FCC ID: R2NSXT-2080 Protocol Reversion Number: 6 Max Conducted Output PWR of various operation modes of SXT-2080 Conducted Output Power(dBm) Radio Configuration Service Option Low Channel(1013) 824.70MHz Mid Channel(384) 836.52MHz High Channel(777) 848.31MHz SO2(Loopback) 25.11 25.34 25.21 SO3(Voice) 25.20 25.37 25.30 F1R1 SO55(Loopback) 25.19 25.40 25.29 SO9(Loopback) 25.12 25.39 25.22 F2R2 SO55(Loopback) 25.18 25.40 25.24 9.6 Kbps 25.16 25.37 25.20 19.2 Kbps 25.13 25.46 25.25 38.4 Kbps 25.14 25.45 25.29 76.8 Kbps 25.10 25.38 25.18 SO2 (Loopback) 153.6 Kbps 25.15 25.44 25.28 9.6 Kbps 25.19 25.41 25.25 19.2 Kbps 25.08 25.45 25.29 38.4 Kbps 25.11 25.46 25.30 76.8 Kbps 25.14 25.45 25.29 SO3 (Voice) 153.6 Kbps 25.32 25.58 25.42 9.6 Kbps 25.20 25.37 25.29 19.2 Kbps 25.15 25.39 25.18 38.4 Kbps 25.20 25.40 25.29 76.8 Kbps 25.12 25.37 25.18 F3R3 SO55 (Loopback) 153.6 Kbps 25.20 25.46 25.21 FCC ID: R2NSXT-2080 Protocol Reversion Number: 6 Max Conducted Output PWR of various operation modes of SXT-2080 ( Continued..) Conducted Output Power(dBm) Radio Configuration Service Option Low Channel(1013) 824.70MHz Mid Channel(384) 836.52MHz High Channel(777) 848.31MHz 9.6 Kbps 25.12 25.39 25.22 19.2 Kbps 25.18 25.40 25.24 38.4 Kbps 25.16 25.37 25.20 76.8 Kbps 25.13 25.46 25.25 SO2 (Loopback) 153.6 Kbps 25.14 25.45 25.29 9.6 Kbps 25.14 25.45 25.29 19.2 Kbps 25.12 25.34 25.30 38.4 Kbps 25.26 25.53 25.40 76.8 Kbps 25.15 25.39 25.18 SO3 (Voice) 153.6 Kbps 25.20 25.40 25.29 9.6 Kbps 25.26 25.51 25.37 19.2 Kbps 25.08 25.45 25.29 38.4 Kbps 25.29 25.54 25.41 76.8 Kbps 25.14 25.45 25.29 F4R3 SO55 (Loopback) 153.6 Kbps 25.12 25.34 25.30 FCC ID: R2NSXT-2080 Protocol Reversion Number: 6 Max Conducted Output PWR of various operation modes of SXT-2080 ( Continued..) Conducted Output Power(dBm) Radio Configuration Service Option Low Channel(1013) 824.70MHz Mid Channel(384) 836.52MHz High Channel(777) 848.31MHz 14.4 Kbps 25.14 25.45 25.29 28.8 Kbps 25.12 25.34 25.30 57.6 Kbps 25.26 25.53 25.40 115.2 Kbps 25.15 25.39 25.18 SO9 (Loopback) 230.4 Kbps 25.20 25.40 25.29 14.4 Kbps 25.20 25.37 25.30 28.8 Kbps 25.19 25.40 25.29 57.6 Kbps 25.12 25.39 25.22 115.2 Kbps 25.18 25.40 25.24 F5R4 SO55 (Loopback) 230.4 Kbps 25.16 25.37 25.20

FCC ID: R2NSXT-2080 TEST PLOTS FCC ID: R2NSXT-2080 Conducted Spurious CDMA Ch. 1013 FCC ID: R2NSXT-2080 Conducted Spurious CDMA Ch. 0384 FCC ID: R2NSXT-2080 Conducted Spurious CDMA Ch. 0777 FCC ID: R2NSXT-2080 Power Out. CDMA Ch. 1013 Power Out. CDMA Ch. 0777 FCC ID: R2NSXT-2080 Power Out. CDMA Ch. 0384 Channel Power. CDMA Ch. 0384 FCC ID: R2NSXT-2080 Occupied Bandwidth. CDMA Ch. 0384 FCC ID: R2NSXT-2080 Band Edge. CDMA Ch. 1013 Band Edge. CDMA Ch. 0777

Applicant : SUNGIL. FCC ID : R2NSXT-2080 TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this WLL phone. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments.

FCC ID: R2NSXT-2080 MPE Calculations The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 25.58 dBm + 3.25 dBi EIRP = 28.83 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 π) S = (361.41 * 2.11) / (4 * 20 2 * π) S = 0.152 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm) Conclusion: The Maximum permissible exposure (MPE) for the general Population/Uncontrolled is 0.55 mW/cm 2 (=f/1500=824/1500).The power density at 20cm does not exceed the 0.55 mW/cm 2 . Therefore, the exposure condition of the EUT is compliant with FCC rules. Estimated safe separation: R = √(PG / 4π) R = √(361.41 * 2.11 / 4π) R = 7.80 cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (3.25 / 10) G = 2.11

DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 1 of 19 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification Dates of Tests: November 18 ~24, 2005 Test Report S/N:DR50110511J Test Site : DIGITAL EMC CO., LTD. Model No. APPLICANT Classification : Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s) : §22(H), §2 EUT Type : CDMA 2000 1x WLL Terminal Model name : SXT-2080 Serial number : Identical prototype TX Frequency Range : 824.70 ~848.31 MHz (CDMA) RX Frequency Range : 869.70 ~893.31 MHz (CDMA) Max. RF Output Power : 0.520W ERP CDMA (27.16 dBm) Emission Designators: : 1M28F9W Date of Issue : November 25, 2005 R2NSXP-2080 SUNGIL TELECOM CO., LTD. DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 2 of 19 TABLE OF CONTENTS ◈ AUTHORIZATION LETTER ◈ CONFIDENTIALITY LETTER(S) ◈ TEST REPORT 1.1 SCOPE 3 2.1 GENERAL INFORMATION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6 5.1 TEST DATA 9 5.2 EFFECTIVE RADIATED POWER OUTPUT 9 5.3 CDMA RADIATED MEASUREMENTS 10 5.4 FREQUENCY STABILITY(CDAM) 13 6.1 PLOTS OF EMISSIONS 15 7.1 LIST OF TEST EQUIPMENT 16 8.1 SAMPLE CALCULATIONS 18 9.1 CONCLUSION 19 ◈ TEST PLOTS ◈ FCC ID LABEL & LOCATION ◈ TEST SETUP PHOTOGRAPHS ◈ EXTERNAL PHOTOGRAPHS ◈ INTERNAL PHOTOGRAPHS ◈ BLOCK DIAGRAM(S) ◈ SCHEMATIC DIAGRAM(S) ◈ OPERATIONAL DESCRIPTION ◈ PARTS LI S T ◈ USER’S MANUAL ◈ ANTENNA SPECIFICATION ◈ MPE CALCULATION ◈ TUNE UP PROCEDURE DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 3 of 19 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information z FCC ID: z Quantity: z Emission Designators: z Tx Freq. Range: z Rx Freq. Range: z Max. Power Rating: z FCC Classification(s): z Equipment (EUT) Type: z Modulation(s): z Frequency Tolerance: z FCC Rule Part(s): z Dates of Tests: z Place of Tests: z Test Report S/N: R2NSXT-2080 Quantity production is planned 1M28F9W (CDMA) 824.70 ~848.31 MHz (CDMA) 869.70 - 893.31 MHz (CDMA) 0.520W ERP CDMA (27.16 dBm) Licensed Non-Broadcast Station Transmitter (TNB) CDMA 2000 1x WLL Terminal CDMA ± 0.00025 % (2.5ppm) §22(H), §2 November 18 ~ 24, 2005 DIGITAL EMC DR50110511J Applicant: SUNGIL TELECOM CO., LTD. Address: Lordland EZ Tower #511, 153, Gumi-Dong, Bundang-Gu, SEONGNAMCITY, GYUNGGI, KOREA Attention: Woo Won Choung DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 4 of 19 2.1. General Information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer November 25, 2005 Won-Jung LEE Data Name Signature Report Reviewed By: manager November 25, 2005 Harvey Sung Data Name Signature Ordering party: Company name : SUNGIL TELECOM CO., LTD. Address : Roadland EZ Tower #511, 513, Gumi-dong, Bundang-Gu, Zipcode : 463-500 City/town : SEONGNAM-CITY, KYUNGGI Country : KOREA Date of order : October 15, 2005 DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 5 of 19 3.1 INSERTS Function of Active Devices (Confidential) The Function of active devices are shown in Attachment K. Block & Schematic Diagrams (Confidential) The block diagrams are shown in Attachment I, and the schematic diagrams are shown in Attachment J. Operating Instructions The instruction manual is shown in Attachment M. Parts List & Tune-Up Procedure (Confidential) The parts list & tune-up procedure is shown in Attachment L. Description of Freq. Stabilization Circuit (Confidential) The description of frequency stabilization circuit is shown in Attachment K. Description for Suppression of Spurious Radiation, for Limiting Modulation, and Harmonic Suppresion Circuits (Confidential) The description of suppression stabilization circuits is shown in Attachment K. DEMC#DR50110511J Copyright ○ c 2005, DIGITAL EMC Co., Ltd. Page 6 of 19 4.1 DESCRIPTION OF TESTS 4.2 Occupied Bandwidth Emission Limits (a) On any frequency outside a licensee’s frequency block, the power of any emission shall be attenuated below the transmitter power (P) by at least 43 + 10 log(P) dB. (b) When measuring the emission limits, the nominal carrier frequency shall be adjusted as close to the licensee’s frequency block edges, both upper and lower, as the design permits. (c) The measurement of emission power can be expressed in peak or average values, provided they are expressed in the same parameters as the transmitter power. 4.3 Occupied Bandwidth The 99% power bandwidth was measured with a calibrated spectrum analyzer. 4.4 Spurious and Harmonic Emissions at Antenna Terminal The level of the carrier and the various conducted spurious and harmonic frequencies is measured by means of a calibrated spectrum analyzer. The spectrum is scanned from the lowest frequency generated in the equipment up to 10 GHz. At the input terminals of the spectrum analyzer, an isolator(RF circulator with on port terminated with 50ohms) and an 870 MHz to 890 MHz bandpass filter is connected between the test transceiver(for conducted tests)or the receive antenna(for radiated tests) and the analyzer . The rejection of the bandpass filter to signals in the 825-845 MHz range is adequate to limit the transmit energy from the test transceiver which appears to a level which will allow the analyzer to measure signals less than-90dBm. Calibration of the test receiver is pe…
