RC6-APL5XX2x2 11ax WIFI AP

Quick Installation Guide Step 5 Access Point Setup Open a web browser on your computer. In the address bar of the web browser, enter 192.168.1.254 and enter. A login screen will appear. By default, the username of the Access Point is admin and the password is admin. Enter the current username and password of the Access Point and then click Login. (Username: admin, Password: admin) TThe Access Point User Interface will appear. This device can operate in Access Point operating mode. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF Exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This radio transmitter FCCID: RC6-APL5XX has been approved by FCC to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. (2) (1) (3) I ndoor Access Point Trade Name Model No. Difference Amigo Technology APL52X 2x2 11ax AP Amigo Technology APL54X 2x2 11ax AP with LTE option (module) Model variants Antenna List (for APL54X) No. Manufacturer Part No. Antenna Type Max Antenna Gain 1 ANJIE AELQ2S-W6159 Dipole 4.4 dBi 2 ANJIE AELQ2S-W6959 Dipole 3.0 dBi Step 1 Package Content (1) Access Point Step 3 Connecting the Device for Configuration Step 4 IP Address Configuration (1)Once your computer is on, ensure that your TCP/IP is enabled. Open Network Connections and then click Local Area Connection. Select Internet Protocol Version 4 (TCP/IPv4). (2)If your computer is already on a network, ensure that you have set it to a Static IP Address on the interface. (Example: 192.168.1.2 , the Subnet Mask address as 255.255.255.0. and Default Gateway is 192.168.1.254 ) (2) Power Adapter (3) Wall Mounting screw kit (1)Determine where the mounting plate of Access Point to be placed and mark location on the surface for the two mounting holes. Use the appropriate drill bit to drill two 26mm depth holes in the markings and hammer the bolts into the openings. (2)Screw the anchors into the holes until they are flush with the wall. (3)Put mounting plate on the wall to map with hole of anchor then screw the included screws into the anchors. (4)Place the Access Point against wall fitting throughout the slots of the Access Point. Step 2 Mounting Kits Installation For Ceiling mount Installation: (1)Slide the ceiling mount base into the slot of the Access Point. (2)Hold the Access Point with one hand to reach the other hand over the T-Rail sides of the bracket. Then hook the stationary end of the ceiling mount bracket onto the T-Rail. For Wall Mount Installation: (4)Ceiling mounting bracket If you are initiating the APL52X , which is the pure 2x2 11ax DBDC access point, the Package Content included (Illustration) Sw i t c h Inj e c to r (B) PoE Injector (Plug in from LAN1 Port) (1)Connect one end of the Ethernet cable into the LAN1 port of the Access Point and the other end to the Ethernet port on the computer. (2)Plug in power source by different ways that depends on user setup environment (A) PoE Switch (Plug in from LAN1 Port) (C) DC Power Adapter (Plug in from DC Jack) -Connect the Power Adapter to the DC-IN port of the Access Point and plug the other end into an electrical outlet. Note: The Access Point supports both IEEE 802.3at PoE (Power over Ethernet) or the included power adapter. You may use either one as the power source. DO NOT use both at the same time.

Quick Installation Guide Step 5 Access Point Setup Open a web browser on your computer. In the address bar of the web browser, enter 192.168.1.254 and enter. A login screen will appear. By default, the username of the Access Point is admin and the password is admin. Enter the current username and password of the Access Point and then click Login. (Username: admin, Password: admin) TThe Access Point User Interface will appear. This device can operate in Access Point operating mode. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF Exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This radio transmitter FCCID: RC6-APL5XX has been approved by FCC to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. (2) (1) (3) I ndoor Access Point Trade Name Model No. Difference Amigo Technology APL52X 2x2 11ax AP Amigo Technology APL54X 2x2 11ax AP with LTE option (module) Model variants Antenna List (for APL54X) No. Manufacturer Part No. Antenna Type Max Antenna Gain 1 ANJIE AELQ2S-W6159 Dipole 4.4 dBi 2 ANJIE AELQ2S-W6959 Dipole 3.0 dBi Step 1 Package Content (1) Access Point Step 3 Connecting the Device for Configuration Step 4 IP Address Configuration (1)Once your computer is on, ensure that your TCP/IP is enabled. Open Network Connections and then click Local Area Connection. Select Internet Protocol Version 4 (TCP/IPv4). (2)If your computer is already on a network, ensure that you have set it to a Static IP Address on the interface. (Example: 192.168.1.2 , the Subnet Mask address as 255.255.255.0. and Default Gateway is 192.168.1.254 ) (2) Power Adapter (3) Wall Mounting screw kit (1)Determine where the mounting plate of Access Point to be placed and mark location on the surface for the two mounting holes. Use the appropriate drill bit to drill two 26mm depth holes in the markings and hammer the bolts into the openings. (2)Screw the anchors into the holes until they are flush with the wall. (3)Put mounting plate on the wall to map with hole of anchor then screw the included screws into the anchors. (4)Place the Access Point against wall fitting throughout the slots of the Access Point. Step 2 Mounting Kits Installation For Ceiling mount Installation: (1)Slide the ceiling mount base into the slot of the Access Point. (2)Hold the Access Point with one hand to reach the other hand over the T-Rail sides of the bracket. Then hook the stationary end of the ceiling mount bracket onto the T-Rail. For Wall Mount Installation: (4)Ceiling mounting bracket (5)External Antenna If you are initiating the APL54X which is the 2x2 11ax DBDC access point with the LTE option, the Package Content included (Illustration) Sw i t c h Inj e c to r (B) PoE Injector (Plug in from LAN1 Port) (1)Connect one end of the Ethernet cable into the LAN1 port of the Access Point and the other end to the Ethernet port on the computer. (2)Plug in power source by different ways that depends on user setup environment (A) PoE Switch (Plug in from LAN1 Port) (C) DC Power Adapter (Plug in from DC Jack) -Connect the Power Adapter to the DC-IN port of the Access Point and plug the other end into an electrical outlet. Note: The Access Point supports both IEEE 802.3at PoE (Power over Ethernet) or the included power adapter. You may use either one as the power source. DO NOT use both at the same time.

Amigo Technology Inc. No.82, Gongye 2nd Rd., Annan Dist., Tainan City 709, Taiwan Rev 11/20/07 Date: June 28, 2021 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: RC6-APL5XX Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description (APL52X, APL54X)BlkDia (APL52X, APL54X)Schem (APL52X, APL54X)OpDes The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ______________________ Signatory Jay Kung, R&D AVP [email protected]

Amigo Technology Inc. No.82, Gongye 2nd Rd., Annan Dist., Tainan City 709, Taiwan Declaration of Authorization We Name: Amigo Technology Inc. Address: No.82, Gongye 2nd Rd., Annan Dist. City: Tainan City 709 Country: Taiwan Declare that: Name Representative of agent: Louis Hsu Agent Company name: DEKRA Testing and Certification Co., Ltd. Address: No.372-2, Sec. 4, Zhongxing Rd., Zhudong Township City: Hsinchu County 31061 Country Taiwan, R.O.C. is authorized to apply for FCC Certification of the following product(s): Product description: 2x2 11ax WIFI AP Type designation: APL52X, APL54X Trademark: Amigo Technology on our behalf. ______________________ Signatory Jay Kung, R&D AVP [email protected]

Amigo Technology Inc. No.82, Gongye 2nd Rd., Annan Dist., Tainan City 709, Taiwan Declaration of Model Names Date: June 28, 2021 To Whom It May Concern: We, the undersigned, hereby confirm that device FCC ID: RC6‐APL5XX have two model names that model name of APL52X, APL54X is identical in RF hardware and software design. These model names have following difference: Model Number Contain a certified WWAN Module APL52X No contain module. APL54X Contain WWAN module which FCC ID: N7NEM75 (Sierra/EM7565). The device accessory has two detachable WWAN antennas that part number are AELQ2S‐W6159 and AELQ2S‐W6959. In addition to the above information, these devices are identical. Sincerely, Signature: ___________________________ FCC grantee contact person information. Name: Jay Kung TEL: +886226093434 Email: [email protected]

Report No.: 2120060R Page: 1 of 7 Attachment 2 : EUT External Photographs (1) EUT Photo (M/N: APL52X) (2) EUT Photo Report No.: 2120060R Page: 2 of 7 (3) EUT Photo (4) EUT Photo Report No.: 2120060R Page: 3 of 7 (5) EUT Photo (6) EUT Photo Report No.: 2120060R Page: 4 of 7 (7) EUT Photo (8) EUT Photo (M/N: APL54X) Report No.: 2120060R Page: 5 of 7 (9) EUT Photo (10) EUT Photo Report No.: 2120060R Page: 6 of 7 (11) EUT Photo (12) EUT Photo Report No.: 2120060R Page: 7 of 7 (13) EUT Photo (14) EUT Photo

Part NO. Part NameDevice Label Description Dimention74.5*44.5mm 左上C2mm Material Print ColorBlack Crystal Version :1.0 Remark Unitsmm Tolerance DrawerDate CustomerAmigo APL52X ±0.5 mm 2020.03.29 Version :1.0 50番白色特多龍+PET膜 74.5mm 44.5mm 1:1 Font: Arial Blod Font: Arial 廠內自印 Code 128A MCA 印製：LAN MAC （NIC0 欄位） Made in Taiwan 全抗碳帶 PL52M YH000 0 1 Amigo 2019 = J 2020 = K 2021 = L 2022 = M 2023 = N S/N : 12碼 CODE 128A Label Location (Bottom Case) 40% APL52X S/NPH52MYH00001 MAC A ABBCC002233 INPUT 12V 2A FCC ID:RC6-APL5XX This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in Taiwan APL52X S/NPH52MYH00001 AABBCC002233LAN MAC 12V 2AINPUT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID:RC6-APL5XX

Part NO. Part NameDevice Label Description Dimention74.5*44.5mm 左上C2mm Material Print ColorBlack Crystal Version :1.0 Remark Unitsmm Tolerance DrawerDate CustomerAmigo APL54X ±0.5 mm 2020.03.29 Version :1.0 50番白色特多龍+PET膜 74.5mm 44.5mm 1:1 Font: Arial Blod Font: Arial 廠內自印 Code 128A MCA 印製：LAN MAC （NIC0 欄位） Made in Taiwan 全抗碳帶 PL54M YH000 0 1 Amigo 2019 = J 2020 = K 2021 = L 2022 = M 2023 = N S/N : 12碼 CODE 128A Label Location (Bottom Case) 40% APL54X S/NPH54MYH00001 MAC AABBCC002233 INPUT 12V 2A FCC ID:RC6-APL5XX Contains FCC ID: N7NEM75 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in Taiwan APL54X S/NPH54MYH00001 AABBCC002233LAN MAC 12V 2AINPUT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID:RC6-APL5XX Contains FCC ID: N7NEM75

Report No.: 2120060R Page: 1 of 29 Attachment 3 : EUT Internal Photographs (1) EUT Photo (M/N: APL52X) (2) EUT Photo Report No.: 2120060R Page: 2 of 29 (3) EUT Photo (4) EUT Photo Report No.: 2120060R Page: 3 of 29 (5) EUT Photo (6) EUT Photo Report No.: 2120060R Page: 4 of 29 (7) EUT Photo (8) EUT Photo Report No.: 2120060R Page: 5 of 29 (9) EUT Photo (2.4GHz WLAN Antenna) (10) EUT Photo (2.4GHz WLAN Antenna) Report No.: 2120060R Page: 6 of 29 (11) EUT Photo (5GHz WLAN Antenna) (12) EUT Photo (5GHz WLAN Antenna) Report No.: 2120060R Page: 7 of 29 (13) EUT Photo (14) EUT Photo RF Chip (5GHz) RF Chip (2.4GHz) RF Chip (Bluetooth) Report No.: 2120060R Page: 8 of 29 (15) EUT Photo (16) EUT Photo Report No.: 2120060R Page: 9 of 29 (17) EUT Photo (18) EUT Photo Report No.: 2120060R Page: 10 of 29 (19) EUT Photo (20) EUT Photo Report No.: 2120060R Page: 11 of 29 (21) EUT Photo (Bluetooth Antenna) (22) EUT Photo Report No.: 2120060R Page: 12 of 29 (23) EUT Photo (24) EUT Photo Report No.: 2120060R Page: 13 of 29 (25) EUT Photo (M/N: APL54X) (26) EUT Photo Report No.: 2120060R Page: 14 of 29 (27) EUT Photo (28) EUT Photo Report No.: 2120060R Page: 15 of 29 (29) EUT Photo (30) EUT Photo Report No.: 2120060R Page: 16 of 29 (31) EUT Photo (32) EUT Photo (LTE Module)

Report No.: 2120060R Page: 17 of 29 (33) EUT Photo (34) EUT Photo Report No.: 2120060R Page: 18 of 29 (35) EUT Photo (36) EUT Photo Report No.: 2120060R Page: 19 of 29 (37) EUT Photo (38) EUT Photo Report No.: 2120060R Page: 20 of 29 (39) EUT Photo (40) EUT Photo Report No.: 2120060R Page: 21 of 29 (41) EUT Photo (42) EUT Photo (2.4GHz WLAN Antenna) Report No.: 2120060R Page: 22 of 29 (43) EUT Photo (2.4GHz WLAN Antenna) (44) EUT Photo (5GHz WLAN Antenna) Report No.: 2120060R Page: 23 of 29 (45) EUT Photo (5GHz WLAN Antenna) (46) EUT Photo RF Chip (5GHz) RF Chip (2.4GHz) RF Chip (Bluetooth) Report No.: 2120060R Page: 24 of 29 (47) EUT Photo (48) EUT Photo Report No.: 2120060R Page: 25 of 29 (49) EUT Photo (50) EUT Photo Report No.: 2120060R Page: 26 of 29 (51) EUT Photo (52) EUT Photo Report No.: 2120060R Page: 27 of 29 (53) EUT Photo (54) EUT Photo (Bluetooth Antenna) Report No.: 2120060R Page: 28 of 29 (55) EUT Photo (LTE Antenna) (56) EUT Photo Report No.: 2120060R Page: 29 of 29 (57) EUT Photo (58) EUT Photo

Report No. 2120060R-E3082100013 Page: 1 of 15 RF Exposure Evaluation Declaration Product Name ：2x2 11ax WIFI AP Trade Name ：Amigo Technology Model No. ：APL52X, APL54X FCC ID ：RC6-APL5XX Applicant : Amigo Technology Inc. Address : No.82, Gongye 2nd Rd., Annan District, Tainan City 70955, Taiwan (R.O.C.) Date of Receipt : Feb. 02, 2021 Date of Declaration : Jun. 28, 2021 Report No. : 2120060R-E3082100013 Report Version : V1.0 The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of DEKRA Testing and Certification Co., Ltd.. Report No. 2120060R-E3082100013 Page: 2 of 15 RF Exposure Evaluation Declaration Issued Date : Jun. 28, 2021 Report No. : 2120060R-E3082100013 Product Name : 2x2 11ax WIFI AP Applicant : Amigo Technology Inc. Address : No.82, Gongye 2nd Rd., Annan District, Tainan City 70955, Taiwan (R.O.C.) Manufacturer : Sapido Technology Inc. Address : No.82, Gongye 2nd Rd., Annan District, Tainan City 70955, Taiwan (R.O.C.) Model No. : APL52X, APL54X FCC ID : RC6-APL5XX EUT Voltage ： 12Vdc, 2A Testing Voltage ： AC 120V/60Hz Trade Name : Amigo Technology Applicable Standard : FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. Test Lab : Hsin Chu Laboratory Address : No.372-2, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County 310, Taiwan, R.O.C. TEL: +886-3-582-8001 / FAX: +886-3-582-8958 Test Result : Complied Tested By : ( Scott Chang / Senior Engineer ) Approved By : ( Louis Hsu / Deputy Manager ) Report No. 2120060R-E3082100013 Page: 3 of 15 Revision History Version Description Issued Date V1.0 Initial issue of report Jun. 28, 2021 Report No. 2120060R-E3082100013 Page: 4 of 15 1.1. Test Facility Ambient conditions in the laboratory: Items Test Item Required Test Site Temperature (°C) Peak Output Power 15 - 35 1 Humidity (%RH) 25 - 75 Note: Test site information refers to Laboratory Information. USA : FCC Registration Number: TW3024 Canada : IC Registration Number: 22397-1 / 22397-2 / 22397-3 The address and introduction of DEKRA Testing and Certification Co., Ltd. laboratories can be founded in our Web site: http://www.dekra.com.tw If you have any comments, please don’t hesitate to contact us. Our test sites as below: Test Laboratory DEKRA Testing and Certification Co., Ltd. Address 1. No.372, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County 31061, Taiwan, R.O.C. 2. No.372-2, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County 31061, Taiwan, R.O.C. Phone number 1. +886-3-582-8001 2. +886-3-582-8001 Fax number 1. +886-3-582-8958 2. +886-3-582-8958 Email address [email protected] Website http://www.dekra.com.tw Report No. 2120060R-E3082100013 Page: 5 of 15 1.2. List of Test Equipment Peak Output Power / SR12-H Instrument Manufacturer Model No. Serial No. Cal. Date Next Cal. Date High Speed Peak Power Meter Dual Input Anritsu ML2496A 1602004 2020/11/30 2021/11/29 Pulse Power Sensor Anritsu MA2411B 1531043 2020/11/30 2021/11/29 Pulse Power Sensor Anritsu MA2411B 1531044 2020/11/30 2021/11/29 Power Meter Keysight 8990B MY510002482020/05/20 2021/05/19 Power Sensor Keysight N1923A MY572400052020/05/20 2021/05/19 Note: All equipment upon which need to calibrated are with calibration period of 1 year. 1.3. Uncertainty Test item Uncertainty Peak Output Power ± 2.26 dB Determining compliance shall be based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. Report No. 2120060R-E3082100013 Page: 6 of 15 2. RF Exposure Evaluation 2.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Reference Period (minutes) 0.003-1023 170 180 - Instantaneous* 0.1-10 - 1.6/ ƒ - 6** 1.29-10 193/ ƒ 0.5 - - 6** 10-20 61.4 0.163 10 6 20-48 129.8/ ƒ 0.25 0.3444/ ƒ 0.25 44.72/ ƒ 0.5 6 48-100 49.33 0.1309 6.455 6 100-6000 15.60 ƒ 0.25 0.04138 ƒ 0.25 0.6455ƒ0.5 6 6000-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.40 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ ƒ 1.2 Note: ƒ is frequency in MHz. *Based on nerve stimulation (NS). ** Based on specific absorption rate (SAR). Report No. 2120060R-E3082100013 Page: 7 of 15 Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 2.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Report No. 2120060R-E3082100013 Page: 8 of 15 2.3. Test Result of RF Exposure Evaluation Product 2x2 11ax WIFI AP Test Mode Transmit Mode Test Condition RF Exposure Evaluation Date of Test 2021/02/25~2021/03/15 Test Site SR12-H Temperature (°C) 23.0 Humidity (%RH) 55.0 Antenna Gain: The maximum antenna gain is 3.3 dBi. Output Power into Antenna & RF Exposure Evaluation Distance: WLAN Function 2.4GHz Band Mode Frequency (MHz) Maximum Conducted Output Power Maximum Power De…

Text truncated - open the document above for the full version.

Report No：2120060R Page: 1 of 16 Attachment 2  Test Result of co-location 30MHz-1GHz Spurious Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Horizontal Temperature (°C) 21.5 Test Condition WiFi 2.4G + 5G + LTE B2 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type 1 49.400 31.27 40.00 -8.73 36.67 -5.40 PK 2 148.340 34.62 43.50 -8.88 38.04 -3.42 PK * 3 191.990 38.06 43.50 -5.44 43.16 -5.10 PK 4 225.940 38.75 46.00 -7.25 42.14 -3.39 PK 5 511.605 33.87 46.00 -12.13 29.95 3.92 PK 6 599.875 34.94 46.00 -11.06 29.87 5.07 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 2 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Vertical Temperature (°C) 21.5 Test Condition WiFi 2.4G + 5G + LTE B2 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type 1 98.870 30.64 43.50 -12.86 35.30 -4.66 PK 2 143.005 31.29 43.50 -12.21 34.39 -3.10 PK 3 226.910 33.97 46.00 -12.03 37.30 -3.33 PK * 4 384.050 43.00 46.00 -3.00 41.49 1.51 PK 5 576.110 35.19 46.00 -10.81 30.42 4.77 PK 6 693.965 31.37 46.00 -14.63 25.34 6.03 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 3 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Horizontal Temperature (°C) 21.5 Test Mode WiFi 2.4G + 5G + LTE B13 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type 1 115.845 27.90 43.50 -15.60 30.67 -2.77 PK * 2 201.690 36.80 43.50 -6.70 41.54 -4.74 PK 3 311.785 24.03 46.00 -21.97 24.87 -0.84 PK 4 507.240 32.61 46.00 -13.39 28.73 3.88 PK 5 599.875 37.03 46.00 -8.97 31.96 5.07 PK 6 682.810 33.47 46.00 -12.53 27.54 5.93 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 4 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Vertical Temperature (°C) 21.5 Test Mode WiFi 2.4G + 5G + LTE B13 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type * 1 72.680 29.35 40.00 -10.65 37.82 -8.47 PK 2 140.580 25.80 43.50 -17.70 28.76 -2.96 PK 3 225.940 26.59 46.00 -19.41 29.98 -3.39 PK 4 384.050 35.10 46.00 -10.90 33.59 1.51 PK 5 521.305 32.92 46.00 -13.08 28.87 4.05 PK 6 853.045 35.33 46.00 -10.67 27.32 8.01 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 5 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Horizontal Temperature (°C) 21.5 Test Condition WiFi 2.4G + 5G + LTE B41 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type 1 36.305 33.65 40.00 -6.35 30.14 3.51 PK 2 149.310 34.44 43.50 -9.06 37.91 -3.47 PK 3 226.425 40.02 46.00 -5.98 43.38 -3.36 PK * 4 384.050 40.50 46.00 -5.50 38.99 1.51 PK 5 509.180 33.15 46.00 -12.85 29.25 3.90 PK 6 552.830 35.01 46.00 -10.99 30.55 4.46 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 6 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Vertical Temperature (°C) 21.5 Test Condition WiFi 2.4G + 5G + LTE B41 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector Type 1 95.960 31.20 43.50 -12.30 36.42 -5.22 PK 2 149.310 32.21 43.50 -11.29 35.68 -3.47 PK 3 191.990 31.18 43.50 -12.32 36.28 -5.10 PK * 4 384.050 40.23 46.00 -5.77 38.72 1.51 PK 5 606.180 31.32 46.00 -14.68 26.18 5.14 PK 6 893.785 34.71 46.00 -11.29 26.21 8.50 PK Note: 1. All reading levels is Quasi-Peak value. 2. “ * ”, means this data is the worst value. 3. Emission Level = Reading Level + Correct Factor 4. The emission under 30MHz were not included is because their levels are lower than 20dB from limit. Report No：2120060R Page: 7 of 16 Model No APL54X Site CB2-H Test Voltage AC 120V/60Hz Test Date 2021/3/16 Test Mode Transmit mode_PoE Mode Engineer Ling Chen Polarity Horizontal Temperature (°C) 21.5 Test Condition WiFi 2.4G + 5G + WCDMA B5 Humidity (%RH) 51.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB) Detector …
