RNB-OEM100Networking Transceiver Module

OEM100 MODULE VERSION 1.1 Hardware Manual www.sensicast.com HARDWARE MANUAL OEM100 Module VERSION 1.1 Sensicast Systems, Inc. 220-3 Reservoir Street Needham, MA 02494 Phone 781.453.2555 [email protected] www.sensicast.com Part # 1390 – OEM100 Module Hardware Manual Copyright 2004 Sensicast Systems, Inc. All rights reserved. Sensicast and SensiNet are trademarks of Sensicast Systems, Inc. in the United States and/or other countries. All other trademarks are property of their respective owners. In the interest of product improvement, information and specifications herein are subject to change without notice. 2 FCC Statement The H900 equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by Sensicast could void the user’s authority to operate this equipment. FCC RF Radiation Exposure Statement: The module complies with FCC's RF exposure requirements and the module must not be co-located or operated in conjunction with any other antenna or transmitter. FCC Labeling The module is labeled with its own FCC ID number (RNB-OEM100). If this number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label with the following wording: “Contains FCC ID:RNB-OEM100” 3 Introduction This design guide is intended to provide a good understanding of the functionality of the OEM100 module. The intended audience is the engineer responsible for integrating the OEM100 into a product. Description and Specifications The OEM100 is a component of the Sensicast H900 Wireless Sensor Network Platform – a completely self- configuring, self-healing, power managed sensor network. Powered by SensiNet, Sensicast’s proprietary mesh networking software, the OEM100 is the most reliable mesh networking radio module on the market today. It has a range of over 1000 feet (outdoors) and 300 feet (indoors, non-line of site). Furthermore, SensiNet uses frequency diverse radio algorithms to ensue reliable, clear channel communication even in the most harsh radio environments. In addition, off-the-shelf H900 infrastructure hardware and software for constructing and maintaining your mesh network is available from Sensicast. Block diagram Antenna There is a board mounted antenna on the device. For best performance, care should be taken to keep metal components away from the antenna. Radio Transceiver The radio is under control of the OEM100’s microcontroller and is contained inside the metal shield. Microcontroller The SensiNet software, including the sensor API, runs on this microcontroller. It includes onboard flash memory, RAM, and analog and digital I/O and a 32Khz real time clock. LEDs There are three LEDS: red, yellow and green that are firmware controlled. Optional temperature and humidity sensor The OEM100 can be preloaded with a temperature and humidity sensor. Please contact Sensicast for temperature and humidity specifications. Antenna Radio Transceiver Microcontroller Connectors Optional temperature and humidity sensor LEDs 4 Connectors The primary interconnection is P3, the 41 position board to board, header (Hirose p/n DF9A-41P-1V(20); mates with: Hirose p/n DF9A-41S-1V(20)) on the bottom of the assembly. Optionally, power can be brought to the board through P5, a two position, right angle wire to board, header (JST p/n S2B-PH-K-S, mate: JST p/n PHR-2). Here is a schematic drawing of P3 and a list of signal descriptions for both connectors: J3 Pin OEM100 Signal Type OEM100 Description 1 GND Ground Ground 2 GND Ground Ground 3 VCC Power Power 4 VCC Power Power 5 GND Ground Ground 6 DIG2/EXTINT2 I/O General I/O / external interrupt 7 SPARE1 I/O General I/O 8 DIG1/EXTINT1 I/O General I/O / external interrupt 9 SPARE0 I/O General I/O 10 DIG0/EXTINT0 Input Initialization 11 AN1 Input Analog In 12 SDA I/O Two-wire interface data 13 AN0 Input Analog In 5 14 DIG3/CNT3 I/O General I/O / external interrupt / counter in 15 GND Ground Ground 16 RTS Output UART RTS 17 RESET# Input Reset (active low) 18 CTS Input UART CTS 19 TCK Input JTAG programming 20 SCK I/O Two-wire interface clock 21 TMS Input JTAG programming 22 SPARE1 I/O General I/O 23 TDI Input JTAG programming 24 Reserved 25 TDO Output JTAG programming 26 Reserved 27 Reserved 28 TXD1 Output UART transmit data 29 Reserved 30 RXD1 Input UART RX 31 Reserved 32 Reserved 33 Reserved 34 FLAG0 Output Initialization 35 Reserved 36 Reserved 37 Reserved 38 VSUPPLY Power Power 39 VSUPPLY Power Power 40 GND Ground Ground 41 GND Ground Ground J5 Pin OEM100 Signal Type OEM100 Description 1 VSUPPLY Power Power 2 GND Ground Ground Functional descriptions Power: The module is powered by a DC power source from 2.0V to 3.3V. The absolute maximum voltage that should be applied is 3.6V. VCC and VSUPPLY are connected through a zero ohm resistor on the module. The power plane is attached directly to VCC. P3 can carry 100mA per pin; P5 can carry 500mA per pin. Ground: These are attached to the ground plane of the module. P3 can carry 100mA per pin; P5 can carry 500mA per pin. General I/O: These are bidirectional, CMOS level, digital signals running between VCC and GND. General I/O / external interrupt: These are bidirectional, CMOS level, digital signals running between VCC and GND. They can also be configured as external, hardware interrupts. General I/O / external interrupt / counter in: This is a bidirectional, CMOS level, digital signal running between VCC and GND. It can be configured as external, hardware interrupt or as an input to a counter. Analog In: These are analog inputs. 6 Initialization: These pins are digital inputs and outputs used during the initialization of the module. Two-wire interface: Both SDA …

Text truncated - open the document above for the full version.

Sensicast systems SensicastSystems,Inc. 220-3ReservoirSt. Needham,MA02494 P: 781.453.2555 F: 781.453.0601 http://www.sensicast.com December15,2004 To: FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046-1609 Curtis-StrausLLCTCB 527GreatRoad Littleton,MA02702 Re:ConfidentialityRequest Gentlemen: Thisletteris tocomplywith47CFR0.457(d)(2)pertainingtoconfidentialmaterial. SensicastSystemsrequeststhatthefollowingdocumentsregardingthissubmissionfor FCCIDNumberRNB-OEMI00bekeptconfidential: 1.Schematics 2.BlockDiagram 3.Circuit/TechnicalDescription Thematerialabovecontainstechnicaldata,whichwouldcustomarilybeguardedfrom competitors. Sincerely, '1d L~j(/;/j1Jt~ 'HaroldJell(l6::!er VicePresident,Operations SensicastSystems,Inc. December15,2004 \

Response to TCB Findings 1. Only the power cable appears to be attached to the device during radiated emissions test. Please explain why the data input port was not populated. Response: The reason there was no data cable is that baseband data is expected to flow to and from a carrier board. The only data interconnect on the OEM100 is a board to board stacking connector; there is no connector for a cable. This is consistent with the description of a carrier board in the hardware manual (see page 7). 2. Please supply the 20dB bandwidth plot for the module. The data is mentioned in the report, but the plot is missing. Response: 20dB plot supplied. 3. Have all the tests presented in this report been performed at nominal voltage of 3.6V, including previous test data used? The voltage variation data suggests that at lower voltages the power levels will drop. Please clarify. Response: The eut has a built in threshold which does not allow it to stay on beyond a certain value. All new testing was performed at the nominal value. The CEMI data is supplied in the report. In the previous application the node was battery powered only so CEMI was not done. For modular testing, it was determined that a 3.6V input to the module provided the highest output power. All testing performed specifically on the module was done at 3.6V. Antenna port conducted data for the module was taken from the original node application which was tested with a 3V battery. The maximum deviation in the POP of the device due to voltage input variations (table pg 15) is 10.8dB with the minimum power at 1.6V and the maximum at 3.6V. Since the device at 3V passed the limit by more than 20dB, the boost in power caused by 3.6V operation will be well within the limit.

v)Sensicast systems LetterofAgency Agent'sAuthorizationLetter November30,2004 I,anofficerofSensicastSystems,Inc.,doherebyauthorize,untilfurthernotice,Curtis-Straus LLC,of527GreatRoad,Littleton,MA01460,toactonourbehalfindealingsbeforethe FederalCommunicationsCommissionwithrespecttoallmattersrelatingtoequipment authorizationsunder47CFR.Thisauthorizationincluded,butit notlimitedto,thesigningof Form731. I certifythatnoparty(asdefinedin47CFR1.2002)tothisapplication,includingmyself,is subjecttoa denialoffederalbenefits,thatincludeFCCbenefits,pursuanttosection5301ofthe Anti-DrugAbuseActof1988,21D.S.C.,853A. C;;?M ~ dB~: 'N-/t,y~ H.{.;ff"'"'". VicePresidentofEngineeringandOperations SensicastSystems,Inc. 220-3ReservoirSt. Needham,MA02494 P:781.453.2555 F:781.453.0601 http://www.sensicast.com

Sensicast ,,'systems SensicastSystems,Inc. 220-3ReservoirSt. Needham,MA02494 P: 781.453.2555 F: 781.453.0601 http://www.sensicast.com December15,2004 Gentlemen: ThefollowinginformationisbeingprovidedpertherequirementsofDAOO-1407regarding modularapprovalofPart15devices. Thistransceiverisa completeRFmodulewithanintegralreferenceoscillator. Externalconnectionsareprovidedforpoweranddatacommunications. ThefollowingnumbereditemscorrespondtosimilarlynumberedparagraphsinDAOO-1407. Eachitemis a responsetotherequirementsofthatdocument. 1)ThemodulehasintegralRFshieldingtoisolateitfromsurroundingequipmentandthe largerenvironmentingeneral. 2)Allinputsareprocessedasdatabytheon-boardmicro-controllerTheoutsideuserhasno directcontrolofthetransmitmodulationscheme.Basebanddataarrivingatthemodule alwaysgetbufferedinoneofthemicrocontrollersinternalregisters;thisdataistransferred toanoutgoingdatabufferbythemicrocontrollerbeforebeingsenttotheradioIC.Under excessivedatainputrateconditions,theexcessdataisignoredandit isprocessedonlyat therateatwhichthemicrocontrollerreadsit fromtheregisters. 3)Thereisnota hardwarevoltageregulatoronboard.Instead,themicro-controllermonitors powersupplyvoltageona continuousbasis.Shouldthesupplyvoltagebefoundtobe outsideofthenormalspecifiedoperatingparameterstheunitwillrefusetotransmit. Further,conductedtestinghasshownthattheunitoperateswithinthestatedPart15 requirementswhenoperatedwithinthespecifiedsupplyvoltagerange. 4)Theantennais solderedtotheboardandis permanentlyattachedtothemodule. 5)Themodulewastestedina stand-aloneconfigurationandfoundtobecompliantwithPart 15regulations 6)AnFCCIDlabelisaffixedtoeachunitatthetimeofmanufacture.Informationisalso clearlypresentedintheuserguideaboutlabelingrequirementsofthefinalassembly. 7)ThisunitiscompliantwithPart15.247.Installationandotherrequirementsarepresented intheuserguidetoallowtheunittobecorrectlyinstalled. 8)TheunitiscompliantwiththeRFexposurerequirementsofPart15.247. FurtherinformationmaybeobtainedfromSensicastSystems,Inc. n£6~~ In'~ SeniorPrincipalHardwareEngineer SensicastSystems,Inc.

Report: E0977-1

DATA GUIDE “SPLATCH” PLANAR ANTENNAS INTRODUCTION The “Splatch” is a breakthrough in compact antenna technology. It combines excellent performance and cost-effectiveness into an antenna package that can be integrated, even by designers lacking RF test equipment. Despite its simplicity and ease of use the “Splatch” should not be thought of as “just any other part”. Its correct function is critical to the performance of your overall device. Dropping the “Splatch” in the center of your board like any popcorn IC will likely yield dismal results. It is critical to follow the guidelines below in order to obtain proper function. 0.062" 1 GROUNDED LINE PLANAR ANTENNA 433-SP 1.102" 0.200" 0.540" 1 1 GROUNDED LINE PLANAR ANTENNA 433-SP ANT . FEED GR OUND GR OUND GR OUND GR OUND GR OUND 1 GROUNDED LINE PLANAR ANTENNA 433-SP Physical Dimensions Electrical Connections Preliminary - Revised 5/30/2000 APPLICATIONS INCLUDE: Remote control Keyless entry Garage / Gate openers Lighting control Medical monitoring Remote data transfer Fire / Security systems RFID Pagers PART # DESCRIPTION ANT-***-SPSplatch Planar Antenna *** Insert Frequency 315, 418, 433, 868, 916 Custom frequencies available with NRE. Splatch antennas are supplied in tube packaging - 20 pcs. per tube. Tape and reel available at extra cost on request. ORDERING INFORMATION FEATURES: Low Cost Eliminates unsightly external antennas Easily concealed Direct PCB mounting Reflow compatible Stable grounded-line element Excellent proximity performance 10MHz approximate useable bandwidth Page 2 ATTACHMENT The antenna pads are designed to support both hand and automated placement. Castellations have been provided to ease solder introduction during hand assembly. The parts are also fully compatible with the reflow process for automated assembly. APPLICATION CONSIDERATIONS When implemented correctly the “Splatch”will yield outstanding and repeat- able results. However, the “Splatch”was designed with very specific feed and mounting requirements. Failure by the designer to respect these require- ments will result in unsatisfactory performance. * The antenna is tuned for direct mounting to a product’s PCB. Mounting the antenna in any other manner will produce poor results. * The antenna should be fed with a trace <=.25". Longer runs or coax feeds are not recommended. * Nothing should be placed under or directly beside the antenna element. Generally, mounting the antenna at the front of a product as illustrated will yield the best results. Typical Remote Control Application 1 GROUNDED LINE PLANAR ANTENNA 433-SP 418 Groundplane on Rear of Board Vias To Groundplane No Groundplane/Copper/Trace Area - BARE PCB .25" or Less Microstripped Feedline Page 3 LAYOUT CONSIDERATIONS Improper placement of planes, traces or components will result in antenna nulls or complete detuning. First, the area under the antenna on all board layers should be completely free of components, traces, or groundplane. In addition, no components or traces should pass within .25" of the top, sides, front or back of the antenna. Ideally the antenna will be mounted at the top of the board and given an unobstructed field of view in all directions. Components placed in the area below the back edge of the antenna will have little effect since the antenna has a null at its back edge when referenced appropriately to groundplane. Components placed to the sides or top of the antenna or items such as displays mounted in proximity to the antenna will produce nulls and, possibly, detuning. The antenna may be referenced to groundplanes of all different surface areas; however, it has been optimized for a 1.5"x 3" plane area. The best performance and lowest VSWR will be obtained when referenced to a plane of similar area. The recommended pad layout is illustrated below. The top layer of the board generally has the antenna mounting pads and feed trace. The ground pads are connected to the groundplane layer through vias. Use care in the sizing and placement of the vias to prevent solder migration from the attachment pads during attachment. Pads and outline shown for groundplane position reference only. Top Layer Bottom Layer Vias To Groundplane 0.100" 0.090" FEED CONSIDERATIONS Like most reduced-size antennas the “Splatch”has a fairly high Q and thus exhibits narrow bandwidth characteristics. The single most critical element in insuring the optimum function of the “Splatch”is to minimize the length of the feed trace (Transmission Line) to the “Splatch”itself. The feed trace should be less than .25" and in all cases microstripped. The term “Microstrip”refers to a trace passed over groundplane of a width appropriate to create a 50-ohm transmission line between the module and the antenna. Since the antenna does not present a true and stable 50-ohm match, the feed trace tends to lower the antenna’s resonant frequency. Given the antenna’s narrow bandwidth, it can easily be detuned by the length of the feed trace; thus, the trace should be kept as short as possible. Additional microstrip details are available in the reference section of this guide SPLATCH SERIES PERFORMANCE DATA About These Measurements The typical performance graphs below were based on a "Splatch" antenna affixed to the test jig illustrated, and measured with a HP-8753D network ana- lyzer in a 20°-25°C environment. *As of the time of this publication, full pattern characterization data was not avail- able. Refer to the Linx website for periodic updates to this document. TYPICAL SMITH CHART TYPICAL VSWR GRAPHS SpecificationFrequencyUnitsNotes 315418433.92868900MHz Electrical Length1/4 λ1/4λ1/4λ1/4λ1/4λ Center Frequency315418433.92868916MHz1 Useable Bandwidth1010102040MHz Characteristic Impedence50Ω50Ω50Ω50Ω50ΩOhms1, 2 VSWR<1.7 Typ.<1.7 Typ. <1.7 Typ.<1.7 Typ. <1.7 Typ.1 Gain/<Loss>-10-6-5-2-11, 3, 4 Notes: 1. At Specified Frequency;2. VSWR <2.0;3. Relative to isotropic;4. Preliminary 1 -5.3926 Ω 70.607 pF CH1 S 11 1: 51.189 Ω STA…

Text truncated - open the document above for the full version.

RF Exposure Evaluation (node) A calculation based on FCC’s Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields (Edition 97-01) appears below. EIRP = 12.5dBm = 17.78mW The limit for general population/uncontrolled exposure is: 601.0][ 2 = cm mW S The distance from the antenna at which this radiation level will be reached is: S EIRP R π4 = 601.04 78.17 ∗ = π R cmR5.1=

Curtis-Straus LLC is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Test Report Report No EE0977-1 Client Sensicast Systems Phone 781-453-2555 Fax 781-453-0601 Models FCC ID RNB-OEM100 FRN 0009860149 Equipment Type Low Power Communication Device Transmitter Equipment Code DSS Results As detailed within this report Prepared by Mairaj Hussain – Test Engineer Authorized by Michael Buchholz – EMC Manager Issue Date 12/10/04 Conditions of issue This Test Report is issued subject to the conditions stated in ‘terms and conditions’ section of this REPORT:EE0977-1 FCC ID:RNB-OEM100 Page 2 of 25 _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Summary ...........................................................................................................3 Test Methodology..............................................................................................3 EUT Configuration.............................................................................................4 Statement of Conformity....................................................................................5 Test Data and Plots...........................................................................................6 Channel Separation - Node...........................................................................6 Number of Hopping Frequencies - Node.......................................................7 Time of Occupancy (Dwell Time) - Node.......................................................7 Peak Output Power - Node..........................................................................10 Conducted Spurious Emissions - Node.......................................................11 Conducted Band Edges - Node...................................................................12 Antenna Gains.............................................................................................14 Radiated Spurious Emissions......................................................................14 Section 15.31(e) ..........................................................................................15 AC Line Conducted Emission Measurements..............................................16 Test Equipment Used......................................................................................17 Terms And Conditions .....................................................................................21 A2LA Accreditation..........................................................................................21 REPORT:EE0977-1 FCC ID:RNB-OEM100 Page 3 of 25 _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Summary This report is an application for modular certification of a transmitter operating under 47 CFR F15.247 of the FCC rules provided for operation of frequency hopping spread spectrum transmitters. The product covered by this report is OEM 100. The product was tested using the methods outlined in FCC public notice DA 00-705 (FHSS), released March 30, 2000, FCC public notice DA 00- 1407 (modular) released June 26, 2000 and ANSI C63.4 (2003). The RF circuitry in OEM 100 is similar to the Node which was tested previously under FCC ID: RNBF19D8MN9LQ2WFA. OEM 100 was tested with all available options. Therefore, OEM100 testing also covers all other OEM series models, please see attached exhibit describing the differences among the OEM models. This report presents the data obtained during the testing of Node for compliance with FCC 15.247. Furthermore, additional testing was done to ensure that spurious emissions from the product comply with FCC 15.209 limits when product is operated without an enclosure. Test Methodology All testing was performed according to the procedures specified in ANSI C63.4 (2003). Frequency range investigated: 150KHz – 10GHz Measurement Distance: Frequency (MHz) Distance (m) Comments 0.15MHz – 30MHz - Conducted 30MHz – 10GHz - Conducted 30MHz – 10GHz (restricted band) 3 m Spurious The EUT was maximized around three orthogonal axes. This product can be powered via battery or DC provided by the host unit. All testing was performed using an external DC source. AC line conducted emissions were performed using a 50Ω\50μH LISN on the AC side of support power supply. All readings are peak unless otherwise noted. REPORT:EE0977-1 FCC ID:RNB-OEM100 Page 4 of 25 _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 EUT Configuration EUT Configuration Work Order: E0977 Company: Sensicast Systems Company Address: 220 Reservoir St. #9 Needham, MA 02494 Contact: John O Brien Person Present: John O Brien MNSN EUT: OEM100K66567 EUT Description: Wireless Integration Module EUT Max Fre quency: 928MHz Support Equipment: MNSN DC power supplyE3610A- EUT Cables: QtyShielded?LengthFerrites DC cable1No1 mNone Unpopulated EUT Ports: QtyReason None Software / Operating Mode Description: Transmitting packets; channel hopping; exercising all board functions Switching to receive mode in between transmissions. REPORT:EE0977-1 FCC ID:RNB-OEM100 Page 5 of 25 _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Statement of Conformity The 915 MHz FHSS RF Module has been found to conform with the following parts of the 47 CFR as detailed below: 47 CFR Part # 47 CFR Part # Comments 15.15(b) The product cont…

Text truncated - open the document above for the full version.

Report: E0977-1 FCC ID: RNB-OEM100

Report: E0977-1 Radiated emissions Radiated emissions Report: E0977-1 AC conducted emissions Report: E0977-1 AC conducted emissions Voltage variation Report: E0977-1
