RUMCL3433MHz Remote Control

Page 1 of 4 FCC ID: RUMCL3 User Manual for models CL3, CS-CL3& BT-CL3 The device compliance with Part 15 of the rules. Operation is subject to following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Page 2 of 4 FCC ID: RUMCL3 Page 3 of 4 FCC ID: RUMCL3 Page 4 of 4 FCC ID: RUMCL3

Page 1 of 1 FCC ID: RUMCL3 Block diagram of CL3, CS-CL3 & BT-CL3 Key pad Encode (PT2262) 433.92 MHz Transmitter (X1) Integral Transmission antenna RF band pass filter (SAW filter) Modulator (Q1) Incorporated into SAW com ponent shown on PCB

Page 1 of 1 FCC ID: RUMCL3 External Photos for Models CL3, CS-CL3 & BT-CL3

Page 1 of 1 FCC ID: RUMCL3 ID Labels for models CL3, CS-CL3&BT-CL3 FCC ID: RUMCL3 Trade mark Due to the size of transmitter, warning sentence according to FCC part 15 is located in user manual., page 1 Label size : 1:1

Page 1 of 2 FCC ID: RUMCL3 Internal Photos of Model CL3, CS-CL3&BT-CL3 Page 2 of 2 FCC ID: RUMCL3

Page 1 of 1 FCC ID:RUMCL3 Technical Description CL3, CS-CL3 & BT-CL3 are 433.92MHz pulsed RF transmitter remote control. The remote control’s internal MCUs receive information from the keypad and convert the keystrokes into a pulse code(by chip PT2262). The pulse code is then sent to the SAW component which incorporate 433.92MHz RF transmitter(X1), RF band pass filter (SAW fliter), then send signal to modulation module (Q1), and transmit through the integral antenna.

Page 1 of 1 FCC ID : RUMCL3 A0 Vcc A1 Dout A2 OSC1 A3 OSC2 A4 TE A5 A11/D0 A6/D5 A10/D1 A7/D4 A9/D2 Vss A8/D3 IC1 PT2262 123456789 181716151413121110 LED D2 IN4148*2 R5, 10k R6, 1M2 Vcc R1 10k R2 10k R3 10k R4 10k EM BAT 12V/23A R7, 240 R9, 51k C3,4p SAW filte r X1 433.92MHz C2,4p C1,3p Vcc ANT. R8, 47 Q1 28C3356 LL,0.47 μ H L1,2p Schematic diagram of CL3, CS-CL3 & BT-CL3 STOP D3 C4, 3p

Report no: JSH0312294-003A Page 1 of 16 FCC ID: RUMCL3 EMC TEST REPORT For FCC Part 15 Certification No. JSH0312294-003A Summary The equipment comply with the requirements according to the following standard(s): 47CFR Part 15:2003: RADIO FREQUENCY DEVICES ANSI C63.4 : 2001 : American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz. Description The appliances were tested by and found compliance with relevant requirements described in FCC Part 15: 2003: RADIO FREQUENCY DEVICES. Test results are contained in this test report and Intertek Testing Services ETL SEMKO Shanghai Limited is assumed full responsibility for the accuracy and completeness of these measurements. The test report applies to tested samples only and shall not be reproduced in part without written approval of Intertek Testing Services ETL SEMKO Shanghai Limited. Date of Test: June 28, 2004 Date of Issue: July 7, 2004 Prepared by: Report Approved by: Tino Pan (Projector Engineer) Steve Li (EMC Manager) Report no: JSH0312294-003A Page 2 of 16 FCC ID: RUMCL3 Description of Test Facility Name of Firm : QuieTek (Shanghai) Corporation Site Location : 716 Yishan Road, Shanghai, China 200233 Name of contact : Mr. Hall (first name) Wang (last name) Phone : 86-21-64700066 ext. 201 Fax : 86-21-64514252 E-mail address : [email protected] FCC Registration number: 142171 Report no: JSH0312294-003A Page 3 of 16 FCC ID: RUMCL3 CONTENTS Summary ........................................................................................................................................ 1 Description..................................................................................................................................... 1 Description of Test Facility ........................................................................................................... 2 1. Applicant Information .............................................................................................................. 4 2.Information of Equipment Under Test (EUT) ......................................................................... 4 2.1 Identification of the EUT ................................................................................................... 4 2.2 Additional information about the EUT ............................................................................ 5 2.3 Peripheral equipment ......................................................................................................... 5 3. Conducted Powerline Measurement ........................................................................................ 6 4. Radiated emission measurement .............................................................................................. 6 4.1 Radiated emission limit ...................................................................................................... 6 4.2 Instruments list .................................................................................................................... 6 4.3 Test setup ............................................................................................................................. 7 4.4 Test configuration ............................................................................................................... 7 4.5 Test procedure ..................................................................................................................... 7 4.6 Test Results ...................................................................................................................... 8 4.7 Measurement Uncertainty ............................................................................................... 12 5. The bandwidth of the emission............................................................................................... 13 5.1 the limit of the bandwidth of the emission ..................................................................... 13 5.2 Instruments list .................................................................................................................. 13 5.3 Test setup ........................................................................................................................... 13 5.4 Test configuration ............................................................................................................. 14 5.5 Test procedure ................................................................................................................... 14 5.6 Test Results .................................................................................................................... 14 5.7 Measurement Uncertainty ............................................................................................... 14 6. Sample field strength calculation ........................................................................................... 15 Report no: JSH0312294-003A Page 4 of 16 FCC ID: RUMCL3 1. Applicant Information Applicant: Geemarc Telecom International Ltd. 19F Mass Mutual Tower 38 Gloucester Road Wanchai Hong Kong Name of contact: Ms. Chen Qingruan Telephone: 86 592 6036442 Telefax: 86 592 6037860 Manufacturer: Xiamen Xinglian Electronics Co., Ltd. 6-7 F No.2 Bldg 2nd Stage Tian An Industrial District, Xiamen, Fujian, P.R.C 2.Information of Equipment Under Test (EUT) 2.1 Identification of the EUT Equipment: ClearSounds Emergency Response/Phone Signaler Type of EUT: ; Production … Pre-product … Pro-type Type/model: CL3, CS-CL3, BT-CL3 Serial number: 0312294-001~003 Date of sample receipt 2004-6-26 Date of test 2004-6-28 Test mode the product has two button which was “stop” and “alarm”, “stop”and “alarm” buttons to deactivate and activate the alarm respectively, therefore, only “stop”and “alarm” mode were tested during test. New battery was used during test. Rating: DC 12V Transmitter Operation frequency : 43…

Text truncated - open the document above for the full version.

Page 1 of 18 FCC ID: RUMCL3 The waveforms of models CL3, CS-CL3&BT-CL3 Radiated Emission waveform below 1GHz X axe (Vertical) MEASUREMENT RESULT: "R40628IT001V_fin QP" 6/28/2004 13:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.58 VERTICAL 14.26 3.71 80.80 4.22 868.255952 56.19 VERTICAL 20.23 5.33 60.80 4.61 Page 2 of 18 FCC ID: RUMCL3 X axe (Horizontal) MEASUREMENT RESULT: "R40628IT001H_fin QP" 6/28/2004 14:14 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.74 HORIZONTAL 14.26 3.71 80.80 4.06 868.259519 57.34 HORIZONTAL 20.23 5.33 60.80 3.46 Page 3 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT002H_fin QP" 6/28/2004 14:47 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.35 HORIZONTAL 14.26 3.71 80.80 3.45 868.259519 57.72 HORIZONTAL 20.23 5.33 60.80 3.08 Page 4 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT002V_fin QP" 6/28/2004 15:12 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.43 VERTICAL 14.26 3.71 80.80 3.37 868.259519 57.91 VERTICAL 20.23 5.33 60.80 2.89 Page 5 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT003H_fin QP" 6/28/2004 15:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 74.76 HORIZONTAL 14.26 3.71 80.80 6.04 868.259519 54.73 HORIZONTAL 20.23 5.33 60.80 6.07 Page 6 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT003V_fin QP" 6/28/2004 16:22 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 73.03 VERTICAL 14.26 3.71 80.80 7.77 868.259519 54.02 VERTICAL 20.23 5.33 60.80 6.78 Page 7 of 18 FCC ID: RUMCL3 Radiated Emission waveform above 1GHz X axe (Horizontal) MEASUREMENT RESULT: "R40628IT004H_fin QP" 6/28/2004 17:06 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.61 HORIZONTAL 23.30 4.30 60.80 4.19 -9.60 1727.173382 57.17 HORIZONTAL 24.50 5.00 60.80 3.43 -9.60 2170.200681 52.74 HORIZONTAL 26.90 5.60 60.80 8.06 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953906 49.77 HORIZONTAL 30.70 7.10 60.80 11.03 -9.60 3909.819639 52.65 HORIZONTAL 31.90 7.60 54.00 1.35 -9.60 Page 8 of 18 FCC ID: RUMCL3 X axe (Vertical) MEASUREMENT RESULT: "R40628IT004V_fin QP" 6/28/2004 17:45 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 54.82 VERTICAL 23.30 4.30 60.80 5.98 -9.60 1727.173382 55.34 VERTICAL 24.50 5.00 60.80 5.46 -9.60 2170.200681 57.05 VERTICAL 26.90 5.60 60.80 3.75 -9.60 2603.206413 58.35 VERTICAL 28.20 5.80 60.80 2.45 -9.60 3476.953908 51.95 VERTICAL 30.70 7.10 60.80 8.85 -9.60 3909.819639 52.87 VERTICAL 31.90 7.60 54.00 1.13 -9.60 Page 9 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT005H_fin QP" 6/28/2004 19:46 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.77 HORIZONTAL 23.30 4.30 60.80 4.03 -9.60 1727.173382 57.18 HORIZONTAL 24.50 5.00 60.80 3.62 -9.60 2170.200681 57.04 HORIZONTAL 26.90 5.60 60.80 3.76 -9.60 2603.206413 57.45 HORIZONTAL 28.20 5.80 60.80 3.35 -9.60 3476.953908 52.43 HORIZONTAL 30.70 7.10 60.80 8.37 -9.60 3909.819639 51.72 HORIZONTAL 31.90 7.60 54.00 2.28 -9.60 Page 10 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT005V_fin QP" 6/28/2004 20:27 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.21 VERTICAL 23.30 4.30 60.80 3.59 -9.60 1727.173382 57.09 VERTICAL 24.50 5.00 60.80 3.71 -9.60 2170.200681 54.03 VERTICAL 26.90 5.60 60.80 6.77 -9.60 2603.206413 54.74 VERTICAL 28.20 5.80 60.80 6.06 -9.60 3476.953908 44.73 VERTICAL 30.70 7.10 60.80 16.07 -9.60 3909.819639 52.93 VERTICAL 31.90 7.60 54.00 1.07 -9.60 Page 11 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT006H_fin QP" 6/28/2004 21:12 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.89 HORIZONTAL 23.30 4.30 60.80 2.91 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 55.73 HORIZONTAL 26.90 5.60 60.80 5.07 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953908 52.96 HORIZONTAL 30.70 7.10 60.80 7.84 -9.60 3909.819639 52.84 HORIZONTAL 31.90 7.60 54.00 1.16 -9.60 Page 12 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT006V_fin QP" 6/28/2004 21:55 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 58.39 HORIZONTAL 23.30 4.30 60.80 2.41 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 56.86 HORIZONTAL 26.90 5.60 60.80 3.94 -9.60 2603.206413 55.01 HORIZONTAL 28.20 5.80 60.80 5.79 -9.60 3476.953908 50.05 HORIZONTAL 30.70 7.10 60.80 10.75 -9.60 3909.819639 52.73 HORIZONTAL 31.90 7.60 54.00 1.27 -9.60 Page 13 of 18 FCC ID: RUMCL3 Waveform of Bandwidth Page 14 of 18 FCC ID: RUMCL3 Waveform of occupied duty cycle 360μs 120μs Page 15 of 18 FCC ID: RUMCL3 - Page 16 of 18 FCC ID: RUMCL3 Page 17 of 18 FCC ID: RUMCL3 Page 18 of 18 FCC ID: RUMCL3

Page 1 of 18 FCC ID: RUMCL3 The waveforms of models CL3, CS-CL3&BT-CL3 Radiated Emission waveform below 1GHz X axe (Vertical) MEASUREMENT RESULT: "R40628IT001V_fin QP" 6/28/2004 13:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.58 VERTICAL 14.26 3.71 80.80 4.22 868.255952 56.19 VERTICAL 20.23 5.33 60.80 4.61 Page 2 of 18 FCC ID: RUMCL3 X axe (Horizontal) MEASUREMENT RESULT: "R40628IT001H_fin QP" 6/28/2004 14:14 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.74 HORIZONTAL 14.26 3.71 80.80 4.06 868.259519 57.34 HORIZONTAL 20.23 5.33 60.80 3.46 Page 3 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT002H_fin QP" 6/28/2004 14:47 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.35 HORIZONTAL 14.26 3.71 80.80 3.45 868.259519 57.72 HORIZONTAL 20.23 5.33 60.80 3.08 Page 4 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT002V_fin QP" 6/28/2004 15:12 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.43 VERTICAL 14.26 3.71 80.80 3.37 868.259519 57.91 VERTICAL 20.23 5.33 60.80 2.89 Page 5 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT003H_fin QP" 6/28/2004 15:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 74.76 HORIZONTAL 14.26 3.71 80.80 6.04 868.259519 54.73 HORIZONTAL 20.23 5.33 60.80 6.07 Page 6 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT003V_fin QP" 6/28/2004 16:22 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 73.03 VERTICAL 14.26 3.71 80.80 7.77 868.259519 54.02 VERTICAL 20.23 5.33 60.80 6.78 Page 7 of 18 FCC ID: RUMCL3 Radiated Emission waveform above 1GHz X axe (Horizontal) MEASUREMENT RESULT: "R40628IT004H_fin QP" 6/28/2004 17:06 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.61 HORIZONTAL 23.30 4.30 60.80 4.19 -9.60 1727.173382 57.17 HORIZONTAL 24.50 5.00 60.80 3.43 -9.60 2170.200681 52.74 HORIZONTAL 26.90 5.60 60.80 8.06 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953906 49.77 HORIZONTAL 30.70 7.10 60.80 11.03 -9.60 3909.819639 52.65 HORIZONTAL 31.90 7.60 54.00 1.35 -9.60 Page 8 of 18 FCC ID: RUMCL3 X axe (Vertical) MEASUREMENT RESULT: "R40628IT004V_fin QP" 6/28/2004 17:45 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 54.82 VERTICAL 23.30 4.30 60.80 5.98 -9.60 1727.173382 55.34 VERTICAL 24.50 5.00 60.80 5.46 -9.60 2170.200681 57.05 VERTICAL 26.90 5.60 60.80 3.75 -9.60 2603.206413 58.35 VERTICAL 28.20 5.80 60.80 2.45 -9.60 3476.953908 51.95 VERTICAL 30.70 7.10 60.80 8.85 -9.60 3909.819639 52.87 VERTICAL 31.90 7.60 54.00 1.13 -9.60 Page 9 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT005H_fin QP" 6/28/2004 19:46 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.77 HORIZONTAL 23.30 4.30 60.80 4.03 -9.60 1727.173382 57.18 HORIZONTAL 24.50 5.00 60.80 3.62 -9.60 2170.200681 57.04 HORIZONTAL 26.90 5.60 60.80 3.76 -9.60 2603.206413 57.45 HORIZONTAL 28.20 5.80 60.80 3.35 -9.60 3476.953908 52.43 HORIZONTAL 30.70 7.10 60.80 8.37 -9.60 3909.819639 51.72 HORIZONTAL 31.90 7.60 54.00 2.28 -9.60 Page 10 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT005V_fin QP" 6/28/2004 20:27 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.21 VERTICAL 23.30 4.30 60.80 3.59 -9.60 1727.173382 57.09 VERTICAL 24.50 5.00 60.80 3.71 -9.60 2170.200681 54.03 VERTICAL 26.90 5.60 60.80 6.77 -9.60 2603.206413 54.74 VERTICAL 28.20 5.80 60.80 6.06 -9.60 3476.953908 44.73 VERTICAL 30.70 7.10 60.80 16.07 -9.60 3909.819639 52.93 VERTICAL 31.90 7.60 54.00 1.07 -9.60 Page 11 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT006H_fin QP" 6/28/2004 21:12 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.89 HORIZONTAL 23.30 4.30 60.80 2.91 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 55.73 HORIZONTAL 26.90 5.60 60.80 5.07 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953908 52.96 HORIZONTAL 30.70 7.10 60.80 7.84 -9.60 3909.819639 52.84 HORIZONTAL 31.90 7.60 54.00 1.16 -9.60 Page 12 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT006V_fin QP" 6/28/2004 21:55 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 58.39 HORIZONTAL 23.30 4.30 60.80 2.41 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 56.86 HORIZONTAL 26.90 5.60 60.80 3.94 -9.60 2603.206413 55.01 HORIZONTAL 28.20 5.80 60.80 5.79 -9.60 3476.953908 50.05 HORIZONTAL 30.70 7.10 60.80 10.75 -9.60 3909.819639 52.73 HORIZONTAL 31.90 7.60 54.00 1.27 -9.60 Page 13 of 18 FCC ID: RUMCL3 Waveform of Bandwidth Page 14 of 18 FCC ID: RUMCL3 Waveform of occupied duty cycle 360μs 120μs Page 15 of 18 FCC ID: RUMCL3 - Page 16 of 18 FCC ID: RUMCL3 Page 17 of 18 FCC ID: RUMCL3 Page 18 of 18 FCC ID: RUMCL3

Page 1 of 18 FCC ID: RUMCL3 The waveforms of models CL3, CS-CL3&BT-CL3 Radiated Emission waveform below 1GHz X axe (Vertical) MEASUREMENT RESULT: "R40628IT001V_fin QP" 6/28/2004 13:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.58 VERTICAL 14.26 3.71 80.80 4.22 868.255952 56.19 VERTICAL 20.23 5.33 60.80 4.61 Page 2 of 18 FCC ID: RUMCL3 X axe (Horizontal) MEASUREMENT RESULT: "R40628IT001H_fin QP" 6/28/2004 14:14 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 76.74 HORIZONTAL 14.26 3.71 80.80 4.06 868.259519 57.34 HORIZONTAL 20.23 5.33 60.80 3.46 Page 3 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT002H_fin QP" 6/28/2004 14:47 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.35 HORIZONTAL 14.26 3.71 80.80 3.45 868.259519 57.72 HORIZONTAL 20.23 5.33 60.80 3.08 Page 4 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT002V_fin QP" 6/28/2004 15:12 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 77.43 VERTICAL 14.26 3.71 80.80 3.37 868.259519 57.91 VERTICAL 20.23 5.33 60.80 2.89 Page 5 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT003H_fin QP" 6/28/2004 15:48 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 74.76 HORIZONTAL 14.26 3.71 80.80 6.04 868.259519 54.73 HORIZONTAL 20.23 5.33 60.80 6.07 Page 6 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT003V_fin QP" 6/28/2004 16:22 Frequency Level Polarisation Attenna Factor Cable Loss Limit Margin MHz dBμV/m dB/m dB dBμV/m dB 434.026575 73.03 VERTICAL 14.26 3.71 80.80 7.77 868.259519 54.02 VERTICAL 20.23 5.33 60.80 6.78 Page 7 of 18 FCC ID: RUMCL3 Radiated Emission waveform above 1GHz X axe (Horizontal) MEASUREMENT RESULT: "R40628IT004H_fin QP" 6/28/2004 17:06 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.61 HORIZONTAL 23.30 4.30 60.80 4.19 -9.60 1727.173382 57.17 HORIZONTAL 24.50 5.00 60.80 3.43 -9.60 2170.200681 52.74 HORIZONTAL 26.90 5.60 60.80 8.06 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953906 49.77 HORIZONTAL 30.70 7.10 60.80 11.03 -9.60 3909.819639 52.65 HORIZONTAL 31.90 7.60 54.00 1.35 -9.60 Page 8 of 18 FCC ID: RUMCL3 X axe (Vertical) MEASUREMENT RESULT: "R40628IT004V_fin QP" 6/28/2004 17:45 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 54.82 VERTICAL 23.30 4.30 60.80 5.98 -9.60 1727.173382 55.34 VERTICAL 24.50 5.00 60.80 5.46 -9.60 2170.200681 57.05 VERTICAL 26.90 5.60 60.80 3.75 -9.60 2603.206413 58.35 VERTICAL 28.20 5.80 60.80 2.45 -9.60 3476.953908 51.95 VERTICAL 30.70 7.10 60.80 8.85 -9.60 3909.819639 52.87 VERTICAL 31.90 7.60 54.00 1.13 -9.60 Page 9 of 18 FCC ID: RUMCL3 Y axe (Horizontal) MEASUREMENT RESULT: "R40628IT005H_fin QP" 6/28/2004 19:46 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 56.77 HORIZONTAL 23.30 4.30 60.80 4.03 -9.60 1727.173382 57.18 HORIZONTAL 24.50 5.00 60.80 3.62 -9.60 2170.200681 57.04 HORIZONTAL 26.90 5.60 60.80 3.76 -9.60 2603.206413 57.45 HORIZONTAL 28.20 5.80 60.80 3.35 -9.60 3476.953908 52.43 HORIZONTAL 30.70 7.10 60.80 8.37 -9.60 3909.819639 51.72 HORIZONTAL 31.90 7.60 54.00 2.28 -9.60 Page 10 of 18 FCC ID: RUMCL3 Y axe (Vertical) MEASUREMENT RESULT: "R40628IT005V_fin QP" 6/28/2004 20:27 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.21 VERTICAL 23.30 4.30 60.80 3.59 -9.60 1727.173382 57.09 VERTICAL 24.50 5.00 60.80 3.71 -9.60 2170.200681 54.03 VERTICAL 26.90 5.60 60.80 6.77 -9.60 2603.206413 54.74 VERTICAL 28.20 5.80 60.80 6.06 -9.60 3476.953908 44.73 VERTICAL 30.70 7.10 60.80 16.07 -9.60 3909.819639 52.93 VERTICAL 31.90 7.60 54.00 1.07 -9.60 Page 11 of 18 FCC ID: RUMCL3 Z axe (Horizontal) MEASUREMENT RESULT: "R40628IT006H_fin QP" 6/28/2004 21:12 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 57.89 HORIZONTAL 23.30 4.30 60.80 2.91 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 55.73 HORIZONTAL 26.90 5.60 60.80 5.07 -9.60 2603.206413 57.04 HORIZONTAL 28.20 5.80 60.80 3.76 -9.60 3476.953908 52.96 HORIZONTAL 30.70 7.10 60.80 7.84 -9.60 3909.819639 52.84 HORIZONTAL 31.90 7.60 54.00 1.16 -9.60 Page 12 of 18 FCC ID: RUMCL3 Z axe (Vertical) MEASUREMENT RESULT: "R40628IT006V_fin QP" 6/28/2004 21:55 Frequency Level Polarisation Antenna Factor Cable loss Limit Margin average factor MHz dBμV/m dB/m dB dBμV/m dB dB 1296.083156 58.39 HORIZONTAL 23.30 4.30 60.80 2.41 -9.60 1727.173382 57.98 HORIZONTAL 24.50 5.00 60.80 2.82 -9.60 2170.200681 56.86 HORIZONTAL 26.90 5.60 60.80 3.94 -9.60 2603.206413 55.01 HORIZONTAL 28.20 5.80 60.80 5.79 -9.60 3476.953908 50.05 HORIZONTAL 30.70 7.10 60.80 10.75 -9.60 3909.819639 52.73 HORIZONTAL 31.90 7.60 54.00 1.27 -9.60 Page 13 of 18 FCC ID: RUMCL3 Waveform of Bandwidth Page 14 of 18 FCC ID: RUMCL3 Waveform of occupied duty cycle 360μs 120μs Page 15 of 18 FCC ID: RUMCL3 - Page 16 of 18 FCC ID: RUMCL3 Page 17 of 18 FCC ID: RUMCL3 Page 18 of 18 FCC ID: RUMCL3

Page 1 of 6 FCC ID: RUMCL3 Test-Setups of Model CL3, CS-CL3&BT-CL3 Test-setups below 1 GHz X axe Page 2 of 6 FCC ID: RUMCL3 Y axe Page 3 of 6 FCC ID: RUMCL3 Z axe Page 4 of 6 FCC ID: RUMCL3 Test-setups above 1 GHz X axe Page 5 of 6 FCC ID: RUMCL3 Y axe Page 6 of 6 FCC ID: RUMCL3 Z axe
