RGR41KMLCLED Lighting Controller

InstallationDo not install the dongle/RF receiver in enclosed metal parts, as this may interfere with connectivity between it and the remot e. Remote Battery: 3V CR2025 (use only the approved battery)Connect the KMLC LED pig-tail (left) to the KMLC LED dongle (right). The dongle is keyed and will only fi t when oriented properly. To prevent battery discharge, install a switch on the RED KMLC power wire so you can turn off the KMLC’s remote receiver when the boat is stored. InstalaciónNo instale el dispositivo/receptor RF en piezas de metal cerradas, dado que esto puede interferir con la conectividad entre ést e y el control remoto. Batería del control remoto: 3V CR2025 (use únicamente la batería aprobada)Conecte el cable fl exible de conexión LED (izquierda) al dispositivo LED KMLC (derecha). El dispositivo está codifi cado y encajará únicamente si está orientado de modo correcto. Para prevenir la descarga de la batería, instale un interruptor en el cable de alimentación KMLC ROJO para que usted puede apagar el receptor remoto del KMLC cuando se almacena el bote. The KICKER KMLC remote greatly expands the functionality of the latest LED capable KM speakers, and you can connect up to 12 LED-lit KM speakers to the KMLC in parallel. For additional speakers, additional remotes will be required. El control remoto KMLC de KICKER amplía enormemente la funcionalidad de lo más reciente en altavoces KM con capacidad LED: usted puede conectar hasta 12 altavoces KM iluminados por LED a su KMLC de forma simultánea. Para altavoces adicionales, se requieren controles remotos adicionales. KMLC Owners ManualLED Remote (for use with LED-equipped KM speakers) Manual de Propietarios del KMLCControl remoto para LED (para uso con los altavoces KM equipados con LED) Specifi cations Dynamic Modes 19 Modes Static Colors 20 Colors Brightness 5 LevelsSpeed 10 LevelsDemo Mode Yes Working Voltage [V] +12 Output Current [A] 3-way, 4A peak per channel Remote Frequency [MHz] 433.92 Remote Distance [M] 30 (open area) Especifi caciones Modos dinámicos 19 Modos Colores estáticos 20 Colores Brillo 5 NivelesVelocidad 10 NivelesModo Demo Sí Tensión en funcionamiento [V] +12 Corriente de salida [A] Trifásica, 4A pico por canal Frecuencia remota [MHz] 433.92 Distancia remota [M] 30 (área abierta) KMLC+E-20131231 ©2013 Stillwater Designs DEMO SPEED SPEED MODEMODE KMLC DEMO SPEED SPEED MODEMODE KMLC 2 2 1 1 6 6 3 3 10 10 7 7 4 4 8 8 5 5 9 9 Ground Conexión a tierra +12V Source Fuente +12V 1. Turn on | Standby: Turn on or switch to standby mode. 2./3. Adjust Speed4./5. Select Static Color6./7. Adjust Dynamic Mode: Cycle dynamic modes. 8./9. Adjust Brightnes10. Demo Mode: Loop through nine dynamic modes. Each mode will play three times. 1. Encendido | En modo de espera: Encienda o cambie a modo de espera. 2./3. Ajuste la velocidad4./5. Seleccione un color estático6./7. Ajuste a Modo dinámico: Modos dinámicos en ciclo. 8./9. Ajuste el Brillo10. Modo demo: Utilice nueve modos dinámicos. Cada modo se reproducirá tres veces. • You can use the remote turn-on lead from the head unit to trigger a relay. However, do not connect the KMLC power wire directly to the head unit power wire; it pulls more current than a typical turn-on circuit provides. • You can also use the stereo’s rocker-style power switch on the dash, if equipped, to turn the KMLC controller on and off.• You can also simply install a toggle or rocker-switch in a convenient location.Do not wire your KMLC’s power wire into your navigational lighting circuit. Depending on USCG or local laws, it may be inappropriate or illegal to be showing navigation lights and accent lighting. Connect all KM and KMLC LED pig-tail wires together according to color. Each LED pig-tail will have Green, Red, Blue, and Black wires. Splice every green wire together, every red wire together et al. Test for functionality with the remote. Troublesh oot beginning with power and LED wiring. If problems persist, test with one speaker to ensure the KMLC is functioning properly. KICKER products are warranted against defects. Duration and terms of warranty depend on the laws in the country in which it was purchased. For details see your local KICKER Dealer or www.kicker.com/warranty. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law . You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. FCC StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harm ful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.—Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Operation is subject to t he following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interferenc…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Stillwater Designs and Audio Inc. Address: 3100 N Husband City: Stillwater State： Oklahoma Country: United States Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: United States is authorized to apply for Certification and signing related documents of the following product(s),including 731 form: Product description: LED Lighting Controller Type designation: 41KMLCRC Trademark: on our behalf. Date: 2013-12-04 City: Stillwater Name: Bill Doering Function: Product Manager Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-Aug-09 RF_501, Issue 5 Page 1 of 1 Company Name: Stillwater Designs and Audio Inc. Address : 3100 N Husband, City: Stillwater Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: RGR41KMLC Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2014-1-3 Name and signature of applicant: Bill Doering Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Stillwater Designs and Audio Inc. Declaration of Product To whom it may concern: We, the undersigned, Name: Stillwater Designs and Audio Inc. Address: 3100 N Husband City: Stillwater State： Oklahoma Country: United States Declare that: Product description: LED Lighting Controller Type designation: 41KMLCRC Trademark: Hereby the product (Model: 41KMLC), as part of a system that operates with or is marketed with, mentioned in the user manual is only a receiver. on our behalf. Date: 2013-12-04 City: Stillwater Name: Bill Doering Function: Product Manager Signature:

Neutron Engineering Inc. Project No.: 1310C156 Page 2 of 7

Operation is subject to the following two conditions: (1)This device may not cause harmful interferenece, and (2) This device must accept any interference received, including intereference that may cause undesired operation. FCC ID: RGR41KMLC 41KMLCRC label location

Neutron Engineering Inc. Project No.: 1310C156 Page 3 of 7 Neutron Engineering Inc. Project No.: 1310C156 Page 4 of 7 0DLQERDUG 0DLQERDUG Neutron Engineering Inc. Project No.: 1310C156 Page 5 of 7 5)PRGXOHFU\VWDO 5)PRGXOH,& Neutron Engineering Inc. Project No.: 1310C156 Page 6 of 7 5)PRGXOHDQWHQQD Neutron Engineering Inc. Project No.: 1310C156 Page 7 of 7

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: RGR41KMLC Project No. : 1310C156 Equipment : LED Lighting Controller Model : 41KMLCRC Applicant : Stillwater Designs and Audio Inc. Address : 3100 N Husband, Stillwater, Oklahoma, United States74075 According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: Maximum measured transmitter power: Output Power (dBuV/m) Out Power (mW) Limit (mW) 76.38 0.01 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 0.01 mW(76.38dBuV/m), therefore all of them are less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 1 of 36 FCC Radio Test Report FCC ID: RGR41KMLC This report concerns (check one): Original Grant Class I Change Issued Date : Dec. 24, 2013 Project No. : 1310C156 Equipment : LED Lighting Controller Model Name : 41KMLCRC Applicant : Stillwater Designs and Audio Inc. Address : 3100 North Husband Rd, Stillwater, Oklahoma 74075, USA Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Oct. 28, 2013 Date of Test: Oct. 28, 2013~ Dec. 23, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 2 of 36 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 3 of 36 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1. FIELD STRENGTH OF FUNDAMENTAL EMISSIONS MEASUREMENT LIMIT 16 4.2.2. MEASURING INSTRUMENTS AND SETTING (FIELD STRENGTH OF FUNDAMENTAL 16 EMISSIONS) 16 4.2.3 RADIATED EMISSIONS MEASUREMENT 17 4.2.4. DWELL TIME OF PERIODIC OPERATION MEASUREMENT 18 4.2.5. MEASUREMENT INSTRUMENTS LIST 20 4.2.6. TEST PROCEDURE 20 4.2.7. DEVIATION FROM TEST STANDARD 20 4.2.8. TEST SETUP 21 4.2.9. EUT OPERATING CONDITIONS 22 4.2.1 0 TEST RESULTS (BELOW 30MHZ) 23 4.2.11. TEST RESULTS (BETWEEN 30 – 1000 MHz) 24 4.2.12 TEST RESULTS (ABOVE 1000 MHz) 27 5. 20dB SPECTRUM BANDWIDTH MEASUREMENT 30 5.1.MEASURING INSTRUMENTS AND SETTING 30 5.2.TEST PROCEDURES 30 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 4 of 36 Table of Contents Page 5.3. TEST SETUP LAYOUT 30 5.4. TEST DEVIATION 30 5.5. EUT OPERATION DURING TEST 30 5.6. TEST RESULT 31 6. TIMING TESTING 32 Limit 32 6.1.MEASURING INSTRUMENTS AND SETTING 32 6.2.TEST PROCEDURES 32 6.3. TEST SETUP LAYOUT 32 6.4. TEST DEVIATION 32 6.5. EUT OPERATION DURING TEST 32 6.6. TEST RESULT 33 7. EUT TEST PHOTO 34 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 5 of 36 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1310C156 Original Issue. Dec. 24, 2013 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 6 of 36 1. CERTIFICATION Equipment : LED Lighting Controller Trade Name : Model Name : 41KMLCRC Applicant : Stillwater Designs and Audio Inc. Manufacturer : Hangzhou Newsources Electronics Co., LTD Address : No.7 Houyang Rd, Anxi Industrial Zone, Liangzhu, Hangzhou 311113, China Factory : Hangzhou Newsources Electronics Co., LTD Address : No.7 Houyang Rd, Anxi Industrial Zone, Liangzhu, Hangzhou 311113, China Date of Test : Oct. 28, 2013~ Dec. 23, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.231)/ ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1310C156) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 7 of 36 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.231) Standard(s) Section Test Item Judgment Remark 15.207 Conducted Emission - N/A RSS-210 2.7 Table 5 15.209 & 15.231(b) Radiated Spurious EmissionPASS RSS-210 A1.1.3 15.231(c) 20dB Occupied Bandwidth Measurement PASS NOTE: (1)” N/A” denotes test is not applicable in this test report. (2) EUT is used new battery. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1310C156 Page 8 of 36 2.1 TEST FACILITY The test facilities used to collect the test data in this report is DG-CB03 at the location of No.3,J…
