RAQLYAATwo-way radio

Waterproof Radio Body-Worn Operation To maintain compliances with FCC/Health Canada RF exposure guidelines, if you wear a radio on your body when transmitting, always place the radio in a Olympia-supplied or approved clip, holder, holster, case or body harness for this product. Use of non-Olympia-approved accessories may exceed FCC/Health Canada RF exposure guidelines.If you do not use one of the Olympia-supplied or approved body-worn accessories and are not using the radio held in the normal use position, ensure the radio and its antenna are at least 1 inch (2.5 cm) from your body when transmitting. Electromagnetic Interference/Compatibility Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed or otherwise configured for electromagnetic compatibility. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference; and 2. This device must accept any interference received, including interference that may cause undesired operation. Facilities To avoid electromagnetic interference and/or compatibility conflicts, turn off the radio in any facility where posted notices instruct you to do so. Hospitals, health care facilities or Airports may be using equipment that is sensitive to external RF energy. Aircraft When instructed to do so, turn off the radio when onboard on aircraft. Any use of a radio must be in accordance with applicable regulations per airline crew instructions. Medical Devices – Pacemakers The Advanced Medical Technology Association recommends that a minimum separation of 6 inches (15 cm) be maintained between a handheld wireless radio and a pacemaker. These recommendations are consistent with the independent research by and recommendations of the U.S. Food and Drug Administration. People with pacemakers should: • ALWAYS keep the radio more than 6 inches (15 cm) from their pacemaker when the radio is turned ON. • Not carry the radio in the breast pocket. • Use the ear opposite the pacemaker to minimize the potential for interference. • Turn the radio OFF immediately if there is any reason to suspect that interference is taking place. Medical Devices – Hearing Aids Some digital wireless radios may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives. Medical Devices - Other If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. Safety and General Use While Driving Check the laws and regulations regarding the use of radios in the area where you drive, and always obey them. If you do use the radio while driving, please: • Give full attention to driving and to the road• Use hands-free operation, if available• Pull off the road and park before making or answering a call if driving conditions so require Do not place a portable radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to occupants of the vehicle. Potentially Explosive Atmospheres Turn off the radio prior to entering any area with a potentially explosive atmosphere. Only radio types that are especially qualified should be used in such areas as “Intrinsically Safe.” Do not remove, install or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death. Note: The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles (such as grain, dust or metal powders) and any other area where you would normally be advised to turn off your vehicle engine. Areas with potentially explosive atmospheres are often—but not always—posted. Blasting Caps and Areas To avoid possible interference with blasting operations, turn off the radio when you are near electrical blasting caps, in a blasting area, or in areas posted “Turn off Two-Way radios.” Obey all signs and instructions. Two-Way Radio R100 Series Owner’s Manual Olympia 2-Way radios are intended for recreational (consumer) use only and are not intended for business use. Olympia offers an alternate product designed specifically for business use - Olympia P324 Business radio. See below for contact information. For a list of accessories sold, please contact us. Contact Us For further information, call Giant International Ltd. at 1-866-537-0384, e-mail us at [email protected] or visit us on the Internet at www.olympiaproducts.com Getting Started Waterproof This radio is waterproof to IP-54 standards. It is dust/splashproof from any direction. The radio is resistant to water and rain splashes only when the battery cover, headset accessory and micro-USB ports are sealed. Open the battery compartment door or headset port cover only when the radio is dry. Use of a headset accessory should be in dry environments only. The micro-USB cable and plug is not waterproof. Do not expose the charger to rain or snow. Charge the radios only in a dry location. The battery door must be tightly closed with the screw to maintain the weatherproof seal of the radio. Installing NiMH Rechargeable Battery Pack or AA Alkaline Batteries 1. With the radio off. Ensure that the belt clip is not attached to the radio. 2. With the back of the radio facing you, loosen the retaining screw on the battery door and open the cover. 3. Remove the NiMH battery pack from the clear plastic bag (do not disassemble or unwrap the battery pack) or remove AA batteries from its p…
