QWB-REM1001SECURITY TRANSMITTER

RemoteRemote Keyfob Setup/Operations Manual INTRODUCTION The RemoteRemote keyfob is a simple 5 button RF wireless remote control. SETUP: Step 1: Carefully pop the case apart (use a small flat-blade screwdriver, or a thin piece of rigid plastic) Step 2: Remove the battery from the holder it came in. (Note the “+” symbol on the battery) Step 3: Insert the battery into the battery holder with the “+” symbol facing towards the metal battery bracket. Step 4: Carefully reinsert the board into the keyfob housing. Step 5: Snap the two keyfob halves back together. (it’s a tight fit, so take your time) LEARNING: The receiver was developed in such a way as to be able to learn new remotes (say if the original remote got lost and you bought a new one.) This process is relatively simple, but necessary before the receiver will recognize the remote. Once you have complete the setup steps above, you can proceed with the learning process. Note that some of these steps need to be done in a time-critical fashion, so you may want to read through the instructions first before attempting the procedure. Warning: Once a receiver has learned a keyfob transmitter, it CANNOT be unlearned! Step 1: At the same time, press and hold down the Volume Up and Volume Down buttons for 5 seconds (and then release) Step 2: Within an additional 5 seconds, press and release the Rewind, Fast Forward, and Play buttons (in that order) Step 3: Now press and hold the Play button for an additional 5 seconds (and then release) Step 4: Your receiver should now have learned your new remote. TROUBLESHOOTING If there is no activity at the receiver you should try these troubleshooting tips: 1.) Make sure the receiver is on. 2.) Is the battery new? Does it need to be replaced? 3.) If you put in a new battery, was it inserted with the correct orientation (+ towards the metal bracket) 4.) Has the receiver learned the keyfob remote? If not, go through the LEARNING process. 5.) If these steps still don’t help, please contact us. FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not approved by the party responsible for FCC compliance could void the user’s permission to operate this equipment. WARRANTY STATEMENT Engineered Audio, LLC (EA) warrants to the original purchaser as follows: All EA products, under normal use, will be free from defects in material and workmanship for 12 months to the end user. EA will, at its sole option, repair or replace a product that is found to be defective. This warranty shall be invalid if, in the sole opinion of EA, a product failure is the result of misuse, abuse, or modification. RemoteRemote Keyfob TECHNICAL SPECIFICATIONS • Dimensions: 2.2 x 1.4 x 0.5 • Built-in Antenna • Power requirement: 3v lithium battery • Modulation: AM/OOK • Frequency: 315Mhz • Operating range: ~100 feet (limited by FCC regulations) • FCC compliant (FCC QWB-REM1001)

Microcontroller (HC908QT1) Remote Keyfob block diagram Transistor / Tuned LC Oscillator P O W E R (Internal 3.2Mhz osc) (Nominal 315Mhz OOK Transmit Freq.) (5 Pushbutton Keys) (3v Lithium Batt.) Keyfob Transmit Timing Manchester Encoding. The RemoteRemote Keyfob uses a small microcontroller to Manchester “encode” its data before transmission. For the Keyfob, the period of each bit is 500uS, with a “1” being high for the first 250uS, and then low for the next 250uS of a period. A “0” is indicated by a low for the first 250uS, followed by a high for 250uS. 110 1 1 0 1 500uS 0 500uS A complete frame of transmitted data consists of a “Front Porch” (2mS high followed by 1mS low), Sync Byte (8 bits), Control Byte (8 bits), Serial Number (16 bits), Command Byte (8 bits), Checksum (8 bits). Further, if the user holds a key down, it will repeat this pattern every 100ms, for up to 4 seconds. So, the total number of transmitted bits is 8+8+16+8+8 = 48. Total data period is 3ms (Front Porch ) + 48 * 500uS = 27ms Total high (on) time is 2ms (Front Porch) + 48 * 250uS = 14 mS.

Model Number: Remote Serial Number: EA-xxxxx FCC ID: QWB-REM1001 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RemoteRemote Keyfob Circuit Description The RemoteRemote Keyfob is a simple On/Off Keyed keyfob-style transmitter with an internal, integrated patch antenna. The keyfob receives its power from a small 3v Lithium button cell battery. The keyfob is normally in sleep mode until the user presses one of 5 buttons, which wakes the microcontroller (MC68HC908QT1 - operating at 3.2Mhz), and sends out manchester encoded data to the transmitter. The transmitter portion of the device is a simple printed circuit LC tuned-tank transistor oscillator operating at a nominal frequency of 315Mhz.

A A B B C C D D E E F F G G H H 11 22 33 44 55 66 RemoteRemote Keyfob Rev 0.1 4/30/2003 Engineered Audio 15924 Sandalwood Creek Wildwood, Missouri 63011 TITLE: mls B Rel. date chk'd by Des. chk Date Drawn by PT#: Page size SHT 1 OF 1 PTA3 PTA4 PTA5 PTA2 PTA1 PTA0 Vdd Vss 4 3 2 1 5 6 7 8 908QT1 SW1 SW2 SW3 SW4 SW5 DGNDDGND 0.1uF C1 Q1 H10 500nH L2 100 R1 10K R2 C2 12 pF C3 3 pF PCB Trace (22nH) L1 DGND DGND 15K R3 No Pop R4

APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 REPORT #: E\ENG_AUDIO\1265UT3\1265UT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 TEST REPORT CONTAINING: PAGE 1.............TEST EQUIPMENT LIST PAGE 2.............TEST PROCEDURE PAGE 3-4...........RADIATION INTERFERENCE TEST DATA PAGE 5.............CALCULATION OF DUTY CYCLE PAGE 6-10..........DUTY CYCLE PLOTS PAGE 11............OCCUPIED BANDWIDTH PAGE 12............OCCUPIED BANDWIDTH PLOT EXHIBIT ATTACHMENTS: EXHIBIT 1...........BLOCK DIAGRAM EXHIBIT 2...........SCHEMATIC EXHIBIT 3...........INSTRUCTION MANUAL EXHIBIT 4...........LABEL SAMPLE EXHIBIT 5...........LABEL LOCATION EXHIBIT 6...........EXTERNAL PHOTOGRAPHS EXHIBIT 7...........INTERNAL PHOTOGRAPHS EXHIBIT 8...........TEST SET UP PHOTOGRAPH EXHIBIT 9...........CIRCUIT DESCRIPTION APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 REPORT #: E\ENG_AUDIO\1265UT3\1265UT3TestReport.doc Page 1 of 12 EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Blue Tower Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Blue Tower RF Preselector HP 85685A 2926A00983 CAL 4/15/03 4/15/05 Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 2/17/03 2/17/05 LISN Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 LISN Electro-Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Log-Periodic Antenna Eaton 96005 1243 CAL 5/8/03 5/8/05 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CAL 3/4/03 3/4/05 Oscilloscope Tektronix 2230 300572 CAL 7/3/03 7/3/05 Silver Tower Preamplifier HP 8449B 3008A01075 CHAR 1/28/02 1/28/04 Silver Tower Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/14/02 10/14/04 Silver Tower RF Preselector HP 85685A 2620A00294 CAL 10/14/02 10/14/04 Silver Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/14/02 10/14/04 Tan Tower Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/03 Tan Tower Quasi-Peak Adapter HP 85650A 3303A01690 CAL 8/31/01 8/31/03 Tan Tower RF Preselector HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 REPORT #: E\ENG_AUDIO\1265UT3\1265UT3TestReport.doc Page 2 of 12 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was 98.3ºF with a humidity of 40%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The UUT was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The UUT was placed in the center of the table. The table used for radiated measurements is capable of continuous rotation. The spectrum was scanned from 30 MHz to 10th harmonic of the fundamental. Peak readings were taken in three (3) orthogonal planes and the highest readings were converted to average readings based on the duration of "ON" time. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. Measurements were made by TIMCO ENGINEERING INC. at the registered open field test site located at 849 N.W. State Road 45, Newberry, Fl 32669. APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 REPORT #: E\ENG_AUDIO\1265UT3\1265UT3TestReport.doc Page 3 of 12 APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1001 NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.231 REQUIREMENTS: Fundamental Field Strength Field Strength of Frequency of Fundamental Harmonics and Spurious MHz dBuV Emissions (dBuV/m @ 3m) 40.66 to 40.70 67.04 47.04 70 to 130 61.94 41.94 130 to 174 61.94 to 71.48 41.94 to 51.48 174 to 260 71.48 51.48 260 to 470 71.48 to 81.94 51.48 to 61.94 470 and above 81.94 61.94 THE LIMIT FOR AVERAGE FIELD STRENGTH dBuV/m FOR THE FUNDAMENTAL FREQUENCY= 75.55 dBuV/m. NO FUNDAMENTAL IS ALLOWED IN THE RESTRICTED BANDS. THE LIMIT FOR AVERAGE FIELD STRENGTH dBuV/m FOR THE HARMONICS AND SPURIOUS FREQUENCIES = 55.55 dBuV/m. SPURIOUS IN THE RESTRICTED BANDS MUST BE LESS THAN 54dBuV/m OR 15.209. TEST DATA: Emission Frequency MHz Meter Reading dBuV ANT. POLARITY Coax Loss dB Correction Factor dB Duty Cycle Factor dB Field Strength dBuV/m Margin dB PHASE 1 313.87 F 50.4 H 2.28 16.54 17.25 51.97 23.58 313.87 F 55.1 V 2.28 16.06 17.25 56.19 19.36 627.84 28.1 V 3.48 19.54 17.25 33.87 21.68 627.84 31.3 H 3.48 19.81 17.25 37.34 18.21 941.80 22.7 V 2.95 25.13 17.25 33.53 22.03 941.80 28.1 V 2.95 25.13 17.25 38.93 16.63 1,255.50 21.3 H 1.33 26.07 17.25 31.45 …
