RGQ-601Smartwatch

FCC ID:RGQ-601 IC:10805A-601 Label 1.Press the middle button to select Top icon 2. Move manual page by lower button and middle button to selection system icon 3. Use middle button to select the certification icon and show FCC ID info on the screen as below

Pebble Technology Corporation 925 Alma St Palo Alto California 94301 United States Date: September 22, 2015 Power of Attorney To whom it may concern, Please be notified that I, Steve Prokup, have designated Eric Huang in Quanta Computer Inc. as the person being responsible for this project and to sign the form 731 and other FCC and IC documentation. Any and all acts carried out by Eric Huang in Quanta Computer Inc.on the matters relating to all processes required in the FCC and IC approvals and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.2002 (b), we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC Grantee Code: RGQ IC Company Number: 10805A Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, ____________ Steve Prokup / Head of Hardware Engineering Pebble Technology Corporation Tel: 650-262-0151 Fax: 650-618-1683 E-mail: [email protected]

Page 1 of 13 Report No.: 150727C14 CONSTRUCTION PHOTOS OF EUT Brand Name: Smartwatch / Model Name: 601 Page 2 of 13 Report No.: 150727C14 Page 3 of 13 Report No.: 150727C14 Page 4 of 13 Report No.: 150727C14 Page 5 of 13 Report No.: 150727C14 Page 6 of 13 Report No.: 150727C14

Pebble Technology Corporation Label Sample & Location FCC ID: RGQ-601 IC:10805A-601 E-label: Back of EUT:

Page 7 of 13 Report No.: 150727C14 Page 8 of 13 Report No.: 150727C14 Page 9 of 13 Report No.: 150727C14 Page 10 of 13 Report No.: 150727C14 Page 11 of 13 Report No.: 150727C14 Page 12 of 13 Report No.: 150727C14 Page 13 of 13 Report No.: 150727C14

FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 1 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 FCC SAR Exclusion Report Report No. : SA150727C14 Applicant : Pebble Technology Corporation Address : 639 High St., Palo Alto, CA 94301, United States Product : Smartwatch Brand : Pebble FCC ID : RGQ-601 Model No. : 601 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 / KDB 865664 D02 v01r01 / KDB 447498 D01 v05r02 Sample Received Date : Jul. 27, 2015 Date of Evaluation : Aug. 17, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Rona Chen / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 2 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 3.1 Maximum Output Power ............................................................................................................................................... 6 3.2 SAR Testing Exclusions ............................................................................................................................................... 6 4. Information on the Testing Laboratories ............................................................................................................................. 7 Appendix A. Photographs of EUT and Setup FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 3 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 Release Control Record Issue No. Reason for Change Date Issued SA150727C14 Initial release Aug. 20, 2015 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 4 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 1. Summary of Maximum SAR Value Equipment Class Mode Highest Reported Extremity SAR 10g (W/kg) DSS Bluetooth Not Required Note: 1. The SAR limit (Head & Body: SAR 1g 1.6 W/kg) for general population / uncontrolled exposure is specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 5 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 2. Description of Equipment Under Test EUT Type Smartwatch Brand Name Pebble FCC ID RGQ-601 Model Name 601 Tx Frequency Bands (Unit: MHz) Bluetooth : 2402 ~ 2480 Uplink Modulations Bluetooth : GFSK, π/4-DQPSK, 8-DPSK Maximum Tune-up Conducted Power (Unit: dBm) Bluetooth : 10.5 Antenna Type PIFA Antenna EUT Stage Production Unit Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. List of Accessory: Battery Brand Name Lishen Model Name 1S1P-SP301618AE-PCM Power Rating 3.8Vdc, >=56 mAh Type Li-ion FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 6 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 3. SAR Measurement Evaluation 3.1 Maximum Output Power The maximum conducted power (Unit: dBm) including tune-up tolerance is shown as below. Mode 2.4G Bluetooth Bluetooth 10.5 3.2 SAR Testing Exclusions According to KDB 447498 D01, the SAR test exclusion condition is based on source-based time-averaged maximum conducted output power, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The SAR exclusion threshold is determined by the fol…

Text truncated - open the document above for the full version.

Report No.: RF150727C14 1 of 44 Report Format Version 5.1.0 FCC TEST REPORT REPORT NO.: RF150727C14 MODEL NO.: 601 FCC ID: RGQ-601 RECEIVED: Jul. 27, 2015 TESTED: Aug. 01, 2015 ~ Aug. 05, 2015 ISSUED: Aug. 11, 2015 APPLICANT: Pebble Technology Corporation ADDRESS: 639 High St., Palo Alto, CA 94301, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150727C14 2 of 44 Report Format Version 5.1.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................................9 3.3 DESCRIPTION OF SUPPORT UNITS ...................................................................................... 11 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 11 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 12 4. TEST TYPES AND RESULTS (FOR BLUETOOTH EDR) ............................................................... 13 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 13 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 13 4.1.2 TEST INSTRUMENTS ................................................................................................. 14 4.1.3 TEST PROCEDURES ................................................................................................. 15 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 15 4.1.5 TEST SETUP ............................................................................................................... 16 4.1.6 EUT OPERATING CONDITIONS ................................................................................ 16 4.1.7 TEST RESULTS........................................................................................................... 17 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 21 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 21 4.2.2 TEST INSTRUMENTS ................................................................................................. 21 4.2.3 TEST PROCEDURES ................................................................................................. 22 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 22 4.2.5 TEST SETUP ............................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 23 4.2.7 TEST RESULTS........................................................................................................... 24 4.3 NUMBER OF HOPPING FREQUENCY USED ........................................................................ 26 4.3.1 LIMIT OF HOPPING FREQUENCY USED ................................................................. 26 4.3.2 TEST SETUP ............................................................................................................... 26 4.3.3 TEST INSTRUMENTS ................................................................................................. 26 4.3.4 TEST PROCEDURE ..................................................................................................…

Text truncated - open the document above for the full version.

FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 1 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 FCC SAR Exclusion Report Report No. : SA150727C14 Applicant : Pebble Technology Corporation Address : 639 High St., Palo Alto, CA 94301, United States Product : Smartwatch Brand : Pebble FCC ID : RGQ-601 Model No. : 601 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 / KDB 865664 D02 v01r01 / KDB 447498 D01 v05r02 Sample Received Date : Jul. 27, 2015 Date of Evaluation : Aug. 17, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Rona Chen / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 2 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 3.1 Maximum Output Power ............................................................................................................................................... 6 3.2 SAR Testing Exclusions ............................................................................................................................................... 6 4. Information on the Testing Laboratories ............................................................................................................................. 7 Appendix A. Photographs of EUT and Setup FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 3 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 Release Control Record Issue No. Reason for Change Date Issued SA150727C14 Initial release Aug. 20, 2015 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 4 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 1. Summary of Maximum SAR Value Equipment Class Mode Highest Reported Extremity SAR 10g (W/kg) DSS Bluetooth Not Required Note: 1. The SAR limit (Head & Body: SAR 1g 1.6 W/kg) for general population / uncontrolled exposure is specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 5 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 2. Description of Equipment Under Test EUT Type Smartwatch Brand Name Pebble FCC ID RGQ-601 Model Name 601 Tx Frequency Bands (Unit: MHz) Bluetooth : 2402 ~ 2480 Uplink Modulations Bluetooth : GFSK, π/4-DQPSK, 8-DPSK Maximum Tune-up Conducted Power (Unit: dBm) Bluetooth : 10.5 Antenna Type PIFA Antenna EUT Stage Production Unit Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. List of Accessory: Battery Brand Name Lishen Model Name 1S1P-SP301618AE-PCM Power Rating 3.8Vdc, >=56 mAh Type Li-ion FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 6 of 7 Report No. : SA150727C14 Issued Date : Aug. 20, 2015 3. SAR Measurement Evaluation 3.1 Maximum Output Power The maximum conducted power (Unit: dBm) including tune-up tolerance is shown as below. Mode 2.4G Bluetooth Bluetooth 10.5 3.2 SAR Testing Exclusions According to KDB 447498 D01, the SAR test exclusion condition is based on source-based time-averaged maximum conducted output power, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The SAR exclusion threshold is determined by the fol…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 <Frequency Range 30MHz ~ 1GHz> RADIATED EMISSION TEST 3 <Frequency Range above 1GHz> RADIATED EMISSION TEST

FCC SAR Exclusion Report Report Format Version 5.0.0 Report No. : SA150727C14 <Photographs of EUT> <Antenna Location> <EUT Front View> BT Antenna
