RNE00515TXDigital Freezer /Refrigerator Thermometer

Instr uction Manual SAVE THIS MANUAL FOR FUTURE REFERENCE. CONTENTS Unpacking Instructions ...........2 Pac kage Contents ..................2 Pr oduct Registration ...............2 ... 2 ....3 Se tup ....................................4 Install or Replace Batter ies......4 Temperature Units ..................4 Placement Guidelines .............5 Using the Thermometer ...........6 Troubleshooting .....................7 Care & Maintenance ..............8 .........................8 FCC Infor mation ....................8 Customer Support ..................9 War ranty...............................9 Digital Refrig er ator/Freezer Thermometer model 00515 Questions? Contact Customer Support at www.AcuRite.com/support or email [email protected] Features & Benefits: Sensors Features & Benefits: Display Specifications 2 Congratulations on your new AcuRite product. To ensure t he best possible product perfor mance, please read this manual in its entirety and retain it for future r ef er ence. Unpacking Instr uctions Remove the protective film that is applied to the LCD screen prior to using this product. Locate the tab and peel off to remove. Package Contents Features & Benefits: Sensors 1. Display 2. Wireless Sensors (2) 3. Instruction Manual 1 6 5 44 1. Refrigerator Sensor 2. Freezer Sensor 3. Suction Cup / Shelf Clip For versatile mounting options. 4. A-B-C Switch ID code that must match displayʼs A-B-C switch to ensure units synchronize. 5. Battery Compartment 6. Wireless Signal Indicator Flashes when data is being sent to the display. 6 2 3 3 5 PR ODUCT REGISTRATION Register online to receive 1 year w ar ranty protection www.AcuRite.com IMPORTANT PR ODUCT MUST BE REGISTERED TO RECEIVE WARRANTY SERVICE 3 Display Features & Benefits 15. Fold-out Stand 16. Battery Compartment 17. °C/°F Button Select between degrees Celsius or Fahrenheit. 18. Integrated Hang Hole For easy wall mounting. 19. Magnet Mount 20. A-B-C Switch ID code that must match sensorʼs A-B-C switch to ensure units synchronize. 21. Battery Compartment Cover 1. & Buttons For setup preferences and to view all-time records. 2. SET Button For alarm setup preferences. 3. Freezer Sensor Signal Strength 4. Freezer Sensor Low Battery Indicator 5. Wireless Signal Indicators Flashes when sensor has lost signal from display. 6. Alarm ON Indicator 7. Min/Max Records Highest and lowest temperatures from the past 24 hours. 8. Freezer Sensor Current Temperature 9. & Buttons For alarm and records settings. 10. Refrigerator Sensor Current Temperature 11. Display Low Battery Indicator 12. Refrigerator Sensor Low Battery Indicator 13. Refrigerator Sensor Signal Strength 14. Button For alarm setup preferences. 2 3 5 6 15 16 18 17 1919 8 10 9 14 12 11 5 4 1 7 2021 13 4 SETUP Install or Replace Batter ies AcuRite r ecommends high quality alkaline batter ies for the best product perfor mance. Heavy duty or rec hargeable batter ies are not r ecommended. The freezer sensor req uir es lithium batter ies for low temperature conditions. Cold temperatures can cause alkaline batter ies to function impr operly. Use lit hium batter ies in the freezer sensor for temperatures below -4ºF / -20ºC. Select Degrees Fahrenheit or Celsius To select between degrees Fahrenheit (ºF) or Celsius (ºC) temperature units, press and release the “ºC/ºF” button, located on the back of the thermometer display. PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE WAY AND IN ACCORDANCE WITH YOUR LOC AL LAWS AND REGULATIONS. BATTERY SAFETY: Clean the batter y contacts and also those of the device prior to batter y installation. Remove batter ies fr om eq uipment which is no t to be used for an extended period of time. Follow the polarity (+/-) diagram in the batter y compartment. Pr omptl y remove dead batter ies from the device. Dispose of used batter ies properly. Only batter ies of the same or eq uivalent type as recommended are to be used. DO NOT incinerate used batter ies. DO N OT dispose of batter ies rec harge non-rec hargeable batter ies. DO NOT short-circuit the supply t er minals. Thermometer Display 1. Lif t up the batter y door and slide off the batter y compartment cover . 2. Insert 3 x AA batter ies into t he batter y compartment. Follow the polarity (+/-) diagram in the batter y compartment. 3. Replace the batter y cover . Sensors 1. Slide off the batter y compartment co vers, located on the front of the units. 2. Insert 2 x AA batter ies into t he batter y compartment. Follow the polarity (+/-) diagram in the batter y compartment. 3. Replace the batter y cover . -40ºF (-40ºC) (37°C) 100°F - 4ºF (-20ºC) ( 37°C) 100°F 5 Display Placement Place display in a dry area free of dirt and dust. Display is magnet mountable and has a fold-out stand for tabletop use. For wall mounting, hang using the keyhole located on the back of the unit. Sensor Placement • Both sensors will work in either the refrigerator or freezer, however the default alerts are set based on the sensor's indicated use (see page 2). • Each sensor is equipped with a silicon band to securely attach to a wire shelf. • Each sensor also includes a detachable suction cup that can be used to attach the sensor to the interior surface of the refrigerator. Please note: suction cups do not adhere well to freezing surfaces. • Display and sensors must be located within 75 ft (23 m) of each other. 6 Using the Thermometer High & Low Records OPERATION The thermometer displays high and low temperature records for all-time and the past 24 hours (rolling). All-time records reflect the highest and lowest temperatures recorded since the batteries were inserted or the records have been cleared. High and low records for the past 24 hours are shown on the display, by default. Press and the release the “ ” or “ ” button to view all-time records. If no buttons are pressed for 5 seconds, the display will return to normal operation mode. To clear the high records, press and hold the “ ” button for 5 seconds while …

Text truncated - open the document above for the full version.

Declaration of Authorization We Name: Chaney Instrument Co. Address: Flat 09,19/F.,Metro Centre Phase I, 32 Lam Hing Street, Kowloon Bay City: Kowloon, Hong Kong State: N/A Country: China Declare that: Name Representative of agent: Ms. Mandy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: Digital Freezer /Refrigerator Thermometer Type designation: 00515TX Trademark: ACURITE FCC ID: RNE00515TX on our behalf. Date: 2020-01-10 City: Kowloon, Hong Kong Name: Victor Mak Function: Project Manager - Digital Products Signature: ............................... Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <2020-01-10> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name RNE00515TX 00515TX For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Signed: Name: Victor Mak Company: Chaney Instrument Co. Address: Flat 09,19/F.,Metro Centre Phase I, 32 Lam Hing Street, Kowloon Bay, Kowloon, Hong Kong, China Phone: +852-35829826 Fax: +852-28890331 E-Mail: [email protected]

Project No.: 1905C11 5 Page 2 of 11

Scale 4:1 Scale 1:1 Scale 1:1 Scale 4:1 Silk Screen Color: Black 1.5V 'AA' (UM3) 1.5V 'AA' (UM3) 1.5V 'AA' (UM3) 1.5V 'AA' (UM3) A B C A B C Scale 1:1 Scale 4:1

Project No.: 1905C11 5 Page 3 of 11 Project No.: 1905C11 5 Page 4 of 11 Project No.: 1905C11 5 Page 5 of 11 Project No.: 1905C11 5 Page 6 of 11 Project No.: 1905C11 5 Page 7 of 11 Project No.: 1905C11 5 Page 8 of 11 Project No.: 1905C11 5 Page 9 of 11 Project No.: 1905C115 Page 10 of 11 Project No.: 1905C115 Page 11 of 11

Report No.: BTL-FCCP-1-1905C115 Page 1 of 47 Report Version: R01 FCC Radio Test Report FCC ID: RNE00515TX This report concerns: Original Grant Project No. : 1905C115 Equipment : Digital Freezer /Refrigerator Thermometer Test Model : 00515TX Series Model : N/A Applicant : Chaney Instrument Co. Address : Flat 09,19/F.,Metro Centre Phase I,32 Lam Hing Street, Kowloon Bay, Kowloon, Hong Kong Date of Receipt : May 23, 2019 Date of Test : May 24, 2019 ~ Jun. 27, 2019 Issued Date : Jan. 14, 2020 Tested by : BTL Inc. Testing Engineer : (Vincent Tan) Technical Manager : (Steven Lu) Authorized Signatory : (Ethan Ma) BTL INC. No.3,Jinshagang 1st Road, Shixia,Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1905C115 Page 2 of 47 Report Version: R01 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-1905C115 Page 3 of 47 Report Version: R01 Table of Contents Page REPORT ISSUED HISTORY 5 1 . GENERAL SUMMARY 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . AC POWER LINE CONDUCTED EMISSIONS TEST 12 4.1 Limit 12 4.2 TEST PROCEDURE 12 4.3 DEVIATION FROM TEST STANDARD 12 4.4 TEST SETUP 13 4.5 EUT OPERATING CONDITIONS 13 4.6 EUT TEST CONDITIONS 13 4.7 TEST RESULTS 13 5 . RADIATED EMISSION TEST 14 5.1 FIELD STRENGTH OF FUNDAMENTAL EMISSIONS MEASUREMENT LIMIT 14 5.2 MEASURING INSTRUMENTS AND SETTING (FIELD STRENGTH OF FUNDAMENTAL EMISSIONS) 14 5.3 RADIATED EMISSIONS MEASUREMENT 15 5.4 DWELL TIME OF PERIODIC OPERATION MEASUREMENT 16 5.5 TEST PROCEDURE 19 5.6 DEVIATION FROM TEST STANDARD 19 5.7 TEST SETUP 19 5.8 DEVIATION FROM TEST STANDARD 20 5.9 DEVIATION FROM TEST STANDARD 20 5.10 TEST RESULTS (9kHz to 30MHz) 21 5.11 TEST RESULTS (30MHz to 1000MHz) 21 5.12 TEST RESULTS (Above 1000MHz) 21 Report No.: BTL-FCCP-1-1905C115 Page 4 of 47 Report Version: R01 Table of Contents Page 6. 20dB SPECTRUM BANDWIDTH MEASUREMENT 22 6.1 MEASURING INSTRUMENTS AND SETTING 22 6.2 TEST PROCEDURES 22 6.3 TEST SETUP LAYOUT 22 6.4 TEST DEVIATION 22 6.5 EUT OPERATION DURING TEST 23 6.6 EUT TEST CONDITIONS 23 6.7 TESTRESULTS 23 7. TIMING TESTING 24 7.1 MEASURING INSTRUMENTS AND SETTING 24 7.2 TEST PROCEDURES 24 7.3 TEST SETUP LAYOUT 24 7.4 TEST DEVIATION 24 7.5 EUT OPERATION DURING TEST 24 7.6 EUT OPERATION DURING TEST 24 7.7 TEST RESULTS 24 8. MEASUREMENT INSTRUMENTS LIST 25 9. EUT TEST PHOTO 27 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 30 APPENDIX B - RADIATED EMISSION - 9 KHz to 30 MHz 31 APPENDIX C - RADIATED EMISSION - 30MHz to 1000MHz 36 APPENDIX D - RADIATED EMISSION - ABOVE 1000MHz 41 APPENDIX E - 20dB SPECTRUM BANDWIDTH 44 APPENDIX F - TIMING TESTING 46 Report No.: BTL-FCCP-1-1905C115 Page 5 of 47 Report Version: R01 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Nov. 29, 2019 R01 Updated the product name. Jan. 14, 2020 Report No.: BTL-FCCP-1-1905C115 Page 6 of 47 Report Version: R01 1. GENERAL SUMMARY Equipment : Digital Freezer /Refrigerator Thermometer Brand Name : ACURITE Test Model : 00515TX Series Model : N/A Applicant : Chaney Instrument Co. Manufacturer : Chaney Instrument Co. Address : Flat 09,19/F.,Metro Centre Phase I,32 Lam Hing Street, Kowloon Bay, Kowloon, Hong Kong Factory : Chaney Instrument Co. Address : Flat 09,19/F.,Metro Centre Phase I,32 Lam Hing Street, Kowloon Bay, Kowloon, Hong Kong Date o f Te s t : May 24, 2019 ~ Jun. 27, 2019 Te s t Sample : Engineering Sample No.: DG190523170-2 Standard(s) : FCC Part15, Subpart C(15.231) ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1905C115) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of A2LA according to…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1905C115 Page 27 of 47 Report Version: R00 9. EUT TEST PHOTO Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1905C115 Page 28 of 47 Report Version: R00 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-1-1905C115 Page 29 of 47 Report Version: R00 Radiated Measurement Photos Above 1000MHz
