ROJ-3711ASatellite Terminal

EXPLORER 510 User manual 98-143082-DraftA6ii Document number: 98-143082-DraftA6 Release date: 7 November 2014 Disclaimer Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed by Thrane & Thrane A/S. The information in this manual is provided for information purposes only, is subject to change without notice and may contain errors or inaccuracies. Manuals issued by Thrane & Thrane A/S are periodically revised and updated. Anyone relying on this information should acquire the most current version e.g. from www.cobham.com/satcom > Service and support, or from the distributor. Thrane & Thrane A/S is not responsible for the content or accuracy of any translations or reproductions, in whole or in part, of this manual from any other source. In the event of any discrepancies, the English version shall be the governing text. Thrane & Thrane A/S is trading as Cobham SATCOM. Copyright © 2014 Thrane & Thrane A/S. All rights reserved. Trademark acknowledgements •Inmarsat is a registered trademark of the International Maritime Satellite Organisation (IMSO) and is licensed by IMSO to Inmarsat Limited and Inmarsat Ventures plc. •Other product and company names mentioned in this manual may be trademarks or trade names of their respective owners. 98-143082-DraftA6iii Safety summary1 The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of the equipment. Cobham SATCOM assumes no liability for the customer's failure to comply with these requirements. Do not operate in an explosive atmosphere Do not operate the equipment in the presence of flammable gases or fumes. Operation of any electrical equipment in such an environment constitutes a definite safety hazard. Keep away from live circuits Operating personnel must not remove equipment covers. Component replacement and internal adjustment must be made by qualified maintenance personnel. Do not replace components with the power cable connected. Under certain conditions, dangerous voltages may exist even with the power cable removed. To avoid injuries, always disconnect power and discharge circuits before touching them. Do not service alone Do not attempt internal service or adjustments unless another person, capable of rendering first aid resuscitation, is present. Do not substitute parts or modify equipment Because of the danger of introducing additional hazards, do not substitute parts or perform any unauthorized modification to the equipment. Keep away from antenna front This device emits radio frequency energy when switched on. To avoid injury, keep a minimum safety distance of 60 cm from the antenna front when the EXPLORER 510 is on. Garder à l'écart de l'avant de l'antenne Le présent appareil émet des radiofréquences lors de son utilisation. Afin d'éviter tout risque pour la santé, une distance minimale de 60 cm est nécessaire entre l'utilisateur et l'avant de l'EXPLORER 510. Only use approved batteries from Cobham SATCOM Use of non approved batteries may result in explosion, fire, electrical shock or injury. Observe marked areas Under extreme heat conditions do not touch areas of the EXPLORER 510 that are marked with this symbol, as it may result in injury. Antenna safety instructions 98-143082-DraftA6iv Antenna safety instructions2 Use only manufacturer supplied antennas. Antenna minimum safe distance: 0.6 m Antenna gain Directional, with maximum gain of 11 dBi (with reference to isotropic). The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits. Antenna mounting The antenna supplied by the manufacturer must be located such that during radio transmission, no person or persons can come closer than the above indicated minimum safe distance to the front face of the antenna, i.e. 0.6 m. L'antenne fournie par le fabricant doit être placée de telle sorte que, durant les transmissions radio, personne ni aucun groupe de personnes ne puisse s'approcher à une distance inférieur à la distance de sécurité minimal indiquée ci-dessus, c.-à-d., 0.6 m. To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding the minimum safe distance shown above, and in accordance with the requirements of the antenna manufacturer or supplier. Antenna substitution Do not use any other antenna than the models supplied or recommended by the manufacturer. You may be exposing people to excess radio frequency radiation. You may contact the manufacturer for further instructions. Radiation warning You, as the qualified end-user of this radio device, must control the exposure conditions of bystanders to ensure the minimum separation distance (above) is maintained between the antenna and nearby persons, for satisfying RF Exposure compliance. The operation of this transmitter must satisfy the requirements of General Population/ Uncontrolled Environment. Only use the terminal when persons are at least the minimum distance from the front face of the antenna. WARNING!Maintain a separation distance of at least 0.6 m from the front face of the antenna to a person. About this manual 98-143082-DraftA6v About this manual3 Intended readers This manual is a user manual for the EXPLORER 510. The manual is intended for anyone who is using or intends to use the EXPLORER 510. No specific skills are required to operate the EXPLORER 510. However, it is important that you observe all safety requirements listed in the Safety summary in the beginning of this manual, and operate the EXPLORER 510 according to the guidelines in this manual. Related documents The following documents are related to this manual and to the EXPLORER 510 syste…

Text truncated - open the document above for the full version.

Thrane & Thrane A/S trading as Cobham SATCOM Registered no.: DK - 65 72 46 18. Registered address: Lundtoftegaardsvej 93 D, DK-2800 Kgs. Lyngby, Denmark www.cobham.com Date: Oct. 14, 2014 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 USA PER: 47 CFR 0.457 and 0.459 RE: FCC ID: ROJ-3711A Pursuant to Sections 0.457 (d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of all of the information accompanying this Application as listed below, i.e.: 1) Block Diagrams, 2) Clock Block Diagrams, 3) Schematic Diagrams, 4) Operational Description, 5) Part lists, 6) Tune up Manual and procedures. In accordance with the FCC Public Notice dated June 15, 2004 (DA 04-1705), we hereby request short-term 180 days confidentiality for the following items prior to marketing the device: 7) Test Setup Photos 8) External Photos 9) Internal Photos 10) Operation Manual (User Manual) These materials contain trade secrets and proprietary information not customarily released to public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefit to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(l)(ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Morten Becker Saul RF Senior Engineer BGAN Research & Development Cobham SATCOM Lundtoftegaardsvej 93 D DK-2800 Kgs. Lyngby Denmark Phone: +45 39 55 88 00 Fax: +45 39 55 88 88 E-mail: [email protected]

Thrane & Thrane A/S trading as Cobham SATCOM Registered no.: DK - 65 72 46 18. Registered address: Lundtoftegaardsvej 93 D, 2800 Kgs. Lyngby, Denmark www.cobham.com Subject: Validity of Test Results from Testing / Certification of the Integrated Module We, THRANE & THRANE A/S, Lundtoftegaardsvej 93 D, Lyngby DK-2800 Denmark, due hereby declare that that the test results from conducted tests applied to the radio module: Manufacturer: Texas Instruments Incorporated Model: WL18MODGB FCC ID: Z64-WL18SBMOD IC: 451I-WL18SBMOD which is incorporated in our host equipment: Manufacturer: THRANE & THRANE A/S Model: TT-3711A FCC ID: ROJ-3711A IC: 6200B-3711A and as reported in module test report(s): Report Number: FR3N2752-01C, Issue Date: 24/04/2014 (WLAN FCC report, Sporton International INC) Report Number: CR3N2752-01CTX, Issue Date: 24/04/2014 (WLAN IC Report, Sporton International INC) Report Number: CI3N2752, Issue Date: 20/01/2014 Accurately represent the test results under the new conditions when the identified radio module is integrated in the identified host equipment. By integration of the said radio module into the identified host equipment no changes were made to it or by external adaptation circuitry that impacts the validity of the results of the original module’s test reports. Sincerely, Morten Becker Saul. BGAN R&D, Project Manager. To Whom It May Concern: Cobham SATCOM Lundtoftegaardsvej 93 D 2800 Kgs. Lyngby Denmark T: +45 39 55 88 00 F: +45 39 55 88 88

Test report no.: 1-8390/14-01-08_AnnexA Page 1 of 10 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Karsten Geraldy Professional Radio Communications & EMC Test report no.: 1-8390/14-01-08_AnnexA Page 2 of 10 External ph ot os o f t he EU T Photo 1: Photo 2: Test report no.: 1-8390/14-01-08_AnnexA Page 3 of 10 Photo 3: Photo 4: Test report no.: 1-8390/14-01-08_AnnexA Page 4 of 10 Photo 5: Photo 6: Test report no.: 1-8390/14-01-08_AnnexA Page 5 of 10 Photo 7: Photo 8: Test report no.: 1-8390/14-01-08_AnnexA Page 6 of 10 Photo 9: Photo 10: Test report no.: 1-8390/14-01-08_AnnexA Page 7 of 10 Photo 11: Photo 12: Test report no.: 1-8390/14-01-08_AnnexA Page 8 of 10 Photo 13: Photo 14: Test report no.: 1-8390/14-01-08_AnnexA Page 9 of 10 Photo 15: Photo 16: Test report no.: 1-8390/14-01-08_AnnexA Page 10 of 10 Docu men t his to r y Version Applied changes Date of release Initial release 2014-11-13

BA 4 3 2 1 ABCD 1 2 3 4 DC SHEET 1 OF 1 CODE IDENT NO. SIZE A3 FIRST ANGLE PROJECTION DR. JGR 25-09-2014 UNLESS OTHERWISE SPECIFIEDDIMENSIONS ARE IN MILLIME-TRES AND TOLERANCES ARE IN ACCORDANCE WITH DS 22768. ANGLES LIN.DIM. MATERIAL USED ON NEXT ASSY APPLICATION DESCRIPTION REVISIONS LTR DATE APPROVAL TITLE TT-3711-A Placement of label A Original 29-09-2014 Telecommunications Engineering Copenhagen Denmark SCALE CH. MBS 26-09-2014 AP. MBS 26-09-2014 AP. DRAWING FILE: TT-3711-A Satcom Thrane & Thrane trading as Cobham Satcom This Document and any other appended documents and drawings are of copyright to Thrane & Thrane A/S. It contains proprietary information w hich is disclosed for information purposes only. The contents of this document shall not in wh ole or in part be used for any other purpose; be disclosed to any member of the recipien ts organisation not having a need to know such information or to any third party, indivi dual, organisation or Government; be stored in any retrieval system or be produced or tr ansmitted in any form by photocopying or any optical, mechanical or other means without prio r permission of Thrane & Thrane A/S. Placement of Type Label

Test report no.: 1-8390/14-01-08_AnnexB Page 1 of 8 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Karsten Geraldy Professional Radio Communications & EMC Test report no.: 1-8390/14-01-08_AnnexB Page 2 of 8 Inter nal p ho tos of the E UT (as p ro vi ded b y the man uf acturer ) Photo 1: Photo 2: Test report no.: 1-8390/14-01-08_AnnexB Page 3 of 8 Photo 3: Photo 4: Test report no.: 1-8390/14-01-08_AnnexB Page 4 of 8 Photo 5: Photo 6: Test report no.: 1-8390/14-01-08_AnnexB Page 5 of 8 Photo 7: Test report no.: 1-8390/14-01-08_AnnexB Page 6 of 8 Photo 8: Test report no.: 1-8390/14-01-08_AnnexB Page 7 of 8 Photo 9: Test report no.: 1-8390/14-01-08_AnnexB Page 8 of 8 Docu men t his to r y Version Applied changes Date of release Initial release 2014-11-13

2015-04-23 Page 1 of 2 Prediction of MPE and ERP/ EIRP As to the TT-3711A BGAN satellite terminal made by Thrane & Thrane A/S, we declare that it complies with the Basic restrictions/Reference levels for electric, magnetic and electromagnetic fields as specified in the following standards for a minimum safety distance of 0.6 m: Nr. Standard Country/Region 1 47CFR FCC Part 1 (10-1-13 Edition) USA 2 RSS-102 (Issue 4, March 2010) Canada 3 EN 62311 / ICNIRP Guideline EU 4 Radiocommunications (Electromagnetic Radiation-Human Exposure) Standard 2003 AUS/NZ The compliance is demonstrated based on the following calculation model assessment: 1. The power density according to far-field model is: where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) 2. For single or multiple RF sources, the calculated power density should comply with the following: 1... lim2lim 2 1lim 1 1 lim   n eqneqeq n n eqn S S S S S S S S where: S eqn = the power density when f is i. S lim n = the reference level requirement for power density when f is i 3. The calculation of the power density or safe distance is: Note 1 The RF exposure is based on the far-field and the radiation exposure is over-estimated. Note 2 The maximum output power level is taken into account as a worst case for the purpose of the calculation of power density or safe distance. Note 3 The minimum antenna feed cable loss (assumed no cable loss) is taken into account as a worst case for the purpose of the calculation of power density or safe distance Note 4 The maximum antenna radiation exposure orientation and maximum antenna gain is taken into account as a worst case for the purpose of the calculation of power density and safe distance. 2 4R PG S   Test report no.: 1-8390/14-01-07 2015-04-23 Page 2 of 2 Calculation for Inmarsat (frequency band 1626.5 – 1660.5 MHz): S ≤ 푷∙푮 ( 푬푰푹푷 ) ∙풕∙푫풄 ퟒ∙흅∙푹 ퟐ = 9.21 W/m 2 푺 푺 풍풊풎 ≤ 0.921 (less than 1, compliant) Where: EIRP (푃∙퐺) = 33.11 W = 15.2 dBW (45.2 dBm) according to test report 1-8390/14-01-05 t = Tune up tolerance (±1.0 dB) Dc = --- R ≥ 0.60 m S lim = 10 W/m 2 Calculation for WLAN (frequency band 2402 – 2483 MHz) : S ≤ 푷∙푮 ( 푬푰푹푷 ) ∙풕∙푫풄 ퟒ∙흅∙푹 ퟐ = 0.0080 W/m 2 푺 푺 풍풊풎 ≤ 0.00080 (less than 1, compliant) Where: EIRP (푃∙퐺) = 0.029 W (14.6 dBm) according to test report 1-8390/14-01-09 t = Tune up tolerance (±1.0 dB) Dc = 1:1 R ≥ 0.60 m S lim = 10 W/m 2 Declaration prepared by: Thomas Vogler Professional Radio Communications & EMC

SPORTON INTERNATIONAL INC. Page Number : 1 of 71 TEL : 886-3-327-3456 Report Issued Date : Jan. 27, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : Z64-WL18SBMOD DTS v1.0 FCC RF Test Report Report No. : FR3N2752-01C FCC RF Test Report APPLICANT : Texas Instruments Incorporated EQUIPMENT : WiFi and Bluetooth Module BRAND NAME : Texas Instruments MODEL NAME : WL18MODGB FCC ID : Z64-WL18SBMOD STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DTS) Digital Transmission System The product was received on Nov. 27, 2013 and testing was completed on Dec. 20, 2013. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown to be compliant with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 71 TEL : 886-3-327-3456 Report Issued Date : Jan. 27, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : Z64-WL18SBMOD DTS v1.0 FCC RF Test Report Report No. : FR3N2752-01C TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Feature of Equipment Under Test ..................................................................................................... 5 1.4 Product Specification of Equipment Under Test ................................................................................ 6 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Testing Site ........................................................................................................................................ 7 1.7 Applied Standards ............................................................................................................................. 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Carrier Frequency and Channel ........................................................................................................ 8 2.2 Pre-Scanned RF Power ..................................................................................................................... 9 2.3 Test Mode ........................................................................................................................................ 10 2.4 Connection Diagram of Test System ............................................................................................... 11 2.5 Support Unit used in test configuration and system ........................................................................ 12 2.6 EUT Operation Test Setup .............................................................................................................. 12 2.7 Measurement Results Explanation Example ................................................................................... 12 3 TEST RESULT ........................................................................................................................................... 13 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 13 3.2 Peak Output Power Measurement .................................................................................................. 16 3.3 Power Spectral Density Measurement ............................................................................................ 19 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 22 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 41 3.6 AC Conducted Emission Measurement........................................................................................... 64 3.7 Antenna Requirements .................................................................................................................... 68 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 70 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 71 APPENDIX A. SETUP PHOTOGRAPHS SPORTON INTERNATIONAL INC. Page Number : 3 of 71 TEL : 886-3-327-3456 Report Issued Date : Jan. 27, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : Z64-WL18SBMOD DTS v1.0 FCC RF Test Report Report No. : FR3N2752-01C REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR3N2752-01C Rev. 01 Initial issue of report Jan. 27, 2014 SPORTON INTERNATIONAL INC. Page Number : 4 of 71 TEL : 886-3-327-3456 Report Issued Date : Jan. 27, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : Z64-WL18SBMOD DTS v1.0 FCC RF Test Report Report No. : FR3N2752-01C SUMMARY OF TEST RESULT Report Section F…

Text truncated - open the document above for the full version.

TEST REPORT Test report no.: 1-8390/14-01-18-A Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-00 Thrane & Thrane A/S Lundtoftegaardsvej 93D DK-2800 Kgs Lyngby / DENMARK Phone: -/- Fax: +45 3955 8888 Contact: Morten Becker Saul e-mail: [email protected] Phone: +45 3955 8209 Manufacturer Thrane & Thrane A/S Lundtoftegaardsvej 93D DK-2800 Kgs Lyngby / DENMARK Test standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices RSS - 210 Issue 8 Spectrum Management and Telecommunications Radio Standards Specification - Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Satellite Terminal Model name: TT-3711A FCC ID: ROJ-TT3711A IC: 6200B-TT3711A Frequency: 2400 MHz to 2483.5 MHz ISM Band (lowest channel 01; highest channel 11) Technology tested: WLAN Antenna: External antenna Power supply: 24V DC Temperature range: -25°C to +55°C This test report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorised: Test performed: Marco Bertolino David Lang Radio Communications & EMC Radio Communications & EMC Test report no.: 1-8390/14-01-18-A Page 2 of 60 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 3.1 Measurement guidance ....................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 5.1 Additional information ........................................................................................................................ 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Description of the test setup ......................................................................................................................... 5 7.1 Radiated measurements chamber F .................................................................................................. 5 7.2 Radiated measurements chamber C ................................................................................................. 6 7.3 Radiated measurements 12.75 GHz to 26 GHz ................................................................................. 7 7.4 AC conducted ...................................................................................................................................... 8 7.5 Conducted measurements ................................................................................................................. 9 8 Summary of measurement results ............................................................................................................. 10 9 Additional comments ................................................................................................................................... 11 10 Measurement results ................................................................................................................................ 12 10.1 Antenna gain .................................................................................................................................. 12 10.2 Maximum output power ................................................................................................................. 13 10.3 Band edge compliance radiated ................................................................................................... 16 10.4 TX spurious emissions radiated................................................................................................... 21 10.5 RX spurious emissions radiated .................................................................................................. 50 10.6 Spurious emissions radiated < 30 MHz ....................................................................................... 54 10.7 Spurious emissions conducted < 30 MHz ................................................................................... 56 11 Test equipment and ancillaries used for tests ...................................................................................... 58 12 Observations ...........................................................................…

Text truncated - open the document above for the full version.

Test report no.: 1-8390/14-01-01_AnnexC Page 1 of 4 Annex C This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: David Lang Specialist Radio Communications & EMC Test report no.: 1-8390/14-01-01_AnnexC Page 2 of 4 EUT Test setup photos Photo 1: Photo 2: Test report no.: 1-8390/14-01-01_AnnexC Page 3 of 4 Photo 3: Photo 4: Test report no.: 1-8390/14-01-01_AnnexC Page 4 of 4 Document history Version Applied changes Date of release Initial release 2014-10-09
