RL9-HCB86Bluetooth Headset

Bluetooth Headset User Guide HCB86  Index . Notice before using 2. Package List 3. Product Introduction 4. Charging the Headset 5. Power On/ Off 6. Pairing the Headset (or any Bluetooth Device) 7. Pair with 2 Bluetooth phones 8. Operating method: While answering the call from st phone, there comes another call from 2nd phone 9. Wearing the Headset 0. Answering calls . Refusing calls 2. Ending calls 3. Voice Dialing 4. Redialing 5. Transferring calls 6. Maintaining calls 7. Ending Call  and answering Call 2 8. Adjusting the Volume 9. Safety Instruction 20. Specifications 2. Excluding Problems 22. Storage of the Headset 23. Q & A 24. Declaration of Conformity 2 1. Notice before using Thank you for purchasing our Bluetooth Headset HCB86. First of all, please check to find everything in your package and care- fully study the user guide to know the function details. HCB86 is developed by the innovative Bluetooth wireless technology, enabled to connect the Bluetooth mobile phone designed with Audio Gateway (HCB8/ HCB2), PDA, desktop and notebook with the USB Bluetooth Dongle plugged-in, etc. Before using it, please confirm your mobile phone complies with Bluetooth V./ V.2/ V2.0/ V2. and supports the Bluetooth Headset or Handsfree Profile. 2. Package List Please inspect the product you purchased. Refer to the below package list to make sure there is no shortage or defect inside. The complete package includes the following items: ► HCB86 Bluetooth Headset ............... ► User Guide ........................................ ► Warranty Card .................................. ► Travel Charger (INPUT: AC100-240V, 50/ 60Hz, OUTPUT: DC5.V, 20mA) ............................. ► Hanging Strap ................................... ► Rubber ..............................................2 If you find any shortage, please contact the retailer shop where you purchased this product. 3 3. Product Introduction Function (Answering/ Ending/ On/ Off) Button 3 LED (Indicator) Light Receiver (Speaker) Microphone Power Interface adapter (charging) Ear Hook Decrease Volume key (-)  Increase Volume key (+) 2 Note: ● For first time use, make sure to fully recharge the Headset bat- tery. 4. Charging the Headset HCB86 comes with a Lithium Polymer battery built-in. Indicator light Speaker 4 . Plug the travel charger into the power socket. 2. Plug the end of the travel charger into the power interface adapter of the Headset. 3. While charging, the indicator will turn red; when charging is completed, the red indicator will shut off or flashes red. Note: Charging time is around 90~20 minutes. ● For first time use, make sure to fully recharge the Headset up to 4 hours. After a long time of not using it (around one month), while recharging, it takes a while for the indicator to turn red. ● While charging, please do not use the Headset. ● Please use the original charger to recharge the Headset. ● When the indicator flashes the red light, it means the battery is low, please recharge the Headset right away. ● Please recharge the Headset within the temperature range of -10 °C (+14°F) +45°C (+113°F). 5. Power On/ Off . Press and hold the function button for 2~3 seconds, the power 5 will turn on after the indicator flashes the blue light 3 times. 2. To turn the power off, press and hold the function button for 2~3 seconds until you see the red indicator flash 3 times. Note: ● While turning the Headset on, you will hear the “Du Du” sound from the receiver. The blue indicator light will flash 5 times, then 2 times, and after repeating this for 5 times, the indicator will flash the blue light every 3 seconds to come into a standby mode. ● While the Headset is turned on, it will automatically search for the paired device. Under “ON” mode and within the effective range of 10 meters from the Headset, the indicator will flash the blue light to indicate that it entered the connecting mode. ● When turning the headset off, you will hear one “Bi” sound fol- lowed by two “Du” sounds, then the indicator will shut off after flashing the red light for a few times. 6. Pairing the Headset (or any Bluetooth Device) You must pair the Headset with your Bluetooth phone or any Bluetooth device before you use the Headset for the first time. . Ensure the Headset is off. 2. Press and hold the function button for 5 seconds until the blue indicator light flashes with the red indicator light to enter the pairing mode. 3. Ensure your mobile phone has the Bluetooth function and 6 start the Bluetooth new device searching function. Please follow the instructions of your mobile phone to proceed the operation. 4. When your mobile phone is in the stage of searching a new Bluetooth device, it will find HCB86. 5. Please choose and confirm HCB86. 6. Key in the Headset Password “0000” and press YES. If the pairing is successful, the indicator turns to flash the blue light only. For some mobile phones, after pairing you may have to select and confirm HCB86 again to start the connection. (Please read your mobile phone manual carefully to take the right steps.) 7. The Headset is in the standby mode, you can start to receive and make call. Note: ● If the pairing is not successful, the Headset will return to the standby mode, please repeat the pairing process to try the pair- ing again. ● While pairing, it is better to keep the distance between the mo- bile phone and Headset around 0 cm to m and make sure no metal objects are between. ● While pairing the Headset with other Bluetooth device, when the device asks for the Password, please key-in “0000”. For more details, please check the manual of your Bluetooth device to proceed the operation. 7 ● Even though the following situations happen, the paired devices remain pairing. - The power for one of the devices is off. - The service for one of the devices is off. - One of the devices is re-switched on. 7. Pair with 2 Bluetooth phones After achievement of pairing st Bluetooth phone, please repea…
