ROR00000003HUB AND RBM MODULE

BLiNQ Networks Inc. X-1200 Intelligent Wireless Backhaul System Installation Guide Release 1.0 Issue 01 D1 April 2014 BLiNQ Networks Inc. X-1200 System Installation Guide Release 1.0 Confidential - Restricted Use and Duplication Page ii Issue 01 D1 Revision History Date Issue Reason for Issue August 2013 01 Early Availability January 2014 1.0 Final Document April 2014 1.0 D1 Label Update (Approvals); Compliance update including Antenna Contact Information: BLiNQ Networks Inc. 400 March Road, Suite 240 Ottawa, ON K2K 3H4 Web Site: http://www.blinqnetworks.com Sales Inquiries: Email: [email protected] Telephone: 1-613-599-3388 x280 Customer Support: Web: http://www.blinqnetworks.com/support Email: [email protected] Telephone: 1-613-599-3388 x270 BLiNQ Networks Inc. X-1200 System Installation Guide Release 1.0 Confidential - Restricted Use and Duplication Page iii Issue 01 D1 Table of Contents 1 Important Safety and Service Notices ..........................................................................................1 1.1 Safety Warnings ............................................................................................................................ 1 1.2 Important Service and Warranty Information .............................................................................. 1 1.3 Overvoltage (Lightning/Surge) Protection .................................................................................... 2 2 System Description .....................................................................................................................4 3 Flowchart: Installation Process Overview ....................................................................................7 4 Required Installation Items .........................................................................................................8 5 Site Preparation........................................................................................................................ 11 5.1 Operating Sector Frequency Check ............................................................................................. 11 5.2 HM and RBM Pre-Installation Checks and Service Provisioning ................................................. 11 6 Installing the Modules (General) ............................................................................................... 13 6.1 General Safety Information ........................................................................................................ 13 6.2 Equipment Distance and Orientation ......................................................................................... 14 6.2.1 Hub Modules ....................................................................................................................... 14 6.2.2 Remote Backhaul Modules ................................................................................................. 14 6.3 Mounting to a Pole or Wall ......................................................................................................... 14 6.3.1 Attaching Pole Clamps to Mounting Bracket ...................................................................... 14 6.3.2 Mounting with U- or V-Clamps ........................................................................................... 16 6.3.3 Mounting with Steel Straps................................................................................................. 17 6.3.4 Mounting onto a Wall ......................................................................................................... 18 6.4 Assembling the Module Brackets ............................................................................................... 19 6.4.1 Attach Elevation Bracket ..................................................................................................... 19 6.4.2 Attach Azimuth Bracket ...................................................................................................... 21 6.5 Installing the Power Supply Unit (Optional) ............................................................................... 23 6.5.1 Installing the PSU Bracket ................................................................................................... 23 6.5.2 Installing the Power Supply Unit ......................................................................................... 24 6.6 Installing the Module onto a Mounting Bracket ......................................................................... 26 6.7 Grounding and Overvoltage Protection Instructions .................................................................. 28 6.7.1 Installing the Grounding Cable ............................................................................................ 28 6.7.2 Installing the Lightning/Surge Arrestor ............................................................................... 29 6.8 Connecting to DC Power ............................................................................................................. 31 6.9 Verifying Basic Installation .......................................................................................................... 33 6.10 Connecting to the Ethernet Backhaul Network .......................................................................... 34 6.10.1 Connecting to the RJ45 Ethernet Port ................................................................................ 34 6.10.2 Connecting to the SFP Port ................................................................................................. 36 6.11 Cable Management ..................................................................................................................... 36 BLiNQ Networks Inc. X-1200 System Installation Guide Release 1.0 Confidential - Restricted Use and Duplication Page iv Issue 01 D1 7 Installing the Hub Module ......................................................................................................... 38 7.1 Ad…

Text truncated - open the document above for the full version.

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at device output terminal:24.57dBm Cable and Jumper loss:0.0dB Maximum peak output power at antenna input terminal:24.57dBm 286.417797mW Single Antenna gain (typical):16dBi Number of Antennae:1 Total Antenna gain (typical):16dBi 39.81071706(numeric) Prediction distance:50cm Prediction frequency:5740MHz MPE limit for uncontrolled exposure at prediction frequency:1mW/cm 2 Power density at prediction frequency:0.362953 mW/cm 2 3.629528W/m 2 Tx On time:1.000000ms Tx period time:1.000000ms Average Factor:100.000000% Average Power density at prediction frequency:3.629528W/m 2 Maximum allowable antenna gain:20.40149873dBi Margin of Compliance:4.401498727 dB 2 4R PG S π =

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation FCC 15.407 and RSS-210 A9.docx; Date: May 2013 SCC Accredited LAB LAB Accrédité CCN TM ONE WORLDOURAPPROVAL Test report 250684-1TRFWL Date of issue: April 7, 2014 Applicant: BLiNQ Wireless Inc. Product: RF module for Hub and RBM Model: RD-5800 FCC ID: IC Registration number: ROR00000003 10794A-00000003 Specifications:  FCC 47 CFR Part 15 Subpart E, §15.407 Unlicensed National Information Infrastructure Devises  RSS-210, Issue 8, December 2010, Annex 9 Local Area Network Devices Report reference ID: 250684-1TRFWL Page 2 of 43 Test location Company name: Nemko Canada Inc. Address: 303 River Road City: Ottawa Province: Ontario Postal code: K1V 1H2 Country: Canada Telephone: +1 613 737 9680 Facsimile: +1 613 737 9691 Toll free: +1 800 563 6336 Website: www.nemko.com Site number: FCC: 176392; IC: 2040A-4 (3 m semi anechoic chamber) Tested by: Andrey Adelberg, Senior Wireless/EMC Specialist Reviewed by: Kevin Rose, Wireless/EMC Specialist Date: April 7, 2014 Signature: Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: 250684-1TRFWL Page 3 of 43 Table of contents Table of contents .......................................................................................................................................................................................................... 3 Section 1. Report summary ................................................................................................................................................................................. 4 1.1 Applicant .................................................................................................................................................................................................................. 4 1.2 Manufacturer ........................................................................................................................................................................................................... 4 1.3 Test specifications .................................................................................................................................................................................................... 4 1.4 Test methods ............................................................................................................................................................................................................ 4 1.5 Statement of compliance ......................................................................................................................................................................................... 4 1.6 Exclusions ................................................................................................................................................................................................................. 5 1.7 Test report revision history ...................................................................................................................................................................................... 5 Section 2. Summary of test results ....................................................................................................................................................................... 6 2.1 FCC Part 15 Subpart C, general requirements test results ........................................................................................................................................ 6 2.2 FCC Part 15 Subpart E, test results ........................................................................................................................................................................... 6 2.3 RSS-Gen, Issue 3, test results.................................................................................................................................................................................... 6 2.4 IC RSS-210, Issue 8, test results ................................................................................................................................................................................ 7 Section 3. Equipment under test (EUT) details ..................................................................................................................................................... 8 3.1 Sample information .................................................................................................................................................................................................. 8 3.2 EUT information ....................................................................................................................................................................................................... 8 3.3 Technical information ................................................................................................................................................................…

Text truncated - open the document above for the full version.

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation setup photos.docx; Date: May 2013 SCC Accredited LAB LAB Accrédité CCN TM ONE WORLDOURAPPROVAL Setup photos 250684-2RADWL Date of issue: April 7, 2014 Applicant: BLiNQ Wireless Inc. Product: RF module for Hub and RBM Model: RD-5800 FCC ID: IC Registration number: ROR00000003 10794A-00000003 Section 1: Internal photos Report reference ID: -2RADWL Page 2 of 5 Section 1. Internal photos 1.1 RF Module top view 1.2 Label view Label location Section 1: Internal photos Report reference ID: -2RADWL Page 3 of 5 1.3 RF Module bottom view Section 1: Internal photos Report reference ID: -2RADWL Page 4 of 5 1.4 Radiated emissions setup view Section 1: Internal photos Report reference ID: -2RADWL Page 5 of 5 1.5 Conducted emissions setup view
