, continuously active signal, alerting staff members whenever a monitored individual enters or exits a restricted zone, approaches a monitored door or exit, or removes the device. The Personal WatcherTM is not for use outside of the monitored area. The Personal WatcherTM (PW) continuously sends a signal to the wireless network, indicating a resident’s current location and status. The PW has multiple sensing capabilities, including strap tamper/open, body contact, and motion sensing. When activated, the PW-830-2 transmits signals separated by a pseudorandom interval of between 9-11 seconds. Burst duration is 6.25 mSec. As per section 15.231(a)(4) “Intentional radiators which are employed for radio control purposes during emergencies involving fire, security, and safety of life, when activated to signal an alarm, may operate during the pendency of the alarm condition” – PW-830 is a safety of life intentional radiator, patient’s life may be in danger when he leaves the nursing home (his signal disappears), or when he presses the panic alert button. Therefore the transmitter normally re-starts a signal transmission about 10 seconds after the last signal transmission (and stops after 5 milliseconds).
Test Report E100221.02 HomeFree System Ltd. Page 1 of 36 FCC ACC M Ver 1.1 05Mayl 2000 DATE: 14 October 2010 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for HomeFree System Ltd. (An Attenti Subsidiary) Equipment under test: Personal Watcher* PW-830-2* * See customer’s declaration on page 5. Written by: _____________________________ E. Ever, Documentation Approved by: _____________________________ E. Ever, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E100221.02 HomeFree System Ltd. Page 2 of 36 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for HomeFree System Ltd. Personal Watcher* PW-830-2* * See customer’s declarationon page 5. FCC ID: QUX-VVST This report concerns: Original Grant: x Class I change: Class II change: Equipment type: Part 15 Security/Remote Control Transceiver 47CFR15 Section 15231 (a-d) Measurement procedure used is ANSI C63.4-2003. Application for Certification: prepared by: Gil Gemer HomeFree Systems Ltd. 2 Habarzel St. Tel-Aviv, 61131 Israel Tel: +972-3-647-8871 Fax: +972-3-647-8872 e-mail: [email protected] Test Report E100221.02 HomeFree System Ltd. Page 3 of 36 FCC ACC M Ver 1.1 05Mayl 2000 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 6 1.3 Product Description ........................................................................................... 7 1.4 Test Methodology .............................................................................................. 7 1.5 Test Facility ....................................................................................................... 7 1.6 Measurement Uncertainty ................................................................................. 7 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 8 2.1 Justification ........................................................................................................ 8 2.2 EUT Exercise Software ..................................................................................... 8 2.3 Special Accessories .......................................................................................... 8 2.4 Equipment Modifications ................................................................................... 8 2.5 Configuration of Tested System ........................................................................ 8 3. RADIATED MEASUREMENT TEST SET-UP PHOTO -------------------------------------------- 9 4. AVERAGE FACTOR CALCULATION ----------------------------------------------------------------10 4.1 Test Instrumentation Used .............................................................................. 11 5. PERIODIC OPERATION ---------------------------------------------------------------------------------12 5.1 Specification .................................................................................................... 12 5.2 Requirements .................................................................................................. 12 5.3 Results............................................................................................................. 12 6. FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------15 6.1 Test Specification ............................................................................................ 15 6.2 Test Procedure ................................................................................................ 15 6.3 Results............................................................................................................. 15 6.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 19 7. RADIATED EMISSION, 9 KHZ – 30 MHZ -----------------------------------------------------------20 7.1 Test Specification ............................................................................................ 20 7.2 Test Procedure ................................................................................................ 20 7.3 Results............................................................................................................. 20 7.4 Test Instrumentation Used, Radiated Measurements .................................... 21 7.5 Field Strength Calculation ............................................................................... 21 8. SPURIOUS RADIATED EMISSION, 30 – 4500 MHZ ---------------------------------------------22 8.1 Test Specification ............................................................................................ 22 8.2 Test Procedure ................................................................................................ 22 8.3 Results............................................................................................................. 23 8.4 Test Instrumentation Used, Radiated Measurements .................................... 25 9. BANDWIDTH ------------------------------------------------------------------------------------------------26 9.1 Test Specification ............................................................................................ 26 9.2 Test procedure ................................................................................................ 26 9.3 Results............................................................................................................. 28 9.4 Test Equipment Used. ..................................................................................... 29 …
Text truncated - open the document above for the full version.
QUX-PW-830-2 Test Setup Photographs
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 433.91 MHz - 433.91 MHz | - |
