BTS-51 BM3251_20140808 V1.0 1 User’s Manual Model: BTS-51 Bluetooth Speaker (Splash-proof) BTS-17 BM3251_20140808 V1.0 2 A. Important Don’ts • Do not place naked flames, such as lighted candles on or near the product. • Do not place objects filled with liquids, such as vases on or near the product. • Do not use or store this product in a place where it is subject to direct sunlight, heat, excessive dust or vibration. • Do not keep or store this product in wet conditions for long period. • Do not clean this product with water or other liquids. • Do not block or cover the slots and holes in the product. • Do not push foreign objects into the slots or holes in the product. • Do not attempt to open this product yourself. There are no user serviceable parts inside. • Do not allow children access to plastic bags. Safety Instructions • Before using this product, read and follow all warnings and instructions. • This product is not intended for use by young children. Young children should be properly supervised. • This product is intended for household use only and not for commercial or industrial use. • Do not expose to dripping or splashing. • No naked flame sources, such as lighted candles, should be placed on the product. • Ventilation should not be impeded by covering ventilation openings with items such as newspapers, table cloths, curtains and the like. • Make sure the unit is adjusted to a stable position. Damage caused by using this product in an unstable position or by failure to follow any other warning or precaution contained within this user manual will not be covered by warranty. Warning • Never remove the casing of this apparatus. • Never place this apparatus on the other electrical equipment. Notice • If at any time in the future you should need to dispose of this product please note that: All batteries and accumulators need to be removed from this product (Removal of Waste Batteries and Accumulators). • Always bring your product to a professional to remove the built-in battery. BTS-17 BM3251_20140808 V1.0 3 B. Outlook and Controls Item Control 1 Button (ON / OFF) 2 Charge LED Indicator 3 Bluetooth LED Indicator (Blue) 4 Button 5 Button 6 Button 7 Button 8 MIC Hole 9 Micro USB socket (Under Rubber Seal Cover) 10 Vacuum Cupule 11 Speaker C. About the rechargeable Battery & Charging 1. Regarding the lithium rechargeable battery
This Bluetooth Speaker has an internal, non–user-replaceable battery. For best results, the first time you use this Bluetooth Speaker, let it charge for about 2 ~ 3 hours or until the “Charge LED (2)” Indicator light from On to off which show you the battery is fully charged.
For maintain the battery life and performance, if speaker isn’t used for a while, the battery might need to be recharged. Charge the battery at least once every month. 2. To recharge the built-in battery:
Connect the Bluetooth Speaker’s “Micro USB socket (9)” with the Computer’s USB port through USB cable.
The “Charge LED (2)” Indicator will turn On in red, the battery is in charging. BTS-17 BM3251_20140808 V1.0 4
The “Charge LED (2)” Indicator will turn Off when the rechargeable battery is fully charged.
Disconnect the USB cable when it is done. D. Power ON and Pairing 1. Press and hold the “ (1)” button to turn On the device. A series of tones will sound, followed by voice announce “It is pairing waiting for device connecting” from speaker. And the “Bluetooth LED (3)” indicator is fast blinking in Blue. 2. Then activate the Bluetooth function in your mobile device (such as Mobile Phone or Personal Computer), the device will enter to Bluetooth searching mode automatically, if not, tap the relate selection to manually enter to searching mode. (refer to your device’s manual when necessary) 3. Your mobile device should show “BTS-17” in list, and then select it for pairing. Waiting for some seconds and you will see connected message as shown on your mobile device. (For some Bluetooth devices, you may need to input “0000” as pairing password) 4. If pairing is successful, voices announce “paired” from speakers, and the “Bluetooth LED (3)” indicator will slow blinking each 3 ~ 4 seconds once. 5. Now, you can start to music play from the mobile device by it music player program. 6. Press and hold the “ (1)” button to turn Off the device when it is not in use. Note: the device will turn Off automatically in about 8 minutes when there have not Bluetooth connected phone at placed. E. Disconnect from paired device 1. Press and hold the “ (7)” button to switch to new “Searching / Pairing” mode, the paired device will disconnect. 2. Or, you can choose “Disconnect” from Bluetooth paired device list on your mobile device. 3. In this case; the Bluetooth Speaker will turn back into “Searching / Pairing” mode in seconds, a series of tones will sound and the “Bluetooth LED (3)” indicator will fast blinking in Blue from slow. 4. Now, you can process for new mobile device pair or power Off the Bluetooth Speaker as you wanted. F. Auto re-connect with paired device and New pairing 1. Every time you turn On the Bluetooth speaker power; it will firstly searching for the mobile device, which has been paired previously BTS-17 BM3251_20140808 V1.0 5 and still in record. The Bluetooth Speaker will re-connect this mobile device as priority if it is in Bluetooth searching device mode. 2. If not found in some seconds, the Bluetooth Speaker then is turn into new pairing mode internally. 3. Now you can process for new mobile device pair. (refer to item D.2~6 methods) G. Bluetooth Music Playing Control Function 1. In playing music, press “ (7)” button to pause the music. To resume the music press it again. 2. Press and hold the “ (5)” button to increases the volume level. 3. Press and hold the “ (4)” button to decreases the volume level. 4. When maximum or minimum volume is reached, a series of tones will sound. 5. Press once the “ (5)” button to go to next music. 6. Press once the “ (4)” button to go to previ…
