RMZ-A26Sound Sport IPX5 True Wireless Auto Pair Earbuds

front side Sound Sport IPX5 True Wireless Auto Pair Earbuds | 01 | 05 | 03 | 07 | 02 | 06 | 04 | 08 Instruction Manual 7197-38 Hello! This is your instruction manual, to help create the best possible experience with this cool product. IPX5 Water Resistant EarbudsPower Case Type C Charging Cable Place the earbuds into the power case. Make sure the earbuds are securely placed into the case. Earbuds will automatically begin to charge. The LED on the earbuds will turn Red. The LED on the Earbuds and Case will turn off when the earbuds are fully charged. You’ll hear a beep prompt when the earbuds need charged. The Earbuds will play audio at max volume for 4.5hrs. Use the provided Type-C Charging Cable to connect to an adapter or computer to charge the power case. When charging the power case 4 WHITE LED lights will indicate the level of charge. The case can also be charged through wireless charging. Place the case onto a wireless charging pad to begin the charge. LED Lights appear when the charge has started Remove both earbuds from the power case, you’ll hear a voice prompt saying “Power On”. Once you both earbuds say “connected” they are synced to each other. If done successfully the one earbud LED Go into your Bluetooth options and select the pairing name “Sound Sport”. If done successfully you will hear the voice prompt “Connected”. You can now enjoy your favorite Audio. Previously connected earbuds will connect automatically after they’re powered ON. If you don’t connect to the earbuds within 3 minutes the earbuds will automatically power OFF. Take out your earbuds from the charging case or press and hold the multi-function button for 3 seconds. You’ll hear the voice prompt “Power On”. Play/Pause Press the Multi-function button on the Right or Left Earbud to play/pause your audio. Next / Previous Song: Next song: Double press the multi-function button on the RIGHT earbud. Previous song: Triple press the Multi-function button on the RIGHT earbud. Volume Controls: Turn UP volume: Double press the multi-function button on the LEFT earbud. Turn DOWN volume: Triple press the multi-function button on the LEFT earbud. If you’re having trouble pairing your earbuds please turn off your Bluetooth. Place both earbuds back into the charged power case. Now remove the earbuds and follow the instructions under “Pairing Both Earbuds”. Answering/End Call: Press the multifunction button once to answer an incoming call, and again to end the call. Reject a Call: Press and hold the multifunction button to reject an incoming call. To turn off your earbuds place them both back into the power case. You can also power off your earbuds by holding the multi-function button on both earbuds until you hear the voice prompt “Power Off”. Charging Case Multi-function button Microphone/Earbud LED Charging case LED (Earbud charging) Type-C input 1. 2. 3. 4. 5. • • • • • • • • • • • • • • • • • • • • • • • • • • • • Safety Precautions: Included Contents: Features: Charging: Pairing Both Earbuds: 1. Pairing: First time 2. Connecting to Bluetooth 3. Power ON 6. Playing Audio 5. Calling 4. Power OFF Resetting your earbuds: 1. Charging the earbuds 2. Charging the power case Please follow the rules described in this manual closely to ensure your safety. Before using the earbuds, we would strongly encourage you read this manual. Do not modify, repair or dismantle the earbuds or power bank. Do not use any liquids to clean the products. Do not use the earbuds near water, or intense temperatures. 1. 2. 3. 4. 5. Long press the Right or Left Earbud multifunction button and you will hear a beep prompt to indicate that your voice Assistand/Siri is “Activated” and waiting your commands. • 7. Activate Voice Assistant 100 5025 back side | 09 | 13 | 11 | 15 | 10 | 14 | 12 | 16| 17 Charging time Charging time Waterproof Rating Bluetooth Range Play time 1.5 hrs (from 0-100) 3 hrs (from 0-100) IPX5 10m 4.5 hrs WARNING–When using this product, basic precautions should always be followed, including the following: Fully read the instructions before using the product. The unit will only achieve full performance after 2 or 3 completed charge and discharge cycles. Do not overcharge your case. The unit may become hot under excessive use. Remove your case once it is fully charged. Never charge your case for more than 7 hours at a time. To reduce the risk of injury, close supervision is required when the product is used near children. Do not expose the device to moisture. Do not use the device in excess of its output rating. Overload outputs above the rating may explosion or risk of injury. Do not disassemble the device. Take the device required. Incorrect reassembly may result in a above 212ºF/100°C may cause explosion. person using only identical replacement parts. This will ensure that the safety of the product is maintained. The Power Case can charge the earbuds 5x (from 0-100). Mobile devices cannot connect with the earbuds if the earbuds are not in pairing mode. If the earbuds dont connect to Bluetooth within 3 minutes, the earbuds will power off. Function Function Start-up failure No sound when paired No indication during charging Shut down automatically Noise during calls Low volume Signal interrupted low battery wrong pairing Earbuds aren’t securely inserted low battery mobile device is too far away earbuds are turned down low environment disturbance, distance to far from mobile device charge earbuds and power case re-pairing check earbuds, and try again charge earbuds and power case bring mobile device closer adjust earbuds to comfort & sound bring the mobile device closer to the earbuds Troubleshooting Safety Precautions IssueReasonSolution 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. MADE IN CHINA Short Press: Play/Pause Audio Double Press the multifunction button to change the song. Long Press the multifunction button until you hear a beep prompt. Following the beep your Siri/Hey Google will be activated. Take out the earbud from the charging c…

Text truncated - open the document above for the full version.

Declaration Sound Sport IPX5 True Wireless Auto Pair Earbuds Model Number: A26, 7197-38 FCC ID: RMZ-A26 The device have left and right earphones ，the left and right earphones are electrically identical. Name: Judy Zhu Title: Manager Company: Richen Industrial Co., Ltd.

Richen Industrial Co.,Ltd Rm.1688, Building A, Bantian International Center, No.5 Huancheng South Street, Longgang, 518129,Shenzhen, China Tel.: 0755-82797557 Fax: 0755-82797557 Statement We Richen Industrial Co.,Ltd. Hereby Declare that The p roduct Sound Sport IPX5 Tr ue Wireless Auto Pair Earbuds models no. A26 and 7197-38 are all identical in interior structure, electrical circuits and components, but only model names are different for the marketing requ irement. The device have left and right earphones ,the left and right ea rphones are electrically identical. Your assistance o n this matter is highly appreciated. Yours sincerely, Signature: Company Name: Richen Industrial Co.,Ltd

Nov 19, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RMZ-A26 Product Name: Sound Sport IPX5 True Wireless Auto Pair Earbuds Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Nov 19, 2020 Agency agreement expiration date: Usually Give 8 - 12 Months By: Judy Zhu Signature Printed Title: Manager On behalf of : Richen Industrial Co.,Ltd Telephone: 0755-82797557

Nov 19, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China. (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Richen Industrial Co.,Ltd./ Rm.1688, Building A, Bantian International Center, No.5 Huancheng South Street, Longgang, 518129,Shenzhen, China Dated this Nov 19, 2020 A gency agreement expiration date:Usually Give 8 -12 Months By: Judy Zhu Si gnature Printed Title: Mana ger On behalf of : Richen Industrial Co.,Ltd Telephone: 0755-82797557

Photographs – EUT Photographs – EUT Photographs – EUT R- Earbuds Photographs – EUT R- Earbuds Photographs – EUT L- Earbuds Photographs – EUT L- Earbuds

订单号 瑞辰有限公司 深圳市龙岗区坂田国际中心A栋1688室 URL:www.iletech.com.cn 型号 A26 Date Created 2020/09/02 REV 1 版本 PANTONE 428 C 外观标志颜色 (ifidelity Logo Color): FCC ID:RMZ-A26 FCC ID:RMZ-A26 Mark Location: Label Location

Photographs – EUT R- Earbuds Photographs – EUT R- Earbuds Photographs – EUT R- Earbuds Photographs – EUT L- Earbuds

FCC ID: RMZ-A26 RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provision s of this secti on shal l be operate d in a manner that ensure that the publi c is not ex po sed to rad io frequency energ y level in ex cess of the Commission’s guideline. This is a Po rtable dev ice . The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (Worse case) [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =1.1/5 * 1.55= 0.34, this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. The SAR measurement is not necessary.

Report No.: TW2010194E File reference No.: 2020-11-03 Applicant: Richen Industrial Co., Ltd. Product: Sound Sport IPX5 True Wireless Auto Pair Earbuds Model No.: A26, 7197-38 Trademark: N/A Test Standards: FCC Part 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15.247 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: November 03, 2020 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: TW2010194E Page 2 of 91 Date: 2020-11-03 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: TW2010194E Page 3 of 91 Date: 2020-11-03 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty................................................................................................. 5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operatin…

Text truncated - open the document above for the full version.

Conducted Emission Test Setup: Radiated Emission Test Setup:
