RGR-HP401402BTBluetooth headphone

NOTE: The microphone button will work with other Smartphone devices that use a 3.5mm headphone jack, but they may only support limited functionality. Please refer to your audio device’s documentation to determine if it is compatible. NOTE : le bouton microphone fonctionne avec d’autres Smartphones équipés d’une prise de casque 3,5 mm, cependant la fonctionnalité peut être limitée par les caractéristiques du téléphone. Veuillez vous référer à la documentation du fabricant de votre appareil afi n de déterminer sa compatibilité. IMPORTANT: Fully charge the headphones for at least 5 hours prior to fi rst use. IMPORTANT : charger complètement le casque durant au moins 5 heures avant la première utilisation. CUSHBLU ™ PREMIUM HEADPHONES OWNER’S MANUAL ENGLISH VERSION Cushblu Specifi cations DESIGN: Over-the-Ear Bluetooth headphones FREQUENCY RESPONSE: 20Hz–20kHz SENSITIVITY: 101 dB/1mW IMPEDANCE: 32 Ohms DRIVE COMPONENTS: 50mm MAX OUTPUT: 118 dB INPUT CONNECTIONS: 3.5mm stereo; Bluetooth A2DP, AVRCP, HFP BATTERY: 3.7V/600mAh Lithium-ion; 10 hours life; 2.5 hours charge time ACCESSORIES: 5’ USB-A to micro USB; 5’ 3.5mm stereo cable; 5’ 3.5mm stereo cable with microphone; KICKER travel bag Spécifi cations techniques CushBlu DESCRIPTION : Casque supra-auriculaire Bluetooth RÉPONSE EN FRÉQUENCE : 20 Hz–20 kHz SENSIBILITÉ : 101 dB/1 mW IMPÉDANCE : 32 Ω ÉLÉMENTS DE COMMANDE : 50 mm SORTIE MAX : 118 dB CONNEXIONS D’ENTRÉE : 3,5 mm stéréo ; Bluetooth A2DP, AVRCP, HFP BATTERIE : Lithium-ion 5 V/600 mAh ; durée de marche 10 heures ; temps de recharge 2,5 heures ACCESSOIRES : USB-A vers micro USB de 1,5 m ; câble stéréo 3,5 mm de 1,5 m ; câble stéréo 3,5 mm avec microphone de 1,5 m; Voyage sac de KICKER increase volume hausse du volume on/offplay-pausemulti-function buttonLED status marche/arrêtplay-pausebouton multifonction voyant d’état previous trackrewind titre précédentrembobiner decrease volume baisse du volume 3.5mm (1/8”) audio and mic AUX input entrée AUX micro et audio 3,5 mm (1/8”) internal microphone microphone interne micro USB micro USB CASQUE DE PRESTIGE Cushblu ™ NOTICE D’UTILISATION VERSION FRANÇAISE next trackfast forward titre suivantavance rapide microphone button bouton microphone Congratulations on your purchase of KICKER’s cushblu Premium Headphones! These fully-featured cans meet the needs of any audio enthusiast. Use the following instructions to learn how to get the most from your new headphones. Powering, Charging, and Resetting your HeadphonesPower: To turn the headphones On/Off, press and hold the multi-function button for 2 seconds until the LED status is On/Off.Charge: Connect the micro-USB cable to the micro-USB jack, then the standard USB cable to a power source. This will begin charging the headphones. You may continue listening to music while charging.Reset: If the headphones ever fail to turn On/Off or respond to other commands, connect the micro-USB cable to the micro-USB jack, then the standard USB cable to a power source. This will reset the headphones.Playing MusicBluetooth Operation: The cushblu headphones will automatically enter Bluetooth pairing mode when turned on for the fi rst time. To enter Bluetooth pairing mode at any time, press and hold the multi-function button for 5 seconds. When in pairing mode, the LED status will show a rapid blue blink.From the Bluetooth menu of your audio device, make sure Bluetooth is enabled and begin scanning for devices, also known as ‘discovery mode’. Select CushBlu . If a code is required by your device, use [ 0000 ]. Once paired, the LED status will show solid blue, and your headphones will automatically connect to your Bluetooth audio device when in range and powered on. Only one device may be paired at a time. When your headphones are paired and connected with a phone, you can answer and hang-up calls by pressing and releasing the multi-function button . To prevent the headphones from automatically reconnecting, place the headphones in pairing mode.AUX Input: The Cushblu headphones support stereo analog input via the 3.5mm stereo jack. If you are in an area that does not allow Bluetooth, such as an airplane or hospital, or if you simply wish to conserve battery power, connect the 3.5mm stereo cable. This requires no battery power, but will deactivate the premium features of the headphones. Félicitations pour votre achat d’un casque prestige cushblu de KICKER ! Ces casques tout équipés répondent aux besoins de tous les audiophiles. Utilisez les instructions suivantes pour découvrir comment profi ter pleinement de votre nouveau casque. Mettre en marche, recharger et redémarrer votre casqueMise en marche : Pour allumer ou éteindre votre casque, appuyez sur le bouton multifonction et maintenez-le enfoncé pendant 2 secondes jusqu’à ce que le voyant d’état soit allumé ou éteint.Recharge : Connectez le câble micro-USB à la prise micro-USB, puis le câble standard USB à la source d’alimentation. Votre casque commencera à charger. Vous pouvez continuer à écouter de la musique pendant la recharge. Redémarrage : Si votre casque ne parvient pas à s’allumer/s’éteindre ou s’il ne répond aux autres commandes, connectez le câble micro-USB à la prise micro-USB, puis le câble standard USB à une source d’alimentation. Cette opération permettra de redémarrer le casque. Écouter de la musiqueFonctionnement Bluetooth : Le jumelage avec Bluetooth se fera automatiquement lors du premier démarrage du casque Cushblu . Pour activer le mode d’appairage Bluetooth à tout moment, appuyez sur le bouton multi-fonction et maintenez-le enfoncé pendant 5 secondes. En mode d’appairage, le voyant d’état clignote rapidement en bleu.À partir du menu Bluetooth de votre appareil audio, assurez-vous que la fonction Blue-tooth est activée et commence la détection des appareils en « mode découverte ». Sé-lectionnez CushBlu . Si votre périphérique exige la saisie d’un code, entrez le code [0000]. Une fois les appareils jumelés, le voyant d’état sera bleu en continu et…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Stillwater Designs And Audio Inc 3100 North Husband Street Stillwater OK 74074,USA 2014-6-10 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Stillwater Designs And Audio Inc hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product: Bluetooth headphone Model: HP401BTB,HP402BTB Sincerely, Signature: name / title : Joe Hobart / R&D Electronics Manager information / address: Stillwater Designs And Audio Inc（3100 North Husband Street Stillwater OK 74074,USA） SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 Stillwater Designs And Audio Inc 3100 North Husband Street Stillwater OK 74074,USA 2014-6-10 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Stillwater Designs And Audio Inc hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Product: Bluetooth headphone Model: HP401BTB,HP402BTB We affirm that between SIEMIC, Inc. and Stillwater Designs And Audio Inc , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: name / title : Joe Hobart / R&D Electronics Manager information / address: Stillwater Designs And Audio Inc（3100 North Husband Street Stillwater OK 74074,USA）

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 3.0 Stillwater Designs And Audio Inc 3100 North Husband Street Stillwater OK 74074,USA Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RGR-HP401402BT We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: name / title : Joe Hobart / R&D Electronics Manager information / address: Stillwater Designs And Audio Inc（3100 North Husband Street Stillwater OK 74074,USA）

DECLARATION OF IDENTITY FCC ID：RGR-HP401402BT IC ID: 11078A-HP401402BT Hereby we: Stillwater Designs And Audio Inc (Name of Manufacturer) Basic Model Number: HP401BTB Basic Brand Name: KICKER Basic Product Name: Bluetooth headphone Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): HP402BTB New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color Signature with Company Chop : Printed Name : Joe Hobart DATE:2014-06-10

Label location

Antenna location

FCC ID: RGR-HP401402BT IC ID:11078A-HP401402BT Keyway Testing Technology Co., Ltd. Report No. 14KWE06147601F Page 1 of 22 FCC TEST REPORT(Bluetooth) for Stillwater Designs And Audio Inc Bluetooth headphone Model Number: HP401BTB,HP402BTB FCC ID: RGR-HP401402BT IC ID:11078A-HP401402BT Prepared for : Stillwater Designs And Audio Inc Address : 3100 North Husband Street Stillwater OK 74075,USA Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE06147601F Date of Test : Jun. 4~8, 2014 Date of Report : Jun. 9, 2014 FCC ID: RGR-HP401402BT IC ID:11078A-HP401402BT Keyway Testing Technology Co., Ltd. Report No. 14KWE06147601F Page 2 of 22 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 5 2.1. Product Function.................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Difference between Model Numbers...................................................................................... 5 2.4. Independent Operation Modes .............................................................................................. 5 2.5. Test Supporting System......................................................................................................... 5 3. TEST SITES .................................................................................................................................. 6 3.1. Test Facilities ......................................................................................................................... 6 3.2. List of Test and Measurement Instruments............................................................................ 7 4. TEST SET-UP AND OPERATION MODES .................................................................................. 8 4.1. Principle of Configuration Selection .......................................................................................8 4.2. Block Diagram of Test Set-up ................................................................................................ 8 4.3. Test Operation Mode and Test Software ............................................................................... 8 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 8 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 8 5. EMISSION TEST RESULTS ......................................................................................................... 9 5.1. Conducted Emission at the Mains Terminals Test................................................................. 9 5.2. Radiated Emission Test ....................................................................................................... 12 6. 20DB OCCUPY BANDWIDTH..................................................................................................... 17 6.1. Limits.................................................................................................................................... 17 6.2. Test setup ............................................................................................................................ 17 7. BAND EDGE COMPLIANCE TEST............................................................................................. 19 7.1. Limits.................................................................................................................................... 19 7.2. Test setup ............................................................................................................................ 19 8. ANTENNA REQUIREMENTS...................................................................................................... 20 8.1. Limits.................................................................................................................................... 20 8.2. Result................................................................................................................................... 20 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 21 10. PHOTOGRAPHS OF THE EUT............................................................................................... 22 FCC ID: RGR-HP401402BT IC ID:11078A-HP401402BT Keyway Testing Technology Co., Ltd. Report No. 14KWE06147601F Page 3 of 22 Keyway Testing Technology Co., Ltd. Applicant: Address: Stillwater Designs And Audio Inc 3100 North Husband Street Stillwater OK 74075,USA Manufacturer: Address: Wata Electronics co.,Ltd No 142,South Tanshen Road, Tanzhou Town,Zhongshan City,Guangdong,China E.U.T: Bluetooth headphone Model Number: HP401BTB,HP402BTB Trade Name: KICKER Serial No.: ------ Date of Receipt: Jun. 4, 2014 Date of Test: Jun. 4~8, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 RSS 210 Issue 8.0:2010 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jun. 9, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology …

Text truncated - open the document above for the full version.

Conducted Emission Radiated Emission
