R2NSEC-3189CDMA 1X EvDo Express Card

SEC-3189 SAM User Manual Rev 1.1 September 4, 2007 Epivalley - 2 - Revision History Rev 0.1 Rev 0.2 Rev 0.3 Rev 0.4 Rev 0.5 Rev 0.6 Rev 0.7 Rev 0.8 Rev 1.0 Rev 1.1 Rev 1.2 2007. 05. 15 2007. 05. 21 2007. 05. 28 2007. 06. 07 2007. 06. 13 2007. 06. 15 2007. 06. 20 2007. 07. 15 2007. 08. 14 2007. 09. 04 2007. 09. 18 First issue Replaced “tool bar” with “status bar” Added description on installation Added contents on Beta 2 Release Added contents on Beta 3, Deleted Voice function Added Results of the SAR Test Modified for VIVO Modified with final version of SAM Change Image Change Company name Add the warning for the modem-memory switch Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo Sung Eun Jo SE Kang SE Kang - 3 - Contents 1. Installation & Setup ........................................................................................................................... 4 1. SAM Installation ........................................................................................................................... 4 2. Express Card Device Installation ................................................................................................. 6 2. Getting Started................................................................................................................................... 9 3. Internet................................................................................................................................................ 9 4. SMS ................................................................................................................................................... 11 1. Send ............................................................................................................................................11 2. Inbox........................................................................................................................................... 12 3. Sent ............................................................................................................................................ 13 4. Temporary .................................................................................................................................. 14 5. Spam .......................................................................................................................................... 15 5. Address ............................................................................................................................................ 16 1. List .............................................................................................................................................. 16 2. Search ........................................................................................................................................ 16 3. Group ......................................................................................................................................... 17 6. Log .................................................................................................................................................... 18 1. Internet Log ................................................................................................................................ 18 7. Settings ............................................................................................................................................ 19 1. General Settings......................................................................................................................... 19 2. SMS Settings.............................................................................................................................. 19 3. Lock Settings.............................................................................................................................. 20 4. Information ................................................................................................................................. 20 8. Web ................................................................................................................................................... 22 9. Email ................................................................................................................................................. 22 10. Others ............................................................................................................................................. 22 1. File.............................................................................................................................................. 22 2. View............................................................................................................................................ 23 3. Help ............................................................................................................................................ 23 4. Internet Access Status Icon ........................................................................................................ 23 5. Tray Icon..................................................................................................................................... 24 6. Mass Storage ............................................................................................................................. 24 11. Specification .................................................................................................................................. 25 SAM User Manual - 4 - 1. Installation & Setup 1. SAM Installation 1.1 Insert the Installation CD to the CD-ROM Drive. If the installation process does not start automatically, run Setup.exe file in the CD-ROM Drive. Select a language and click “OK”. (Do not plug the Express Card in the PCI express port before you finish installing SAM.) 1.2 To continue installation, click “Next”. 1.3 Se…

Text truncated - open the document above for the full version.

Roadland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sungnam City, Kyunggi-Do, Korea September 29, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: R2NSEC-3189 including signing of all documents relating to these matters. Any and all acts carried out by DIGITAL EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Epivalley CO.,LTD. Sincerely, W.W CHOUNG/Senior Engineer

Roadland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sungnam City, Kyunggi-Do, Korea September 29, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re : Epivalley CO.,LTD. FCC ID : R2NSEC-3189 Request for Confidentiality Gentlemen: In accordance with 0.457 and 0.459 of CFR 47, Epivalley CO.,LTD. hereby requests confidentiality of the Block Diagram(Block Diagram_R2NSEC-3189), Schematics(Schematics_R2NSEC-3189), Part List(Part List_R2NSEC- 3189), Part Location(Part Location_R2NSEC-3189) and Operational description(Operational Description_R2NSEC- 3189) of the attached test report. These documents contain detailed system and equipment description and related information about the product which Epivalley CO.,LTD. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Epivalley CO.,LTD.considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, W.W CHOUNG/Senior Engineer

Roadland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sungnam City, Kyunggi-Do, Korea September 29, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re: Epivalley CO.,LTD. FCC ID: R2NSEC-3189 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, Epivalley CO., LTD. requests short-term confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos_R2NSEC-3189 External photos_R2NSEC-3189 Internal photos_R2NSEC-3189 User’s manual_R2NSEC-3189 These documents contain detailed system and equipment descriptions and related information about the product, which Epivalley CO., LTD. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Epivalley CO., LTD. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. W.W CHOUNG/Senior Engineer

FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 1/4 page EXTERNAL PHOTOGRAPHS FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 2/4 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 3/4 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 4/4 page

FCC ID: R2NSEC-3189 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase (SEE NEXT PAGE) FCC ID: R2NSEC-3189 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 1/6 page INTERNAL PHOTOGRAPHS FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 2/6 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 3/6 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 4/6 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 5/6 page FCC ID: R2NSEC-3189 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. 6/6 page

Applicant : Epivalley CO.,LTD. FCC ID : R2NSEC-3189 TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this CDMA 1X EvDo Express Card. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments.

G Copyright ̺ c 2007, DIGITAL EMC Co., Ltd. DIPOLE CALIBRATION G Copyright ̺ c 2007, DIGITAL EMC Co., Ltd. 1. 835 Dipole Calibration G Copyright ̺ c 2007, DIGITAL EMC Co., Ltd. 2. 1900 Dipole Calibration

G G Copyright ̺ c 2007, DIGITAL EMC Co., Ltd. PROBE CALIBRATION

DEMC#DR50110709Q_rev.1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 24 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification Dates of Tests: September 12 ~ 19, 2007 Test Report S/N: DR50110709Q_rev.1 Test Site : DIGITAL EMC CO., LTD. Model No. APPLICANT Classification : PCS Licensed Transmitter (PCB) FCC Rule Part(s) : §22(H), §24(E), §2 EUT Type : CDMA 1X EvDo Express Card CDMA MS Protocol Rev. Number : 6 CDMA EvDo Rev. Number : 0 Model name : SEC-3189 Serial number : Identical prototype TX Frequency Range : 824.70 ~848.31 MHz (Cellular band) 1851.25 ~ 1908.75MHz (PCS band) RX Frequency Range : 869.70 ~893.31 MHz (Cellular band) 1931.25 ~ 1988.75MHz (PCS band) Max. RF Output Power : 0.182W ERP CDMA Cellular Band (22.61dBm) 0.149W EIRP CDMA PCS Band (21.73dBm) Max. SAR Measurement : 1.38W/kg CDMA Cellular Band Body SAR 1.34W/kg CDMA PCS Band Body SAR Emission Designators: : CDMA Cellular Band - 1M26F9W CDMA PCS Band - 1M28F9W Date of Issue : September 28, 2007 R2NSEC-3189 Epivalley CO., LTD. DEMC#DR50110709Q_rev.1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 24 TABLE OF CONTENTS ◈ AUTHORIZATION LETTER ◈ CONFIDENTIALITY LETTER(S) ◈ TEST REPORT 1.1 SCOPE 3 2.1 GENERAL INFORMATION 4 3.1 DESCRIPTION OF TESTS 5 4.1 TEST DATA 8 4.1.1 CONDUCTED OUTPUT POWER 8 4.1.2 EFFECTIVE RADIATED POWER OUTPUT 9 4.1.3 CDMA RADIATED MEASUREMENTS 10 4.1.4 FREQUENCY STABILITY(CDAM) 16 5.1 PLOTS OF EMISSIONS 20 6.1 LIST OF TEST EQUIPMENT 21 7.1 SAMPLE CALCULATIONS 23 8.1 CONCLUSION 24 ◈ TEST PLOTS ◈ FCC ID LABEL & LOCATION ◈ TEST SETUP PHOTOGRAPHS ◈ EXTERNAL PHOTOGRAPHS ◈ INTERNAL PHOTOGRAPHS ◈ BLOCK DIAGRAM(S) ◈ SCHEMATIC DIAGRAM(S) ◈ OPERATIONAL DESCRIPTION ◈ PARTS LI S T ◈ PARTS LOCATION ◈ USER’S MANUAL DEMC#DR50110709Q_rev.1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 3 of 24 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information z FCC ID: z Quantity: z Emission Designators: z Tx Freq. Range: z Rx Freq. Range: z Max. Power Rating: z FCC Classification(s): z Equipment (EUT) Type: z CDMA MS Protocol Revision Number z CDMA EvDo Revision Number z Modulation(s): z Frequency Tolerance: z FCC Rule Part(s): z Dates of Tests: z Place of Tests: z Test Report S/N: R2NSEC-3189 Quantity production is planned CDMA Cellular Band - 1M26F9W CDMA PCS Band - 1M28F9W 824.70 ~ 848.31 MHz (Cellular Band) 1851.25 ~ 1908.75MHz (MHz Band) 869.70 - 893.31 MHz (Cellular Band) 1931.25 ~ 1988.75MHz (PCS Band) 0.182W ERP CDMA Cellular Band(22.61dBm) 0.149W ERP CDMA PCS Band (21.73dBm) PCS Licensed Transmitter (PCB) CDMA 1X EvDo Express Card 6 0 CDMA ± 0.00025 % (2.5ppm) §22(H), §24(E), §2 September 12 ~ 19, 2007 DIGITAL EMC DR50110709Q_rev.1 Applicant: Epivalley CO., LTD. Address: Lordland EZ Tower #511, 153, Gumi-Dong, Bundang-Gu, SEONGNAMCITY, GYUNGGI, KOREA Attention: Woo Won Choung DEMC#DR50110709Q_rev.1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 4 of 24 2.1. General Information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer September 27, 2007 Won-Jung LEE Data Name Signature Report Reviewed By: manager September 27, 2007 Harvey Sung Data Name Signature Ordering party: Company name : Epivalley CO., LTD. Address : Loadland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Zipcode : 463-500 City/town : SEONGNAM-CITY, KYUNGGI Country : KOREA Date of order : August 28, 2007 DEMC#DR50110709Q_rev.1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 5 of 24 3.1 DESCRIPTION OF TESTS 3.1.1 Occupied Bandwidth Emission Limits (a) On any frequency outside a licensee’s frequency block, the power of any emission shall be attenuated below the transmitter power (P) by at least 43 + 10 log(P) dB. (b) When measuring the emission limits, the nominal carrier frequency shall be adjusted as close to the licensee’s frequency block edges, both upper and lower, as the design permits. (c) The measurement of emission power can be expressed in peak or average values, provided they are expressed in the same parameters as the transmitter power. 3.1.2 Occupied Bandwidth The 99% power bandwidth was measured with a calibrated spectrum analyzer. 3.1.3 Spurious and Harmonic Emissions at Antenna Terminal The level of the carrier and the various conducted spurious and harmonic frequencies is measured by means of a calibrated spectrum analyzer. The spectrum is scanned from the lowest frequency generated in the equipment up to 10 GHz. At the input terminals of the spectrum analyzer, an isolator(RF circulator with on port terminated with 50ohms) and an 870 MHz to 890 MHz band pass filter is connected between the test transceiver(for conducted tests)or the receive antenna(for radiated tests) and the analyzer . The rejection of the band pass filter to signals in the 825-845 MHz range is adequate to limit the transmit energy from the test transceiver which appears to a level which will allow the analyzer to measure signals less than-90dBm. Calibration of the test receiver is performed in the 870-890 MHz range to insure accuracy to allow variation in the band pass filter insertion loss to be calibrated. 3.1.4 Frequencies At the input terminals of the spectrum analyzer, an isolator (RF pad) and a high-pass filter are connected between the test tra…

Text truncated - open the document above for the full version.

DEMC#DR50110709O_Rev1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 34 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com SAR TEST REPORT Dates of Tests: September 03~October 11, 2007 Test Report S/N:DR50110709O_Rev1 Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification: Licensed Portable Transmitter (PCB) EUT Type: CDMA 2000 1x EV-DO Express Card Model Name SEC-3189 Test Device Serial No.: Identical prototype TX Frequency Range: 824.70 ~848.31 MHz (CDMA_CELL) 1851.25~1908.75MHz(CDMA_PCS) RX Frequency Range: 869.70 ~893.31 MHz (CDMA_CELL) 1931.25~1988.75MHz(CDMA_PCS) Max. SAR Measurement: 1.38 mW/g CDMA _CELL Body SAR 1.34 mW/g CDMA _PCS Body SAR Max. RF Output Power 0.182W ERP CDMA Cellular Band (22.61dBm) 0.149W EIRP CDMA PCS Band (21.73dBm) Application Type: Certification Rule Part(s): §2.1093; FCC/OET Bulletin Supplement C[July 2001] Data of issue: October 15, 2007 Tested by : Reviewed by : Sun-Kyu Ryu (Engineer) Harvey Sung (Chief Engineering Director) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528- 2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. R2NSEC-3189 Epivalley CO., LTD. DEMC#DR50110709O_Rev1 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 34 1. INTRODUCTION ...................................................................................................... 3 SAR DEFINITION .................................................................................................... 3 2. SAR MEASUREMENT SETUP......................................................................................... 4 Robotic System.......................................................................................................... 4 System Hardware ....................................................................................................... 4 System Electronics...................................................................................................... 4 3. DASY4 E-FIELD PROBE SYSTEM................................................................................... 5 Probe Measurement System......................................................................................... 5 Probe Specifications .................................................................................................... 5 4. Probe Calibration Process............................................................................................ 6 Dosimetric Assessment Procedure.................................................................................. 6 Free Space Assessment ............................................................................................... 6 Temperature Assessment ............................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES.............................................................................. 7 SAM Phantom ........................................................................................................... 7 Brain & Muscle Simulating Mixture Characterization ....................................................... 7 Device Holder for Transmitters..................................................................................... 7 6. TEST SYSTEM SPECIFICATIONS.................................................................................. 8 Automated Test System Specifications.......................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ........................................................... 9 Measurement Procedure............................................................................................. 9 Specific Anthropomorphic Mannequin (SAM) Specifications.............................................. 9 8. DEFINITION OF REFERENCE POINTS .......................................................................... 10 EAR Reference Point................................................................................................... 10 Handset Reference Points............................................................................................ 10 9. TEST CONFIGURATION POSITIONS ............................................................................. 11 Positioning for Cheek/Touch ........................................................................................ 11 Positioning for Ear /15° Tilt ......................................................................................... 12 Body Holster /Belt Clip Configurations .......................................................................... 13 10. ICNIRP GUIDELINES RF EXPOSURE LIMITS.................................................................. 14 Uncontrolled Environment ........................................................................................... 14 Controlled Environment............................................................................................... 14 11. MEASUREMENT UNCERTAINTIES............................................................................... 15 SAR Measurement Uncertainties .................................................................................. 15 12. SYSTEM VERIFICATION........................................................................................... 16 Tissue Verification...................................…

Text truncated - open the document above for the full version.

DIGITAL EMC CO., LTD DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:464 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.887 mho/m; ε r = 40.7; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(6.34, 6.34, 6.34); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM with 835MHz; Type: SAM; Serial: TP-1223 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-09-04; Ambient Temp: 21.3; Tissue Temp: 21.2 Dipole Validation Area Scan (51x101x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.122 dB Peak SAR (extrapolated) = 3.70 W/kg SAR(1 g) = 2.48 mW/g; SAR(10 g) = 1.63 mW/g 0 dB = 2.67mW/g DIGITAL EMC CO., LTD DUT: Dipole 1900 MHz; Type: D1900V2; Serial: D1900V2 - SN:5d029 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.37 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(5.27, 5.27, 5.27); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-09-03; Ambient Temp: 21.5; Tissue Temp: 21.3 Dipole Validation Area Scan (51x71x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.030 dB Peak SAR (extrapolated) = 20.2 W/kg SAR(1 g) = 10.4 mW/g; SAR(10 g) = 5.12 mW/g 0 dB = 11.9mW/g DIGITAL EMC CO., LTD DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:464 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.89 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(6.34, 6.34, 6.34); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM with 835MHz; Type: SAM; Serial: TP-1223 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-10-10; Ambient Temp: 21.3; Tissue Temp: 21.2 Dipole Validation Area Scan (51x101x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.095 dB Peak SAR (extrapolated) = 3.35 W/kg SAR(1 g) = 2.37 mW/g; SAR(10 g) = 1.58 mW/g 0 dB = 2.57mW/g DIGITAL EMC CO., LTD DUT: Dipole 1900 MHz; Type: D1900V2; Serial: D1900V2 - SN:5d029 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.42 mho/m; ε r = 38.8; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(5.27, 5.27, 5.27); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-10-11; Ambient Temp: 21.4; Tissue Temp: 21.3 Dipole Validation Area Scan (51x81x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.031 dB Peak SAR (extrapolated) = 18.2 W/kg SAR(1 g) = 10.3 mW/g; SAR(10 g) = 5.36 mW/g 0 dB = 11.6mW/g DIGITAL EMC CO., LTD DUT: SEC-3189; Type: Express Card Communication System: FCC CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium parameters used: f = 824.7 MHz; σ = 0.982 mho/m; ε r = 54.1; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(6.22, 6.22, 6.22); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM with 835MHz; Type: SAM; Serial: TP-1223 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-09-04; Ambient Temp: 21.3; Tissue Temp: 21.2 19mm from Body, CDMA_Cellular Ch.1013, Ant Horizontal Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Power Drift = 0.140 dB Peak SAR (extrapolated) = 1.32 W/kg SAR(1 g) = 0.904 mW/g; SAR(10 g) = 0.602 mW/g 0 dB = 0.959mW/g DIGITAL EMC CO., LTD DUT: SEC-3189; Type: Express Card Communication System: FCC CDMA; Frequency: 836.52 MHz;Duty Cycle: 1:1 Medium parameters used: f = 836.52 MHz; σ = 0.996 mho/m; ε r = 54; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(6.22, 6.22, 6.22); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM with 835MHz; Type: SAM; Serial: TP-1223 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-09-04; Ambient Temp: 21.3; Tissue Temp: 21.2 19mm from Body, CDMA_Cellular Ch.384, Ant Horizontal Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Power Drift = -0.174 dB Peak SAR (extrapolated) = 1.25 W/kg SAR(1 g) = 0.876 mW/g; SAR(10 g) = 0.580 mW/g 0 dB = 0.949mW/g DIGITAL EMC CO., LTD DUT: SEC-3189; Type: Express Card Communication System: FCC CDMA; Frequency: 848.31 MHz;Duty Cycle: 1:1 Medium parameters used: f = 848.31 MHz; σ = 1.01 mho/m; ε r = 53.9; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1702; ConvF(6.22, 6.22, 6.22); Calibrated: 2007-03-20; Electronics: DAE3 Sn519 Phantom: SAM with 835MHz; Type: SAM; Serial: TP-1223 Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 161 Test Date: 2007-09-04; Ambient Temp: 21.3; Tissue Temp: 21.2 19mm from Body, CDMA_Cellular Ch.777, Ant Horizontal Area Scan (51x81x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Power Drift = -0.269 dB Peak SAR (extrapolated) = 1.21 W/kg SAR(1 g) = 0.828 mW/g; SAR(10 g) = 0.548 mW/g 0 dB = 0.896mW/g DIGITAL EMC CO., LTD DUT: SEC-3189; Type: Express Card Communication System: FCC CDMA; Frequency: 848.31 MHz;Duty Cycle: 1:1 Medium…

Text truncated - open the document above for the full version.

FCC ID: R2NSEC-3189 ATTACHMENT Te s t P l o t s Te s t P l o t s FCC ID: R2NSEC-3189 1/18 page - Conducted Spurious CDMA Cellular Band Ch. 1013 Te s t P l o t s FCC ID: R2NSEC-3189 2/18 page - Conducted Spurious CDMA Cellular Band Ch. 0384 Te s t P l o t s FCC ID: R2NSEC-3189 3/18 page - Conducted Spurious CDMA Cellular Band Ch. 0777 Te s t P l o t s FCC ID: R2NSEC-3189 4/18 page - Power Out. CDMA Cellular Band Ch. 1013 Te s t P l o t s FCC ID: R2NSEC-3189 5/18 page - Power Out. CDMA Cellular Band Ch. 0384 Te s t P l o t s FCC ID: R2NSEC-3189 6/18 page - Power Out. CDMA Cellular Band Ch. 0777 Te s t P l o t s FCC ID: R2NSEC-3189 7/18 page - Occupied Bandwidth. CDMA Cellular Band Ch. 0384 - Channel Power. CDMA Cellular Band Ch. 0384 Te s t P l o t s FCC ID: R2NSEC-3189 8/18 page - Band Edge. CDMA Cellular Ban…
