R4UARCFLEXHRXIndustrial radio remote control system

Industrial radio remote control system FLEX12HRX FLEX8HRX Instruction Manual Flex 12HRX/8HRX Standard, AB and Tandem Instruction Manual (FCC/CE) September 2016 Page 1 of 43 Service Information Your New Radio Remote Control System Thank you for your purchase of ARC Flex 12HRX/8HRX radio remote control system. Without a doubt, our Flex 12HRX/8HRX system is the ultimate solution for providing precise, undeterred, and safe control of your material. If your product ever needs modification or service, please contact our representative in your country or at the following location: World Headquarter: Advanced Radiotech Corporation No. 3, South 1st Road, Chien Chen District, Kaohsiung City, Taiwan Telephone: +886 7 812 8112 Fax Number: +886 7 812 8119 Website: www.advanced-radiotech.com E-mails: [email protected] [email protected] All rights reserved. This notice applies to all copyrighted materials included with this product, including, but not limited to, this manual and software embodied within the product. This manual is intended for the sole use of the person(s) to whom it was provided, and any unauthorized distribution of the manual or dispersal of its contents is strictly forbidden. This manual may not be reproduced in whole or in part by any means whatsoever without the expressed written permission of ARC. Flex 12HRX/8HRX Standard, AB and Tandem Instruction Manual (FCC/CE) September 2016 Page 2 of 43 PRODUCT MANUAL SAFETY INFORMATION Advanced Radiotech Corporation (ARC) offers a broad range of radio remote control product for material handling applications. This manual has been prepared by ARC to provide information and recommendations for the installation, use, operation and service of ARC’s material handling products and systems (ARC Products). Anyone who uses, operates, maintains, services, installs or owns ARC Products should know, understand, and follow the instructions and safety recommendations in this manual for ARC Products. The recommendations in this manual do not take precedence over any of the following requirements relating to cranes, hoists lifting devices or other material handling equipment which use or include ARC Products: •Instructions, manuals, and safety warnings of the manufacturers of the equipment where the radio system is used. •Plant safety rules and procedures of the employers and the owners of facilities where the ARC Products are being used. •Safety standards and practices for the industries in which ARC Products are used. This manual does not include or address the specific instructions and safety warnings of these manufacturers or any of the other requirements listed above. It is the responsibility of the owners, users and operators of the ARC Products to know, understand and follow all of these requirements. It is the responsibility of the employer to make its employees aware of all of the above listed requirements and to make certain that all operators are properly trained. No one should use ARC Products prior to becoming familiar with and being trained in these requirements and the instructions and safety recommendations in this manual. WARRANTY INFORMATION For information on ARC’s product warranties, please contact ARC representative nearest to you or visit www.advanced-radiotech.com. FCC WARNINGS and CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation of the device. (b) For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: ⚫This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. ⚫Any changes or modifications not expressly approved by the party responsible for compliance Flex 12HRX/8HRX Standard, AB and Tandem Instruction Manual (FCC/CE) September 2016 Page 3 of 43 could void the authority to operate equipment. ⚫This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. ⚫End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. ⚫For product available in the USA/Canada market, only channel 1~141 can be operated. Selection of other channels is not possible Industry Canada ICES-003 Compliance Label: CAN ICES-3 (B)/NMB-3(B) ⚫. Flex 12HRX/8HRX Standard, AB and Tandem Instruction Manual (FCC/CE) September 2016 Page 4 of 43 Table of Contents Page 1. Introduction 5 2. Radio Controlled Safety 6 2.1. CRITICAL INSTALLATION CONSIDERATIONS 7 2.2. GENERAL 7 2.3. PERSONS AUTHORIZED TO OPERATE RADIO CONTROLLED CRANES 7 2.4. SAFETY INFORMATION AND RECOMMENDED TRAINING FOR RADIO CONTROLLED EQUIPMENT OPERATORS 8 2.5. TRANSMITTER UNIT 9 2.6. PR…

Text truncated - open the document above for the full version.

DECLARATION We ADVANCED RADIOTECH CORPORATION No.3, S. 1 st Rd., Chien Chen Dist., Kaohsiung City, Taiwan. declare that the product name: FLEX HRX (RECEIVER) Model name : FLEX 12HRX / FLEX 8HRX (RECEIVER) FCC ID: R4UARCFLEXHRX The device will be a receiver only. No RF function. However, the manufacturer should ensure it cannot be changed and used as a transmitter. This device is designed to be used as a receiver only and hardware disabled to be transmitter when installed into the remote control system Name : TOM JOU Responsibility : President Authorized Signature : Date Place : Nov. 12, 2019 : Taiwan

Page: 1 / 8 Report No.: T190902W05-2 Rev.: 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Receiver: FLEX 12HRX 、FLEX 8HRX Page: 2 / 8 Report No.: T190902W05-2 Rev.: 00 Page: 3 / 8 Report No.: T190902W05-2 Rev.: 00

A A d d v v a a n n c c e e d d R R a a d d i i o o t t e e c c h h C C o o r r p p o o r r a a t t i i o o n n No.3, South 1st Road, Chien Chen District, Kaohsiung City, Taiwan Tel: 886-7-812-8112 Fax: 886-7-812-8119 Email: [email protected] Model: FLEX 8HRX (RX) Model: FLEX 12HRX (RX)

Page: 4 / 8 Report No.: T190902W05-2 Rev.: 00 INTERNAL PHOTOGRAPHS OF EUT Receiver: FLEX 12HRX 、FLEX 8HRX Page: 5 / 8 Report No.: T190902W05-2 Rev.: 00 Page: 6 / 8 Report No.: T190902W05-2 Rev.: 00 Page: 7 / 8 Report No.: T190902W05-2 Rev.: 00 Module Crystal Page: 8 / 8 Report No.: T190902W05-2 Rev.: 00 Antenna

Page: 1 / 21 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 No.163-1, Jhongsheng Road, Xindian District, New Taipei City 23151, Taiwan / 新北市新店區中生路163-1號 t: (886-2) 2217-0894 f:(886-2) 2217-1029 www.sgs.tw www.ccsrf.com FCC TEST REPORT for Industrial radio remote control system MODEL: FLEX 12EPH; FLEX 8EPH; FLEX 12HRX; FLEX 8HRX Issued to: ADVANCED RADIOTECH CORPORATION No. 3, South 1st Road, Chien Chen District, Kaohsiung City, Taiwan Issued by: Compliance Certification Services Inc. Xindian Lab. No.163-1, Jhongsheng Rd., Xindian Dist., New Taipei City, 23151 Taiwan. TEL: 886-2-22170894 FAX: 886-2-22171029 Issued Date: December 3, 2019 Note: This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NIST or any government agencies. Page: 2 / 21 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 December 3, 2019 Initial Issue ALL Amy Wang Page: 3 / 21 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................ 4 2 EUT DESCRIPTION ................................................................................................ 5 3 TEST METHODOLOGY .......................................................................................... 6 3.1. DECISION OF FINAL TEST MODE ........................................................................ 6 3.2. EUT SYSTEM OPERATION ................................................................................... 6 4 SETUP OF EQUIPMENT UNDER TEST ................................................................ 7 4.1. DESCRIPTION OF SUPPORT UNITS .................................................................... 7 4.2. CONFIGURATION OF SYSTEM UNDER TEST ..................................................... 7 5 FACILITIES AND ACCREDITATIONS .................................................................... 8 5.1. FACILITIES ............................................................................................................. 8 5.2. ACCREDITATIONS................................................................................................. 8 5.3. MEASUREMENT UNCERTAINTY .......................................................................... 8 6 CONDUCTED EMISSION MEASUREMENT .......................................................... 9 6.1. LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................ 9 6.2. TEST INSTRUMENTS ............................................................................................ 9 6.3. TEST PROCEDURES ........................................................................................... 10 6.4. TEST SETUP ........................................................................................................ 11 6.5. DATA SAMPLE ..................................................................................................... 11 6.6. TEST RESULTS ................................................................................................... 12 7 RADIATED EMISSION MEASUREMENT ............................................................ 14 7.1. LIMITS OF RADIATED EMISSION MEASUREMENT .......................................... 14 7.2. TEST INSTRUMENTS .......................................................................................... 15 7.3. TEST PROCEDURES ........................................................................................... 16 7.4. TEST SETUP ........................................................................................................ 17 7.5. DATA SAMPLE ..................................................................................................... 18 7.6. TEST RESULTS ................................................................................................... 19 APPENDIX 1 - PHOTOGRAPHS OF THE TEST CONFIGURATION ......................... A1-1 APPENDIX 2 - PHOTOGRAPHS OF EUT .................................................................. A2-1 Page: 4 / 21 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 1 TEST RESULT CERTIFICATION Product: Industrial radio remote control system Model: FLEX 12EPH; FLEX 8EPH; FLEX 12HRX; FLEX 8HRX Brand: ARC Applicant: ADVANCED RADIOTECH CORPORATION No. 3, South 1st Road, Chien Chen District, Kaohsiung City, Taiwan Manufacturer: ADVANCED RADIOTECH CORPORATION No. 3, South 1st Road, Chien Chen District, Kaohsiung City, Taiwan Tested: September 7, 2019 EMISSION Standard Item ResultRemarks FCC 47 CFR Part 15 Subpart B, ICES-003 Issue 6-2016 ANSI C63.4-2014 Conducted (Power Port) PASS Meet Class B limit Radiated PASS Meet Class B limit Statements of Conformity Determination of compliance is based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Page: 5 / 21 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 2 EUT DESCRIPTION Product Industrial radio remote control system Brand Name ARC Model FLEX 12EPH; FLEX 8EPH; FLEX 12HRX; FLEX 8HRX Applicant ADVANCED RADIOTECH CORPORATION Housing material Plastic Identify Number T190902W05 Received Date September 2, 2019 EUT Power Rating TX: 3VDC from Battery RX: 12-24VDC form DC Power Supply DC Power During Test 24VDC Model Differences Model Buttons Size Solid state relays Tested (Check) FLEX 12EPH TX 12 Key 24…

Text truncated - open the document above for the full version.

Page: A1-1 / 2 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 APPENDIX 1 - PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Page: A1-2 / 2 Report No.: T190902W05-F FCC RX ID: R4UARCFLEXHRX Rev.: 00 RADIATED EMISSION TEST
