RIIBTS30V01Mini Speakerphone

Contents • SPECIFICATIONS • DISCLAIMER • WARRANTY / LIABILITIES • PACKAGE CONTENT • INSTALLATIONS • BATTERY OPERATIONS • SPEAKERPHONE OPERATIONS • BUTTON FUNCTIONS AND OPERATION • CARE AND MAINTENANCE • TROUBLE SHOOTING • CUSTOMER SERVICE / CONTACT US • FCC / ICC 2 • Distracted driving is dangerous. Always use the Bluetooth ® Device in a manner that does not reduce your attention and ability to drive carefully and safely. • Adhere to all applicable traffic laws and motor vehicle regulations applicable to the device. • Consult local laws and regulations for any restrictions on installation or use. • Do not install on or near an airbag. Such installation could interfere with airbag deployment or could cause the pr oduct or another object to become a projectile, which could result in serious personal injury to occupants. • Ensure the product location will not obstruct your vision while driving. • Observe all signs that require an electrical device or RF radio product to be switched off in the designated ar eas. These could include hospitals, blasting areas, and potentially explosive atmospheres. • Tur n off your device prior to boarding an aircraft. Do not use your device in an aircraft. • Never allow children to play with the device. Small parts may be a choking hazard. Specifications Disclaimer - Bluetooth ® Spec.: v2.1 - Weight: 45g - Talk Time: 5 Hours - Standby Time: 150 Hours - Profiles Support: Headset, Handsfree - Operating Range: 10 Meters - Operation Voltage: 3.3V - Battery: Li-polymer, 300mAh - Noise / Echo Reduction: CVC Noise & Echo Reduction - Volume Control Level: 15 Levels - Operating Temperature: -5ºC to 40ºC - Storage Temperature: -10ºC to 70ºC 3 IMPORTANT: Before using the BTS30 Hands-Free Speakerphone: • Charge the battery before us ing for the first ti me • Only use rechargeable batteries provided A. Low Battery Indication Recharge battery when: • Red indicator light turns red • BTS30 emits a beeping sound B. Charging the Battery Follow the steps below when charging the BTS30 Hands-Free Speakerphone: • Insert the charging cable to the USB charging port of the BTS30 • Plug the cable to a power port • When the device is in charging mode, the red battery indicator light is On indicating that charging is in pr ogress NOTE: • Standard charge time is around 3 hours • Battery indicator light will turn Off once fully charged IMPORTANT: Do not leave unit charging unattended if you must leave key in the ignition to charge, unless your vehicle is equipped with a port that is powered with key out of ignition. NOTE: To charge the unit at home, use a 12V DC to AC convert or use a USB power outlet with a USB to Mini USB cable Installations IMPORTANT: Before installing the BTS30, make sure: • Vehicle is parked in a safe area • Car engine is OFF • Emergency brake is set Your BTS30 may be installed in your vehicle’s sun visor. Sun Visor Mounting Follow the steps below to install the B T S 3 0 to your car’s sunshade panel: • Attach and secure the visor mount on the back side of the BTS30 • Slide and mount the BTS30 to the vehicle’s sun visor 1 Battery Operations 2 7 CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. NOTE: Actual talk time and standby time for the BTS30 will vary with differ ent Bluetooth ® enabled mobile phones due to differ ent implementation of power down modes. Speakerphone Operations volume down speaker volume up USB outlet micr ophone ON/OFF A. Power ON/OFF To tur n the BTS30 ON: • Pr ess and hold the ON/OFF button for 2 seconds • The blue LED indicator will light up, indicating the standby mode was initiated To tur n the BTS30 OFF: • Pr ess and hold the ON/OFF button for 4 seconds (in any mode) • The BTS30 will shut down • A long beep sound is heard B. Pairing/Linking Pairing Bluetooth ® enabled devices like mobile phones with the BTS30 Hands-Free Speakerphone authorizes the devices to work with each. This step only needs to be performed once. Before Pairing the BTS30 Hands-Free Speakerphone: • Ensure the BTS30 is fully charged • Ensure that the BTS30 is unplugged from the charger • Ensure the BTS30 is in the OFF mode • Ensure the Bluetooth ® on your mobile phone is activated Follow the steps below to pair your BTS30 with your mobile phone for the first time: • Pr ess and hold ON/OFF key for 4 seconds until the LED indicator alternately blinks red and blue. Do not let go until you see both colors flashing NOTE: BTS30 is now in pairing mode send/end 8 C. Call Operations Making / Receiving Calls User can make a call either from the mobile phone or YD- V44. Before you make or receive calls, ensure: • Bluetooth ® connection is established between your BTS30 and mobile phone • Battery is fully charged 1. Answering Calls NOTE: Calls may be answered via the mobile handset in the normal way. To answer calls via the BTS30: • Check if power is ON and device is linked • The BTS30 will ring or emit a beep sound when there is an incoming call • Pr ess the SEND/END button when ring tone is heard NOTE: Some flip phones may require you to change phone answer setting to any key answer. 2. Rejecting Calls • The BTS30 will ring or emit a beep sound when there is an incoming call • Pr ess and hold the SEND/END button for 2 seconds to reject a call 3. Terminating a Call NOTE: Calls may be ended through the mobile phone To end calls via the BTS30: • Pr ess the SEND/END button • Activate the Bluetooth ® settings of your mobile phone NOTE: The following steps are general procedure; to access Bluetooth ® Menu for your mobile phone, please refer to your phone user manual. • Select SET-UP or CONNECT from your mobile phone menu • Find and select OPTION to discover Bluetooth ® devices; establishing a connection may take several minutes • If found, phone display should indicate BTS30 device was detected or Select “BTS30” from the list • Phone should give you a prompt asking if you want to pair the device • Select OK or…

Text truncated - open the document above for the full version.

To: Faderal Communication Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mils Road Columbia, Maryland 21046 FCC ID: RIIBTS30V01 We, the under signed, Unifat Technology Ltd declared that, our products: Mini speakerphone , BTS30,YD-V44,VV100,V2 . were sold in the market within the final modifications shown in the test report SZEMO11020055901. . Thank you. By: __________________________ ___Samme Cheng (Signature 1 ) (Print name) Title: _Director__________ On behalf of: Unifat Technology Ltd (Company Name) Telephone: __852-2424 6457 Date: 10 May, 2011

Authority to Act as Agent Date: April 20, 2011 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) , to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____12 months_____ By: __________________________ ___Samme Cheng_______ (Signature 1 ) (Print name) Title: _____Director_____________ On behalf of: _Unifat Technology Ltd_ (Company Name) Telephone: _852-2424 6457____________

Request for Confidentiality Date: April 20, 2011 Subject: Confidentiality Request for FCC ID: RIIBTS30V01 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _UNIFAT TECHNOLOGY LTD______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ATCB in the event information regarding the product or the product is made available to the public. ATCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: __________________________ _______Samme Cheng (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://atcb.com/publicdocs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Model Confirmation Letter We, Unifat Technology Ltd (Company name) certify the product: Mini speakerphone And item No.: BTS30,YD-V44,VV100,V2 Their electrical circuit design, layout, components used and internal wiring are identical, Only the model numbers, brand names and packaging are different.

1 Photographs - EUT Constructional Details

1 Photographs - EUT Constructional Details

SGS-CSTC Standards Technical Services Co., Ltd. No. 1 Workshop, M-10, Middle Section, Science & Technology Park, District Shenzhen, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Page: 1 of 1 FCC ID: RIIBTS30V01 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1.1 RF Exposure Compliance Requirement 1.1.1 Standard requirement 15.247(b)(4) requirement: (4) The conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6 dBi. Except as shown in paragraph (c) of this section. if transmitting antennas of directional gain greater than 6 dBi are used. the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1). (b)(2). and (b)(3) of this section as appropriate. by the amount in dB that the directional gain of the antenna exceeds 6 dBi. 1.1.2 EUT RF Exposure The Max Conducted Peak Output Power is 1.64dBm (1.459mW) at the lowest channel; The best case gain of the antenna is 0dBi. 0dBi corresponds to linear antenna gain : 1. According to the formula, the calculation the EIRP test result: EIRP= P x G = 1.459 mW x 1= 1.459mW ① SAR requirement: S= 60 / f(GHz) = 60/2.402 = 24.979mW ② ; ① < ②. So the SAR measurement is not required.

SGS-CSTC Standards Technical Services Ltd. No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEMO11020055901 Page : 1 of 67 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover Page FCC REPORT Application No: SZEMO110200559RF Applicant: Unifat Technology Ltd Manufacturer/Factory: DONGGUAN EASYFAT ELECTRONIC MFY. SIMA CHANG PING Product Name: Mini Speakerphone Operation Frequency: 2402MHz to 2480MHz FCC ID: RIIBTS30V01 Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247: 2009 Date of Receipt: 2011-02-17 Date of Test: 2011-02-17 to 2011-04-20 Date of Issue: 2011-05-10 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEMO11020055901 Page : 2 of 67 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Contents Page 1 COVER PAGE.........................................................................................................................................................1 2 CONTENTS.............................................................................................................................................................. 2 3 TEST SUMMARY.................................................................................................................................................... 3 4 GENERAL INFORMATION................................................................................................................................... 4 4.1 CLIENT INFORMATION.......................................................................................................................................... 4 4.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 4 4.3 E.U.T OPERATION MODE...................................................................................................................................... 6 4.4 DESCRIPTION OF SUPPORT UNITS......................................................................................................................... 6 4.5 TEST FACILITY..................................................................................................................................................... 7 4.6 TEST LOCATION................................................................................................................................................... 7 4.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER................................................................…

Text truncated - open the document above for the full version.

1 Photographs-test setup photo Test Model NO.: BTS30 Radiated Emission Radiated Spurious Emission
