QWB-REM1002remote control transmitter

REV: 11/11/03 RemoteRemote Users’ Manual INTRODUCTION The RemoteRemote receiver and keyfob is a simple 5-button radio-frequency (RF) wireless remote control for the Apple iPOD. CONTENTS 1This Users’ Guide 1 5-button keyfob 1 RemoteRemote receiver with cable 13-volt Li-on battery (CR2032) REQUIREMENTS • Apple iPOD, third generation (10-, 15-, and 30-GB models) with dock connector • Headphones, powered speakers, or stereo receiver Please follow these simple steps to get your RemoteRemote up and running. INSERTING THE BATTERY Step 1: Remove the keyfob from its plastic shipping bag. Step 2: Carefully separate the top and bottom halves of the keyfob. (For best results, use a thin piece of rigid plastic, or use a small flat-blade screwdriver, being careful not to damage the keyfob. With the two halves separated, Take note of the positioning of the green board, so that you may reinsert it properly later.) Step 2: Remove the battery from its plastic bag, noting the “+” symbol on one side of the battery. Step 3: Place the green PC board on a flat surface, with the metal bracket (battery holder) facing up. (Do not handle the green board any more than necessary and treat it carefully. Avoid handling it in areas of high static electricity.) Insert the battery into the metal battery bracket, with the “+” symbol also facing up (towards the metal battery bracket). If you are unsure, please see “www.engineeredaudio.com/faq.html” for further guidance. Step 4: Once the battery is inserted, replace the green board within the fob. Make sure the notches in the sides of the green board line up with the guides in the fob. Step 5: Snap the two keyfob halves back together. (It’s a tight fit, so take your time.) CONNECTING THE RECEIVER TO THE iPOD Step 1: If the headphones are attached to your iPOD, remove them. Step 2: Remove the RemoteRemote receiver (with cable, labeled “RemoteRemote”) from its plastic shipping bag. Step 3: Insert the connector plug of the receiver into the headphones jack of the iPOD, making sure it is firmly seated. Step 4: Plug headphones into the stereo jack at the end of the receiver. Note that the receiver draws its power from the iPOD, even when the iPOD is off. If the iPOD is not to be used for a while, or is not being charged, unplug the receiver to prevent the draining the iPOD battery. SYNCHRONIZING THE KEYFOB AND RECEIVER The receiver and keyfob must be synchronized prior to use. This ensures that your iPOD is controlled by only your fob, and not by the fobs of other users nearby. Once you have completed the set-up steps above, you can begin the synchronization (also called “learning”) process. Note that some of these steps need to be done in a time-critical fashion, so you may want to read through the instructions first before attempting the procedure. You may also have to repeat these procedures more than once, as the receiver periodically “sleeps” and may not hear the synchronization command. Note: A receiver can be synchronized with 5 separate fobs. If you synchronize 6 or more fobs, the receiver will only work with (or “remember”) the last five fobs synchronized. Should you lose a fob and replace it, simply follow the synchronization procedure with the new fob. Step 1: Press and hold (simultaneously) both the Fast Forward and Rewind buttons for 5 seconds, then release. Step 2: Within an additional 5 seconds, press and release the Play button. Your receiver has now “learned” your new RemoteRemote. If the receiver and iPOD fail to operate properly at this point, repeat the sync procedure. REV: 11/11/03 ERASING SYNCHRONIZATION WARNING: Erasing should only be done when absolutely necessary. Once the erase command has been sent, as outlined below, none of the fob(s) previously synchronized will control your iPOD. Be aware that, if you have multiple fobs synchronized with the receiver, the Erase command disables ALL keyfobs, not just the fob from which it is sent. Step 1: Press and hold (simultaneously) the Volume up, Volume Down, Fast Forward, and Rewind buttons for 5 seconds, then release. Step 2: Press and hold the Play button 5 seconds, then release. Again, as above, if the procedure does not work the first time, repeat it. If you disable a fob and wish to re-enable it, simply follow the “Synchronizing the Keyfob and Receiver” steps listed above. BASIC OPERATIONS • Play/Pause: press and release to toggle between play and pause. Hold down for 5 seconds to turn the iPOD off. • Next Track/Fast Forward: press and release to skip to the next track. Hold down for fast forward within a track. • Previous Track/Rewind: press and release to skip to the previous track. Hold down for rewind within a track. • Volume Up/Volume Down: press and hold until the desired volume is reached. • Locking the keypad: To prevent the keyfob from transmitting, for example, when it is in your pocket, you can lock the keypad. Once the keypad is locked, it will not control your iPOD until you unlock it. Step 1: Press and hold (simultaneously) the Volume up and Volume Down buttons for 5 seconds, then release. Step 2: Press and release the Play button. • Unlocking the keypad: To unlock the keypad, simultaneously press and hold the Volume Up and Volume Down keys for 5 seconds. TROUBLESHOOTING If there is no iPOD activity using the RemoteRemote you should try these troubleshooting tips: 1.) Is the iPOD battery charged and the iPOD otherwise operational? 2.) Is the keyfob battery installed correctly? 3.) Does the keyfob battery need to be replaced? 4.) Has the receiver “learned” the keyfob? If not, go through the “Synchronizing the Keyfob and Receiver” process. 5.) Has the keypad on the fob been locked? If so, unlock it as noted above. 6.) Is the receiver cable firmly and correctly seated to the iPOD? 7.) Is the audio cable from the receiver (to the headphones or other speakers) firmly and correctly seated? 8.) If these steps still don’t help, please contact us. FCC STATEMENT This device complies with Part 15 of th…

Text truncated - open the document above for the full version.

Microcontroller (HC908QT1) Remote Keyfob block diagram SAW Resonator based LC Transistor Oscillator P O W E R (Internal 3.2Mhz osc) (Nominal 433.92Mhz OOK Transmit Freq.) (5 Pushbutton Keys) (3v Lithium Batt.)

Model Number: Remote Serial Number: EA-xxxxx FCC ID: QWB-REM1002 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RemoteRemote Keyfob Circuit Description The RemoteRemote Keyfob is a simple On/Off Keyed keyfob-style transmitter with an internal, integrated patch antenna. The keyfob receives its power from a small 3v Lithium button cell battery (type CR2032). The keyfob is normally in sleep mode until the user presses one of 5 buttons, which wakes the microcontroller (MC68HC908QT1 - operating at 3.2Mhz), and sends out manchester encoded data to the transmitter section. The transmitter section consists of a SAW resonator stabilized printed circuit LC tuned- tank transistor oscillator operating at a nominal frequency of 433.92Mhz.

A A B B C C D D E E F F G G H H 11 22 33 44 55 66 04/20/04 Rev 2.1 Operating Frequency: 433.92Mhz (saw stablized) Operating voltage: 2.7 to 3.0 volts Operating temperature: 0 deg. C - 55 deg. C Resistors: 0603 5% Carbon unless otherwise noted Capacitors: 0603 xx Ceramic unless otherwise noted 03/07/04 Initial Design 04/02/04 Changed C2 from 100pF to 0.01uF 04/19/04 Changed C4 to 1pf, C3 to 6pf 04/20/04 Changed key assignments to fully match PCB layout iPod transmitter Rev 2 Engineered Audio 15924 Sandalwood Creek Wildwood, Missouri 63011 TITLE: mls B Rel. date chk'd by Des. chk Date Drawn by PT#: Page size SHT 1 OF 1 PTA3 PTA4 PTA5 PTA2 PTA1 PTA0 Vdd Vss 4 3 2 1 5 6 7 8 M68HLC908QT1 IC1 Vol+ SW1 FF SW2 Rew SW3 Vol- SW4 Play SW5 DGND Vcc 0.1uF C1 Q1 MMBTH10LT1 100 R2 DGND 20K R1 433.92 Mhz SAW 0.01uF C2 DGND C4 1 pF C3 6pf L1 PCB trace DGND Vcc BAT1 3.0v CR2032

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 REPORT #: E\ENG_AUDIO\566UT4\566UT4TestReport.doc COVER SHEET Test Report Product Name: REMOTE CONTROL TRANSMITTER FCC ID: QWB-REM1002 Applicant: ENGINEERED AUDIO, LLC 15924 SANDALWOOD CREEK WILDWOOD MISSOURI 63011 Date Receipt: APRIL 21, 2004 Date Tested: MAY 5, 2004 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 REPORT #: E\ENG_AUDIO\566UT4\566UT4TestReport.doc TABLE OF CONTENTS TABLE OF CONTENTS APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 TEST REPORT CONTAINING: PAGE 1.............TEST EQUIPMENT LIST PAGE 2.............TEST PROCEDURE PAGE 3-4...........RADIATION INTERFERENCE TEST DATA PAGE 5.............CALCULATION OF DUTY CYCLE PAGE 6-9...........DUTY CYCLE PLOTS PAGE 10............OCCUPIED BANDWIDTH PAGE 11............OCCUPIED BANDWIDTH PLOT EXHIBIT INCLUDING: BLOCK DIAGRAM SCHEMATIC INSTRUCTION MANUAL LABEL SAMPLE LABEL LOCATION EXTERNAL PHOTOGRAPHS INTERNAL PHOTOGRAPHS OPERATIONAL DESCRIPTION TEST SET UP PHOTOGRAPH TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 REPORT #: E\ENG_AUDIO\566UT4\566UT4TestReport.doc Page 1 of 11 EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/27/04 3/26/07 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Blue Tower Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Blue Tower RF Preselector HP 85685A 2620A00294 out for Cal Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 Double- Ridged Horn Antenna Electro- Metrics RGA-180 2319 CAL 2/17/03 2/17/05 LISN Electro- Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 LISN Electro- Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Log- Periodic Antenna Eaton 96005 1243 CAL 5/8/03 5/8/05 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 REPORT #: E\ENG_AUDIO\566UT4\566UT4TestReport.doc Page 2 of 11 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was 98.3ºF with a humidity of 40%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The UUT was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The UUT was placed in the center of the table. The table used for radiated measurements is capable of continuous rotation. The spectrum was scanned from 30 MHz to 10th harmonic of the fundamental. Peak readings were taken in three (3) orthogonal planes and the highest readings were converted to average readings based on the duration of "ON" time. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. Measurements were made by TIMCO ENGINEERING INC. at the registered open field test site located at 849 N.W. State Road 45, Newberry, Fl 32669. TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 REPORT #: E\ENG_AUDIO\566UT4\566UT4TestReport.doc Page 3 of 11 APPLICANT: ENGINEERED AUDIO, LLC FCC ID: QWB-REM1002 NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.231 REQUIREMENTS: Fundamental Field Strength Field Strength of Frequency of Fundamental Harmonics and Spurious MHz dBuV Emissions (dBuV/m @ 3m) 40.66 to 40.70 67.04 47.04 70 to 130 61.94 41.94 130 to 174 61.94 to 71.48 41.94 to 51.48 174 to 260 71.48 51.48 260 to 470 71.48 to 81.94 51.48 to 61.94 470 and above 81.94 61.94 THE LIMIT FOR AVERAGE FIELD STRENGTH dBuV/m FOR THE FUNDAMENTAL FREQUENCY = 80.83 dBuV/m. NO FUNDAMENTAL IS ALLOWED IN THE RESTRICTED BANDS. THE LIMIT FOR AVERAGE FIELD STRENGTH dBuV/m FOR THE HARMONICS AND SPURIOUS FREQUENCIES = 60.83 dBuV/m. SPURIOUS IN THE RESTRICTED BANDS MUST BE LESS THAN 54 dBuV/m OR 15.209. TEST DATA: Emission Frequency MHz * Meter Reading dBuV Ant. Polarity Coax Loss dB Correction Factor dB Duty Cycle Factor dB Field Strength dBuV/m Margin dB 433.77 53.6 H 3.44 17.15 20.00 54.19 26.64 433.77 57.8 V 3.44 16.94 20.00 58.18 22.65 433.78 52.6 V 3.44 16.94 20.00 52.98 27.85 433.78 60.1 H 3.44 17.15 20.00 60.69 20.14 433.79 55.4 V 3.44 16.93 20.00 55.77 25.06 867.57 31.4 H 4.94 22.62 20.00 38.96 21.87 867.57 38.2 V 4.94 21.85 20.00 44.99 15.84…
