1 Bluetooth speaker YM-S1 INSTRUCTION MANUAL PLEASE READ ALL INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE USE 2 2 Getting started  Remove the Bluetooth speaker & accessories from the box.  Remove all packaging from the Bluetooth speaker.  Place the packaging inside the box to either store or dispose of safely. In the Box  Bluetooth Speaker  USB Charging Cable  Instruction Manual  Hanger wire  AUX cable Features  With Hanger wire  With Selfie function  Enjoy music by micro sd card or Bluetooth or Aux  Built-in mic for hands free phone calls  Volume Control  Media Control (pause/play, previous track/next track) 3 3 Safety Instructions  Read this manual carefully before putting the appliance into operation and keep this manual for future reference.  Keep the device away from heat, direct sunlight and sharp edges.  Keep the device away from naked flames.  Do not insert any metal object into the device. Risk of short circuit!  To avoid a static charge, do not use the device in an extremely dry climate.  Do not repair the unit yourself but contact an authorized specialist.  Do not submerge in water. 4 4 Description of buttons 1 5 5 2 3 4 5 6 7 6 6 1: Power on/off button, Selfie button 2: Play/pause, phone pick up/hang up button---short press, Long press for “M” function, Transfer micro sd card model & Bluetooth mod or AUX mode 3: Short rotate-PREV, Long Rotate- Volume down 4: Short rotate- NEXT, Long rotate- Volume up 5. Micro sd card 6. Aux jack 7. USB charging jack Charging Instructions This Bluetooth speaker comes with a built in rechargeable battery. Before using it for the first time we recommend you charge the battery fully. 1. Connect the USB cable to the micro USB port on the unit. 2. Connect the other end of the USB cable to a USB port on a PC or an AC/DC adapter. The red LED turns on indicating the battery is being charged. When the battery is fully charged, the LED will turn off. 7 7 Bluetooth pairing 1. Turn on the Bluetooth speaker. 2. Turn on your Bluetooth enabled device and activate the Bluetooth function. 3. Search for the Bluetooth device, “YM-S1” will show up. 4. Pair your Bluetooth enabled device with “YM-S1”. If a password is needed, type in “0000”. After the “YM-S1” is paired with your device, connect it to your device. Tips: Once the speaker is paired and connected to your Bluetooth device, it automatically connects the next time as long as the Bluetooth on your device is on. Selfie function Once the speaker is connect with your mobile phone, you can use it take photos. It is very convenient and popular. Just enjoy it for music and Selfie. 8 8 Specifications Bluetooth version 3.0+EDR Bluetooth profiles HSP, HFP, A2DP and AVRCP Bluetooth range 10 meters (equal to 33 feet) Frequency range 2.402-2.48GHz Audio Output power 3 watts Frequency response 100Hz-20kHz Distortion ≤1% Microphone sensitivity -40db Playback time 4 hours Charging input power DC 5V Charging time Approx 3 hours Unit size 52*30*82 mm Unit weight Approx. 75g Battery Capacity 300mAH Note: Battery life & charging time may vary, based on usage & types of devices used. 9 9 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential 10 10 installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit 11 11 different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. IC Warnings: This device complies with Industry Canada’s licence-exempt RSSs Operation is subject to the following two conditions: (1) This device may not cause interference and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage 12 12 radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

July 08, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: R8HYM-S1_ Product Name: Bluetooth speaker with selfie function Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Linda Zou Position Merchandiser Company Name Shenzhen XinHuaMei Electronics Limited Company Address Bldg 5, Taifeng Industrial Park, No.10, Jianan Road, Shajing Sub- district, Baoan District, Shenzhen, China Tel +86-755-33675121 Fax +86-755-33675299 Email [email protected] FCC ID: R8HYM-S1 Product Name: Bluetooth speaker with selfie function

Label 40mm 25mm Label Here FCC ID: R8HYM-S1 Shenzhen XinHuaMei Electronics Limited Company Model name: Bluetooth speaker with selfie function Model No.: Logiix Blue Piston Nomad (YM-S1)

FCC ID: R8HYM-S1 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances İ50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] g[Ĝf(GHz)] İ3.0 for 1-g SAR and İ7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2441MHz -3.28dBm(0.4706mW) output power] (0.470mW /5mm) g[Ĝ2.441(GHz)]= 0.147 <3.0 for 1-g SAR Then SAR evaluation is not required 0.47 mW) output 0.148
