RNKDS-2038Wireless Mouse

This product is adopting the very advanced RF and Optical technology. It lets you enjoy the freedom of wireless and enjoyment of developed with the IC from Agilent voltage, and low power deplete with orientation. It has the highest resolution at 800DPI that allow . No readjustment is atteries and the current is below The IC has an environment adjustment function in the circuit integration; It can automatically adjust different kind of desktop usage will be double while desktop is Can be compatible with IBM PC and all kinds of branded Can be used under DOS, Win95/98/2000/Me/XP and Windows Channel 256 ID Code, setting instruction: please refer to the No.3 of Assembly Instructions. Power Saving: The circuit is embedded with an automatic sleeping power-saving function. If the mouse is not moved or touched for 4 minutes, the brightness from LED will be lowered and after another 30 seconds, all other current except for waking-up feature will be off automatically. After 8 minutes more, it will enter into full-sleeping state and the power-usage is almost near zero. Voltage-Protection: When the current voltage is decreased to a minimum level, the mouse will be powered off automatically and the new batteries must be replaced. Wake-up Feeler: two ways. 1. touch mode: Grasp the mouse 2. press mode: Click any key Features of receiver: Frequency: 27MHz Interface: PS/2, USB & Combo available Current: +5V DC Assembly Instructions: 1. Connect the receiver: Connect the receiver with interface of computer: please note that PS/2 Interface must USB connector can be used whenever it is plugged. 2. Battery Installation Open the battery cover on the bottom of the mouse, insert two brand new batteries, (please note that the right side or it will cause s WARNING: Different kinds of batteries ( batteries) mixed using may cause explosive damage. 3. Adjusting code Before using it, please be sure that the adjusting code are not interfered, for exampl distances, the ID codes can be set through the buttons on the bottom of the mouse, Thus, it start working within 4 seconds either of them can be pressed first (As per Picture). 4. Usage The receiver (box) can be pla Mouse can be used on any desktop surface. (We recommend to use it on any white or lighter color surface of desktop, thus, the power can be saved.)

Optical Wireless Mouse Application Manual Item Number: DS-2038 Wireless & Optical Mouse Features: This product is adopting the very advanced RF and Optical technology. It lets you enjoy the freedom of wireless and enjoyment of speed. This product is developed with the IC from Agilent ADNS-2030, which is low-voltage, and low power deplete with optical-orientation. It has the highest resolution at 800DPI that allow you to have a fascinating speed and accuracy. No readjustment is necessary, thus. It prolongs the working life. This product uses 2 units of AA batteries and the current is below 30 mA (white desktop). The IC has an environment adjustment function in the circuit integration; It can automatically adjust different kind of desktop surface or color. (The power-usage will be double while desktop is black) Compatibility: Can be compatible with IBM PC and all kinds of branded notebook. Can be used under DOS, Win95/98/2000/Me/XP and Windows NT(except for USB). Features of Emitter: 27MHz RF Emitting. +3VDC (2 pcs of AA batteries) Uni-Channel 256 ID Code, setting instruction: please refer to the No.3 of Assembly Instructions. Power Saving: The circuit is embedded with an automatic sleeping power-saving function. If the mouse is not moved or touched for 4 minutes, the brightness from LED will be lowered and after another 30 seconds, all other current except for waking-up feature will be off automatically. After 8 minutes more, it will enter into full- sleeping state and the power-usage is almost near zero. Voltage-Protection: When the current voltage is decreased to a minimum level, the mouse will be powered off automatically and the new batteries must be replaced. Wake-up Feeler: two ways. 1. touch mode: Grasp the mouse 2. press mode: Click any key Features of receiver: Frequency: 27MHz Interface: PS/2, USB & Combo available Current: +5V DC Assembly Instructions: 1. Connect the receiver: Connect the receiver with interface of computer: please note that PS/2 Interface must be connected before turning on the computer, USB connector can be used whenever it is plugged. 2. Battery Installation Open the battery cover on the bottom of the mouse, insert two brand new batteries, (please note that “+”and “-” should be putting at the right side or it will cause short circuit)(As per Picture) WARNING: Different kinds of batteries (e.g. Alkaline and Rechargeable batteries) mixed using may cause explosive damage. 3. Adjusting code Before using it, please be sure that the adjusting code are not interfered, for example, when several mice are used at a close distances, the ID codes can be set through the buttons on the bottom of the mouse, Thus, it start working within 4 seconds either of them can be pressed first (As per Picture). 4. Usage The receiver (box) can be placed any distance within 1.5M to 2M. Mouse can be used on any desktop surface. (We recommend to use it on any white or lighter color surface of desktop, thus, the power can be saved.) Simple maintenance and technique support If you are not going to use it for a long time, please take the batteries out to avoid any damages on the circuit or if replacement time for batteries is too long, the adjusting code needs to be reset. In case it cannot be used, do not open up the mouse yourself. You should contact the service center that near by your place. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help.

Block Diagram(DS-2038) L,M,R Optical Sensor Wheel Micro Processor Oscilator 27.045 MHz Colpits OSC Amp Bandpass Filter Battery Power Model: DS-2038 Button Cursor Capture Wheel Data Power Control Antenna

APPENDIX C - EUT PHOTOGRAPHS EUT - Front View EUT - Rear View

APPENDIX A - FCC PRODUCT LABELING AND WARNING STATEMENT FCC ID Label Specifications: Text is black in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing and shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT Bottom of EUT, FCC ID Label Proposed Location FCC ID: RNKDS-2038 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2.1875" 1.0" Label Here

EUT - Cover Off View EUT - Component View EUT - Solder View

EUT – Chassis Top View EUT – Chassis Bottom View EUT – Chassis Side View EUT – Cover Off View PCB 1 – Component View PCB 1 – Solder View PCB 2 – Component View PCB 2 – Solder View

Circuit ‘s operation Description for DS-2038 This circuit is mainly consisted of convertor IC(U3,U4), IC(U1), MC(U I), C(U2). IC U4 provides the circuit with a stable 3Vvolts d.c and U3 provide the circuit with a stanble 4V . to keep the circuit working. when the mouse is moving on the desktop, photoelectric processor IC-U1collect optical signals reflected by the desktop and transfer them into the MCU IC-U2, then processed and managed. By MCU together, they are sent to the FSK circuit. In the MCU IC-U2,there is internal RF Generator the electric signals out from MCU will be generated, and output the data from 8# feet of U2 and radiate the signal to outside. MCU will provide and generate a code from the 22# feet of IC-U2 when you press the ID buttonat the same time ,MCU will storage this code, and keeping the ID code unchanged until out of power. The MCU IC-U2 have two functions of sleep and wake up. For saving up the capacity of power, the circuit will keep sleeping model when the mouse has stopped on the desktop for a fixture time; you can press any key or wheel switch to let it work again.

Eastern Times MOUSE BOM modleDS-2038(A2051) Prepared By Yu-Heping Modified Date 2003-10-11 Checked By: : 2-1 No. component name model quartity remark 1 PCB 1.0X40X21mm 1 2038 U+P 2 IC MA6062 SO-16 1 U3 3 IC UTC3361 SO-16 1 U1 4 IC 93C46 SO-8 1 U2 5 BPF 455K 5P 1 B1 6 BPF C28 1 X1 7 crystal frequency genrator 26.590MHZ 3X8mm 1 Y1 8 crystal frequency genrator 6.0MHz CRY/S 1 Y2 9 dynatron 2SC945 SOT-23 1 Q1 10 diode 1N4148 SD3.5M 1 D1 11 electrolyte capacitance 47UF/16V 5X7mm 2 C15 C17 12 electrolyte capacitance 100UF/16V 6X7mm 1 C20 13 lacker capacitance 104 0603 8 C1,C3,C4,C5,C6,C8 C12,C16, 14 lacker capacitance 33P 0603 1 C7 15 lacker capacitance 0 C9 16 lacker capacitance 103 0603 1 C13 17 lacker capacitance 22P 0603 1 C10 18 lacker capacitance 43P 0603 2 C11, C14 19 lacker capacitance 105 0603 1 C18 20 lacker capacitance 102 0603 2 C19,C23 21 lacker capacitance 22p 0603 1 C2 22 lacker capacitance 3p 0603 1 C21 23 resistance 4K7 0603 1 R1 24 resistance 100 0603 2 R2 R13 ATT Eastern Times MOUSE BOM modleDS-2038(A2051) Prepared By Yu-Heping Modified Date 2003-10-11 Checked By: : 2-2 No component name model quartity remark 1 resistance 2K7 0603 1 R3 2 resistance 3K3 0603 1 R4 3 resistance 33K 0603 1 R5 4 resistance 27K 0603 1 R6 5 resistance 100K 0603 1 R8 6 resistance 1M 0603 1 R9 7 resistance 560 0603 1 R10 8 resistance 330 0603 1 R11 9 LED 3mm 2Pin Red 1 LD1 10 IDswitch TS3-100PL 7X6X6mm 1 SW1

DS-2038 TX SCH PCB ANT SW_Z R3 L3 L4 D1 C18 C19 C3 SW_ID C12C16 C15 C20 Y2 C17 PD SW_R SW_M SW_L + C9 C2 SCLK SDIO C4 R2 + C21 Y3 LD2 PD VDD REFB 8 REFA 7 XY_LED 6 YA 5 YB 4 XB 3 XA 2 SCLK 1 OSC_IN 9 GND 10 OSC_OUT 11 GND 12 VDD 13 R_BIN 14 PD 15 SDIO 16 U1 SDIOSCLK LBUT 7 MBUT 6 RBUT 5 VDD 4 OSC2 3 VSS 2 OSC1 1 RFOUT 8 ORFIN0 9 ORFIN1 10 ORFO 11 TXD 12 PD 13 WA 14 WB 15 Z1IN 16 Z2IN 17 SDIO 18 SCLK 19 BATL 20 TYPE 21 TXCB 22 BBUT 23 FBUT 24 SVD_IN 25 DCVR 26 VL 27 VL_NM 28 U2 C11 C13 Y1 C14 C10 - + VBAT1 L1 + C7 C1 VBT L2 VSS 1 OUT 2 LX 3 U3 VDD D2 + C23 C22 VSS 1 OUT 2 LX 3 U4 VBT vcc Touch Pad 2038U+P RX SCH BUAD 8 DEC2 7 DEC1 6 IFI 5 VCC 4 MBCO 3 OSCE 2 OSCB 1 AUTO 9 FI 10 FO 11 SQI 12 SCAN 13 MUTE 14 GND 15 MOCI 16 U1 C10 C11 C12 C14 C3 C4 Y1 R1 C19 C21 PCB ANT R4 C3C8 R5 Q1 D1 R6 R10 SW1 SK 4 CS 3 VCC 2 DC 1 DI 5 DO 6 GND 7 PSDT 8 U3 D2 R13 R2 X1 1 2 3 4 CON1 C6 + C17 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 U2 R1 C2C3 + C15 R13 C16 F1 C2 X1 C5 + C18 + C20 D+ D- R3

Note: This test report is specially limited to the above client company and product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15.227 EMI MEASUREMENT AND TEST REPORT For Eastern Times Technology Co., Ltd Rm2003C,Qunxing Plaza,Huaqiang Rd.(N),Futian District,Shenzhen,China FCC ID: RNKDS-2038 2004 -1-14 This Report Concerns: Original Report Equipment Type: Transmitter, Wireless Mouse Test Engineer: Ling Zhang Report No.: R0312311(T) Test Date: 2004-01-06 Reviewed By: Ming Jing Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732-9164 Eastern Times Technology Co., Ltd FCC ID: RNKDS-2038 Report # R0312311T Page 2 of 13 FCC ID Per 15.227 Report TABLE OF CONTENTS GENERAL INFORMATION......................................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)...............................................................................................3 OBJECTIVE.......................................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S)............................................................................................................................................3 TEST METHODOLOGY....................................................................................................................................................................3 TEST FACILITY................................................................................................................................................................................3 SYSTEM TEST CONFIGURATION........................................................................................................................................5 JUSTIFICATION................................................................................................................................................................................5 SCHEMATICS AND BLOCK DIAGRAM...........................................................................................................................................5 EQUIPMENT MODIFICATIONS........................................................................................................................................................5 TEST SETUP CONFIGURATION.......................................................................................................................................................5 SUMMARY OF TEST RESULTS..............................................................................................................................................6 §15.203 - ANTENNA REQUIREMENT...................................................................................................................................7 STANDARD APPLICABLE................................................................................................................................................................7 ANTENNA CONNECTED CONSTRUCTION.....................................................................................................................................7 §15.205, §15.209, §15.227(B) - RADIATED EMISSIONS TEST.......................................................................................8 MEASUREMENT UNCERTAINTY....................................................................................................................................................8 EUT SETUP......................................................................................................................................................................................8 SPECTRUM ANALYZER SETUP......................................................................................................................................................8 TEST EQUIPMENT LIST AND DETAILS..........................................................................................................................................9 TEST PROCEDURE...........................................................................................................................................................................9 CORRECTED AMPLITUDE & MARGIN CALCULATION.............................................................................................................11 SUMMARY OF TEST RESULTS......................................................................................................................................................11 RADIATED EMISSIONS TEST RESULT DATA.............................................................................................................................12 §15.227(B) - OUT OF BAND EMISSION...............................................................................................................................13 Eastern Times Technology Co., Ltd FCC ID: RNKDS-2038 Report # R0312311T Page 3 of 13 FCC ID Per 15.227 Report GENERAL INFORMATION Product Description for Equipment Under Test (EUT) The Eastern Times’s product, model number: DS-2038 or the "EUT" as referred to in this report is a Wireless Mouse Transmitter. The EUT is measured approximately 125mm L x 61mm W x 37mm H. * The test data gathered are from production sample, serial number: 20381, provided by the manufacturer. Objective This Type approval report is prepared on behalf of Eastern Times in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective is to determine compliance with FCC rules, sec 15.209 and sec 15.227. Re…

Text truncated - open the document above for the full version.

APPENDIX B - TEST SETUP PHOTOGRAPHS Radiated Emission - Front View Radiated Emission - Rear View
