RAY-ICN700REMOTE CONTROL TRANSCEIVER

iCN 700 series User Manual English - Europe / New Zealand © 2006 Brunswick New Technologies Asia Pte Limited. Navman is a registered trademark of Brunswick New Technologies Asia Pte Limited and is used under licence by Navman New Zealand. All rights reserved. The software contains proprietary information of Navman; it is provided under a licence agreement containing restrictions on use and disclosure and is also protected by copyright law. Reverse engineering of the software is prohibited. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Navman. Back-On-Track, Drive-Away, NavPix, Smart5 and Turn-by-Turn are either registered trademarks or trademarks of Brunswick New Technologies Asia Pte Limited and are used under licence by Navman New Zealand. All rights reserved. Microsoft Windows 98 SE, ME, 2000 and XP SP1, Microsoft Internet Explorer and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All rights reserved. Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. All rights reserved. Location Identifiers © 2005 International Air Transport Association. All other trademarks and registrations are the property of their respective owners. Published in New Zealand. Disclaimer Due to continued product development this information may change without notice. Navman does not warrant that this document is error-free. The screenshots and other presentations shown in this User Manual may differ from the actual screens and presentations generated by the actual product. All such differences are minor and the actual product will deliver the described functionality as presented in this User Manual in all material respects. Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The software is based in part on the work of the Independent JPEG Group. iCN 700 series | Important safety information 3 Important safety information PLEASE READ CAREFULLY BEFORE INSTALLING PRODUCT IN VEHICLE This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage. Removing original equipment, adding accessories or modifying your vehicle could affect the vehicle’s safety or make it illegal to operate in some jurisdictions. Follow all product instructions and all instructions in your vehicle owner’s manual regarding accessories or modifications. Consult your country’s and/or state’s laws regarding operation of a vehicle with any accessories or modifications. It is your sole responsibility to place, secure and use the iCN in a manner that will not cause accidents, personal injury or property damage. Always observe safe driving practices. Mount the iCN in a position that is secure and does not obstruct the driver’s view. Do not mount the iCN in a way that may interfere with the safe operation of the vehicle, the deployment of air bags or other safety equipment. Do not operate the iCN while driving. Before you use your iCN for the first time, make yourself familiar with your device and its operation. On main roads, the distance to an exit calculated by the iCN may be further than the distance shown on road signs. Road signs show the distance to the start of an exit while your iCN shows the distance to the next intersection, i.e., the end of the exit ramp or road. To prepare to exit a road, always follow distance information on road signs. iCN 700 series | Important safety information 4 Do not handle the iCN while it is hot. Let the product cool, out of direct sunlight. Do not expose the iCN to direct sunlight in an unattended vehicle for prolonged periods. Overheating may damage the unit. To discourage theft, do not leave the iCN, mounting bracket or any cables in plain view in an unattended vehicle. Failure to adhere to these warnings and cautions may lead to death, serious injury or property damage. Navman disclaims all liability for installation or use of the iCN that causes or contributes to death, injury or property damage or that violates any law. iCN 700 series | Contents 5 Contents Important safety information...................................................................................................................3 Welcome................................................................................................................................................7 Box contents .....................................................................................................................................8 Typographical conventions ...............................................................................................................9 Getting to know your iCN ................................................................................................................10 Front components.......................................................................................................................10 Side components........................................................................................................................11 Top component…

Text truncated - open the document above for the full version.

8 Appendix 1 [continued] Section A4 Casing material and shape Case Material: Plastic and Metal panels EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 22 of 32 This report may not be reproduced except in full 9. PHOTOGRAPHS External views iCN750 iCN720 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 23 of 32 This report may not be reproduced except in full


               !"
# $

  %&  !'(!
) RevDateDescriptionCR No. A20/01/2006 1st Issue NOT TO SCALE SHEET 1 OF 1 Serial Number Label, Cook iCN720 This document contains confidential and proprietary information and rights that belongs to Navman NZ Ltd. Using, or permitting the use of, any of the information contained herein, copying or imaging all or part of this document by any means, or permitting any such copying or imaging, or disclosing, or permitting the disclosure of,any of its content to third parties is strictly forbidden without express written consent of NAVMAN NZ Ltd. © Copyright 2004 Navman NZ Ltd LB00XXXX-GAA4 Jon O'Brien DO NOT SCALE DRAWING Newton Auckland New Zealand Navman NZ 7-21 Kawana St. Northcote PO Box 68 155 Rev Title: Draw n By: Size:Part Number:   &(*+
))),#+ +  *)   ! &
)-"

9 Appendix 1 [continued] Section A5 Type and length of wiring looms Not applicable. Section A6 Identification of components EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 24 of 32 This report may not be reproduced except in full Internal views – iCN720 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 25 of 32 This report may not be reproduced except in full EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 26 of 32 This report may not be reproduced except in full Internal views – iCN750 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 27 of 32 This report may not be reproduced except in full EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 28 of 32 This report may not be reproduced except in full Items common to both iCN720 and iCN750 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 29 of 32 This report may not be reproduced except in full 10 GPS Antenna GPS Receiver Module

iCN 700 Product type and general commercial description Navman's iCN700 Series is a GPS (Global Positioning System) in vehicle road navigation device with 2D and/or 3D (dimensional) map display and turn by turn visual and voice instructions. The iCN700 Series is supplied with windscreen mount hardware and a 12Vdc cigarette lighter plug supply. The internals are quite similar to a PDA product with more peripheral such as a camera and GPS receiver. This design is based around the PXA270 processor from Intel. The basis of this is that geographical road maps are store on the CF/HDD mass storage and then displayed on the colour TFT LCD. The GPS receiver which has an antenna in the flap allows the unit to display the correct position of the unit and subsequently the user on the map. This is also combined with street and location names thus allowing the user to program in a location that they would like to navigate to. The unit then calculates a route (dependent on user settings - highway usage, toll road usage, keep out areas etc) then displays the direction to travel and gives visual and audio turning directions as the user progresses along the route. There are of course many other sub functionalities such as the ability to receive traffic information via a serial connection to a separate module, take pictures, display points of interest (PIs) such as parking, petrol stations, hospital, restaurants, tourist attractions etc and of course display the lat log location and satellite information. Most of these features and peripherals can be reached by either hot keys on the unit or by navigating through the menu via the touch screen. The unit will also be available with an RF remote control for controlling volume and brightness and basic navigation operations. This can be mounted nearby on the steering wheel for user convenience. Other accessories include Car and Mains adapters, USB cable and External GPS Antenna. RF Remote Product type and general commercial description The remote will be sold as an accessory with the iCN720 and iCN750 products. It may also be used with future products. It is a simple RF remote transmitting at 2.4GHz using a simple protocol. Its button functions are: • Cancel route • Route to Home • Volume Control • Brightness Control • Mute • Change view mode The remote is powered by two CR2025 or CR2032 3volt lithium batteries and will come with a small cradle that can be strapped to the steering wheel of a car for convenience of the driver.

2 Product type and general commercial descriptions Navman's iCN700 Series is a GPS (Global Positioning System) in vehicle road navigation device with 2D and/or 3D (dimensional) map display and turn by turn visual and voice instructions. The iCN700 Series is supplied with windscreen mount hardware and a 12Vdc cigarette lighter plug supply. See Appendix 1 for further variant information.. Name and address of manufacturer Navman NZ Limited, 17 Kawana St, North Shore, Auckland, New Zealand Location and method of affixing the EEC approval mark The EEC approval mark will be affixed to the main body of the unit Addresses of assembly plants Group Sense PDA Ltd Cai Wu Industrial Park, Wusha Chang An, Donguan, P.R.C. Tel: (0769) 554 6828 ESA comment The ESA shall be approved as a component. Any restrictions of use and conditions of fitting 3 Appendix 1 Section A1 ESA types, variants and labeling The electronic sub-assemblies for the iCN700 Series product are the following: - • iCN700 Series System Board • 1803 GPS Module • 3.7V 1890mA/hr Li-ion rechargeable battery • LCD screen – Samsung LTP400WQ-F01 4” TFT • Speaker 4O 1W • Camera module 1.3Mp • Seagate Hard Drive 4Gig • GPS Antenna flag • iCN700Series will be imprinted on the front panel of all units. The units in this series will be technically and functionally identical although carry differing sub designations iCN7?? (for example iCN720, iCN750) depending on a couple of features that will be listed in a table at the end of this document. 11 Appendix 1 [continued] Section A7 Details of filters, screening to improve EMC performance The following circuit design principles and components were used to minimize EMI on the iCN700: - • Slowest clock rate and risetime for acceptable performance. • All components used are surface mount components and IC sockets were avoided. • Multiple RF bypass capacitors were used on all power supply pins. • Solid power and ground planes were used on the PCB. • High speed tracks were buried inside the board. • The address, data and high-speed control lines were implemented as transmission lines and terminated with the characteristics impedance. • RF beads, low pass filters and overvoltage transient protection components protected external I/O lines. The length of cables and connectors was minimized. EMI shielding was achieved in the iCN700 by the following measures: - • Vias were used to stitch the top and bottom layer ground planes together on PCB. • Shield cans were used to cover potential EMC producing components. EMI reduction techniques used in the iCN700 PCB design include: - • Multi layer PCB used. • Multiple power supply bypass capacitors. Pre-compliance testing to CE and e-Mark standards performed prior to product qualifications. 12 Appendix 1 [continued] Section A8 Clock frequencies 1803 GPS Module Clocks TCXO Frequency 24.5535 MHz First LO 1565.97 MHz Receiver Frequency 1575.42 MHz (commonly referred to as L1) 1 st IF 9.45 MHz Real Time Clock crystal 32.768 KHz. iCN700 Series System Board Clocks Microprocessor Frequency 312MHz SDRAM Clock Frequency 104MHz Base Clock Frequency 13MHz Audio Codec 24. 576MHz USB Crystal 30MHz RTC 32.768KHz DOT_CLK 9MHz. Section A9 Differences between ICN720 and ICN750 iCN720 iCN750 Labels ICN720 ICN750 Mass Storage CF card Hard drive Battery 1350mAh 1890mAh USB 2.0 No (only USB 1.1) Yes

iCN 700 series | Reference 120 Specifications Specifications General Operating voltage: DC5V Operating voltage range: DC10.8–16.0V Maximum operation current: 2.5A Grounding system: car battery negative pole AC Adapter Operating voltage range: AC85-265V Maximum operation current: 2.5A Car adapter Operating voltage: DC12V Operating voltage range: DC8–24V Maximum operation current: 2.5A TFT Monitor Screen diagonal: 4 inches (105mm) Usable display area: 87.84mm (W) x 49.8mm (H) Resolution: WQVGA 480 (W) x 272 (H) pixels Brightness: 180cd/m (centre brightness after 30 minutes) Top viewing angle: 58° Bottom viewing angle: 52° Horizontal viewing angle: +66° Dimensions Dimensions: 136mm (W) x 77mm (H) x 31mm (D) Net weight: 300g Remote Control Frequency range: 2.4 – 2.483GHz Nominal output power: 0 dBm Modulation: FSK Camera Effective Pixels: 1.3 M Resolution: 1304 x 968 SXGA Aperture range: F 4.9mm Battery Capacity: 1350mAH Type: Lithium-ion Hardware Processor: Intel PXA270 416Mhz RAM: 64MB ROM: 64MB HDD: 4GB (iCN750) Internal CF card: 512MB (iCN720) SD/MMC Memory Expansion Environment Operating temperature: -10°C–+60°C Storage temperature: -30°C–+70°C Operating humidity: 45%–80% RH Storage humidity: 30%–90% RH EMC: e-Mark, FCC, CE, C Tick, RSS-210 Operating shock: 4G Non-operating shock: 75G

1 iCN700 Series FCC List of contents Page / section Contents Page 1 Make [Trade name of manufacturer] Page 2 Product type and general commercial descriptions Page 2 Name and address of manufacturer Page 2 Location and method of affixing the EEC approval mark Page 2 Addresses of assembly plants Page 2 ESA comment Page 2 Any restrictions of use and conditions of fitting Page 2 Appendix 1 ESA types, variants and labeling Section A1 Rated voltage and grounding/polarity requirements Section A2 Circuit / block diagrams, and PCB layout Section A3 Casing material and shape Section A4 Type and length of wiring loom Section A5 Identification of component Section A6 Details of filters, screening to improve EMC performance Section A7 Clock frequencies Section A8 Differences between ICN720 and ICN750 Section A9 Make [Trade name of manufacturer] Navman NZ Limited 2 Product type and general commercial descriptions Navman's iCN700 Series is a GPS (Global Positioning System) in vehicle road navigation device with 2D and/or 3D (dimensional) map display and turn by turn visual and voice instructions. The iCN700 Series is supplied with windscreen mount hardware and a 12Vdc cigarette lighter plug supply. See Appendix 1 for further variant information.. Name and address of manufacturer Navman NZ Limited, 17 Kawana St, North Shore, Auckland, New Zealand Location and method of affixing the EEC approval mark The EEC approval mark will be affixed to the main body of the unit Addresses of assembly plants Group Sense PDA Ltd Cai Wu Industrial Park, Wusha Chang An, Donguan, P.R.C. Tel: (0769) 554 6828 ESA comment The ESA shall be approved as a component. Any restrictions of use and conditions of fitting 3 Appendix 1 Section A1 ESA types, variants and labeling The electronic sub-assemblies for the iCN700 Series product are the following: - • iCN700 Series System Board • 1803 GPS Module • 3.7V 1890mA/hr Li-ion rechargeable battery • LCD screen – Samsung LTP400WQ-F01 4” TFT • Speaker 4O 1W • Camera module 1.3Mp • Seagate Hard Drive 4Gig • GPS Antenna flag • iCN700Series will be imprinted on the front panel of all units. The units in this series will be technically and functionally identical although carry differing sub designations iCN7?? (for example iCN720, iCN750) depending on a couple of features that will be listed in a table at the end of this document. 4 • Appendix 1 [continued] Section A 2 Rated voltage and grounding/polarity requirements Cigarette lighter plug +12Vdc +12 Vdc input +5Vdc output,2.5A +- DC Plug Polarity DC plug CB269B-G Car Adaptor iCN Series T1/P1 Series 5 Appendix 1 [continued] Section A3 Circuit / block diagrams, and PCB layouts 6 Layout PCB, Topview 7 PCB, bottom 8 Appendix 1 [continued] Section A4 Casing material and shape Case Material: Plastic and Metal panels 9 Appendix 1 [continued] Section A5 Type and length of wiring looms Not applicable. Section A6 Identification of components 10 GPS Antenna GPS Receiver Module 11 Appendix 1 [continued] Section A7 Details of filters, screening to improve EMC performance The following circuit design principles and components were used to minimize EMI on the iCN700: - • Slowest clock rate and risetime for acceptable performance. • All components used are surface mount components and IC sockets were avoided. • Multiple RF bypass capacitors were used on all power supply pins. • Solid power and ground planes were used on the PCB. • High speed tracks were buried inside the board. • The address, data and high-speed control lines were implemented as transmission lines and terminated with the characteristics impedance. • RF beads, low pass filters and overvoltage transient protection components protected external I/O lines. The length of cables and connectors was minimized. EMI shielding was achieved in the iCN700 by the following measures: - • Vias were used to stitch the top and bottom layer ground planes together on PCB. • Shield cans were used to cover potential EMC producing components. EMI reduction techniques used in the iCN700 PCB design include: - • Multi layer PCB used. • Multiple power supply bypass capacitors. Pre-compliance testing to CE and e-Mark standards performed prior to product qualifications. 12 Appendix 1 [continued] Section A8 Clock frequencies 1803 GPS Module Clocks TCXO Frequency 24.5535 MHz First LO 1565.97 MHz Receiver Frequency 1575.42 MHz (commonly referred to as L1) 1 st IF 9.45 MHz Real Time Clock crystal 32.768 KHz. iCN700 Series System Board Clocks Microprocessor Frequency 312MHz SDRAM Clock Frequency 104MHz Base Clock Frequency 13MHz Audio Codec 24. 576MHz USB Crystal 30MHz RTC 32.768KHz DOT_CLK 9MHz. Section A9 Differences between ICN720 and ICN750 iCN720 iCN750 Labels ICN720 ICN750 Mass Storage CF card Hard drive Battery 1350mAh 1890mAh USB 2.0 No (only USB 1.1) Yes

iCN 720 / 750 Test Procedure The above mentioned devices were testing in accordance with FCC part 15 section 15.249. To assist with this testing reference was made to ANSI C63.4, 2003. The devices are short range transmitters operating in the range 2400 – 2483.5 MHz. Normal operations mean that the transmitter only transmits an acknowledgement signal to remote control transmitters once the remote transmitter has interrogated the iCN device. In order to test the FSK signal from the device the client enabled the transmitters to transmit almost continuously using a test programme which also enabled the changing of the operating frequency to one of the 6 programmed channels. Testing was carried out at the open area test site using a measuring receiver, spectrum analyser and various antennas where applicable. Where possible all emission measurements were made at a distance of 3 metres however this distance was reduced to 1 metre in order to determine whether any of the transmitter spurious emissions could be detected. Testing was also carried out in standby mode, transmitter turned off, with the iCN devices being powered at either 12 Vdc or 110 Vac with various ancillary items attached as this device can operate in a number of different modes.

EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 1 of 32 This report may not be reproduced except in full TEST REPORT Navman iCN720 / iCN750 2.4GHz Remote Control Transceiver tested to the Code of Federal Regulations (CFR) 47 Part 15 – Radio Frequency Devices, Subpart C – Intentional Radiators Section 15.249 – Operation in the band 2400 – 2483.5 MHz for Navman New Zealand This Test Report is issued with the authority of: ________________________________________ Andrew Cutler - General Manager EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 2 of 32 This report may not be reproduced except in full Table of Contents 1. CLIENT INFORMATION 3 2. DESCRIPTION OF TEST SAMPLE 3 3. SUMMARY OF TEST RESULTS 4 4. TEST SAMPLE DESCRIPTION 5 5. ATTESTATION 6 6. TRANSMITTER TEST RESULTS 7 7. TEST EQUIPMENT USED 21 8. ACCREDITATIONS 21 9. PHOTOGRAPHS 22 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 3 of 32 This report may not be reproduced except in full 1. CLIENT INFORMATION Company Name Navman New Zealand Address PO Box 68-155 Newton City Auckland Country New Zealand Contact Mr Dominic Cranfield 2. DESCRIPTION OF TEST SAMPLE Brand Name Navman Model Number iCN 720 / iCN 750 Product 2.4GHz Remote Control Transceiver Manufacturer Navman New Zealand Country of Origin New Zealand FCC ID RAY-ICN700 Sample Details Unit Serial No. PCB Firmware iCN750 BD01-QA3-0198 QA3 V4.00.0012 iCN720 BD00-QA3-0217 QA3 V4.00.0012 EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 4 of 32 This report may not be reproduced except in full 3. COMPLIANCE STATEMENT The Navman iCN 720 / iCN 750 2.4GHz Remote Control Transceiver complies with 47 CFR Part 15 and in particular Sections, 15.205, 15.207, 15.209, 15.215 and 15.249 as detailed below. CLAUSE TEST PERFORMED RESULT 15.109 Radiated emission limits Complies 15.203 Antenna requirement Complies 15.205 Operation in restricted bands Complies 15.207 Conducted emissions Complies 15.209 Radiated emissions Complies 15.215 Additional provisions Complies 15.249: (a) Field strength of fundamental Complies (a) Field strength of harmonics Complies (b) Fixed, point to point operations Not applicable (c) 3 metre measurement distance Noted (d) Spurious emission levels except harmonics Complies (e) Detectors above 1000 MHz Noted (f) Reference to section 15.37(d) Noted EMC Technologies (NZ) Ltd Test Report No 60224.3 Report date: 14 th March 2006 ____________________________________________________________________________________________________________________________________________________________________________ EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au Page 5 of 32 This report may not be reproduced except in full 4. TEST SAMP…
