RNE00991Hixson Temp Tag

Chaney Instrument Co. Hong Kong Primex Asia Limited ShenZhen Representative office AB,29/F HAIYING BUILDING SOUTH CAITIAN ROAD FUTIAN DISTRICT SHENZHEN CHINA 29AB H H i i x x s s o o n n T T e e m m p p T T a a g g Hixson Version 5.0 5 st Nov 2005 H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 1 AForeword The user is cautioned that changes or modifications not expressly approved by Chaney Instruments Co. could void the user's authority to operate the equipment. 15.105: For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15.19 (labeling not on EUT due to size must be in manual: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1. Definition list Sender: A wireless sending module. Receiver : A wireless receiving module which displays temperature. BFunctional Specification 1. Features: a. Temperature Range: 80`F-120`F b. The system included a receiver and a sender. H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 2 c. The system will transmit the temperature 4 times per hour. ( d. Temperature alarm function: A red LED and LCD will flash in the receiver when temperature range over 104`F and it will display “- - - “when the temperature range is outside 80- 120`F. 2. LCD display 1) The Sender without LCD. 2) The receiver with following LCD: 3. Operation a. When power on the receiver, its LCD will fully display as the below figure, then the LCD will display as next figure. b. The time code will be preset in the factory and exit factory by pair which is matched the time code. c. Customer can register the new time code by pressing the rest key on the back side of the receiver .(need to screw out the screw to access the reset key) The receiver will clear the old time code and keep it in learning mode to learn the new time code from a transmitter once the reset key is pressed. The learning process should be by placing a pair in a shielded box or by keeping the pair far away from any other sets in order to avoid any interference from any other pairs of receivers and transmitters. d. The learning process takes 15 minutes to learn the time code for the handshake. e. Transmitter sends the data every 15 minutes. f. The LCD of the receiver will display “-E-“ when the receiver cannot receive any signal for more than 8 consecutive times. H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 3 5. Configuration (Industry Design) H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 4

ADT (Shanghai) Corporation 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China Dec. 16, 2005 FCC ID: RNE00991 The following lists are the answers for the comments on Dec, 15, 2005, please kindly have a review on it: 1) Please adjust the following exhibits to only show the device covered by this application (remove information regarding the RX) :a) Block Diagram; b) Labeling Exhibit; c) Schematics Re: See the attachment (RNE00991)BlkDia_1216; (RNE00991)Label_1216; (RNE00991)Schem_1216. 2) Layout (first page of schematics) shows a 433.92 MHz resonator, while this application appears to be for 315 MHz. Please adjust/correct the application as necessary. Re: See the attachment (RNE00991)Schem_1216. 3) The users manual does not contain proper FCC statements such as the following that are typically required: Re: See the attachment (RNE00991)UserMan_1216. 4) The correction factor applied for average measurements is based upon 300 msec. This is not allowed as the FCC rules cite a maximum worse case of 100 msec. This makes an almost 9.5 dB difference in the allowed duty cycle correction. (20 log 0.64 = 3.9). This will cause reading at the 2nd, 3rd, and also possibly the 5th harmonic to exceed the limit. Re: See the attachment (RNE00991)TestRpt _1216. 5) There are a PK few readings above 1 GHz which exceed 54 dBuV/m, but average results were not shown. Where peak emissions exceed average limits, average results must be provided as well. Please correct. Re: See the attachment (RNE00991)TestRpt _1216. 6) FYI....The RX appears to be a super-regenerative device and must be approved either by a separate Certification application, or a DoC application. Please note that to qualify to perform DoC applications, the test lab must be accredited by an acceptable agency and meet the requirement of 2.948(e) to perform testing under the DoC procedure and the device has additional labeling and manual requirements for the DoC. Currently labs from China do not appear as an accredited test lab on the FCC site under 2.948(e). Re: The FCC DOC report is issued by our head office in Taiwan. See the attachment (RNE00991)TestRpt.Doc _1216. Thank you very much.

Chaney Instrument Co. Hong Kong Primex Asia Limited ShenZhen Representative office AB,29/F HAIYING BUILDING SOUTH CAITIAN ROAD FUTIAN DISTRICT SHENZHEN CHINA 29AB Copyright@2005 Chaney Instrument Co Inc. –All rights reserved HARDWARE INFORMATION TX Unit Using MCU to test the resistor of NTC temperature sensor, Then transmitting the encoded data package through the inside helix antenna by ASK modulated with 315MHz frequency. RX Unit Receiving the RF signal by PCB antenna, passing LNA, Super-regeneration Amplifier, Demodulator, operating Amplifier, LPF , then decoding the out temperature data package; Otherwise, MCU display in LCD at the same.

Chaney Instrument Co. Hong Kong Primex Asia Limited ShenZhen Representative office AB,29/F HAIYING BUILDING SOUTH CAITIAN ROAD FUTIAN DISTRICT SHENZHEN CHINA 29AB H H i i x x s s o o n n T T e e m m p p T T a a g g Hixson Version 5.0 5 st Nov 2005 H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 1 AForeword 1. Definition list Sender: A wireless sending module. Receiver : A wireless receiving module which displays temperature. BFunctional Specification 1. Features: a. Temperature Range: 80`F-120`F b. The system included a receiver and a sender. c. The system will transmit the temperature 4 times per hour. ( d. Temperature alarm function: A red LED and LCD will flash in the receiver when temperature range over 104`F and it will display “- - - “when the temperature range is outside 80- 120`F. 2. LCD display 1) The Sender without LCD. 2) The receiver with following LCD: 3. Operation a. When power on the receiver, its LCD will fully display as the below figure, then the LCD will display as next figure. H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 2 b. The time code will be preset in the factory and exit factory by pair which is matched the time code. c. Customer can register the new time code by pressing the rest key on the back side of the receiver .(need to screw out the screw to access the reset key) The receiver will clear the old time code and keep it in learning mode to learn the new time code from a transmitter once the reset key is pressed. The learning process should be by placing a pair in a shielded box or by keeping the pair far away from any other sets in order to avoid any interference from any other pairs of receivers and transmitters. d. The learning process takes 15 minutes to learn the time code for the handshake. e. Transmitter sends the data every 15 minutes. f. The LCD of the receiver will display “-E-“ when the receiver cannot receive any signal for more than 8 consecutive times. 5. Configuration (Industry Design) H i x s o n Te m p Ta g (V5.00)- m m a a n n u u a a l l Copyright@2005 Chaney Instrument Co Inc. –All rights reserved 3

Report No.: 051105FIA01 1 Report Format Version1.0.1 FCC TEST REPORT REPORT NO.: 051105FIA01 MODEL NO.: HIXSON02 RECEIVED: Nov. 2, 2005 TESTED: Nov. 2 ~ Dec. 8, 2005 ISSUED: Dec. 8, 2005 APPLICANT: Chaney Instrument Co. ADDRESS: AB 29/F HaiYing Building South Caitian Road Futian District Shenzhen China ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China This test report consists of 19 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. ADT (Shanghai) Corporation. Report No.: 051105FIA01 2 Report Format Version1.0.1 Table of Contents 1 CERTIFICATION ............................................................................................. 3 2 SUMMARY OF TEST RESULTS ..................................................................... 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION.............................................................................. 4 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 4 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................ 6 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 6 4 EMISSION TEST ............................................................................................. 7 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 7 4.1.2 TEST RESULT............................................................................................. 7 4.2 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................... 8 4.2.1 LIMITS OF BAND EDGES MEASUREMENT .............................................. 8 4.2.2 TEST INSTRUMENTS................................................................................. 8 4.2.3 TEST PROCEDURES ................................................................................. 8 4.2.4 DEVIATION FROM TEST STANDARD........................................................ 8 4.2.5 TEST SETUP............................................................................................... 8 4.2.6 TEST RESULTS .......................................................................................... 9 4.3 RADIATED EMISSION MEASUREMENT.................................................. 10 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................... 10 4.3.2 TEST INSTRUMENTS............................................................................... 12 4.3.3 TEST PROCEDURE.................................................................................. 13 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 13 4.3.5 TEST SETUP............................................................................................. 13 4.3.6 EUT OPERATING CONDITIONS .............................................................. 14 4.3.7 TEST RESULTS ........................................................................................ 14 5 APPENDIX - INFORMATION ON THE TESTING LABORATORIES ............. 19 Report No.: 051105FIA01 3 Report Format Version1.0.1 1 CERTIFICATION PRODUCT: HIXSON MODEL NO.: HIXSON02 APPLICANT: Chaney Instrument Co. TESTED: Nov. 2 ~ Dec. 8, 2005 TEST ITEM: Engineering Sample STANDARDS: FCC Part 15:2005, Subpart C (Section 15.209 and 15.231), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:DEC. 8, 2005 Responsible for EMI (Wailand Zhang) APPROVED BY : , DATE:DEC. 8, 2005 (Wallace Pan, Manager ) Report No.: 051105FIA01 4 Report Format Version1.0.1 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type ResultRemarks 15.207 Conducted Emission Test N/A 15.231(c) 20dB Occupied Bandwidth Measurement PASS Meet the requirement of limit 15.209 15.231(e) Radiated Emission Test PASS Minimum passing AV margin is –1.22dB at 946.650MHz Note: This report contains data that were produced under subcontract by Laboratory ADT (Shanghai) Corporation. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: Measurement Value Conducted emissions 1.8dB Radiated emissions 3.5dB 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT HIXSON MODEL NO. HIXSON02 POWER SUPPLY 6Vdc from battery MODULATION TYPE ASK CARRIER FREQUENCY OF EACH CHANNEL 315MHz NUMBER OF CHANNEL 1 ANTENNA TYPE Soldered on PCB DATA CABLE SUPPLIED N/A I/O PORTS N/A NOTE: The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. Report No.: 051105FIA01 5 Report Format Version1.0.1 3.2 DESCRIPTION OF TEST MODES One channel is provided to this EUT: Channel Frequency 1 315 MHz Test Mode Applicability AND TESTED CHANNEL DETAIL: Applicable to EUT configure mode PLC RE<1G RE≥1GAPM Description - - x x x NA Where PLC: Power Line Conducted Emission RE<1G RE: Radiated Emission below 1GHz RE≥1G: Radi…
