ROJEXPLORER-300INMARSAT TERMINAL WITH BLUETOOTH

USER MANUAL EXPLORER 300 Thrane & Thrane A/S • [email protected] • www.thrane.com 32573-EXP300-BT-USER-cover-A4 03/05/06 14:44 Side 1 TT 98-123571-DraftAii TT-3705A EXPLORER™ 300 Document number: TT 98-123571-DraftA Release date: 22 May 2006 Information in this document is subject to change without notice and does not represent a commitment on the part of Thrane & Thrane A/S. Copyright © 2006 Thrane & Thrane A/S. All rights reserved. Trademark acknowledgements •EXPLORER is a trademark of Thrane & Thrane A/S. •Bluetooth is a registered trademark of Bluetooth SIG. •Windows and Outlook are registered trademarks of Microsoft Corporation in the United States and other countries. •Inmarsat is a registered trademark of the International Maritime Satellite Organisation (IMSO) and is licensed by IMSO to Inmarsat Limited and Inmarsat Ventures plc. •Inmarsat’s product names are either trademarks or registered trademarks of Inmarsat. •Other product and company names mentioned in this manual may be trademarks or trade names of their respective owners. Company Addresses www.thrane.com DenmarkDenmark Thrane & Thrane A/S Lundtoftegårdsvej 93 D DK-2800 Kgs. Lyngby Denmark T: +45 39 55 88 00 F: +45 39 55 88 88 Thrane & Thrane Aalborg A/S Porsvej 2 DK-9200 Aalborg SV Denmark T: +45 39 55 88 00 F: +45 96 34 61 01 USAChina Thrane & Thrane, Inc. 509 Viking Drive, Suites K, L and M Virginia Beach, VA 23452 USA T: +1(866) SATCOMS or +1 (757) 463-9557 F: +1 (757) 463-9581 Thrane & Thrane Shanghai Representative Office 28J Pufa Tower 588 Pudong Rd(S), Pu Dong 200120 Shanghai P. R. China T: +86 21 68 87 87 80 F: +86 21 68 87 71 12 TT 98-123571-DraftAiii Safety summary1 The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of the equipment. Thrane & Thrane A/S assume no liability for the customer's failure to comply with these requirements. Do not operate in an explosive atmosphere Do not operate the equipment in the presence of flammable gases or fumes. Operation of any electrical equipment in such an environment constitutes a definite safety hazard. Keep away from live circuits Operating personnel must not remove equipment covers. Component replacement and internal adjustment must be made by qualified maintenance personnel. Do not replace components with the power cable connected. Under certain conditions, dangerous voltages may exist even with the power cable removed. To avoid injuries, always disconnect power and discharge circuits before touching them. Do not service alone Do not attempt internal service or adjustments unless another person, capable of rendering first aid resuscitation, is present. Do not substitute parts or modify equipment Because of the danger of introducing additional hazards, do not substitute parts or perform any unauthorized modification to the equipment. Keep away from active antenna front This device emits radio frequency energy when switched on. To avoid injury, keep a minimum safety distance of 0.6 m from the antenna front when the EXPLORER™ 300 is on. See also the below section Antenna safety instructions. Only use approved batteries from Thrane & Thrane Use of non approved batteries may result in explosion, fire, electrical shock or injury. Observe marked areas Under extreme heat conditions do not touch areas of the EXPLORER™ 300 that are marked with this symbol, as it may result in injury. Antenna safety instructions TT 98-123571-DraftAiv Antenna safety instructions2 Use only manufacturer supplied antennas Antenna minimum safe distance: 60 cm Antenna gain Directional, with maximum gain of 11.1 dB reference to isotropic. The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits. Antenna mounting The antenna supplied by the manufacturer must be located such that during radio transmission, no person or persons can come closer than the above indicated minimum safe distance to the antenna, i.e. 60 cm. To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding the minimum safe distance shown above, and in accordance with the requirements of the antenna manufacturer or supplier. Antenna substitution Do not substitute any antenna for the models supplied or recommended by the manufacturer. You may be exposing people to excess radio frequency radiation. You may contact the manufacturer for further instructions. Radiation warning You, as the qualified end-user of this radio device, must control the exposure conditions of bystanders to ensure the minimum separation distance (above) is maintained between the antenna and nearby persons, for satisfying RF Exposure compliance. The operation of this transmitter must satisfy the requirements of Occupational/Controlled Exposure Environment, for work-related use. Only use the terminal when persons are at least the minimum distance from the front face of the antenna. WARNING!Maintain a separation distance of at least 60 cm from the front face of the antenna to a person. About this manual TT 98-123571-DraftAv About this manual3 Intended readers This manual is a user manual for the EXPLORER™ 300. The readers of the manual include anyone who is using or intends to use the EXPLORER™ 300. No specific skills are required to operate the EXPLORER™ 300. However, it is important that you observe all safety requirements listed in the Safety summary and in the Antenna safety instructions in the beginning of this manual, and operate the EXPLORER™ 300 according to the guidelines in this manual. Manual overview This manual has the following chapters: •Introduction contains an overview of the BGAN services and a brief description of the system. •Getting started explains how to inse…

Text truncated - open the document above for the full version.

Figure 1 Front view Figure 2 Side view Figure 3 Rear view Figure 4 bottom view Figure 5 Battery Figure 6 Battery Figure 7 Battery Figure 8 Battery Figure 9 Battery Figure 10 Battery Figure 11 Battery

Figure 1 Mainboard Figure 2 Mainboard Figure 3 Mainboard Figure 4 Mainboard Figure 5 Mainboard

Figure 1 PSU, 2-Wire and GPS Board Figure 2 PSU, 2-Wire and GPS Board Figure 3 Display and Keyboard Figure 4 Display and Keyboard

Figure 1 Frontend Module with shields Figure 2 Frontend Module with shields Figure 3 Frontend Module without shields Figure 4 Frontend Module without shields Figure 5 Transceiver Module with shields Figure 6 Transceiver Module with shields Placement of WLAN card Bluetooth section Figure 7 Transceiver Module without shields Figure 8 Transceiver Module without shields Figure 9 WLAN card with shield Figure 10 WLAN card without shield Figure 11 WLAN card Bluetooth antenna WLAN Card WLAN antenna WLAN antenna Figure 12 Transceiver and WLAN boards in the Transceiver Unit Bluetooth antenna WLAN antenna WLAN antenna Figure 13 Bluetooth and WLAN antennas Bluetooth antenna WLAN antenna WLAN antenna Figure 14 Bluetooth and WLAN antennas

M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Environmental Assessment for Mobiles/Fixed Base Station FCC ID: FCC ID: ROJEXPLORER-300 Model:Explorer 300 to Federal Communications Commission 47 CFR 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: May 23, 2006 On the Behalf of the Applicant: Thrane & Thrane A/S At the Request of: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark Attention of: Morten Becker Saul +45 39 55 8209 Email: [email protected] Supervised By: David E. Lee, FCC/IC Compliance Manager M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 1 of 7 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0640004 d) Client: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark e) Identification: Explorer 300 FCC ID: ROJEXPLORER-300 Description: Immarsat Terminal f) EUT Condition: Not required unless specified in individual tests. g) Report Date: May 23, 2006 EUT Received: Apr 2, 2006 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, FCC/IC Compliance Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 2 of 7 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Identification of the Equipment Under Test (EUT) Name and Address of Applicant: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark Manufacturer: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark FCC ID: ROJEXPLORER-300 Model Number: Explorer 300 Description: Immarsat Terminal Type of Emission: 16QAM, QPSK Frequency Range, MHz: 1626.5 – 1660.5 Power Rating, Watts (EIRP): 10.0 Switchable X Variable N/A Modulation: AMPS TDMA X CDMA X OTHER Antenna: Helical Monopole Whip X Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 11 dBi) and RF Power set to highest nominal power across all channels. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 3 of 7 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 NIST I am pleased to inform you that your laboratory has been validated by the Chinese Taipei Bureau of Standards, Metrology and Inspection (BSMI) under the Asia Pacific Economic Cooperation Mutual Recognition Agreement (APEC MRA). Your laboratory is now formally designated to act as a Conformity Assessment Body (CAB) under Appendix B, Phase I Procedures, of the APEC MRA between the American Institute in Taiwan (AIT) and the Taipei Economic and Cultural Representative Office (TECRO) in the United States, covering equipment subject to Electro-Magnetic Compatibility (EMC) requirements. The names of all validated and nominated laboratories will be posted on the NIST website at http://ts.nist.gov/mra under the ‘Asia’ category.” BSMI Number: SL2-IN-E-041R M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 4 of 7 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2003, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 5 of 7 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER500 (480) 926-3100 phone, fax (480) 926-3598 MFAp0640004, d0580059 Name of Test: Environmental Assessment Specification: FCC: 47 CFR 1.1310 Measurement Guide: ANSI/IEEE C95.1 1992 Test Equipment: Maximum Permissible Exposure (MPE) measurement system, consisting of: Amplifier Research FP6001 Electric Field Probe Kit (Calibrated July 2005) Measurement Procedure: 1. The f…

Text truncated - open the document above for the full version.

M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 Date: May 23, 2006 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Thrane & Thrane A/S Equipment: Explorer 300 FCC ID: ROJEXPLORER-300 FCC Rules: Part 25, and Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Michael Schafer, President enclosure(s) cc: Applicant DEL/del M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 Transmitter Certification of FCC ID: ROJEXPLORER-300 Model: Explorer 300 to Federal Communications Commission Rule Part(s) Part 25, and Confidentiality Date of report: May 23, 2006 On the Behalf of the Applicant: Thrane & Thrane A/S At the Request of: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark Attention of: Morten Becker Saul +45 39 55 8209 Email: [email protected] Supervised by: David E. Lee, FCC/IC Compliance Manager M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: Thrane & Thrane A/S FCC ID: ROJEXPLORER-300 By Applicant: 1. Letter of Authorization 2. Confidentiality Request: 0.457 And 0.459 3. Identification Drawings, 2.1033(c)(11) Label Location of Label Compliance Statement Location of Compliance Statement 4. Photographs, 2.1033(c)(12) 5. Documentation: 2.1033(c) (3) User Manual (9) Tune Up Info (10) Schematic Diagram (10) Circuit Description Block Diagram Parts List Active Devices 6. MPE Report By M.F.A. Inc.: A. Testimonial & Statement of Certification M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 Table of Contents Rule Description Page 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 2.1033(c) General Information Required 4 2.1046(a) Carrier Output Power (Conducted) 6 2.1046(a) EIRP Carrier Power (Radiated) 8 2.1051 Unwanted Emissions (Transmitter Conducted) 10 2.1053(a) Field Strength of Spurious Radiation 14 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 17 2.1055(a)(1) Frequency Stability (Temperature Variation) 26 2.1055(b)(1) Frequency Stability (Voltage Variation) 28 25.216 Limits on Emissions (Mobile Earth Stations) 30 25.253 Special Requirements 32 15.205. Restricted Bands Of Operation 36 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 37 Chandler, Arizona 85225-7176 FCC ID: ROJEXPLORER-300 (480) 926-3100 phone, (480) 926-3598 fax MFA p0640004, d0660006 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0640004 d) Client: Thrane & Thrane A/S Lundtoftegardsvej 93D DK-2800 Lyngby, Denmark e) Identification: Explorer 300 FCC ID: ROJEXPLORER-300 EUT Description: Immarsat Terminal f) EUT Condition: Not required unless specified in individual tests. g) Report Date: May 23, 2006 EUT Received: April 2, 2006 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, FCC/IC Compliance Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: Thi…

Text truncated - open the document above for the full version.
