RMZ-BTH024TBluetooth Headphone

MEMOREX-CE.COM User Guide Please read these instructions completely before operating this product. CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. ATTENTION: The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING: Users of this product are cautioned not to make modifications or changes that are not approved by MEM-CE, LLC., doing so may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND FULLY INSERT. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 4.MRX-MHBT0245 will appear in list of discoverable devices on smartphone or tablet. There will be a tone indicating the Bluetooth connection is now enabled, and the Blue LED will blink slowly when successfully paired. 5.Refer to your mobile device for instruction on enabling Bluetooth. It is usually located in the Settings menu or similar location. If connection is lost after successful pairing, check to make sure the distance between speaker and Bluetooth-enabled device does not exceed 30 ft/10 m. If the connection is interrupted due to low battery, switch the speaker off, recharge the internal battery, and repeat steps when fully charged. Note: When powered ON and in Bluetooth source mode, the Headphones will automatically try to connect to the most recently played paired device when available. Listen to Music 1.When the Bluetooth-enabled device is paired, use your mobile device to Play and Pause music and adjust Volume Controls under the Music or Conversation Mode. 2.In Music mode, press the Skip Back button to play Previous song, or Skip Next button to play Next song. Press the Play/Pause button (middle of Multi-Function control) to Pause the music; press again to continue Play. 3.Use the Volume +/– buttons to increase or decrease the volume while in music mode Using Gesture Touch Operations: 1.For Volume Control while wearing Headphone Set, glide one finger upward or towards right side in the Gesture Touch Area for Volume Up, or glide one finger downward or towards left side for Volume Down. 2.To advance to Next song, glide two fingers upward or towards the right. 3.To play Previous song, glide two fingers downward or towards the left. 4.To Pause/Play music, click the center of the touch area once. To Answer or End Calls: While wearing the Headphones answer an incoming call with built-in speaker from your Bluetooth-enabled smartphone by pressing the Power Button. •Reject an incoming call by pressing and holding the Power/Phone button for 2 seconds. •End a conversation by pressing and holding the Power/Phone button for 2 seconds. •To Redial the last call, double-click the Power/Phone button and the Headphones will remotely and automatically dial the last phone number. AUTO OFF The BTH-024T will automatically shut off if there is no music from a Line-in source or from a Bluetooth-enabled device for more than 20 minutes. LINE IN AUDIO JACK 1.Insert one end of the audio cable (included) into the Line Out Jack (or Headphone Jack) on your external audio device and the other end into the Line-In Jack. 2.Use the connected external audio device to play and pause music. Sound will be heard through the headphone set. 3.Adjust the speaker volume level either by pushing the “+” or “–” Volume Buttons on the headphone set, or by using the volume controls on the mobile device. SURGE PROTECTORS: It is recommended to use a surge protector for AC connection. Lightning and power surges ARE NOT covered under warranty for this product. MEM-CE, LLC. 11485 Valley View Road, Eden Prairie, MN 55344 USA MEMOREX-CE.COM Memorex and the Memorex logo are trademarks of Imation Corp and its affiliates. The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Imation Corp is under license. All other trademarks are the property of their respe…

Text truncated - open the document above for the full version.

DATE : May 25, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RMZ-BTH024T Product Name: Bluetooth Headphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this May 25, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Judy Zhu Signature Printed Title: Manager On behalf of : Richen Industrial Co.,Ltd Telephone: 0755-83268139

Outside view Outside view Outside view

Mark Location: Label Location

ILE Bluetooth Headphone Model No.: BTH-024T Internal Battery: 3.7V Input: 5 V FCC ID: RMZ-BTH024T This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Inside view Inside view

RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (BLE is the Worse Case): [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =2.00/5 * 1.57= 0.63, this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. The SAR measurement is not necessary.

ISO/IEC17025Accredited Lab. Report No: FCC 1504225-02 File reference No: 2015-05-26 Applicant: Richen Industrial Co., Ltd. Product: Bluetooth Headphone Model No: BTH-024T Trademark: ILE Test Standards: FCC Part 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15.247 and RSS-210 Issue 8 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: May 26, 2015 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Room 512-519, 5/F., East Tower, Building 4, Anhua Industrial Zone, Futian District, Shenzhen, Guangdong, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: FCC1504225-02 Page 2 of 45 Date: 2015-05-26 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement˖ The testing quality ability of our laboratory meet with “Quality Law of People’s Republic of China” Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAL/AC01:2002 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC-Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-02. Report No: FCC1504225-02 Page 3 of 45 Date: 2015-05-26 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT ........................................................................................... 4 1.4 Submitted Sample.............................................................................................. 4 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty............................................................................................... 5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification.............................................................................................7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condition....................................................................................9 5.5 Conducted Emission Limit............…

Text truncated - open the document above for the full version.

Conducted Emission Test Setup: Radiated Emission Test Setup:
