RAYVHFNRS2MARINE BLACK BOX DSC/AIS VHF RADIO SYSTEM

RS100/RS100-B V100/V100-B USER MANUAL ENGLISH www.simrad-yachting.com | www.bandg.com RS100/RS100-B V100/V100-B Preface Disclaimer As Navico is continuously improving this product, we retain the right to make changes to the product at any time which may not be reflected in this version of the manual. Please contact your nearest distributor if you require any further assistance. It is the owner’s sole responsibility to install and use the equipment in a manner that is legal and will not cause accidents, personal injury or property damage. The user of this product is solely responsible for observing safe boating practices. NAVICO HOLDING AS AND ITS SUBSIDIARIES, BRANCHES AND AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY VIOLATE THE LAW. Governing Language This statement, any instruction manuals, user guides and other information relating to the product (Documentation) may be translated to, or has been translated from, another language (Translation). In the event of any conflict between any Translation of the Documentation, the English language version of the Documentation will be the official version of the Documentation. This manual represents the product as at the time of creation. Navico Holding AS and its subsidiaries, branches and affiliates reserve the right to make changes to specifications without notice. Continuous improvement: Software updates applied to the radio may not be reflected in this manual. Copyright Copyright © 2020 Navico Holding AS. Warranty The warranty card is supplied as a separate document. In case of any queries, refer to the brand website of your unit or system: • www.simrad-yachting.com • www.bandg.com About this manual This manual is a reference guide for installing and operating the RS100, RS100-B, V100, V100-B Blackbox VHF radio systems. Important text that requires special attention from the reader is emphasized as follows: ¼Note: Used to draw the reader’s attention to a comment or some important information. ⚠Warning: Used when it is necessary to warn personnel that they should proceed carefully to prevent risk of injury and/or damage to equipment/personnel. Blackbox VHF radio system This manual covers the following products and components: SIMRAD® RS100 Blackbox VHF Radio System • NRS-1 Marine VHF Radio Processor • HS100 Wired Handset SIMRAD • SP100 Wired Speaker SIMRAD® RS100-B Blackbox VHF & AIS Radio System • NRS-2 Marine VHF Radio & AIS Class-B Processor • HS100 Wired Handset SIMRAD® • SP100 Wired Speaker | 3 Preface | RS100 / RS100-B / V100 / V100-B User Manual B&G® V100 Blackbox VHF Radio System • NRS-1 Marine VHF Radio Processor • H100 Wired Handset B&G® • SP100 Wired Speaker B&G® V100-B Blackbox VHF + AIS Radio System • NRS-2 Marine VHF Radio & AIS Class-B Processor • H100 Wired Handset B&G® • SP100 Wired Speaker Optional components Wireless Handset SIMRAD (HS40) Wireless Handset B&G (H60) Wireless Antenna Extension cable, 6 meters (CW100-6) Handset Cable, 20 meters (CH100-20) Handset Extension cable, 10 meters Licensing information • The user is advised to check the radio operating licensing requirements of their country before using this VHF radio. The operator is solely responsible for observing proper radio installation and usage practices. • In some regions/countries, a Radio Operator’s license is required and it is the user’s responsibility to determine whether such a license is required before operating the radio. • The frequencies used by this radio are reserved for Maritime use only and those frequencies must be included on the user’s Radio Operator’s license. • A valid USER MMSI number must be entered into this radio before DSC functions can be used. You must apply for an MMSI number which is usually obtained from the same authority that issues the Radio Operator’s license. Contact the appropriate licensing authority in your country. If you’re unsure who to contact, consult your Simrad or B&G dealers. • A valid ATIS ID number must be entered into this radio before ATIS functions can be used. An ATIS ID number is issued by Ofcom when you add one or more pieces of ATIS equipment to your Ship Radio License. Important information • This VHF Blackbox radio system is designed to generate a digital maritime distress call to facilitate search and rescue. To be effective as a safety device, this radio must be used only within the geographic range of a shore-based VHF marine Channel 70 distress and safety watch system. The geographic range may vary but under normal conditions is approximately 20 nautical miles. • This radio can be configured to operate in the user’s region and country of operation. The user must select the region and country of operation during the initial setup of the radio. Refer to “Country Settings table” on page 94 for details of supported Region and Countries. • The radio’s region and country setting can be changed at any time from the Reset menu. Refer to “Reset” on page 35 for more details. Regulatory compliance statements European Union Navico declare under our sole responsibility that the RS100, RS100-B, V100, and V100-B conforms with the requirements of Directive 2014/53/EU (RED). HS40 and H60 Wired Handset complies with CE under EMC Directive 2014/30/EU. The relevant Declaration of conformity is available in the product’s section at the following website: • www.navico-commercial.com 4 | Preface | RS100 / RS100-B / V100 / V100-B User Manual EU RF exposure compliance notice for fixed mount VHF To be protected against all verified adverse effects, the separation distance of at least 2.1 m must be maintained between the antenna of the radio having max. 6 dBi antenna and all persons. Countries of intended use in the EU AUT - AustriaBEL - BelgiumBGR - BulgariaCHE - Switzerland CYP - CyprusCZE - Czech Republic DEU - GermanyDNK - Denmark EST - EstoniaESP - Spain FIN - FinlandFRA - France GRC - GreeceHRV - CroatiaHUN - HungaryIRL - Ireland ISL - IcelandITA -…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 External Photos for SZEM2007006018CR FCC ID: RAYVHFNRS2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 EUT Constructional Details Wifi Antenna GNSS Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 VHF Antenna Port WiFi Port AIS Antenna Port SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

Label of NRS-2 （top of the blackbox） （back of the blackbox） （side of the blackbox）

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 7 Internal Photos for SZEM2007006018CR FCC ID: RAYVHFNRS2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 7 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 7 GNSS module WiFi module SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 7 VHF/DSC Board SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 7 AIS Tx Board SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 7

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700601801 Page: 1 of 15 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2007006018CR Applicant: Navico Inc. Address of Applicant: 4500 S. 129th East Avenue, Ste. 200, Tulsa, Oklahoma, 74134 United States Manufacturer: Navico Auckland Limited Address of Manufacturer: Arrenway Drive, Rosedale, Auckland, 0632 New Zealand Factory: Shenzhen Fastrain Technology Co., Ltd. Address of Factory: No.3 Baolong 4th Rd., Baolong Industrial Area, Longgang District, Shenzhen, China Equipment Under Test (EUT): EUT Name: MARINE BLACK BOX DSC/AIS VHF RADIO SYSTEM Model No.: NRS-2 Trade Mark: NAVICO Standard(s) : 47 CFR Part 15, Subpart B Date of Receipt: 2020-07-03 Date of Test: 2020-07-31 to 2020-09-04 Date of Issue: 2020-09-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700601801 Page: 2 of 15 Revision Record Version Chapter Date Modifier Remark 01 2020-09-18 Original Authorized for issue by: Edison Li /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700601801 Page: 3 of 15 2 Test Summary Emission Part Item Standard Method Requirement Result Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (above 1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Internal Source Upper Frequency Below 1.705MHz 30MHz 1.705MHz to 108MHz 1GHz 108MHz to 500MHz 2GHz 500MHz to 1GHz 5GHz Above 1GHz 5th harmonic of the highest frequency or 40GHz, whichever is lower SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700601801 Page: 4 of 15 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 5 4.1 DETAILS OF E.U.T. ......................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 4.4 TEST LOCATION ............................................................................................................................. 6 4.5 TEST FACILITY ............................................................................................................................... 6 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 6 5 EQUIPMENT LIST ............................................................................................................................... 7 6 EMISSION TEST RESULTS................................................................................................................. 8 6.1 RADIATED EMISSIONS (30MHZ-1GHZ) ............................................................................................. 8 6.1.1 E.U.T. Operation ...................................................................................................................... 8 6.1.2 Test Setup Diagram ................................................................................................................. 8 6.1.3 Measurement Data................................................................................................................... 8 6.2 RADIATED EMISSIONS (ABOVE 1GHZ) ..............................................................................................11 6.2.1 E.U.T. Operation .....................................................................................................................11 6.2.2 Test Setup Diagram ................................................................................................................11 6.2.3 Measurement Data..................................................................................................................11 7 PHOTOGRAPHS ................................................................................................................................14 7.1 RADIATED EMISSIONS (30MHZ-1GHZ) ............................................................................................14 7.2 RADIATED EMISSIONS (ABOVE 1GHZ) ..............................................................................................14 7.3 EUT CONSTRUCTIONAL DETAILS (EUT PHOTOS) .............................................................................15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700601801 Page: 5 of 15 4 General Information 4.1 Details of E.U.T. Power Supply: 12 VDC battery system Cable: DC cable: longer than 300cm unshielded Sample Type: Mobile device Internal Source: More than 108MHz 4.2 Description of Support Units Description Manufacturer Model No. Serial No. DC power ZHAOXIN RXN-305D REF. No.SEA2700 Coaxial Attenuator Provided by client TS4 HYT168793 Cell Site Test Set HP 8921A 3633A04615 Audio Analyzer Rohde & Schwarz UPV SEM008-03 Wired Handset SIMRAD HS100 / Wired Speaker / SP100 / Wired Handset B&G H100 / Wired Speaker / SP100 / 4.3 Measu…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 2 Setup Photos for SZEM2007006018CR FCC ID: RAYVHFNRS2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 2 1 Photographs 1.1 Radiated Emissions Test Setup
