R3X0010819168Remoter for Wireless Remoter Switch

BATTERY INFORMATION AND REPLACEMENT: 1. On the bottom of the remote use your finger to depress the tab to slide out the battery holder. 2. Remove the used battery and insert a new CR2032 Lithium 3-volt battery with the “+” polarity mark facing up. 3. Slide the battery holder back inside so that the tab sets in place. 4. Dispose of old battery properly. WARNING: Keep batteries away from children and pets. Follow the battery manufacturer’s safety and usage instructions. • Remove battery if product is to be left unused for a long time. • Clean the battery contacts prior to battery installation. • Do not dispose batteries in fire. Batteries may explode or leak. Notice: Functional Range may be adversely affected by one or more of the following factors: Orientation of the transmitter or receiver, weather, radio frequency interference, low transmitter battery and obstructions between the transmitter and receiver. NOTE: In case of a power failure, the system will need to be reset . ATTENTION: INSTRUCTIONS FOR PROPER USE • FULLY EXTEND CORD BEFORE USING • USE WITHIN THE ELECTRICAL RATING MARKED ON THE CORD SET • RATED 125 VOLTS • Unplug when not in use (grasp plug, not cord, to unplug from outlet) • Inspect periodically • Do not splice, repair or modify cord set • Do not walk or drive on cord set • Suitable for use with outdoor appliances - store indoors when not in use • Suitable for damp location • Do not use as permanent source of power • When used outdoors, plug into a GFCI protected receptacle. Receptacle should be mounted in an approved “weatherproof while in use” type outlet box. Install according to all applicable local areas. • Do not expose directly to water - rain tight • Do not plug one extension cord into another • Install the cord and unit above ground level at least 5 ft. (1.5m) with receptacles (outlets) facing downward. CAUTION • Risk of Fire. • DO NOT PLUG IN MORE THAN THE RATED LOAD. • This is a Radio Frequency (RF) Device. Therefore the range of the transmitter is affected by obstructions, walls and other electronic devices. WARNING: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment . The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment . NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FRONT A5 5.8 in H x 8.3 in W BACK A5 5.8 in H x 8.3 in W 2 Outlet Outdoor Remote Control Instructions with Countdown Timer Function ITEM NO: 58373 Specifications a. Receiver: 125VAC, 60Hz, 8A 1000W Tungsten with 2 Grounded Outlets and 6 in. (15.2 cm) 18AWG SJTW Power Cord. b. Transmitter: 433MHz, remote range up to 80 ft. (24.3 m) using (1) CR2032 Lithium 3-volt battery (included). Operation a. ON/OFF Remote Control Note: When the receiver is fully inserted into a working outlet, its red indicator light will come on showing power to the unit. Press: ON: Receiver is power ON continuously. “ON” appears on the LCD display. OFF: Receiver is power OFF instantly. “OF” appears on the LCD display. b. Remote Countdown Press: 2Hr, 4Hr, 6Hr or 8Hr: Receiver instant on and then off after completing the selected countdown hours. Notes: 1. Setting the countdown hours may be done with the receivers ON. 2. The remaining countdown hours for the receiver will be shown on the LCD display. The countdown symbol at the top of “Hr” flashes to indicate the countdown is in progress. “ON” shows that power is on. After the countdown is finished, the power to the outlet goes off with “OF” displayed. 3. Pressing the remote ON or OFF button cancels the current countdown operation with power to the outlet remaining continuously on or off. c. Repeat function This function repeats the last countdown operation the same time everyday. Press: REPEAT ON: Do this during or after the countdown operation. “RPT” appears on the LCD display above “ON”. Once the current countdown operation is finished the countdown hours and RPT remain on the LCD display. Notes: 1. To cancel the repeat operation, press REPEAT OFF. “RPT” will disappear. If in the off status, the countdown operation hours will also disappear. 2. Pressing the remote ON or OFF button cancels the current day’s countdown operation with power to the outlet remaining continuously on or off. This will not interfere the next day’s repeat operation. 3. Setting a new countdown operation cancels the current day’s repeated countdown operation. Power output will be ON or OFF as the new operation. This will not interfere the next da…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Shenzhen Chuangjiexing Electronics Ltd. 2010-08-05 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, __ Shenzhen Chuangjiexing Electronics Ltd._ hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Remoter for Wireless Remoter Switch We affirm that between SIEMIC and __ Shenzhen Chuangjiexing Electronics Ltd. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: William Huo/ General Manager Contact information / address: 5/F Bldg. A5 Laodong 1ST Industrial Zone, Xixiang, BaoAn, Shenzhen, China

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Shenzhen Chuangjiexing Electronics Ltd. 2010-08-05 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: R3X0010819168 We hereby request confidential treatment of information accompanying this application as outlined below: - Schematics - Block Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: William Huo/ General Manager Contact information / address: 5/F Bldg. A5 Laodong 1ST Industrial Zone, Xixiang, BaoAn, Shenzhen, China

Note: Their electrical circuit design, PCB layout, components, internal wiring and model number are identical, only the appearance and crust’s colour is different.

Label Location

Global United Technology Server Co., Ltd. 环球众一科技有限公司 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Email: [email protected] Report No.: GTSE10070012101 Page: 1 of 19 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS International Electrical Approvals or testing done by GTS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by GTS International Electrical Approvals in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover PageFCC REPORT Application No: GTSE100700121RF Applicant: Shenzhen Chuangjiexing Electronics Ltd. Address of Applicant: 5/F Bldg. A5 Laodong 1ST Industrial Zone, Xixiang, BaoAn, Shenzhen, China Equipment Under Test (EUT) EUT Name: Remoter for Wireless Remoter Switch Model No. RT101T Trademark: N/A Operation Frequency: 433.92MHz FCC ID: R3X0010819168 Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231: 2008 Date of Receipt: 27 July, 2010 Date of Test: 28 July to 02 Aug., 2010 Date of Issue: 03 August, 2010 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE10070012101 Page: 2 of 19 2 Contents Page 1 COVER PAGE......................................................................................................................................................... 1 2 CONTENTS.............................................................................................................................................................. 2 3 TEST SUMMARY.................................................................................................................................................... 3 4 GENERAL INFORMATION................................................................................................................................... 4 4.1 CLIENT INFORMATION....................................................................................................................................... 4 4.2 GENERAL DESCRIPTION OF E.U.T................................................................................................................... 4 4.3 E.U.T OPERATION MODE.................................................................................................................................. 5 4.4 TEST FACILITY................................................................................................................................................... 6 4.5 TEST LOCATION................................................................................................................................................ 6 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER.................................................................................. 6 4.7 TEST INSTRUMENTS LIST.................................................................................................................................. 7 5 TEST RESULTS AND MEASUREMENT DATA................................................................................................ 8 5.1 ANTENNA REQUIREMENT:................................................................................................................................. 8 5.2 RADIATED EMISSION......................................................................................................................................... 9 5.2.1 Field Strength Of The Fundamental Signal......................................................................................... 11 5.2.2 Spurious Emissions................................................................................................................................. 14 5.3 20DB BANDWIDTH........................................................................................................................................... 16 5.4 DWELL TIME:................................................................................................................................................... 18 Report No.: GTSE10070012101 Page: 3 of 19 3 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Passed Field strength of the fundamental signal15.231 (b) Passed Spurious emissions 15.231 (b)/15.209 Passed 20dB Bandwidth 15.231 (c) Passed Dwell time 15.231 (a) Passed Remark: Passed: The EUT complies with the essential requirements in the standard. Failed: The EUT does not comply with the essential requirements in the standard. Report No.: GTSE10070012101 Page: 4 of 19 4 General Information 4.1 Client Information Applicant: Shenzhen Chuangjiexing Electronics Ltd. Address of Applicant: 5/F Bldg. A5 Laodong 1ST Industrial Zone, Xixiang, BaoAn, Shenzhen, China Manufacturer/ Factory: Shenzhen Chuangjiexing Electronics Ltd. Address of Manufacturer/ Factory: 5/F Bldg. A5 Laodong 1ST Industrial Zone, Xixiang, BaoAn, Shenzhen, China 4.2 General Description of E.U.T. Product Name: Remoter for Wireless Remoter Switch Model No.: RT…
