Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 1 of 10 PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 2 of 10 Wireless Thermometer Product Freezer Thermometer Manual Model No. 00985 Written By ____________________ Verified By _____________________ Approved By ____________________ PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 3 of 10 1. INTRODUCTION Wireless refrigerator / freezer thermometer product is composed of a receiver and two senders. Two remote sensor controllers are included in this system. The controller can receive the temperature signal and raise the audio alarm signal. 2. FEATURES 2.1 Temperature Range of Sender: -40F To 104F(-40°CTo +40°C) 2.2 Temperature Accuracy: +/- 2F 2.3 Centigrade or Fahrenheit displays by a switch 2.4 The sender can detect the low voltage of battery and indicate this information on the display of receiver. 2.5 The receiver has Key tone function. 2.6 There is a stochastic 8 bits ID codes in every sender. 2.7 The system has an audio alarm with beep. 2.8 The Max and Min of temperature can be displayed in the display screen of the receiver. 2.9 The base frequency is 433MHz. 3. LCD DISPLAY 3.1 The senders are without LCD. 3.2 The receiver’s LCD fully displays as following, PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 4 of 10 4. Operation 4.1 Power on / Reset a. When power on the receiver, it will fully display with beep as the below figure, b. Then the receiver starts to receive the signal from the sender. 4.2 BUTTON FUNCTION 4.2.1 ALARM 1 a. To press Alarm1 button switch to on/off alarm function. The “ALARM” icon is displayed; the unit will enable alarm function after 15 minutes. b. Press and hold Alarm1 for 2 seconds is to enter channel 1 alarm maximum setup mode. 4.2.2 ALARM 2 a. To press Alarm2 button switch to on/off alarm function. The “ALARM” icon is displayed; the unit will enable alarm function after 15 minutes. b. Press and hold Alarm2 for 2 seconds is to enter channel 2 alarm maximum setup mode. 4.2.3 + /- Press “+” or “–” to change values for alarm – press and hold for 2 seconds for rapid scroll through of values. 4.2.4 CLEAR Press “CLEAR” is to clear the max and min in the memory. PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 5 of 10 4.3 When the temperature value is more than the Max limit 104 F, the unit will display as following, 4.4 When the temperature value is less than the Min limit -40 F, the unit will display as following, 5. Alarm Function 5.1 Channel 1 alarm setup mode 5.1.1 The maximum default of Channel 1 is 40 F. The minimum default of Channel 1 is 33 F. 5.1.2 Press and hold Alarm1 for 2 seconds is to enter channel 1 alarm max. setup mode . The Max. will be displayed as the below figure, PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 6 of 10 5.1.3 And then press Alarm1 is to enter Min. setup mode (then with key tone), the Min. will be displayed as the below figure, 5.1.4 Press Alarm1 again under the above mode (then with key tone). The unit will be back to normal mode and display as the below figure, 5.1.5 If no any button is pressed within 10 seconds, the menu will be back to normal mode from setup mode. 5.1.6 After press “Clear” button, the menu will be back to normal mode from setup mode and display “Alarm” icon. 5.1.7 After finished setup maximum / minimum and exit setup mode, the unit will enable alarm function after 15 minutes. 5.1.8 After set the maximum, the unit will auto adjust the minimum and make it less than the maximum. 5.1.9 The maximum is to be set within the concessional temperature range. 5.2 Channel 2 alarm setup mode PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 7 of 10 5.2.1 The maximum default of Channel 2 is 0 F. The minimum default of Channel 2 is -22 F. 5.2.2 Press and hold Alarm2 for 2 seconds is to enter channel 2 alarm max. setup mode. The Max. will be displayed as the below figure, 5.2.3 And then press Alarm2 is to enter Min. setup mode (then with key tone), the Min. will be displayed as the below figure, 5.2.4 Press Alarm2 again under the above mode (then with key tone). The unit will be back to normal mode and display as the below figure. 5.2.5 If no any button is pressed within 10 seconds, the menu will be back to normal mode from setup mode. PRIMEX/CHANEY INSTRUMENT CO. Hong Kong Primex Asia Limited Shenzhen Representative Office REV (1.3) DATED 28/12/05 Copyright © 2005 Primex Inc. - All rights reserved Page 8 of 10 5.2.6 After press “Clear” button, the menu will be back to normal mode from setup mode and display “Alarm” icon. 5.2.7 After finished setup maximum / minimum and exit setup mode, the receiver will display “Alarm” icon and enable alarm function after 15 minutes. 5.2.8 After set the maximum, the unit will auto adjust the minimum and make it less than the maximum. 5.2.9 The maximum could be set within the concessional temperature range. 5.3 If alarm function is enabled, the unit will raise the audio alarm when the temperature value more than the max or min. 5.4 The unit will alarm for 1 minute. Then the unit will beep for three times after each 1 minute. 5.4.1 For alarm1, see the below figure, 5.4.2 For alarm2, see the below figur…
Text truncated - open the document above for the full version.
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 30, 2005 RE: FCC ID: RNE00985TX_ATCB003059 Attention: Wallace Pan / Lily Liu I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. FYI - Please note that the operators manual is generally not an adequate operational description. In future applications, please provide an operational description that is in accordance with 47CFR2.1033 requirements 2. FYI – no action needed at this time. Please note that Block diagrams must be in accordance with 2.1033 which states that all clocks and data paths must be listed on the block diagram 3. Please note that the FCC ID number is to be on one single line and not split into two lines. Please see 47CFR2.925(a)(1). Please provide a label that is in accordance with the FCC rules. 4. Please show how the device meets the requirement that “In addition, devices operated under the provisions of this paragraph shall be provided with a means for automatically limiting operation so that the duration of each transmission shall not be greater than one second and the silent period between transmissions shall be at least 30 times the duration of the transmission but in no case less than 10 seconds.” This is not made clear in the operational description. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
ADT (Shanghai) Corporation 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China Jan. 4, 2006 FCC ID: RNE00985TX The following lists are the answers for the comments on Dec, 30, 2005, please kindly have a review on it: 1) Please note that the FCC ID number is to be on one single line and not split into two lines. Please see 47CFR2.925 (a) (1). Please provide a label that is in accordance with the FCC rules. Re: See the attachment (RNE00985TX)Label_0104. 2.) Please show how the device meets the requirement that “In addition, devices operated under the provisions of this paragraph shall be provided with a means for automatically limiting operation so that the duration of each transmission shall not be greater than one second and the silent period between transmissions shall be at least 30 times the duration of the transmission but in no case less than 10 seconds.” This is not made clear in the operational description. Re: The statement that should be added is in section 6.5, page 10. See the attachment (RNE00985TX)UserMan _0104. Thank you very much.
Fridge monitor Tx FCC NO. BCD 12 A 3 2 1 4 BA 56 DRAWN CHK'D APPV'D MFG Q.A UNLESS OTHERWISE SPECIFIED:DIMENSIONS ARE IN MILLIMETERSSURFACE FINISH:TOLERANCES: LINEAR: ANGULAR: FINISH: DEBUR AND BREAK SHARP EDGES NAME SIGNATURE DATE MATERIAL: DO NOT SCALE DRAWING REVISION TITLE: DWG NO.SCALE:1:1 SHEET 1 OF 1 A4 C WEIGHT: THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF PRIMEX ASIA LIMITED . ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF PRIMEX ASIA LIMITED IS PROHIBITED.
Report No.: 051135FIA01 1 Report Format Version1.0.1 FCC TEST REPORT REPORT NO.: 051135FIA01 MODEL NO.: 00985 transmitter RECEIVED: Nov. 29, 2005 TESTED: Nov. 29 ~ Dec. 28, 2005 ISSUED: Dec. 29, 2005 APPLICANT: Chaney Instrument Co. ADDRESS: AB 29/F HaiYing Building South Caitian Road Futian District Shenzhen China ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China This test report consists of 21 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. ADT (Shanghai) Corporation. Report No.: 051135FIA01 2 Report Format Version1.0.1 Table of Contents 1 CERTIFICATION ............................................................................................. 3 2 SUMMARY OF TEST RESULTS ..................................................................... 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION.............................................................................. 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST ............................................................................................. 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULT............................................................................................. 8 4.2 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................... 9 4.2.1 LIMITS OF BAND EDGES MEASUREMENT .............................................. 9 4.2.2 TEST INSTRUMENTS................................................................................. 9 4.2.3 TEST PROCEDURES ................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD........................................................ 9 4.2.5 TEST SETUP............................................................................................... 9 4.2.6 TEST RESULTS ........................................................................................ 10 4.3 RADIATED EMISSION MEASUREMENT.................................................. 11 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT ............................... 11 4.3.2 TEST INSTRUMENTS............................................................................... 13 4.3.3 TEST PROCEDURE.................................................................................. 14 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 14 4.3.5 TEST SETUP............................................................................................. 14 4.3.6 EUT OPERATING CONDITIONS .............................................................. 15 4.3.7 TEST RESULTS ........................................................................................ 15 5 APPENDIX - INFORMATION ON THE TESTING LABORATORIES ............. 21 Report No.: 051135FIA01 3 Report Format Version1.0.1 1 CERTIFICATION PRODUCT: Wireless refrigerator / freezer thermometer MODEL NO.: 00985 transmitter APPLICANT: Chaney Instrument Co. TESTED: Nov. 29 ~ Dec. 28, 2005 TEST ITEM: Engineering Sample STANDARDS: FCC Part 15:2005, Subpart C (Section 15.209 and 15.231), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:DEC. 29, 2005 Responsible for EMI (Wailand Zhang) APPROVED BY : , DATE:DEC. 29, 2005 (Wallace Pan, Manager ) Report No.: 051135FIA01 4 Report Format Version1.0.1 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type ResultRemarks 15.207 Conducted Emission Test N/A 15.231(c) 20dB Occupied Bandwidth Measurement PASS Meet the requirement of limit 15.209 15.231(e) Radiated Emission Test PASS Minimum passing AV margin is –6.04dB at 3037.440MHz Note: This report contains data that were produced under subcontract by Laboratory ADT (Shanghai) Corporation. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: Measurement Value Conducted emissions 1.8dB Radiated emissions 3.5dB Report No.: 051135FIA01 5 Report Format Version1.0.1 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless refrigerator / freezer thermometer MODEL NO. 00985 transmitter POWER SUPPLY 3Vdc from battery MODULATION TYPE ASK CARRIER FREQUENCY OF EACH CHANNEL 433.92MHz NUMBER OF CHANNEL 1 EACH CHANNEL FREQUENCY Fixed CHANNEL SEPARATION +/-75KHz CHANNEL CONTROL Manual ANTENNA TYPE Connector ANTENNA JOINT TYPE Soldered RF OUTPUT POWER - 15dBm DATA CABLE SUPPLIED N/A I/O PORTS N/A NOTE: The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. 3.2 DESCRIPTION OF TEST MODES One channel is provided to this EUT: Channel …
Text truncated - open the document above for the full version.
2F, Building C, No.1618, Yishan rd., · Shanghai · China
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231(e) | 433.975 MHz - 433.975 MHz | - |
