RF7SI670RXRemote Control

TV Everywhere!™ SI670 Instructions Read and save these instructions. TWwroead Dear Sharper Image Customer,Thank you for your purchase of a Sharper Image Design product. We appreciate your business very much.Please accept my personal assurance of your complete satisfaction with this product’s quality and performance. We offer generous return privileges and excellent warranties on all our products.For more than 25 years, The Sharper Image has shared the fun of discovering innovative products that make life easier and more enjoyable. We’ve been in business a long time because we are an exciting place to shop and - just as importantly - we strive to deliver great customer service that exceeds your expectations.Enjoy your purchase!Respectfully,Richard ThalheimerFounder, Chairman and Chief Executive Officer Shop our complete Internet catalog. TW Introduction............................................................................... 6Quick Start ................................................................................ 8 Receiver/Monitor ................................................................... 8 Transmitter/Tuner ................................................................... 9 Source Selection .................................................................. 10 Channel Programming ......................................................... 11 Viewing Stand and Wire Brackets ........................................ 12General Instructions................................................................. 15 Parts Diagram ...................................................................... 15 Operation Overview ............................................................ 19 Setup ................................................................................... 21 Mode Selections .................................................................. 24 Programming Remote Functions........................................... 30 Special Features ................................................................... 32Troubleshooting ....................................................................... 33Statement of FCC/DHHS Compliance...................................... 34FCC Label Compliance Statement ........................................... 35Warranty.....................................................................Back Cover Table of Contents The TV Everywhere! ™ is a full-featured TV, “split” into two parts: 1. The tuner/transmitter connects to an audio/video source (cable, VCR, DVD player, etc.), interprets the signal and for-wards the picture and sound to the receiver. 2. The receiver is connected to and plays back through your TV. The following items are included with the product: •Tuner/Transmitter• Receiver •Remote Control•AC Adapters for the tranmitter and the receiver•Infrared Signal Device •Assorted Cables Introduction 6 TwfT The cables are color-coded to match equipment standards and will allow you to connect to a video source in any of the following ways: • Directly to an existing unused coaxial cable. • Split connection from an existing coaxial cable. •To the audio/video out jacks of a VCR or DVD player.•To the coaxial out jack of a VCR or TV.• To audio/video input jacks for viewing on another TV or monitor. This instruction manual includes Quick Start instructions followed by more detailed General Instructions and operating procedures. Refer to the General Instructions if you have difficulty understand-ing the Quick Start guide. Introduction 7 Remote Control 1. Slide to open and remove the battery cover from the rear of the remote control. 2. Install the two included AA batteries and replace the cover. Transmitter/Tuner 1. Option 1: Connect the CABLE INPUT post on the transmitter/ tuner to a coaxial cable signal source. (Cable output post can also be connected to a separate television in the room.)Option 2: Connect the color-coded RCA posts on the transmitter/tuner to the matching color output posts on a VCR, DVD player or other video source. Note: Connect using both options for maximum performance. 2. Connect the AC adapter to the AC INPUT/POWER jack and a 110V household outlet. 3. To turn on the unit, press the ON/OFF button. Quick Start 8 1. Connect the color-coded RCA posts on the receiver to the matching input posts on your remote television set. 2. Connect the AC adapter to the DC POWER jack and to a 110V household outlet. Receiver 9 Cable In Television Out (Standard/Wired Connection) Television Out (Wireless) TRANSMITTER/TUNER RECEIVER T4 1. Press the POWER ON/OFF button on the the Tuner/ Transmitter first, then the Receiver POWER ON/OFF button. 2. To activate the mode options, press the MODE SELECT button on the remote (or the receiver front panel). Input Source TV, Video, VCR3 or VCR4 appear on the screen. 3. To select the appropriate source option, press the UP/DOWN buttons on the remote (or the receiver front panel): • TV: If you are connected to a coaxial cable or a VCR coaxial post set to TV mode. • VCR3 or VCR4 : If you are connected to your VCR coaxial post set to VCR mode. • Video: If you are connected to an RCA post of a video source. Note: In all modes except TV, the channel and viewing are controlled by the viewing source’s (VCR, DVD player, etc.) remote. The receiver/remote CHANNEL / buttons can be programmed to mimic two functions of the source remote while operating in the Video, VCR3 or VCR4 modes. (See Programming Remote Functions in the General Instructions.) Source Selection 10 Note: The following steps are for coaxial connections in the TV mode.Turn on the receiver/monitor and the VCR (if connected) off.1. To activate mode selection options, press the MODE SELECT button. 2. Select TV mode (if not already selected). 3. To select Auto Program mode, press the LEFT/RIGHT or button on the upper area of the remote control. 4. To set the source option to CATV (cable) or AIR (antenna), press the UP/DOWN buttons on the upper area of the …

Text truncated - open the document above for the full version.

Report No.: GLEM0040801288RF Page: 1 of 21 FCC ID: RF7SI670RX Authorized Signature: Kent Hsu Laboratory Manager SGS-CSTC Co.,Ltd. This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the SGS PRODUCT CERTIFICATION MARK.. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. Member of the SGS Group (Société Générale de Surveillance) SGS-CSTC Standards Technical Services Ltd. 1/F., Building No. 1 Building, Agriculture Machinery Materials Co. Wushan Road, Shipai, Tianhe District,Guangzhou, China Telephone: +86 (0) 20 3848 1001 Fax: +86 (0) 20 3848 1006 [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 282399 FCC TEST REPORT Application No. : GLEM0040801288RF Applicant : STL INTERNATIONAL LTD FCC ID : RF7SI670RX Fundamental Frequency : 433.880MHz Equipment under Test (EUT): Name : TV Everywhere Model : SI670 Standards : FCC PART 15, SUBPART C : 2002 (Section 15.231) Date of Receipt : 07 September 2004 Date of Test : 10 September to 12 October 2003 Date of Issue : 19 October 2003 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID No.: RF7SI670RX Report No.: GLEM0040801288RF Page: 2 of 21 SGS-CSTC Standards Technical Services Ltd. 2 Contents Page 1 COVER PAGE.........................................................................................................................................................1 2 CONTENTS .............................................................................................................................................................. 2 3 GENERAL INFORMATION.................................................................................................................................. 3 3.1 CLIENT INFORMATION............................................................................................................................................ 3 3.2 DETAILS OF E.U.T. ................................................................................................................................................. 3 3.3 DESCRIPTION OF SUPPORT UNITS........................................................................................................................... 3 3.4 TEST LOCATION...................................................................................................................................................... 3 3.5 OTHER INFORMATION REQUESTED BY THE CUSTOMER.......................................................................................... 3 3.6 TEST FACILITY........................................................................................................................................................ 4 4 TEST RESULTS....................................................................................................................................................... 5 4.1 TEST INSTRUMENTS................................................................................................................................................ 5 4.2 E.U.T. OPERATION................................................................................................................................................. 5 4.3 TEST PROCEDURE & MEASUREMENT DATA........................................................................................................... 6 4.3.1 Radiated Emissions (Fundamental & Harmonics)....................................................................................... 6 4.3.2 Radiated Emissions (Other Spurious Emissions) ......................................................................................... 9 4.3.3 Conducted Emissions, 150KHz to 30MHz ................................................................................................ 10 4.3.4 Occupied Bandwidth .................................................................................................................................. 11 4.3.5 Calculation Of Duty Cycle: ........................................................................................................................ 12 5 PHOTOGRAPHS - TEST SETUP........................................................................................................................ 14 6 PHOTOGRAPHS - EUT CONSTRUCTIONAL DETAILS .........................................................................15-21 FCC ID No.: RF7SI670RX Report No.: GLEM0040801288RF Page: 3 of 21 SGS-CSTC Standards Technical Services Ltd. 3 General Information 3.1 Client Information Applicant: STL INTERNATIONAL LTD Address of Applicant: TUNG KONG INDUSTRIAL ZONE.LIU MEI VILLAGE,YUEN ZHOU,BOLOU,PRC 3.2 Details of E.U.T. Product Name: TV Everywhere Model: SI670 Power Supply: 120Vac/60Hz, AC/AC Adapter which supplied by the applicant. Adapter Input: 120 Vac, 60Hz 14W. Output: AC 9V, 600mA. Romote control part: 3.0V (2 x ‘AA’ Size Batteries). Power Cord: 1.8m, 2 wires unshielded cable. 3.3 Description of Support Units The EUT was tested as an independent unit: a 433MHz radio transmitter. The whole TV Everywhere including the with : (1). Tuner/Transmitter. (2.4GHz) (2). Receiver.(433MHz) (3). Remote Control; AC Adapt…

Text truncated - open the document above for the full version.

Radiated Emission: Conducted Emission:
