QUX-UTX-830-2Universal Transmitter - UTX-830

Universal Transmitter USER MANUAL FCC ID: QUX-UTX-830-2 HomeFree Systems Ltd Universal Transmitter User Manual 1 Table of Contents 1. Foreword.................................................................................. 2 1.1. Activating the Universal Transmitter:.......................................2 1.2. Activating a Panic Alert:...........................................................3 1.3. Deactivating a Panic Alert:........................................................3 1.4. Deactivating the Universal Transmitter:...................................3 1.5. Cleaning Instructions.................................................................4 2. FCC Notices ............................................................................. 5 HomeFree Systems Ltd Universal Transmitter User Manual 2 1. Foreword The HomeFree at Care Centers system was designed to monitor special needs and Dementia individuals in the care center environment. The Universal Transmitter is one of the many unique elements of this system. 1.1. The UTX-830 is a small frame-head device, to be installed at internal or external doors of nursing homes and assisted leaving homes. The device is combined with a magnet on the door to detect door open / close status. When the door is open, the device shall transmit panic messages once every 18-22 seconds (random interval within this range), until closed door is detected. It will be possible to turn the UTX830 on and off by pulling out the battery (for saving battery life and for aviation safety while shipped). While UTX-830 is ON, it shall transmit a status message, once every hour, to indicate that it is still functioning and to report its battery level. 1.2. The UTX-830 is a stand-alone unit. It can be battery operated or externally powered by a dedicated AC adaptor; it has RF transmitter module, a microcontroller, which controls the UTX- 830 operation, one PCB, and a door magnet. 1.3. The UTX-830 has one RF channel. It is 318 MHz carrier with FSK modulated data. 1.1. Activating the Universal Transmitter: The Universal Transmitter is turned off by the manufacturer before shipment and must be activated before use. To activate, insert the HomeFree Systems Ltd Universal Transmitter User Manual 3 battery into the battery case, and/or plug in the power supply to the correct jack. Once the Universal Transmitter is working, it sends a status message to the monitoring station. The monitoring station then indicates the current battery status. This status message is sent until the Universal Transmitter is deactivated. 1.2. Activating a Panic Alert: The UTX-830 sends a panic transition alert message to the monitoring station in the following way, activate the reed switch (Normally open / Close). Once in panic alert mode, the Universal Transmitter sends a panic alert message to the monitoring station. This message is sent until the panic alert is deactivated. 1.3. Deactivating a Panic Alert: Change the status of the monitoring device from Normally Open to normally close and vice versa. Even though the panic alert has been deactivated, the Universal Transmitter is still working. Therefore, the Universal Transmitter still sends a status message to the monitoring station. This status message is sent until the Universal Transmitter is deactivated. 1.4. Deactivating the Universal Transmitter: Holding the Universal Transmitter: HomeFree Systems Ltd Universal Transmitter User Manual 4 1. Take off the power supply from the unit. 2. Disconnect the battery from the case. 1.5. Cleaning Instructions A soft brush and any cleaning solution are all that is needed to clean the Universal Transmitter. Alcohol based solutions; Soapy water or Lysol can be used to clean the Universal Transmitter. Holding the strap or leash, spray the Universal Transmitter (Panic Button) with cleaning solution of choice (see above). Using a piece of cloth or a paper towel, dry the outer side of the Universal Transmitter. Lay the Universal Transmitter on the towel with its inner side facing up. Using a soft brush or another piece of cloth/towel gently scrub the inner side of the Universal Transmitter. Dry the Universal Transmitter (Panic Button) using a piece of cloth/paper towel or simply let it dry. HomeFree Systems Ltd Universal Transmitter User Manual 5 2. FCC Notices This note is applicable to the American Universal Transmitter (Panic Button) NOTE The Universal Transmitter complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates uses and can radiate radio frequency energy and, if installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one or more of the following measures • Reorient or relocate the receiving antenna • Increase the separation between the equipment and the receiver. HomeFree Systems Ltd Universal Transmitter User Manual 6 • Consult the dealer or an experienced radio/TV technician for help. CAUTION Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. For Customer Support contact: Home Free Systems Inc. Wireless Tele home Care Solutions 6629 West Mill Road Milwaukee, WI 53218 USA Toll Free 1-800-606-0…

Text truncated - open the document above for the full version.

UTX-830-2 Block Diagram

FCC Confidentiality Form 03.10.2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen, This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. HomeFree would like the following documents regarding this submission for FCC ID: QUX-UTX-830-2 to be kept confidential. • Permanent Confidentiality: Schematics • Short-term Confidentiality (180 days): Installation Manual The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want this document to be accessible to the general public. Sincerely, Gil Gemer CTO

External pictures of the UTX-830-2

Internal Pictures of the UTX-830-2

Universal Transmitter UTX-830-2 Operational description 1. General Description 1.1. The UTX-830-2 is a small frame-head device, to be installed at internal or external doors of nursing homes and assisted leaving homes. The device is combined with a magnet on the door to detect door open / close status. When the door is open, the device shall transmit panic messages once every 18-22 seconds (random interval within this range), until closed door is detected. It will be possible to turn the UTX-830-2 on and off by pulling out the battery (for saving battery life and for aviation safety while shipped). While UTX-830-2 is ON, it shall transmit a status message, once every hour, to indicate that it is still functioning and to report its battery level. 1.2. The UTX-830-2 is a stand-alone unit. It can be battery operated or externally powered by a dedicated AC adaptor; it has RF transmitter module, a microcontroller, which controls the UTX-830-2 operation, one PCB, and a door magnet. 1.3. The UTX-830-2 has one RF channel. It is 433 MHz carrier with FSK modulated data. 2. Functional Description 2.1. The UTX-830-2 has four modes of operation. a) ACTIVATING THE UTX-830-2: Three 6.5ms transmissions within 1s. b) ACTIVE (door closed): The UTX-830-2 sends a status message to the monitoring station (one 6.5ms transmission per hour) to indicate the current battery status. c) ACTIVE to PANIC transition: The UTX-830-2 sends a panic transition alert message to the monitoring station in the following way. A burst of three 6.5ms transmissions within 1s. d) PANIC ALERT (door open): The UTX-830-2 sends a 6.5ms alert message transmission every randomly chosen interval of 18-22 s. This panic alert message is re-sent until the "door close" is detected. e) PANIC to ACTIVE transition: The UTX-830-2 sends an active transition alert message to the monitoring station in the following way. A burst of three 6.5ms transmissions within 1s . UTX-830-2 time diagram 6.5ms Start StartStartStart additional additionaladditionaladditional Panic PanicPanicPanic Alert AlertAlertAlert 6.5ms 6.5ms 1 111s sss 6.5ms 18-22 s sss 18-22 s sss 6.5ms Panic PanicPanicPanic alert alertalertalert mode modemodemode 6.5ms msmsms 6.5ms 6.5ms msmsms 6.5ms 6.5ms 60 min minminmin Send SendSendSend battery batterybatterybattery status statusstatusstatus Send SendSendSend battery batterybatterybattery status statusstatusstatus 60 min minminmin Activating the UTX830 Active ActiveActiveActive mode modemodemode 6.5ms 60 min minminmin Send SendSendSend battery batterybatterybattery status statusstatusstatus Send SendSendSend battery batterybatterybattery status statusstatusstatus 60 min minminmin Deactivation DeactivationDeactivationDeactivation the thethethe Panic PanicPanicPanic alert alertalertalert Active ActiveActiveActive mode modemodemode additional additionaladditionaladditional Panic PanicPanicPanic Alert AlertAlertAlert 1 s 6.5ms 6.5ms 1 s 6.5ms 6.5ms Activating the UTX- 830-2

DATE: 13 September 2010 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for HomeFree Systems Ltd. (An Attenti Subsidiary) Equipment under test: Universal Transmitter UTX-830 Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E100191.00 HomeFree Systems Ltd. Page 1 of 46 FCC ACC M Ver 1.1 05Mayl 2000 Test Report E100191.00 HomeFree Systems Ltd. Page 2 of 46 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for HomeFree Systems Ltd. Universal Transmitter UTX-830 FCC ID: QUX-UTX-830-2 This report concerns: Original Grant: x Class I change: Class II change: Equipment type: Part 15 Security/Remote Control Transceiver 47CFR15 Section 15231 (a-d) Measurement procedure used is ANSI C63.4-2003. Application for Certification: prepared by: Koby Cohen Home Free 2 Habarzel St. Tel-Aviv, 61131 Israel Tel: +972-3-647-8871 Fax: +972-3-647-8872 e-mail: [email protected] TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 5 1.1 Administrative Information ................................................................................. 5 1.2 List of Accreditations ......................................................................................... 6 1.3 Product Description ........................................................................................... 7 1.4 Test Methodology .............................................................................................. 7 1.5 Test Facility ....................................................................................................... 7 1.6 Measurement Uncertainty ................................................................................. 7 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 8 2.1 Justification ........................................................................................................ 8 2.2 Special Accessories .......................................................................................... 8 2.3 Equipment Modifications ................................................................................... 8 2.4 Configuration of Tested System ........................................................................ 8 3. CONDUCTED AND RADIATED MEASUREMENT TEST SET-UP PHOTOS --------------- 9 4. CONDUCTED EMISSION DATA -----------------------------------------------------------------------11 4.1 Test Specification ............................................................................................ 11 4.2 Test Procedure ................................................................................................ 11 4.3 Measured Data ................................................................................................ 11 4.4 Test Instrumentation Used, Conducted Measurement ................................... 16 5. AVERAGE FACTOR CALCULATION ----------------------------------------------------------------17 5.1 Test Instrumentation Used .............................................................................. 19 6. PERIODIC OPERATION ---------------------------------------------------------------------------------20 6.1 Specification .................................................................................................... 20 6.2 Requirements .................................................................................................. 20 6.3 Results............................................................................................................. 20 6.4 Test Instrumentation Used .............................................................................. 25 7. FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------26 7.1 Test Specification ............................................................................................ 26 7.2 Test Procedure ................................................................................................ 26 7.3 Measured Data ................................................................................................ 26 7.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 30 8. RADIATED EMISSION, 9 KHZ – 30 MHZ -----------------------------------------------------------31 8.1 Test Specification ............................................................................................ 31 8.2 Test Procedure ................................................................................................ 31 8.3 Measured Data ................................................................................................ 31 8.4 Test Instrumentation Used, Radiated Measurements .................................... 32 8.5 Field Strength Calculation ............................................................................... 32 9. SPURIOUS RADIATED EMISSION, 30 -4330 MHZ ----------------------------------------------33 9.1 Test Specification ............................................................................................ 33 9.2 Test Procedure ................................................................................................ 33 9.3 Test Data ......................................................................................................... 34 9.4 Test Instrumentation Used, Radiated Measurements .................................... 36 10. BANDWIDTH ------------------------------------------------------------------------------------------------37 10.1 Test procedure ...........................................................................................…

Text truncated - open the document above for the full version.

UTX-830-2 Test Setup Photographs
