Responsive Innovations ResponseCard RF User’s Manual RCRF-01 & RRRF-01 User’s Manual Ver. Preliminary REGULATORY INFORMATION FCC Statement This product has been tested and found to comply with Part 15 of the FCC Rules. Operation it subject to the following conditions: it may not cause harmful interference and must be accept interference received, including interference that may cause undesired operations. Changes or modifications not expressly approved by the party responsible fo r compliance could void the user’s authority to operate the equipment. Canada Statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. pressed. Valid keys are ‘0’ through ‘9’. Valid RF Channels are ‘000’ through ‘127’. While in Set RF Channel mode pressing a valid key will cause the status LED to briefly flash YELLOW. When Set RF Channel Mode exits, the status LED indicates the result as follows: SOLID GREEN - Set RF Channel successful SOLID RED - Set RF Channel failed Overview: The RI RF Keypad is designed to be used with the RI RF Receiver connected to a PC. The keypad transmits key presses via radio frequency to the RF receiver for accumulation by the PC. The keypad consists of 12 data keys (0-9, Go/Login, ?) and a single status LED. In Idle state, the LED is OFF. The keypad returns to idle state after completion of a key press. Standard Operation Mode: Initially the status LED is OFF. Pressing a single key will cause the key to be transmitted to the receiver. After pressing a key the status LED shows status as follows: Quick YELLOW Blink then OFF - Receiver is not accepting data at this time BLINKING YELLOW - key is being transmitted (up to 5 seconds) SOLID GREEN - key transmit successful - ready for input SOLID RED - key transmit failed – ready for input BLINKING GREEN - Receiver indicated correct answer BLINKING RED - Receiver indicated incorrect answer Blinking Green and Blinking Red will only occur if the Receiver is configured to indicate a correct or incorrect answer (CO RRECT POLLING mode). Setup Modes: Active at any time the keyboard is ready for input. Match Mode (Check RF connection) Press ‘?’ In order for Match Mode to operate properly an RF Receiver MUST also be placed into Match Mode. Quick YELLOW Blink then OFF - Receiver is not accepting data at this time BLINKING YELLOW - key is being transmitted SOLID GREEN - RF receiver found, but not in Match Mode SOLID RED - Key transmit failed BLINKING GREEN - RF receiver in Match Mode found BLINKING RED - RF receiver found, but not in Match Mode Auto Match Mode (find RF Receiver) Press Go/Login, while holding Go/Login, quickly press and hold ‘?’. Release both keys. In order for Auto Match Mode to operate properly an RF Receiver MUST also be placed into Match Mode, otherwise the keypad will always indicate that Auto Match Mode has failed. BLINKING YELLOW - search is in progress SOLID GREEN - search successful – Match Mode exits SOLID RED - search failed – Match Mode exits Set RF Channel Press GO/LOGIN Set RF Channel mode is indicated by the status LED flashing a RED then GREEN pattern. Set RF Channel mode exits automatically after three valid keys are pressed, if no valid key is pressed for 5 seconds, or at any time an invalid key is

FCC ID: Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Responsive Innovations, LLC, hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Kevin G. Adkins President & CEO Responsive Innovations, LLC

Assembled in Korea FCC ID: R4WRCRF01 P/N : RCRF-01 1.866.746.3105

Page 1 of 31 Engineering Test Report No. 35112-02 Measurement of RF Interference from a Model RCRF-01 Transceiver For : Responsive Innovations Akron, OH P.O. No. : 1037 Date Received : May 16, 2005 Date Tested : May 16, 2005 through May 20, 2005 Test Personnel : Mark E. Longinotti Specification : FCC "Code of Federal Regulations” Title 47 Part 15, Subpart B and Subpart C, Section 15.249 for Intentional Radiators Operating within the 2400-2483.5MHz band Test Report By : Mark E. Longinotti Witnessed by : Kevin G. Adkins Responsive Innovations Approved By : Raymond J. Klouda Registered Professional Engineer of Illinois - 44894 Elite Electronic Engineering Inc. 1516 Centre Circle Downers Grove, IL 60515 Tel : (630) 495-9770 Fax: (630) 495-9785 www.elitetest.com Engineering Test Report No. 35112-02 THIS REPORT SHALL NOT BE REPRODUCED, EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF ELITE ELECTRONIC ENGINEERING INCORPORATED. Page 2 of 31 TABLE OF CONTENTS PARAGRAPH DESCRIPTION OF CONTENTS PAGE NO. 1.0 INTRODUCTION ................................................................................................................................................ 3 1.1 Description of Test Item.................................................................................................................................... 3 1.2 Purpose ............................................................................................................................................................. 3 1.3 Deviations, Additions and Exclusions ............................................................................................................... 3 1.4 Applicable Documents ...................................................................................................................................... 3 1.5 Subcontractor Identification .............................................................................................................................. 3 1.6 Laboratory Conditions..................................................................................................................................... 3 2.0 TEST ITEM SETUP AND OPERATION............................................................................................................. 4 2.1 Power Input...................................................................................................................................................... 4 2.2 Grounding......................................................................................................................................................... 4 2.3 Peripheral Equipment........................................................................................................................................ 4 2.4 Interconnect Cables........................................................................................................................................... 4 2.5 Operational Mode ............................................................................................................................................. 4 2.6 Test Item Modifications................................................................................................................................... 4 3.0 TEST EQUIPMENT............................................................................................................................................. 4 3.1 Test Equipment List .......................................................................................................................................... 4 3.2 Calibration Traceability ................................................................................................................................... 4 3.3 Measurement Uncertainty................................................................................................................................ 4 4.0 REQUIREMENTS, PROCEDURES AND RESULTS.......................................................................................... 5 4.1 Powerline Conducted Emissions ..................................................................................................................... 5 4.1.1 Requirements............................................................................................................................................ 5 4.2 Duty Cycle Factor Measurements .................................................................................................................. 5 4.2.1 Procedures ............................................................................................................................................... 5 4.2.2 Results ..................................................................................................................................................... 5 4.3 Radiated Measurements................................................................................................................................... 5 4.3.1 Requirements............................................................................................................................................ 5 4.3.2 Procedures ................................................................................................................................................ 6 4.3.3 Results ...................................................................................................................................................... 7 4.4 Band Edge Compliance ................................................................................................................................... 7 4.4.1 Requirement ............................................................................................................................................. 7 4.4.2 Procedures ................................................................................................................................................ 7 4.4.3…

Text truncated - open the document above for the full version.

Figure 2 Test Setup for Radiated Emissions – Horizontal Polarization Test Setup for Radiated Emissions – Vertical Polarization
