RLQPGCHF01FM Band Hands-Free Car Kit Transmitter

1234 A B C D 4 321 D C B A Title NumberRevisionSize A4 Date:17-Jun-2003Sheet of File:F:\\PCB\luo文件夹板Drawn By: Microphonevoice enlarges Oscillators Enlarger Power supply ANT electric circuit electric circuit PDF created with FinePrint pdfFactory trial version http://www.fineprint.com

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

FCC ID: RLQPGCHF01 Circuit Description The 17.6MHz (x5 to 88.04)MHz crystal oscillator drives the base of Q3 the final/buffer amplifier. The modulation provided by Mic. The output of Q3 has the matching network consisting of L1 and C12 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source There is no external atenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“CR2032” size battery x 1) primary battery

Date: 2003-10-11 TEST REPORT Page 1 of 17 No.: HM110795 FCC PART 15 SUBPART C CERTIFICATION REPORT FOR LOW POWER TRANSMITTER TEST REPORT No.: HM110795 Equipment Under Test [EUT]: Car Handsfree Kit Model Number: PG-CHF-01 Applicant: Zhongshan K-mate Electronics Co., Ltd. FCC ID : RLQPGCHF01 Date: 2003-10-11 TEST REPORT Page 2 of 17 No.: HM110795 CONTENT: Cover Page 1 of 17 Content Page 2-3 of 17 Conclusion Page 4 of 17 1.0 General Details 1.1 Test Laboratory Page 5 of 17 1.2 Applicant Details Page 5 of 17 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 6 of 17 Description of EUT operation 1.4 Date of Order Page 6 of 17 1.5 Submitted Sample Page 6 of 17 1.6 Test Duration Page 6 of 17 1.7 Country of Origin Page 6 of 17 1.8 Additional Information of EUT Page 7 of 17 2.0 Technical Details 2.1 Investigations Requested Page 8 of 17 2.2 Test Standards and Results Summary Page 8 of 17 3.0 Test Results 3.1 Emission Page 9-12 of 17 3.2 Bandwidth Measurement Page 13-14 of 17 Date: 2003-10-11 TEST REPORT Page 3 of 17 No.: HM110795 Appendix A List of Measurement Equipment Page 15 of 17 Appendix B Photographs Page 16-17 of 17 Date: 2003-10-11 TEST REPORT Page 4 of 17 No.: HM110795 CONCLUSION The submitted product was deemed to have COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Verified by Ivan Toa K C Lee for Chief Executive Date: 2003-10-11 TEST REPORT Page 5 of 17 No.: HM110795 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant ZHONGSHAN K-MATE ELECTRONICS CO., LTD. Fu Wan Industrial Zone, Sun Wen East Road, Zhongshan, Guangdong, China HKSTC Code Number for Applicant PEG002 Manufacturer ZHONGSHAN K-MATE ELECTRONICS CO., LTD. Fu Wan Industrial Zone, Sun Wen East Road, Zhongshan, Guangdong, China Date: 2003-10-11 TEST REPORT Page 6 of 17 No.: HM110795 1.3 Equipment Under Test [EUT] Description of Sample Product: Car Handsfree Kit Manufacturer: Zhongshan K-mate Electronics Co., Ltd. Brand Name: N/A Model Number: PG-CHF-01 Input Voltage: 3Vd.c (“CR2032” size battery x 1) 1.3.1 Description of EUT Operation The Equipment Under Test(EUT) is an Zhongshan K-mate Electronics Co., Ltd., Car Handsfree Kit. The transmitter is a 2 button transmitter. The EUT continues to transmit while button is being pressed. It is voice transmission, Modulation by Mic. and tape is frequency modulation. 1.4 Date of Order 2003-06-30 1.5 Submitted Sample(s): 6 Samples per model 1.6 Test Duration 2003-10-06 1.7 Country of Origin China Date: 2003-10-11 TEST REPORT Page 7 of 17 No.: HM110795 1.8 Additional Information of EUT Submitted Not Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label Date: 2003-10-11 TEST REPORT Page 8 of 17 No.: HM110795 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4: 2000 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.239 ANSI C63.4:2000 N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209 ANSI C63.4:2000 Class B Conducted Emissions on AC, 0.15MHz to 30MHz FCC 47CFR 15.207 ANSI C63.4:2000 Class B Note: N/A - Not Applicable Date: 2003-10-11 TEST REPORT Page 9 of 17 No.: HM110795 3.0 Test Results 3.1 Emission 3.1.1 Radiated Emissions (30 – 1000MHz) Test Requirement: FCC 47CFR 15.109 Class A Test Method: ANSI C63.4:2000 Test Date: 2003-06-30 Mode of Operation: On mode Test Method: The sample was placed 0.8m above the ground plane on the OATS *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. *: OATS [Open Area Test Site] located at HKSTC with a metal ground plane filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 90657. Test Setup: EUT Pre-Amplifier Distance = 3m Receiver Turn Table Computer Ground Plane Date: 2003-10-11 TEST REPORT Page 10 of 17 No.: HM110795 Limits for Field Strength of Fundamental Emissions [FCC 47CFR 15.239]: Frequency Range of Fundamental Peak Limits Average Limits [MHz] [ μ V/m] [ μ V/m] 88-108 2,500 250 Results: FrequencyCorrectionLimit @3mE-Field FactorPolarity MHz dB μ V/m μ V/m 88.0429.410.439.897.72,500Horizontal μ V/mdB μ V/m Field Strength dB μ V/m Field Strength of Fundamental Emissions Peak Value Measured Level @3m Field Strength FrequencyCorrectionLimit @3mE-Field FactorPolarity MHz dBμV/mμV/m 88.0429.110.439.594.4250Horizontal Field Strength of Fundamental Emissions Average Value* Measured Level @3m Field Strength μV/mdBμV/m Field Strength dBμV/m Remarks: Correction Factor included Antenna Factor and Cable Attenuation. Calculated measurement uncertainty : 30MHz to 300MHz ±3.7dB 300MHz to 1GHz +3.0dB / -2.7dB According to FCC 47CFR15.35, the limit on the radio frequency emissions as measured using instrumentation with a peak detector function, corresponding to 20dB above the maximum permitted average limit for the frequency being investigated unless a different peak emission limit is othe…

Text truncated - open the document above for the full version.

RLQPGCHF01

Chris Harvey From: Chris Harvey Sent: Monday, October 13, 2003 11:13 AM To: Chris Harvey; 'Alice Wong @ hkstc ([email protected])' Cc: 'Kitty @ HKSTC EED - Choy ([email protected])'; Marianne Bosley Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 10/13/2003 Alice, I have one more question. One statement in the Users Manual indicates that the Receiver will turn off after 45 minutes to save battery. This application is for a transmitter only. Is there a receiver that is approved separately, or is this device a transceiver? Thank you, Chris Harvey -----Original Message----- From: Chris Harvey Sent: Monday, October 13, 2003 10:53 AM To: Alice Wong @ hkstc ([email protected]) Cc: Kitty @ HKSTC EED - Choy ([email protected]); Marianne Bosley Subject: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice and Kitty: The Users Manual for this device indicates that it can operate from 88MHz to 105.5MHz, or a band of 17.5MHz. The test report shows data for one operating frequency (88.04MHz). According to FCC Rule 15.33 (m), Intentional radiators that operate/tune over more than 10MHz need to be tested at 3 operating frequencies, one at the bottom of the band, one at the center and one at the top of the band. Please provide data for compliance with FCC 15.239 (a) and (b) for the appropriate number of operating ‘channels’. If this device only operates at 2 channels then please submit the data for those 2 channels. Please describe more detail how this audio (FM) modulated device was modulated during the Bandwidth test to ensure that the maximum bandwidth was captured in the plot, and how the EUT operating channel is changed. Additionally, the Label submitted contains the statement required by FCC 15.19. However the label location has a different formatted label, which does not incorporate the 15.19 statement. Based on the size of the device you can request that the 15.19 statement be located in the Users Manual. Please be sure that the label, label location and Users manual information are consistent, and that if you wish to place the 15.19 statement in the Users Manual, that you submit a request to do this based on the small physical size of the EUT. Please submit the corrected information requested above so that the application review can be completed. Best regards, Chris Harvey EMC Lab Director MET Laboratories, Inc. 1-800-638-6057 x-310

Chris Harvey From: Chris Harvey Sent: Tuesday, October 14, 2003 7:30 AM To: 'alice_wong'; Marianne Bosley Cc: Chris Harvey; EED - Choy, Kitty Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 10/14/2003 Alice thank you for this information. I am still waiting for Modulation/bandwidth information and the Label information from my original e-mail below. Please review the original e-mail and respond to those 2 items so the application review can be completed. Please contact me if you have any further questions. Best regards, Chris Harvey -----Original Message----- From: alice_wong [mailto:[email protected]] Sent: Monday, October 13, 2003 10:56 PM To: [email protected] Cc: [email protected]; EED - Choy, Kitty Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 Hi Marianne, We confirm customer is apply TX only. EUT is fixed frequency on 88.04 MHz. Best Regards Alice ----- Original Message ----- From: alice_wong To: M K Law Sent: Tuesday, October 14, 2003 9:08 AM Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 Dear Kit, Please confirm this job HM110795 is transmitter only or transceiver? Best Regards Alice ----- Original Message ----- From: [email protected] To: [email protected] ; [email protected] Cc: [email protected] ; [email protected] Sent: Monday, October 13, 2003 11:13 PM Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice, I have one more question. One statement in the Users Manual indicates that the Receiver will turn off after 45 minutes to save battery. This application is for a transmitter only. Is there a receiver that is approved separately, or is this device a transceiver? Thank you, Chris Harvey -----Original Message----- From: Chris Harvey Sent: Monday, October 13, 2003 10:53 AM To: Alice Wong @ hkstc ([email protected]) Cc: Kitty @ HKSTC EED - Choy ([email protected]); Marianne Bosley Subject: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice and Kitty: The Users Manual for this device indicates that it can operate from 88MHz to 105.5MHz, or a band of 17.5MHz. The test report shows data for one operating frequency (88.04MHz). According to FCC Rule 15.33 (m), Intentional radiators that operate/tune over more than 10MHz need to be tested at 3 operating frequencies, one at the bottom of the band, one at the center and one at the top of the band. Please provide data for compliance with FCC 15.239 (a) and (b) for the appropriate number of operating 'channels'. If this device only operates at 2 channels then please submit the data for those 2 channels. Please describe more detail how this audio (FM) modulated device was modulated during the Bandwidth test to ensure that the maximum bandwidth was captured in the plot, and how the EUT operating channel is changed. Additionally, the Label submitted contains the statement required by FCC 15.19. However the label location has a different formatted label, which does not incorporate the 15.19 statement. Based on the size of the device you can request that the 15.19 statement be located in the Users Manual. Please be sure that the label, label location and Users manual information are consistent, and that if you wish to place the 15.19 statement in the Users Manual, that you submit a request to do this based on the small physical size of the EUT. Please submit the corrected information requested above so that the application review can be completed. Best regards, Chris Harvey EMC Lab Director MET Laboratories, Inc. 1-800-638-6057 x-310 10/14/2003

1 Marianne Bosley From: Chris Harvey Sent: Friday, October 17, 2003 6:20 AM To: 'alice_wong '; Chris Harvey Cc: Marianne Bosley; 'EED - Choy, Kitty ' Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice, the questions were not answered. You have submitted a new bandwidth plot but not answered the question of how the device was modulated (was it with a loud voice or signal generator, what frequency tone, what level of tone). You submitted a label with FCC ID: PG-CHF-01 (I think this is the model number, not the FC ID number), when the original aplication was for FCC ID: RA5PGCHF01. You re-submitted the Users manual listing both 88.MHz and 105.55MHz in section 1.b, when you have stated that the device only operates at 88.04MHz. It appears that each of the questions is still unanswered. Please address these questions so this application can be completed. Best regards, Chris Harvey -----Original Message----- From: alice_wong To: [email protected] Cc: [email protected]; EED - Choy, Kitty Sent: 10/17/2003 6:03 AM Subject: Re: TCB Application FCC ID: RA5PGCHF01 MT#14533 Dear Chris, Please see attached file for revised FCC Label, Manual & bandwidth (is that ok?). If have any question, please let me know. Thanks & Have a nice day Best Regards Alice ----- Original Message ----- From: [email protected] <mailto:[email protected]> To: [email protected] <mailto:[email protected]> ; [email protected] <mailto:[email protected]> Cc: [email protected] <mailto:[email protected]> ; [email protected] <mailto:[email protected]> Sent: Tuesday, October 14, 2003 7:30 PM Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice thank you for this information. I am still waiting for Modulation/bandwidth information and the Label information from my original e-mail below. Please review the original e-mail and respond to those 2 items so the application review can be completed. Please contact me if you have any further questions. Best regards, Chris Harvey -----Original Message----- From: alice_wong [mailto:[email protected]] Sent: Monday, October 13, 2003 10:56 PM To: [email protected] <mailto:[email protected]> Cc: [email protected] <mailto:[email protected]> ; EED - Choy, Kitty Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 2 Hi Marianne, We confirm customer is apply TX only. EUT is fixed frequency on 88.04 MHz. Best Regards Alice ----- Original Message ----- From: alice_wong <mailto:[email protected]> To: M K Law <mailto:[email protected]> Sent: Tuesday, October 14, 2003 9:08 AM Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 Dear Kit, Please confirm this job HM110795 is transmitter only or transceiver? Best Regards Alice ----- Original Message ----- From: [email protected] <mailto:[email protected]> To: [email protected] <mailto:[email protected]> ; [email protected] <mailto:[email protected]> Cc: [email protected] <mailto:[email protected]> ; [email protected] <mailto:[email protected]> Sent: Monday, October 13, 2003 11:13 PM Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice, I have one more question. One statement in the Users Manual indicates that the Receiver will turn off after 45 minutes to save battery. This application is for a transmitter only. Is there a receiver that is approved separately, or is this device a transceiver? Thank you, Chris Harvey -----Original Message----- From: Chris Harvey Sent: Monday, October 13, 2003 10:53 AM To: Alice Wong @ hkstc ( [email protected] <mailto:[email protected]> ) Cc: Kitty @ HKSTC EED - Choy ( [email protected] <mailto:[email protected]> ); Marianne Bosley Subject: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice and Kitty: The Users Manual for this device indicates that it can operate from 88MHz to 105.5MHz, or a band of 17.5MHz. The test report shows data for one operating frequency (88.04MHz). According to FCC Rule 15.33 (m), Intentional radiators that operate/tune over more than 10MHz need to be tested at 3 operating frequencies, one at the bottom of the band, one at the center and one at the top of the band. Please provide data for compliance with FCC 15.239 (a) and (b) for the appropriate number of operating 'channels'. If this device only operates at 2 channels then please submit the data for those 2 channels. Please describe more detail how this audio (FM) modulated device was modulated during the Bandwidth test to ensure that the maximum bandwidth was captured in the plot, and how the EUT operating channel is changed. 3 Additionally, the Label submitted contains the statement required by FCC 15.19. However the label location has a different formatted label, which does not incorporate the 15.19 statement. Based on the size of the device you can request that the 15.19 statement be located in the Users Manual. Please be sure that the label, label location and Users manual information are consistent, and that if you wish to place the 15.19 statement in the Users Manual, that you submit a request to do this based on the small physical size of the EUT. Please submit the corrected information requested above so that the application review can be completed. Best regards, Chris Harvey EMC Lab Director MET Laboratories, Inc. 1-800-638-6057 x-310 <<User manual(88MHZ) r1.pdf>> <<FCC ID Label.pdf>> <<Bandwidth.pdf>>

1 Chris Harvey From:Chris Harvey Sent:Thursday, October 23, 2003 1:37 PM To:'alice_wong'; Chris Harvey Cc:EED - Choy, Kitty; K C Lee@hkstc; Marianne Bosley Subject:RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 Alice, the response satisfies all but one of the remaining open issues with this application. There is a problem with the Grantee Code RA5. This Grantee Code does not exist in the FCC database, which means that the FCC ID is not valid. Is it possible that the Grantee Code was filed for, but the fee was never paid? From earlier, the Label submitted contains the statement required by FCC 15.19. However the label location has a different formatted label, which does not incorporate the 15.19 statement. Based on the size of the device you can request that the 15.19 statement be located in the Users Manual. Please be sure that the label, label location and Users manual information are consistent, and that if you wish to place the 15.19 statement in the Users Manual, that you submit a request to do this based on the small physical size of the EUT. This still needs to be addressed. Please note, the following statement in FCC 15.215, which is stated as a recommendation and not a requirement: If a frequency stability is not specified in the regulations, it is recommended that the fundamental emission be kept within at least the central 80% of the permitted band in order to minimize the possibility of out-of-band operation. The operation at 88.04MHz with a 67.5kHz bandwidth does not meet this recommendation, although this does not violate the regulation. Please forward this information to the manufacturer so they can develop future products with this in consideration. We will await a response to these issues. Best regards, Chris Harvey -----Original Message----- From: alice_wong [mailto:[email protected]] Sent: Wednesday, October 22, 2003 10:46 PM To: [email protected] Cc: EED - Choy, Kitty; K C Lee@hkstc Subject: TCB Application FCC ID: RA5PGCHF01 MT#14533 Dear Chris, During the test,we would use cassette player with 1KHz tape and adjust to max. volume. besides, try different sound (very loud) to take the worst result (widthest) Another, client have update the user manual again. (Frequency 88MHz), please see attached file. Thanks Best Regards 2 Alice > > > > ----- Original Message ----- > > From: <[email protected]> > > To: <[email protected]>; <[email protected]> > > Cc: <[email protected]>; <[email protected]> > > Sent: Friday, October 17, 2003 6:20 PM > > Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > > Alice, the questions were not answered. You have submitted a new > > bandwidth > > > plot but not answered the question of how the device was modulated (was > it > > > with a loud voice or signal generator, what frequency tone, what > > > level > of > > > tone). You submitted a label with FCC ID: PG-CHF-01 (I think this > > > is > the > > > model number, not the FC ID number), when the original aplication > > > was > for > > > FCC ID: RA5PGCHF01. You re-submitted the Users manual listing > > > both > 88.MHz > > > and 105.55MHz in section 1.b, when you have stated that the device only > > > operates at 88.04MHz. > > > > > > It appears that each of the questions is still unanswered. Please > address > > > these questions so this application can be completed. > > > > > > Best regards, > > > > > > Chris Harvey > > > > > > -----Original Message----- > > > From: alice_wong > > > To: [email protected] > > > Cc: [email protected]; EED - Choy, Kitty > > > Sent: 10/17/2003 6:03 AM > > > Subject: Re: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Dear Chris, > > > 3 > > > Please see attached file for revised FCC Label, Manual & bandwidth > > > (is that ok?). If have any question, please let me know. > > > > > > Thanks & Have a nice day > > > Best Regards > > > Alice > > > > > > > > > ----- Original Message ----- > > > From: [email protected] <mailto:[email protected]> > > > To: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Sent: Tuesday, October 14, 2003 7:30 PM > > > Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Alice thank you for this information. I am still waiting for > > > Modulation/bandwidth information and the Label information from my > > > original e-mail below. Please review the original e-mail and > > > respond to > > > those 2 items so the application review can be completed. Please > > > contact me if you have any further questions. > > > > > > Best regards, > > > > > > Chris Harvey > > > -----Original Message----- > > > From: alice_wong [mailto:[email protected]] > > > Sent: Monday, October 13, 2003 10:56 PM > > > To: [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; EED - Choy, Kitty > > > Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > > > > Hi Marianne, > > > > > > We confirm customer is apply TX only. > > > EUT is fixed frequency on 88.04 MHz. > > > > > > Best Regards > > > Alice > > > > > > ----- Original Message ----- > > > From: alice_wong <mailto:[email protected]> > > > To: M K Law <mailto:[email protected]> > > > Sent: Tuesday, October 14, 2003 9:08 AM 4 > > > Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Dear Kit, > > > > > > Please confirm this job HM110795 is transmitter only or > > > transceiver? > > > > > > Best Regards > > > Alice > > > > > > ----- Original Message ----- > > > From: [email protected] <mailto:[email protected]> > > > To: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Sent: Monday, October 13, 20…

Text truncated - open the document above for the full version.

1 Chris Harvey From:alice_wong [[email protected]] Sent:Wednesday, October 22, 2003 10:46 PM To:[email protected] Cc:EED - Choy, Kitty; K C Lee@hkstc Subject:TCB Application FCC ID: RA5PGCHF01 MT#14533 User manual(88MHZ) r2.pdf (128... Dear Chris, During the test,we would use cassette player with 1KHz tape and adjust to max. volume. besides, try different sound (very loud) to take the worst result (widthest) Another, client have update the user manual again. (Frequency 88MHz), please see attached file. Thanks Best Regards Alice > > > > ----- Original Message ----- > > From: <[email protected]> > > To: <[email protected]>; <[email protected]> > > Cc: <[email protected]>; <[email protected]> > > Sent: Friday, October 17, 2003 6:20 PM > > Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > > Alice, the questions were not answered. You have submitted a new > > bandwidth > > > plot but not answered the question of how the device was modulated (was > it > > > with a loud voice or signal generator, what frequency tone, what > > > level > of > > > tone). You submitted a label with FCC ID: PG-CHF-01 (I think this > > > is > the > > > model number, not the FC ID number), when the original aplication > > > was > for > > > FCC ID: RA5PGCHF01. You re-submitted the Users manual listing > > > both > 88.MHz > > > and 105.55MHz in section 1.b, when you have stated that the device only 2 > > > operates at 88.04MHz. > > > > > > It appears that each of the questions is still unanswered. Please > address > > > these questions so this application can be completed. > > > > > > Best regards, > > > > > > Chris Harvey > > > > > > -----Original Message----- > > > From: alice_wong > > > To: [email protected] > > > Cc: [email protected]; EED - Choy, Kitty > > > Sent: 10/17/2003 6:03 AM > > > Subject: Re: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Dear Chris, > > > > > > Please see attached file for revised FCC Label, Manual & bandwidth > > > (is that ok?). If have any question, please let me know. > > > > > > Thanks & Have a nice day > > > Best Regards > > > Alice > > > > > > > > > ----- Original Message ----- > > > From: [email protected] <mailto:[email protected]> > > > To: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Sent: Tuesday, October 14, 2003 7:30 PM > > > Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Alice thank you for this information. I am still waiting for > > > Modulation/bandwidth information and the Label information from my > > > original e-mail below. Please review the original e-mail and > > > respond to > > > those 2 items so the application review can be completed. Please > > > contact me if you have any further questions. > > > > > > Best regards, > > > > > > Chris Harvey > > > -----Original Message----- > > > From: alice_wong [mailto:[email protected]] 3 > > > Sent: Monday, October 13, 2003 10:56 PM > > > To: [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; EED - Choy, Kitty > > > Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > > > > Hi Marianne, > > > > > > We confirm customer is apply TX only. > > > EUT is fixed frequency on 88.04 MHz. > > > > > > Best Regards > > > Alice > > > > > > ----- Original Message ----- > > > From: alice_wong <mailto:[email protected]> > > > To: M K Law <mailto:[email protected]> > > > Sent: Tuesday, October 14, 2003 9:08 AM > > > Subject: Fw: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Dear Kit, > > > > > > Please confirm this job HM110795 is transmitter only or > > > transceiver? > > > > > > Best Regards > > > Alice > > > > > > ----- Original Message ----- > > > From: [email protected] <mailto:[email protected]> > > > To: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Cc: [email protected] <mailto:[email protected]> ; > > > [email protected] <mailto:[email protected]> > > > Sent: Monday, October 13, 2003 11:13 PM > > > Subject: RE: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > Alice, I have one more question. One statement in the Users > > > Manual indicates that the Receiver will turn off after 45 minutes > > > to save battery. This application is for a transmitter only. Is > > > there a receiver that is approved separately, or is this device a > > > transceiver? > > > > > > Thank you, > > > > > > Chris Harvey > > > -----Original Message----- > > > From: Chris Harvey 4 > > > Sent: Monday, October 13, 2003 10:53 AM > > > To: Alice Wong @ hkstc ( [email protected] > > > <mailto:[email protected]> ) > > > Cc: Kitty @ HKSTC EED - Choy ( [email protected] > > > <mailto:[email protected]> ); Marianne Bosley > > > Subject: TCB Application FCC ID: RA5PGCHF01 MT#14533 > > > > > > > > > Alice and Kitty: > > > > > > > > > > > > The Users Manual for this device indicates that it can operate > > > from 88MHz to 105.5MHz, or a band of 17.5MHz. The test report > > > shows data for > > > one operating frequency (88.04MHz). According to FCC Rule 15.33 > > > (m), Intentional radiators that operate/tune over more than 10MHz > > > need to be > > > tested at 3 operating frequencies, one at the bottom of the band, > > > one at > > > the center and one at the top of the band. Please provide data > > > for compliance with FCC 15.239 (a) and (b) for the appropriate > > > number of operating 'channels'. If this device only operates at 2 > > > channe…
