R2NSWR-8225WiMAX Mobile Hostpot Router

Page 1 / 15 WiMAX Mobile Router 04272010 S S W W R R ‐ ‐ 8 8 2 2 2 2 5 5 U U S S E E R R M M A A N N U U A A L L EPIVALLEY Page 2 / 15 WiMAX Mobile Router 04272010 WiMAX Mobile Hotspot Router WiMAX Mobile Hotspot Guide Version 04.27.2010 Table of Contents The Browser Interface and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 WiMAX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Local Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Network Address Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Multi SSID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Secure Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Trusted MAC Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Firewall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Port Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 VPN Passthrough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Traffic Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Port Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 DMZ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Backup & Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Power Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Factory Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Page 3 / 15 WiMAX Mobile Router 04272010 Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 The Browser Interface and Settings Open your Web browser and enter http://192.168.5.1/or http://wimax_ap.hotspot/ into the address window. The browser interface will open. Your WiMAX and WiFi use a browser interface to configure the device. The browser interface lets you:  View the status of aspects of your network.  Set up DHCP, WEP or WPA security, MAC filtering, port filtering, port forwarding, DMZ, and VPN pass through.  Set up a hotspot to allow a maximum of 255 connections to your device without having to share your network name and network key. Menu Bar Page 4 / 15 WiMAX Mobile Router 04272010 Home The Home screen is the first screen you see after logging in to the browser interface. It is the main point of entry for all your work in the browser interface. The menu bar runs horizontally along the top of the browser interface. It shows WiFi embedded devices are connected. It also displays information about your device’s connection strength and battery level. WiMAX The WiMAX menu allows you to set your authentication or WiMAX auto connection option. It also provides internet connection information as well and traffic counters.  Status The WiMAX status screen is divided into two sections. The Connection Informations section also displays the following information:  Duration of the current connection.  The device’s IP address and subnet mask.  Gateways IP address.  Primary, secondary DNS server’s IP address. Click Connect to connect to your 3G network. It will not normally require any additional configuration to the basic settings unless you are using the device behind a corporate firewall, and this may require the appropriate proxy server settings to be modified. Page 5 / 15 WiMAX Mobile Router 04272010 The Usage Informations section displays the following:  Total duration of connection  Total data bytes sent and received, total data packets sent and received.  Max uplink(UP) speed and downlink(DN) speed. This section displays a count for the current session.  Configurations The Conf…

Text truncated - open the document above for the full version.

EpiValley Co., Ltd. Lordland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sungnam City, Kyunggi-Do, Korea Date: April 14, 2010 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Harvey sung Director REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

EpiValley Co., Ltd. Lordland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sungnam City, Kyunggi-Do, Korea Date: April 14, 2010 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize Harvey Sung of DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: R2NSWR-8225 including signing of all documents relating to these matters. Any and all acts carried out by DIGITAL EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from EpiValley Co., Ltd. Sincerely, Woo Won Choung Principal Engineer

FCCID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 1 FCCID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 2 FCCID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 3 FCCID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 4

FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, Including interference that may cause undesired operations

FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 1 FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 2 FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 3 FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 4 - WIMAX Antenna - WLAN Antenna FCC ID: R2NSWR-8225 Copyright Ⓒ 2010, DIGITAL EMC Co., Ltd. View 5

Antenna Space/Distance 1. Antenna-to-Edges - Top Edge : 5.75mm 5.75 - Bottom Edge : 69.7mm 69.7 Left Edge : 3.8mm 3.8 - Right Edge : 3.8mm 3.8 3.8 2. Antenna-to-surface - Upper Surface : 2.68mm 2.68 - Rear Surface : 1.9mm 1.9 3. Antenna-to-Antenna : 21.7mm 21.7

REMARK CUSTOMER 검 토 승 인담 당 Rev. No.R01 IN-WFSEV055 MAKER/업체명 승 인 원 Model명SWR-8225 CODE No. 품 명WIFI Ant 규 격 MAXWAVE i 양산승인 한정승인 배포부서 ■ 구 매 ■ 품 질 ■ 생 산 □ 조립업체 ■ 연 구 소 ■ 제조기술 ■ 공급업체 □ 기 타 2010 년 5 월 6 일 PROVIDER 담 당 검 토 승 인 품 질 부품개발 CONSENT 양산승인 한정승인 1 1. 기술적 사항 -----------------------------------------3 전기적 사양 기구적 사양 포장사양 2. 시험조건 ------------------------------------------- -4 시험환경 조건 시험장비 3. 전기적 요구사항 -------------------------------------- -5 단말기 정재파비 복사패턴 안테나 이득 4. 전기적 시험결과 -------------------------------------- -6 V.S.W.R 방사패턴 5. 기구적 요구사항 -------------------------------------- -10 4.1 1.2 목 차 1.1 2.2 1.3 3.1 3.3 3.2 2.1 4.2 기구 신뢰성 환경 신뢰성 6. 기구적 시험결과 -------------------------------------- -11 7. 승인도 --------------------------------------------- -14 8. Part List -------------------------------------------- -15 9. Lot No. 표기방법 ------------------------------------- -15 10. 안테나 검사 지그 정재파비(VSWR)및 CPK Data관리공정도 --- 16 11. 사용상 주의사항 ------------------------------------- -17 기구 신뢰성 환경 신뢰성 12. 관리공정도 ----------------------------------------- -18 13. 유해물질 성적서 ------------------------------------- -19 11.1 5.1 5.2 11.2 2 1. 기술적 사항 1.1 전기적 사양 1.2 기구적 사양 2.72 : 1 -11.10 -7.78 -11.40 2480㎒ 3.24 : 1 -12.10 -10.40 -13.20 수직 무지향성 커넥터 전장 CONTACT TYPE 도면참조 E2-Plane 공칭 임피던스 2400㎒ 주파수 대역 ( Frequency Range) 이득 (Gain) 50Ω 편파 복사패턴 H-Plane 단말기 정재파비 (V.S.W.R) EI-Plane 1.3 포장사양 form패드 25TRAY / 1BOX(1,750EA) 1EA / 1BOX 70EA / 1TRAYPS 품명비고 트레이 종이 동작온도 중량 -40°C ~ +80°C 1.3±0.2g 7.6 참조 재질수량 포장 박스 LOT-NO 표기 3 2. 시험조건 2.1 시험환경 조건 전기, 기구적 및 환경시험은 표준상태를 기준으로 전처리 한 후 시험이다. (표준 상태 기준: 20°C, 대기압) - 기구적 시험은 전처리 과정을 1시간으로 한다. - 환경 시험 후 기구적 시험은 전처리 과정을 2시간으로 한다. - 단, 전처리 과정 진행 후 시험 전 이력이 있을 시 전처리 과정을 연장한다. 2.2 시험장비 하는 목적으로 시험품 을 처리한다. 전처리의 목적은 시험전 이력의 영향을 제거하거나 또는 부정적으로 중화하거나 표준상태란 15~20°C와 상대습도 25~80%, 기압 86~160Kpa 의미하며, 장비명사용내용비고 네트웍 아날라이저 안테나의 정재파비 및 임피던 스 측정 표준(혼) 안테나 GSM/DCS/PCS대역에서의 기준 설정 염수 분무 시험기 염수 분무 테스트용 항온 항습기 고온고습 테스트용 안테나 이득 측정케이블, 커넥터 구비요 낙하시험기 낙하 테스트용시험지그(단말기)으로 할 것 버니어캐리퍼스 및 공구현미경 치수 측정용 전파 무반사실 4 3.. 전기적 요구사항 3.1 정재파비 안테나는 전기적 사양에 명시되어 있는 정재파비 요구사항을 만족 해야 한다. 2400㎒ 1.56 : 1 2480㎒ 1.83 : 1 주파수 대역 ( Frequency Ran ge) 단말기 정재파비 (V.S.W.R) <그림3.1Testing with network analyzer> 3.2 복사패턴 이 안테나의 복사 패턴은 수직면에서 무 지향성 패턴을 가져야 한다. 3.3 안테나이득 되어야 한다. 안테나의 Gain과 효율성을 실험하기 위해 셋트에 조립되어야 하며, 완전히 조립되고 작동하는 VI3핸드폰에서 테스트 되어져야 한다. 안테나는 무 반향실의 free space 에서 H,E1,E2 플랜에 의해 테스트가 실시되어야 한다. 안테나 지향성도는 전달/수용 밴드(transmit and receive bands) 중앙에서 측정 < 그림 3.2 Geometry for SER-8189 for radiation patterns > < 그림 3.1 Testing with network analyzer > +x + y + H E E Thet Ph 5 4. 전기적 시험 결과 4.1.1 IN Put Return Loss(반사손실) 및 V.S.W.R. 측정 데이터 6 4.2 방사 패턴 4.2.1 WIFI BAND (H-plane) -18.04 -10.70 2432 Mhz-6.31 -15.25 -9.74 2464 Mhz-7.23 -25.71 -10.80 2480 Mhz-7.92 -25.16 -12.10 2400 Mhz-7.93 -32.04 -11.10 2416 Mhz-7.61 MinAvg 2448 Mhz-10.07 -22.18 -13.60 < Phone mounted typical measurements> FrequencyMax 7 4.2.2 WIFI BAND (E1-plane) 2480 Mhz-7.03 -13.76 -10.40 2464 Mhz-6.17 -12.73 -8.66 2448 Mhz-9.36 -15.41 -11.20 2432 Mhz-5.36 -12.50 -7.56 2416 Mhz-5.58 -14.11 -8.49 2400 Mhz-3.95 -10.80 -7.78 FrequencyMaxMinAvg < Phone mounted typical measurements> 8 4.2.3 WIFI BAND (E2-plane) < Phone mounted typical measurements> FrequencyMaxMinAvg 2400 Mhz-7.78 -22.35 -11.40 2416 Mhz-8.39 -22.67 -11.60 2432 Mhz-8.25 -16.02 -11.70 -18.41 -14.60 2464 Mhz-9.00 -17.44 -11.60 2448 Mhz 2480 Mhz-10.27 -19.53 -13.20 -11.54 9 5. 기구적 요구사항 3염수분무 시험 ① 염수농도 5%, 35±2도, 72Hr 시 험 기구 및 전기적 특성 만족할 것 2고온고습 ① 온도 : 80°C ② 상대습도 : 80±5% ③ 시험시간 : 96시간 기구 및 전기적 특성 만족할 것 1낙하시험 ① 가로/세로 1,000mm, 두께 20mm 철판 기구 및 전기적 특성 만족할 것 5.2 환경 신뢰성 NO신뢰성 항 목검사 방법 판정 기준 2 외관 치수 해당사양 사내 승인도면 또는 고객 의 최종 승인원을 만족할 것 개별사양 및 좌동에 준함 NO 5.1 기구 신뢰성 판정 기준 1외관 및 구조 육안으로 확인하여 해당사양과 일 치하는지 여부 확인 해당사양과 일치할 것 신뢰성 항 목검사 방법 10 6. 기구적 시험 결과 낙하시험 시 험 항 목 시 험 방 법 안테나를 낙하시험지그(단말기)에 장착 후 1.5M 높이에서 가로 1,000㎜, 세로 1,000㎜, 두께20㎜ 철판에 떨어드린다. 낙하는 단말기 각 면2회 시험 후 기구적 특성 및 전기적 요구 사항을 만족 해야 한다 요 구 사 항 기구 및 전기적 특성 만족할 것 시 험 조 건 OK OK OK OK 5 OK OK OK OK OK OK OK 4 OK OK OK OK OK OK OK 3 OK OK OK OK OK OK OK 2 OK OK OK OK OK1 OK OK OK OK OK Before After Before After Before AfterBefore After Before After Before After Before After 결과 V.S.W.R/ 외관 이상없을 것 주파수 2400 Mhz 시 험 D A T A 시료 NO Spec. (V.S.W.R.) 2480 Mhz 검사항목 3.5 : 1 이하 4.1 : 1 이하 11 시 험 결 과 시험 전시험 후 시 험 방 법 안테나를 t1=20°C 온도의 신뢰성 측정 챔버에 놓는다. 1시간동안 상대습 도 80±5%, 온도 t2=+80°C로 증가시키고, 96시간 동안 측정한다. - 테스트가 완료된 후 : 외관적으로 손상이 없어야 하며 기구적으로 작동 을 하여야 한다. 요 구 사 항 기구 및 전기적 특성 만족할 것 시 험 항 목 고온/고습 시험 OK OK5 OK 4 OK OK OK OK OK OK OK OK OK OK 3 OK OK OK OK 2 OK OK OK OK 시료 NO OK 1 OK OK OK Before After Before AfterBefore After Before After Before AfterAfter Spec. (V.S.W.R.) 시 험 조 건 시 험 D A T A 결과 Before 3.5 : 1 이하 4.1 : 1 이하 주파수 2400 Mhz 2480 Mhz 검사항목 V.S.W.R/ 외관 이상없을 것 Before After 12 시 험 결 과 시료 1시료 2 시료 3 시료 4 시 험 방 법 안테나를 온도 +35°C, 염수농도 5%의 염수 분무 조건의 장비 안에서 72 시간 테스트를 진행한다. 테스트 진행 후, 외관 상 이상이 없어야 하고, 시험 후 측정하는 동안 전기 적 요구사항을 만족해야 한다 요 구 사 항 기구 및 전기적 특성 만족할 것 시 험 항 목 염수분무 시험 시료 5 OK OK OK OK 5 OK OK OK OK OK OK OK 4 OK OK OK OK OK OK OK 3 OK OK OK OK OK OK OK 2 OK OK OK OK Before After 1 OK OK OK OK OK OK Before After Before AfterBefore After Before AfterBefore After Before After Spec. (V.S.W.R.) 3.5 : 1 이하 4.1 : 1 이하 시 험 D A T A 시료 NO 검사항목 결과 V.S.W.R/ 외관 이상없을 것 주파수 2400 Mhz 시 험 장 비 2480 Mhz 13 7. 승인도 14 8. Part List 9. Lot No. 표기방법 당사에서 제조된 "내장형 안테나" 제품에 대한 고유번호, 생산 년월, 일련 번호별 생산 로트 순으로 다음과 같은 방법으로 부여한다. 여기서 일련번호 네 자리는 10진수로 표기한다. FINISH 후가공 신한테크 NAME 부품명 COLOR 색상 FACTORY 가공업체 (조립) METHOD 가공방법 FINISH 후가공업체 METERIAL 원료명 (사양) MATERIAL 원료업체 QTY 개수 비고 신규유무 프레스--1PATTERN STS301 대한STSilver유 15 10. 안테나 검사 지그 정재파비(VSWR)및 CPK Data 16 11. 사용상 주의사항 11.1 보관 11.1.1 보관조건 1 11.2 운반 이 중요합니다. 그런 경우 contact부 반응을 저하시키고 불량 접촉의 원인이 됩니다. 안테나는 contact부와 접촉하고 있기 때문에, contact부를 구부리거나 누르지 않는 것 안테나를 조심스럽게 운반하여야 하며, 구부러짐과 손상은 안테나 작동상의 문제를 초래할 수 있습니다. 맨손으로 직접 제품을 만지는 것을 삼가시기 바랍니다. 이는 안테나 위에 지문을 남길 것이며, 손의 산 성분이 안테나의 변색을 초래할 것입 니다. 이는 안테나 성능에 영향을 미치지는 않으나 부품 외관상의 문제를 초래합니 다 제품을 부식성의 가스(황화수소, 아황산, 염소, 암모니아 등)과 같은 것에서 떨어 진 곳에 보관하십시오. 산은 금속 안테나의 부식과…

Text truncated - open the document above for the full version.

1008-00774 DRTFCC1009-0196 TRF-RF-303(03)100616 Page2 / 35 Copyright ○ C 2010, Digital EMC Co., Ltd. CONTENTS 1. General Information ....................................................................... 5 1.1 Equipment information ................................................................ 5 2. INTROCUCTION/SAR DEFINITION ............................................... 5 2.1 SAR Definition ............................................................................. 5 3. SAR MEASUREMENT SETUP ....................................................... 6 3.1Robotic System ........................................................................... 6 3.2 System Hardware ...................................................................... 6 3.3 System Electronics .................................................................... 6 3.4Probe Measurement System ...................................................... 7 3.5 Probe Specifications .................................................................. 7 4. Probe Calibration Process ............................................................ 8 4.1Dosimetric Assessment Procedure ............................................. 8 4.2Free Space Assessment ............................................................. 8 4.3 Temperature Assessment * ........................................................ 8 5. PHANTOM & EQUIVALENT TISSUES ........................................... 9 5.1SAM Phantom ............................................................................. 9 5.2 Brain & Muscle Simulating Mixture Characterization ................. 9 5.3Device Holder for Transmitters ................................................... 9 6. TEST SYSTEM SPECIFICATIONS ............................................... 10 6.1Automated Test System Specifications ..................................... 10 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ................... 11 7.1 Measurement Procedure ......................................................... 11 7.2 Specific Anthropomorphic Mannequin (SAM) Specifications ... 11 8. DEFINITION OF REFERENCE POINTS ....................................... 12 8.1 EAR Reference Point ............................................................... 12 8.2 Handset Reference Points ....................................................... 12 9. DESCRIPTION OF SUPPORTED UNITS ..................................... 13 1008-00774 DRTFCC1009-0196 TRF-RF-303(03)100616 Page3 / 35 Copyright ○ C 2010, Digital EMC Co., Ltd. 10. TEST SETUP AND TEST SINGAL DETAIL ................................ 14 12. TEST CONFIGURATION POSITIONS ........................................ 19 12.1 The exterior of the device ...................................................... 19 12.2 The following test configurations have been applied in this test report(only WiMAX): ....................................................................... 20 13. ANSI / IEEE C95.1-1992 RF EXPOSURE LIMITS ...................... 21 13.1 Uncontrolled Environment ...................................................... 21 13.2 Controlled Environment ......................................................... 21 14. IEEE P1528 –MEASUREMENT UNCERTAINTIES .................... 22 15. SYSTEM VERIFICATION ............................................................ 23 15.1 Tissue Verification .................................................................. 23 15.2 Test System Validation ........................................................... 23 16DESCRIPTION OF TEST MODE AND SUMMARY OF RESULTS 24 16.1 DESCRIPTION OF TEST MODE ........................................... 24 16.2 SUMMARY OF TEST RESULTS (Actual measured SAR) ..... 24 17. SCALING VALUE OF SAR ......................................................... 25 17.1 SUMMARY OF TEST RESULTS (Scaling SAR) .................... 25 18. POWER TABLE .......................................................................... 26 18.1WiMAX Max. Power Output Table for SWR-8225 (W/ USB Cable) 26 18.2 WiMAX Conducted Power Test Setup Diagram ..................... 26 19.Multiple TRANSMITTERS SAR CONSIDERATIONS ................. 27 19.1 Introduction ............................................................................ 27 19.2 Output Power Thresholds for Unlicensed Transmitters .......... 27 19.3 Multiple Antenna Transmission Information for SWR-8225 ... 27 19.3.1 The closest separation distance between WiMAX and W-LAN antennas ....................................................................................... 27 19.3.2 W-LAN Max. Power Output Table for SWR-8225 (W/ USB Cable) 27 19.4 Summary of SAR Evaluation Requirements for Cell phones with MultipleTransmitters ....................................................................... 28 20. Configuring 802.11 a/b/g Transmitters for SAR Measurement29 1008-00774 DRTFCC1009-0196 TRF-RF-303(03)100616 Page4 / 35 Copyright ○ C 2010, Digital EMC Co., Ltd. 20.1 SAR Testing with IEEE 802.11 a/b/g Transmitters ................. 29 20.2 General Device Setup ............................................................ 29 20.3 Frequency Channel Configurations ....................................... 29 21. SAR TEST DATA SUMMARY ..................................................... 30 22.Linearity response & Scan resolution check ........................... 32 22.1 Linearity response check: ...................................................... 32 22.2 Compare with different scan grid size .................................... 32 23. SAR TEST EQUOPMENT ........................................................... 33 24.CONCLUSION .............................................................................. 34 25. REFERENCES ............................................................................ 35 1008- TRF-R 1. G 1.1 FCC E Equip Equip Equip Modu Duple Equip TX Fr RX Fr Max. 2. IN In 1 (NIR), Congr In co develo spons chara on bi o scient At th the I n IRPA/ forms magn inclu d A glo 2.1 Spe…

Text truncated - open the document above for the full version.

DIGITAL EMC CO., LTD DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:726 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 2.09 mho/m; ε r = 53.3; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 Dipole Validation Area Scan (51x71x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.053 dB Peak SAR (extrapolated) = 26.5 W/kg SAR(1 g) = 12.6 mW/g; SAR(10 g) = 5.84 mW/g 0 dB = 18.0mW/g DIGITAL EMC CO., LTD DUT: Dipole 2600 MHz; Type: D2600V2; Serial: D2600V2 - SN:1016 Communication System: CW; Frequency: 2600 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2600 MHz; σ = 2.16 mho/m; ε r = 53.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.25, 7.25, 7.25); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-14; Ambient Temp: 22.5; Tissue Temp: 23.0 Dipole Validation Area Scan (51x71x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.059 dB Peak SAR (extrapolated) = 30.3 W/kg SAR(1 g) = 13.9 mW/g; SAR(10 g) = 6.1 mW/g 0 dB = 16.0mW/g DIGITAL EMC CO., LTD DUT: SWR-8225; Type: USB Modem Communication System: W-LAN; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.99 mho/m; ε r = 53; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 1cm space from Body, Top, W-LAN(802.11b) Ch. Low(2412 MHz), Ant Internal Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.295 dB Peak SAR (extrapolated) = 0.065 W/kg SAR(1 g) = 0.037 mW/g; SAR(10 g) = 0.022 mW/g 0 dB = 0.048mW/g DIGITAL EMC CO., LTD DUT: SWR-8225; Type: USB Modem Communication System: W-LAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 2 mho/m; ε r = 53.1; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 1cm space from Body, Top, W-LAN(802.11b) Ch. Mid(2437 MHz), Ant Internal Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = 0.041 dB Peak SAR (extrapolated) = 0.085 W/kg SAR(1 g) = 0.040 mW/g; SAR(10 g) = 0.020 mW/g 0 dB = 0.056mW/g DIGITAL EMC CO., LTD DUT: SWR-8225; Type: USB Modem Communication System: W-LAN; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 2.11 mho/m; ε r = 53.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 1cm space from Body, Top, W-LAN(802.11b) Ch. High(2462 MHz), Ant Internal Area Scan (121x161x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.109 dB Peak SAR (extrapolated) = 0.012 W/kg SAR(1 g) = 0.00559 mW/g; SAR(10 g) = 0.00242 mW/g 0 dB = 0.011mW/g DIGITAL EMC CO., LTD DUT: SWR-8225; Type: USB Modem Communication System: W-LAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 2 mho/m; ε r = 53.1; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 1cm space from Body, Bottom, W-LAN(802.11b) Ch. Mid(2437 MHz), Ant Internal Area Scan (101x111x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.107 dB Peak SAR (extrapolated) = 0.014 W/kg SAR(1 g) = 0.00271 mW/g; SAR(10 g) = 0.0012 mW/g 0 dB = 0.010mW/g DIGITAL EMC CO., LTD DUT: SWR-8225; Type: USB Modem Communication System: W-LAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 2 mho/m; ε r = 53.1; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: Probe: EX3DV4 - SN3643; ConvF(7.41, 7.41, 7.41); Calibrated: 2010-01-26; Electronics: DAE3 Sn520 Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1224 Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Test Date: 2010-09-03; Ambient Temp: 22.0; Tissue Temp: 22.5 1cm space from Body, Horizontal Up, W-LAN(802.11b) Ch. Mid(2437 MHz), Ant Internal Front/Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = -0.003 dB Peak SAR (extrapolated) = 0.030 W/kg SAR(1 g) = 0.011 mW/g; SAR(10 g) = 0.00846 mW/g 0 dB = 0.014mW/g …

Text truncated - open the document above for the full version.

DRTFCC1005-0054(10041614801 ) TRF-RF-201(01)100216 Page 1 of 90 Copyright ○ c 2010, DIGITAL EMC Co., Ltd. DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE EpiValley Co., Ltd. Lordland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Sunganam-City, Kyunggi-Do, Korea Dates of Tests: May 03 ~ 10, 2010 Test Report S/N:DRTFCC1005-0054 Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT Purpose : Original Grant FCC Equipment Class : Digital Transmission System (DTS) Device name : WiMAX Mobile Hostpot Router Manufacturer : Epivalley Co., Ltd. FCC ID : R2NSWR-8225 Model name : SWR-8225 Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15.247 Subpart C ANS…
