RWO-RZ010133Gaming Mouse

0 | For gamers by gamers™ USER MANUAL USER MANUAL 1 | razer™ 3. TECHNICAL SPECIFICATIONS Lapboard (RZ03-0133) • Anti-ghosting capability for up to 10 simultaneous key presses • Chiclet styled keycaps • Dedicated Android buttons • Cortex quick launch button • Battery life of up to 4 months - The life expectancy of this battery depends upon its usage • Battery type: Li-Po (1500 mAh) Mouse (RZ01-0133) • 3500 DPI optical sensor • Ambidextrous form factor • 40 hours battery life for continuous use - The life expectancy of this battery depends upon its usage • Battery type: Li-Po (1000 mAh) 2 | For gamers by gamers™ 4. DEVICE LAYOUT A. lapboard B. mouse C. RF USB Dongle D. Rechargeable battery for Razer Turret gaming mouse E. Charging dock F. Power connector cable G. Power adapter H. Interchangeable plugs* *May include adapter plugs for specific regions USER MANUAL 3 | razer™ CONNECTING THE RAZER TURRET VIA BLUETOOTH® SMART Note: The Razer Turret gaming lapboard and mouse are set to Bluetooth mode by default. Razer Turret gaming mouse 1. Push the slider switch on the Razer Turret mouse to . This switches the mouse on and activates pairing mode. The LED indicator will start to blink in blue. 2. Activate Bluetooth® on your device and search for new Bluetooth® devices. 3. Select “Razer Turret gaming mouse” from the list of devices found. 4 | For gamers by gamers™ 4. When pairing is complete, the LED indicator will stay lit in blue for 5s before fading off. Note: To pair your Razer Turret gaming mouse to a different device, disconnect the current Bluetooth connection from host device. Then, press and hold the 4 side buttons for 3s to manually activate pairing mode. USER MANUAL 5 | razer™ Razer Turret gaming lapboard 1. Push the Slider switch on the Razer Turret gaming lapboard to . 2. Press the Power button to turn the Razer Turret gaming lapboard on and activate pairing mode. The LED indicator will start to blink in blue. 6 | For gamers by gamers™ 3. Activate Bluetooth® on your device and search for new Bluetooth® devices. 4. Select “Razer Turret gaming lapboard” from the list of devices found. 5. When pairing is complete, the LED indicator will stay lit in blue for 5s before fading off. Note: To pair your Razer Turret gaming lapboard to a different device, disconnect the current Bluetooth connection from host device. Then, press and hold the power button for 3s to manually activate pairing mode. USER MANUAL 7 | razer™ CONNECTING THE RAZER TURRET VIA THE WIRELESS DONGLE 1. Push the Slider switch on both the Razer Turret gaming lapboard and mouse to (2.4GHz wireless). 2. Remove the top cover of the Razer Turret gaming mouse by lifting the back of the top cover and pulling it backwards. Retrieve the USB dongle. Reattach the top cover. 8 | For gamers by gamers™ 3. Plug the USB dongle to the device you wish to pair to. 4. Press the Power button to turn the Razer Turret gaming lapboard on. 5. When successfully connected, the LED indicator will stay lit in green for 5s before fading off. USER MANUAL 9 | razer™ 6. INSTALLING YOUR RAZER TURRET Step 1: Connect your Razer device to the USB port of your computer. Step 2: Install Razer Synapse when prompted* or download the installer from www.razerzone.com/synapse. Step 3: Create your Razer ID or login to Synapse with your existing Razer ID. *Applicable for Windows 8 or later. Note: Razer Synapse is only available when the Razer Turret is connected to a PC. 10 | For gamers by gamers™ 11. SAFETY AND MAINTENANCE IMPORTANT SAFETY & MAINTENANCE INFORMATION WARNING : Failure to follow these safety instructions could result in fire, electric shock, or other injury or damage. Please follow these safety rules for handling your Razer Turret and for working more comfortably. Keep these guide handy for future reference by you and others. To operate your Razer Turret safely and reduce the possibility of heat-related injuries, follow these guidelines: 1. Set up your Razer Turret and power adapter on a stable work surface that allows for adequate air circulation under and around the computer/TV. 2. Do not use or install near water, moisture, or other wet surfaces. 3. Do not use or install near any heat or naked flame sources. Do not use around radiators, stoves, fire places, candles or other hot surfaces. 4. Do not block ventilation grills or openings. Install the apparatus in a cool, dry place. 5. Clean only with a dry or damp cloth. Unplug the apparatus before cleaning and do not use aerosol or liquid cleaning agents. 6. Do not insert or push any objects into openings on the product. 7. Refer all servicing to qualified service personnel. Do not attempt to service this apparatus yourself. Removing the covers will expose you to dangerous electric currents. USER MANUAL 11 | razer™ POWER ADAPTER FOR THE RAZER TURRET NOTICE : Incorrect storage or use of your power adapter may void the manufacturer’s warranty. This power adapter complies with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950-1). This apparatus should only be operated from the type of power source indicated on the label. If you are unsure of the power source in the location you intend to operate the apparatus please consult the local power company or a qualified technician. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. 1. Use only the power adapter that came with your Razer Turret, or the Razer- authorized power adapter that is compatible with this product. 2. The power adapter is equipped with exchangeable adapter plug, use only the appropriate adapter plug for your region. 3. Make sure the exchangeable adapter plug is fully inserted into the power adapter before plugging the adapter into a power outlet. 4.…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Razer Inc. Address: 2035 Corte Del Nogal, Suite 101 City: Carlsbad State: California 92011 Country: United States Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: Gaming Mouse Type designation: RZ01-0133 Trademark: RAZER on our behalf. Date: 2015-04-22 City: Carlsbad Name: Johnsen Tia Function: Senior Engineer Signature: ...............................

Project No.: 1504C030 Page 2 of 9 Project No.: 1504C030 Page 3 of 9 Project No.: 1504C030 Page 4 of 9 Project No.: 1504C030 Page 5 of 9

Project No.: 1504C030 Page 6 of 9 Project No.: 1504C030 Page 7 of 9 Project No.: 1504C030 Page 8 of 9 Project No.: 1504C030 Page 9 of 9

FCC RF EXPOSURE REPORT FCC ID: RWO-RZ010133 Equipment : Gaming Mouse Model : RZ01-0133 Applicant : Razer Inc. Address : 2035 Corte Del Nogal, Suite 101. Carlsbad California 92011. USA According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Table for Filed Antenna Ant. Brand P/N Antenna TypeConnector Gain(dBi) 1 RFANT8010080A3TChip N/A 3.03 GENERAL CONCULUSION: Maximum measured transmitter power: OutputPower (dBm) Output Power (mW) Limit (mW) -0.79 0.83 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 0.83mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold.

Report No.: BTL-FCCP-1-1504C030 Page 1 of 61 FCC Radio Test Report FCC ID:RWO-RZ010133 This report concerns (check one): Original Grant Class II Change Project No. : 1504C030 Equipment : Gaming Mouse Model Name : RZ01-0133 Applicant : Razer Inc. Address : 2035 Corte Del Nogal, Suite 101. Carlsbad California 92011. USA Date of Receipt : Apr. 01, 2015 Date of Test : Apr. 01, 2015~ Apr. 17, 2015 Issued Date : Apr. 20, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1504C030 Page 2 of 61 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1504C030 Page 3 of 61 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 EUT TEST CONDITIONS 14 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 TEST PROCEDURE 16 4.2.3 DEVIATION FROM TEST STANDARD 16 4.2.4 TEST SETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 EUT TEST CONDITIONS 18 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 18 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 19 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 19 5 . BANDWIDTH TEST 20 5.1 APPLIED PROCEDURES / LIMIT 20 5.1.1 TEST PROCEDURE 20 5.1.2 DEVIATION FROM STANDARD 20 5.1.3 TEST SETUP 20 5.1.4 EUT OPERATION CONDITIONS 20 5.1.5 EUT TEST CONDITIONS 20 5.1.6 TEST RESULTS 20 Report No.: BTL-FCCP-1-1504C030 Page 4 of 61 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 21 6.1 APPLIED PROCEDURES / LIMIT 21 6.1.1 TEST PROCEDURE 21 6.1.2 DEVIATION FROM STANDARD 21 6.1.3 TEST SETUP 21 6.1.4 EUT OPERATION CONDITIONS 21 6.1.5 EUT TEST CONDITIONS 21 6.1.6 TEST RESULTS 21 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 22 7.1 APPLIED PROCEDURES / LIMIT 22 7.1.1 TEST PROCEDURE 22 7.1.2 DEVIATION FROM STANDARD 22 7.1.3 TEST SETUP 22 7.1.4 EUT OPERATION CONDITIONS 22 7.1.5 EUT OPERATION CONDITIONS 22 7.1.6 TEST RESULTS 22 8 . POWER SPECTRAL DENSITY TEST 23 8.1 APPLIED PROCEDURES / LIMIT 23 8.1.1 TEST PROCEDURE 23 8.1.2 DEVIATION FROM STANDARD 23 8.1.3 TEST SETUP 23 8.1.4 EUT OPERATION CONDITIONS 23 8.1.5 EUT TEST CONDITIONS 23 8.1.6 TEST RESULTS 23 9 . MEASUREMENT INSTRUMENTS LIST 24 ATTACHMENT A - CONDUCTED EMISSION 26 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 29 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 31 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 38 ATTACHMENT E - BANDWIDTH 51 ATTACHMENT F - MAXIMUM OUTPUT POWER TEST 54 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 55 ATTACHMENT H - POWER SPECTRAL DENSITY TEST 59 Report No.: BTL-FCCP-1-1504C030 Page 5 of 61 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1504C030 Original Issue. Apr. 20, 2015 Report No.: BTL-FCCP-1-1504C030 Page 6 of 61 1. CERTIFICATION Equipment : Gaming Mouse Brand Name : RAZER Model Name : RZ01-0133 Applicant : Razer Inc. Manufacturer : Razer (Asia-Pacific) Pte Ltd Address : 514 Chai Chee Lane #07-01 ~ 06 Singapore 469029 Factory : RAZER TECHNOLOGY AND DEVELOPMENT (SHENZHEN) CO., LTD Address : East Wing, 3rd Floor, Block 2, Phase 1 of Vision Shenzhen Business Park Keji South Road, Hi-Tech Industrial Park, Shenzhen 518057, China Date of Test : Apr. 01, 2015~ Apr. 17, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C :2014 (15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1504C030) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-1-1504C030 Page 7 of 61 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Ite…
