RNW-AQL-BASE-RFRF Base Station

Aqua LogicAqua Logic Aqua LogicAqua Logic Aqua Logic Base Receiver Installation/Operation Manual for model AQL-BASE-RF LDLINE CONTROLS INC. G North Kingstown, RI USA www.goldlinecontrols.com ® Compatibility This product is compatible with all Aqua Logic controls operating software revision r1.10 or higher. To verify the software level of your Aqua Logic control: Press the Menu button (possibly multiple times) until “Diagnostic Menu” is displayed. Next, press the “>” or “<“ keys (possibly multiple times) until the main and display soft- ware revision levels are displayed (the “main” rev should be r1.10 or higher). If the software revision level is less than r1.10 contact the Goldline Technical Service Dept. from Monday through Friday, 8AM to 8PM Eastern at 888-921-7665 for infor- mation on upgrades. This Aqua Logic base receiver can communicate with the Aqua Logic spa-side remote (AQL-SPASIDE-RF) and also the wireless in-house remote display/keypads (AQL- REMOTE-RF-PS-4/8/16). 1 Installation Installation is very easy and should just take a few minutes. Disconnect power and then remove the panel from the Aqua Logic control unit. Re- move the knock-out on the upper left side of the Aqua Logic main unit and mount the RF base station. Secure the base receiver in place by firmly tightening the nut from inside the Aqua Logic unit. Lastly, plug the pigtail cable into the “wireless connector” connector on the Aqua Logic main circuit board. Base Receiver (AQL-BASE-RF) Tighten nut Aqua Logic Main PCB Connector for Base Receiver 2 Operation Every Base Receiver is manufactured with a unique ID code. This allows private, secure communication with all of your remote devices while ignoring any signals transmitted by other wireless devices including any other Aqua Logic controls in the neighborhood. IMPORTANT: Before trying to use any remote device: You must "teach" the correct ID code to the remote device so it knows which base receiver to communicate with. Refer to the Aqua Logic Operation Manual or the manual for your remote device for "teaching" instructions . The Aqua Logic Base Receiver and remote devices are programmed with a sophisti- cated protocol that automatically switches frequencies if other devices are interfering. In the unlikely event that it can not find a usable frequency, it may be necessary to change channels. Refer to the Aqua Logic Operation Manual for instructions. 3 Troubleshooting If you believe that your system is not operating properly or if you have a general question regarding system operation, you may call the Goldline Technical Service Dept. from Monday through Friday, 8AM to 8PM Eastern at 888-921-7665. 1.Can’t find the “Teach Wireless” display: Press the “menu” button (possibly more than once) until “Settings Menu” is displayed. Next, press the “<“ or “>” buttons (possibly more than once) until “Teach Wireless” display appears. If you go through all of the displays without ever seeing the "Teach Wireless" and you get to the point where “Settings Menu” appears again, then this means that the Aqua Logic control unit is not communicating with the Base Receiver. Check that the 4 wire cable from the base receiver is plugged into the “wireless connec- tor” on the main printed circuit board (refer to the Installation section for connec- tion diagram). If this connector is already plugged in (for more than 30 seconds), then call Goldline Technical Service for assistance. 2.“Teach Wireless” failed: Ensure that the remote is powered when pressing the button. This is indicated by a single flash on the LED on the spa-side remote or a message on the display of the in-house remotes. If the remote is powered, then the next most likely cause is that the distance between the base receiver and the remote is too great—try moving the remote closer to the receiver. Lastly, there may be other equipment in the neighborhood that is using the same frequency. To see if this is the case, go to the Settings Menu/Wireless Channel and select another channel. Note that after you change the channel you will have to “re- teach” every wireless remote device in the system. 3.Unreliable communication with remote devices: The most likely cause is that the distance between the base receiver and the remote is too great—try moving the remote closer to the receiver. Lastly, there may be other equipment in the neighborhood that is using the same frequency. To see if this is the case, go to the Settings Menu/Wireless Channel and select another channel. Note that after you change the channel you will have to “re-teach” every wireless remote device in the system. 4.No communication with remote controls: Try the “Teach Wireless” procedure to ensure that the remote knows the ID code of the base receiver and also what channel to communicate on. If this procedure is not successful, then refer to the “Teach Wireless” failed section above. 4 5 Aqua RiteAqua Rite Aqua RiteAqua Rite Aqua Rite ® , Aqua LogicAqua Logic Aqua LogicAqua Logic Aqua Logic ® & Aqua TrolAqua Trol Aqua TrolAqua Trol Aqua Trol ® Limited Warranty This warranty statement is applicable to all Aqua Rite ® Aqua Logic and Aqua Trol ® units with product date codes of January 1, 2002 and after, and supersedes all warranty statements dated prior to January 1, 2002. This Limited Warranty applies only to Aqua Rite ® Aqua Logic and Aqua Trol ® Electronic Chlorine Generators. Refer to the appropriate limited warranty state- ment for all other Goldline Controls products. When installed on private, single-family residential swimming pools or spas within the USA and Canada: Goldline Controls, Inc. (Goldline) warrants Aqua Rite ® Aqua Logic and Aqua Trol ® to be free from defects in material or workmanship, under normal use and service on private, single-family residential swimming pools within the USA and Canada for five years from date of the initial system installation, provided it is installed and maintained in accordance with the installation instructions and sp…

Text truncated - open the document above for the full version.

42 Ladd Street, East Greenwich, RI 02818 Tel: 800-343-0826 / 401-884-6990 Fax: 401-885-1500 www.goldlinecontrols.com F C C CONFIDENTIALITY Date: 11/20/03 To: FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Non disclosure for FCC ID: RNW - AQL-BASE-RF . To Whom It May Concern: Pursuant to 47 CFR Section 0.459, _Goldline Controls, Inc. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID # ( RNW - AQL-BASE-RF ) a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Goldline Controls, Inc. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Sincerely yours, Charles Savoie Engineering Manager Goldline Controls, Inc.

#CS 01136 FCC ID#: RNW-AQL-BASE-RF Goldline Controls Incorporated We have identified this issue following our review of the application: 1. Please justify the reasoning for not having the 15.19(a)(3) statement on the label. Photo Three – External Base Transceiver with Close Up of FCC ID Label Response: Based on the size of the product and the imbedded plastic area for the label, the label size restriction will not provide enough room for the following statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Please see the mechanical dimensions file submitted. The mechanical drawn of the Base case work is in inches. The bar code lines provide manufacturing and shipping control. The base unit is also typically mounted against a flat surface which restricts casual viewing of this statement. This statement is printed in the operator’s manual for viewing. It is viewed that this statement would not have an impact on the performance or operation of this product.

Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo One – External Base Transceiver Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Two – External Base Transceiver with FCC ID Label and Power Connection Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Three – External Base Transceiver with Close Up of FCC ID Label

Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Four – Internal Base Transceiver Open for Inspection Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Five – Internal Base Transceiver PCB – Component Side Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Six – Internal Base Transceiver PCB – RF Section Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Seven – Internal Base Transceiver PCB – Flip Side Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Eight – Internal Base Transceiver PCB – Flip Side RF Section Goldline Controls Incorporated AquaLogic Spa-side Remote Control 902 – 926 MHz Radio FCC ID#: RNW-AQL-BASE-RF Photo Nine – Internal Base Transceiver PCB – Antenna Connection

L.S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, WI 53012 262-375-4400 Fax: 262-375-4248 COMPLIANCE TESTING OF: AquaLogic RF Base Station PREPARED FOR: Goldline Controls, Incorporated Attn.: Mr. Charles Savoie 42 Ladd Street East Greenwich, RI 02818 TEST REPORT NUMBER: 303459-TX Rev. 1 TEST DATE(S): November 18 th , 2003 All results of this report relate only to the items that were tested. This report is not to be reproduced, except in full, without written approval of L. S. Compliance, Inc. L.S. Compliance, Inc. Page 2 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls Table of Contents Section Description Page Index 2 1 L. S. Compliance in Review 3 2 A2LA Certificate of Accreditation 4 3 A2LA Scope of Accreditation 5 4 Validation Letter-U.S. Competent Body for EMC Directive 89/336/EEC 6 5 Signature Page 7 6 Product and General Information 8 7 Product Description 8 8 Test Requirements 9 9 Declaration of Conformity 9 10 Introduction 9 11 Purpose 9 12 Radiated Emissions Test 10-16 13 Conducted Emissions Test (AC Power Line) 17-21 14 Band-Edge Measurements 22 15 Frequency and Power Stability versus Voltage 23 Appendix A Test Equipment List 24 L.S. Compliance, Inc. Page 3 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 1. L. S. Compliance In Review Brief Review of L.S. Compliance Accreditations and Listing’s As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025 : 1999 with Electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Listing of 3 Meter Semi-Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Listing of 3 and 10 meter OATS based on Title 47CFR – Part 2.948 FCC Registration Number: 90757 Industry Canada On file, 3 Meter Semi-Anechoic Chamber based on RSS-212 – Issue 1 File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility –Council Directive 89/336/EEC, Article 10.2. Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operating under the U.S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment – Council Directive 99/5/EC, Annex V. Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 L.S. Compliance, Inc. Page 4 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 2. A2LA Certificate of Accreditation L.S. Compliance, Inc. Page 5 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 3. A2LA Scope of Accreditation L.S. Compliance, Inc. Page 6 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 4. Validation Letter – U.S. Competent Body for EMC Directive 89/336/EEC L.S. Compliance, Inc. Page 7 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 5. Signature Page Prepared By: January 23, 2004 Teresa A. White, Document Coordinator Date Tested By: January 23, 2004 Abtin Spantman, EMC Engineer Date Approved By: January 23, 2004 Kenneth L. Boston, EMC Lab Manager Date PE #31926 Licensed Professional Engineer Registered in the State of Wisconsin, United States L.S. Compliance, Inc. Page 8 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 6. Product and General Information Manufacturer: Goldline Controls, Incorporated Model No.: Aqua Logic Base Serial No.: Engineering Unit # 104 Description: Wireless Remote Spa Controller 7. Product Description The Goldline AquaLogic RF Base Station provides a remote wireless solution for a Spa controller system . The system is composed of a “Base Unit” containing the transceiver and control circuitry for the Spa, and a “Remote Controller Unit” containing a transceiver and keypad. The base and remote units comprise a remote control system that utilizes a 5 channel scanning scheme to obtain a clear channel. Base receiver will continuously scan 5 channels for a signal from the remote. The remote is normally in sleep mode and wakes up and transmits upon keypad activation. The RF design is based upon the ‘Chipcon’ CC1020 transceiver IC (half-duplex) for operation in the 902-928 ISM band. The system uses Manchester-encoded binary data at 9600 bps, frequency modulated with a 19.8 kHz peak to peak deviation. The base unit is powered from an external power supply source providing 10 volts DC, which is then regulated to 3.3 VDC internally. The system uses a frequency modulation technique, and is capable of utilizing 25 different frequency channels in the 902-928 MHz band. Three channels were selected for testing: Set 1, channel 1 (902.5 MHz), set 3, channel 3 (914.5 MHz), and set 5, channel 5 (926.5 MHz). The channel and sets are defined as follows: Channel Set Channel Set 1 Set 2 Set 3 Set 4 Set 5 1 902.5 903.5 904.5 905.5 906.5 2 907.5 908.5 909.5 910.5 911.5 3 912.5 913.5 914.5 915.5 916.5 4 917.5 918.5 919.5 920.5 921.5 5 922.5 923.5 924.5 925.5 926.5 MHz MHz MHz MHz MHz L.S. Compliance, Inc. Page 9 of 24 Test Report Number: 303459-TX Rev. 1 Prepared For: Goldline Controls 8. Test Requirements The tests were performed in order to determine the compliance of the Goldline AquaLogic RF Base Station with limits contained in various provisions of Title 47 CFR, FCC Part 15, including 15.109, 15.205, 15.207, and 15.249. All radiated emissions tests were performed to measure the emissions in the frequency bands described by the above sections, and to determine whether said emissions are below the limits established by the above sections. These tests were performed in …

Text truncated - open the document above for the full version.

Photos Taken During Radiated Emission Testing Front view of the EUT Rear view of the EUT, showing the connection port and the 4-wire cable. Setup of the EUT with the external DC power supply, in the semi-anechoic chamber, during the radiated emission testing. Photo(s) Taken During Conducted Emission Testing View of the EUT during Conducted Emissions Testing
