Digital Path Networks Gen3 Repeater Description Description: The DPN Gen 3 repeater functions as a wireless access point and relay point. It allows customers to connect directly to its omni-directional antenna while simultaneously providing a link to the main network backhaul. It connects to the customer premise equipment (CPE) on IEEE 802.11b/g frequencies and protocol. It connects to the main network backhaul through IEEE 802.11a frequencies and protocol. The antennas used are panel, dish, sector, or omni-directional. The ground for the system is referenced to earth from the 3 rd prong of the AC mains outlet. The Gen3 repeater is produced in a few different variants. The host processor board, radios, and antennas can be eliminated, exchanged, or configured to change the operating mode. The Gen3 repeater consists of 3 modules. The host processor board, the Mini- PCI radio card, and the antenna(s). Host Processor Board Digital Path uses a dual supply of host processor boards from two separate manufactures. Host Processor Board #1 PC Engines WRAP.1c Description WRAP is a small single board computer optimized for wireless access and network routing applications. · National SC1100 CPU, 266 MHz 5x86 CPU, 16KB cache · 2 Ethernet channels (National DP83816) · 2 mini-PCI sockets for 802.11 wireless cards and other expansion · 64 MB SDRAM, 64 bit wide for high memory bandwidth · 128 KB flash for tinyBIOS system BIOS. · 7 to 28V DC supply through DC jack or passive power over LAN 1 connector · 1 serial port (DB9 male) Block Diagram (PC Engines WRAP.1c) Host Processor Board #2 Soekris Net 4801 Description The net4801 is a small single board computer optimized for wireless access and network routing applications. National SC1100 CPU, 266 MHz 5x86 CPU, 16KB cache 3 10/100 Mbit Ethernet ports Up to 128 Mbyte SDRAM Compact Flash for Data storage Standard 3.3V PCI expansion slot Mini-PCI type III 3.3V expansions slot USB 1.1 interface 7 to 28V DC supply through DC jack mini-PCI mini-PCI DP8316 LAN 2 DP8316 LAN 1 SDRAM PC 133 64MB National SC1100 20V/18V Compact Flash 33V BIOS Flash 33V DC-DC Converter PCI bus 33MHz +3.3V I/O 7.. 28VDC 2.0V SC1100 core 27MHz 25MHz 802.11x 802.11x 10/100 Eth. 10/100 Eth. IDE DRAM CLK 100MHz Passive POE 7 .. 28VDC Block Diagram (Soekris net4801) Mini-PCI Radio Card The mini-PCI radio card is a complete 802.11a/b/g transmitter receiver with MAC / base band processor. It interfaces with the host processor board via the PCI bus. Digital Path uses radio cards based on two different reference designs from Atheros. • Atheros 5002x o 5112 Radio On a Chip (ROC) o 5212 MAC / base band processor • Atheros 5004x o 5112 (ROC) o 5213 MAC base band processor mini-PCI PCI DP8316 Eth0 DP8316 Eth1 DP8316 Eth2 SDRAM PC 133 128MB National SC1100 Compact Flash 3.3V BIOS Flash 3.3V DC-DC Converter PCI bus 33MHz +3.3V I/O 7 to 28VDC 2.0V SC1100 core 27MHz 25MHz 802.11x 802.11x 10/100 Eth. 10/100 Eth. 10/100 Eth. IDE DRAM CLK 100MHz Block Diagram (Atheros 5004x and 5002x chipset) See the Atheros PDF page 20, figure 1-3 Antenna Each repeater has a combination of 1 or 2 antenna(s) depending on the configuration and number of radio cards present. 2.4GHz Panel Superpass 14.2 dBi RF Technics 14.0 dBi Omni-directional Superpass 8.0 dBi RF Technics 9.0 dBi Sector (180 degrees) Superpass 9.1 dBi 5.3-5.8GHz Panel Superpass 18.0 dBi RF Technics 18.0 dBi Dish Andrews 29.2 dBi Pacific Wireless 26.0 dBi
