RGQ-PEBBLE-WATCHASmartwatch

IC Radiation Exposure Statement: The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. Déclaration d'exposition aux radiations: Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats-Unis et le Canada établies pour un environnement non contrôlé. Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF peut être augmentée si l'appareil peut être conservé aussi loin que possible du corps de l'utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter, except tested built-in radios.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction avec une autre antenne ou un autre émetteur, exception faites des radios intég Pebble Bluetooth Watch Pebble Bluetooth Watch Key Features Key Features• ST ARM 32-bit CORTEX –M3 CPU• Panasonic PAN1316 Bluetooth EDR 2.1 (4.0 disable) module support SPP, AVRCP profile; The maximum power consumption is less than 15 mA and the average powerconsumption is about 1 uA • SHARP 1.26’,TFT LCD module with 144 168 resolution in a 24192-pixel stripe array • Waterproof to 5 ATM• Accelerometer and magnetometer sensor• Vibrator indicate• Display Backlight • LiPoly Battery (120mAh)• 4 function Key Form Factor Form Factor• Dimension: 50.33 mm X 32 mm X 8.44 mm • Weight: 39g• Operation System – TBD

Date: September 30, 2013 Power of Attorney To whom it may concern, Please be notified that I, Eric Migicovsky, have designated Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan on the matters relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.2002 (b), we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: RGQ-PEBBLE_WATCHA If you have any acknowledgement and response, please send it to Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan directly. Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours,

Date: September 30, 2013 Federal Communications Commission 7345 Oakland Mills Road Columbia MD21046 Subject: Request for Confidentiality FCC ID: RGQ-PEBBLE_WATCHA To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.
Schematic Diagram
Block Diagram
Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards,

1 CONSTRUCTION PHOTOS OF EUT 2 9 10

3 4 5 6 7 8 11 12 13 14 15 16

Report No.: SA130808C21 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA130808C21 MODEL NO.: 8471_41_01_50,301BL,301RD,301OR,301GR,301W H,RGQ-PEBBLE-WATCH FCC ID: RGQ-PEBBLE-WATCHA RECEIVED: Aug. 09, 2013 ISSUED: Sep. 18, 2013 APPLICANT: Pebble Technology Corporation ADDRESS: 639 High St., Palo Alto, CA 94301, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA130808C21 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION .............................................................................................. 4 2. EVALUATION RESULT .................................................................................... 5 3. SAR TEST EXCLUSION THRESHOLDS ......................................................... 6 Report No.: SA130808C21 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130808C21 Original release Sep. 18, 2013 Report No.: SA130808C21 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Smartwatch MODEL: 8471_41_01_50,301BL,301RD,301OR,301GR,301WH,RGQ- PEBBLE-WATCH BRAND: Pebble APPLICANT: Pebble Technology Corporation TEST SAMPLE: Production Unit STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Sep. 18, 2013 Evonne Liu / Specialist APPROVED BY : , DATE : Sep. 18, 2013 Roy Wu / Manager Report No.: SA130808C21 5 of 6 Report Format Version 5.0.0 2. EVALUATION RESULT Following FCC KDB 447498 D01 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  .  d distance are rounded to the nearest mW and mm before calculation.  The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [Threshold at 50 mm in step 1) + (test separation distance - 50mm)·( f(MHz)/150)] mW, at 100MHz to 1500 MHz b) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 3) At frequencies below 100 MHz, the following may be considered for SAR test exclusion. a) The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separation distances > 50 mm and < 200 mm. b) The threshold determined by the equation in a) for 50 mm and 100 MHz is multiplied by ½ for test separation distances ≤ 50 mm. c) SAR measurement procedures are not established below 100 MHz. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any test results to be acceptable. Report No.: SA130808C21 6 of 6 Report Format Version 5.0.0 3. SAR TEST EXCLUSION THRESHOLDS Sample Description A Rear Face of EUT with Glued B Rear Face of EUT with Screw Maximum measured transmitter power: Frequency (GHz) Max. Power (mW) Min. test separation distance (mm) SAR test exclusion calculation value (NOTE 2) 10-g extremity SAR test exclusion thresholds Result 2.402 ~ 2.480 14.791 5 4.583 7.5 Pass NOTE: 1. The antenna type is PIFA antenna with -3.03dBi gain for sample A and -3.08dBi gain for sample B. 2. Calculate SAR test exclusion thresholds from condition “1” formulas.

Report No.: RF130808C21 1 of 46 Report Format Version 5.0.0 FCC TEST REPORT (BLUETOOTH) REPORT NO.: RF130808C21 MODEL NO.: 8471_41_01_50,301BL,301RD, 301OR,301GR,301WH,RGQ-P EBBLE-WATCH FCC ID: RGQ-PEBBLE-WATCHA RECEIVED: Aug. 09, 2013 TESTED: Sep. 04, 2013 ~ Sep. 09, 2013 ISSUED: Sep. 18, 2013 APPLICANT: Pebble Technology Corporation ADDRESS: 639 High St., Palo Alto, CA 94301, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF130808C21 2 of 46 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD ......................................................................................................... 4 1. CERTIFICATION ...................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ................................................................................................ 6 3. GENERAL INFORMATION ...................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT....................................................................................... 7 3.2 DESCRIPTION OF TEST MODES......................................................................................... 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................................ 9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................................... 11 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................................. 12 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST .................................................................. 12 4. TEST TYPES AND RESULTS ............................................................................................... 13 4.1 Radiated Emission AND BANDEDGE Measurement ........................................................... 13 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ........................... 13 4.1.2 TEST INSTRUMENTS ......................................................................................................... 14 4.1.3 TEST PROCEDURES .......................................................................................................... 15 4.1.4 DEVIATION FROM TEST STANDARD ................................................................................ 15 4.1.5 TEST SETUP ....................................................................................................................... 16 4.1.6 EUT OPERATING CONDITIONS ......................................................................................... 16 4.1.7 TEST RESULTS ................................................................................................................... 17 4.2 CONDUCTED EMISSION MEASUREMENT ....................................................................... 23 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 23 4.2.2 TEST INSTRUMENTS ......................................................................................................... 23 4.2.3 TEST PROCEDURES .......................................................................................................... 24 4.2.4 DEVIATION FROM TEST STANDARD ................................................................................ 24 4.2.5 TEST SETUP ....................................................................................................................... 25 4.2.6 EUT OPERATING CONDITIONS ......................................................................................... 25 4.2.7 TEST RESULTS ................................................................................................................... 26 4.3 NUMBER OF HOPPING FREQUENCY USED .................................................................... 28 4.3.1 LIMIT OF HOPPING FREQUENCY USED .......................................................................... 28 4.3.2 TEST SETUP ....................................................................................................................... 28 4.3.3 TEST INSTRUMENTS ...........................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
