RWO-RZ010299Wireless Mouse

USER MANUAL FOR WIRELESS MOUSE (MODEL: RZ01-0299) WHICH ALSO CONSIST OF A USB DONGLE (MODEL: DGRFG6) 23 MAY 2020 FOR GAMERS. BY GAMERS. ™ 1 WHAT’S INSIDE Wireless Mouse (Model: RZ01-0299) A. Left mouse button B. Right mouse button C. Scroll wheel D. Left tilt-click E. Right tilt-click F. Cycle DPI stage up button G. Status indicator H. Mouse button 5 I. Mouse button 4 J. Micro-USB port K. Ultraslick mouse feet L. 5G optical sensor M. USB dongle compartment N. Slider switch  Bluetooth mode  Power off mode  2.4GHz mode O. Pairing indicator P. Pair/switch button Q. 2.4GHz Wireless USB dongle R. USB cable DPI stages are as follows: 800, 1800 (default), 3200, 5000, and 10000. The DPI stages can be customized using Razer Synapse 3. FOR GAMERS. BY GAMERS. ™ 2 WHAT’S NEEDED PRODUCT REQUIREMENTS  PC with a free USB port or Bluetooth connectivity LET’S GET YOU COVERED You’ve got a great device in your hands complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com Got a question? Ask the Razer Support Team at support.razer.com Your product’s serial number can be found here. FOR GAMERS. BY GAMERS. ™ 3 GETTING STARTED CHARGING YOUR RAZER RZ01-0299 Plug the USB cable from your computer’s USB port to your Razer RZ01-0299. This connection also acts as the WIRED MODE for your device. For best results, please fully charge your Razer RZ01-0299 before using it for the first time. A depleted battery will be fully charged in approximately 4 hours. If the Razer RZ01-0299 has not been used for an extended period, you may need to recharge it before use. The Razer RZ01-0299 requires a USB connection that can supply sufficient power to charge the battery. The battery charging process of the Razer RZ01-0299 may be affected if connected to a non- powered USB hub or non-powered USB ports found on certain keyboards and other peripherals. When in doubt, it’s preferable to connect the Razer RZ01-0299 directly to the USB port of your computer. CHARGING INDICATOR While plugged in, the Razer RZ01-0299 ’s status indicator will display its current battery level (as shown below). Battery level Color Effect <25% Red Breathing 26-50% Orange Breathing FOR GAMERS. BY GAMERS. ™ 4 51-75% Yellow Breathing 76-99% Green Breathing 100% Green Static LOW POWER INDICATOR The Razer RZ01-0299 ’s status indicator will blink red twice in repeated intervals to indicate that the battery’s power is less than 5%. This lighting sequence will repeat until the battery is drained or the mouse is connected to the PC via the charging cable. You can also check the Razer RZ01-0299’s battery level by moving the slider switch from power off to either Bluetooth or 2.4Ghz mode. The status indicator will light up in the color according to the mouse’s current power level (as shown below). Battery level Color <25% Red 26-50% Orange 51-75% Yellow 76-100% Green FOR GAMERS. BY GAMERS. ™ 5 CONNECTING THE RAZER RZ01-0299 VIA 2.4 GHz MODE 1. Remove the compartment cover of the Razer RZ01-0299 and pull out the wireless USB dongle. 2. Close the compartment cover and connect the wireless USB dongle to the USB port of your computer. 3. Switch the slider to 2.4 GHz mode. The pairing indicator will start blinking rapidly. FOR GAMERS. BY GAMERS. ™ 6 4. Wait until the mouse automatically pairs with the wireless USB dongle. When paired, the pairing indicator will change to static white for 3 seconds before turning off. Pairing Paired Keep the pairing devices within close proximity of each other for a faster and more stable connection. Congratulations, your Razer RZ01-0299 is now ready to use in 2.4 GHz mode. CONNECTING THE RAZER RZ01-0299 VIA BLUETOOTH MODE 1. Switch the slider to Bluetooth mode ( ). 2. Select a slot for your Bluetooth device by tapping the pair/switch button. You can pair up to 3 Bluetooth devices on your Razer RZ01-0299. Slot Color 1 (Default) Blue 2 Green FOR GAMERS. BY GAMERS. ™ 7 3 Yellow 3. Press and hold the pair/switch button for 3 seconds. The pairing indicator will blink twice in repeated intervals to show that the device is in pairing mode. Pairing 4. Activate Bluetooth on your device and search for “Razer RZ01-0299” from the list of devices found. 5. Wait until both devices are paired. When paired, the pairing indicator will change to static for 3 seconds before turning off. Paired Keep the pairing devices within close proximity of each other for faster and more stable connection. FOR GAMERS. BY GAMERS. ™ 8 Once both devices have been paired, your Razer RZ01-0299 will automatically reconnect to the device whenever it is in Bluetooth mode and the device is within range. Download the Razer Synapse installer from razer.com/synapse or find out more about your brand-new mouse at support.razer.com FOR GAMERS. BY GAMERS. ™ 9 SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer RZ01-0299, we suggest that you adopt the following guidelines: Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com for assistance. Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads. Keep the device away from liquid, humidity or moisture. Operate the device only within the specific temperature range of 0°C (32°F) to 40°C (104°F). Should the temperature exceed this range, unplug and/or switch off the device in order to let the temperature stabilize to an optimal level. COMFORT Research has shown that long periods of repetitive motion, improper positioning of your computer peripherals, incorrect body position, and poor habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. Below are some guidelines to avoid injury and ensure optimum comfort while using your Razer RZ01-0299.  Position your keyboard and monitor directly in f…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Razer Inc. Address: 9 Pasteur, Suite 100 City: Irvine State: California Country: United States Declare that: Name Representative of agent: Ms. Mandy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: Wireless Mouse Type designation: RZ01-0299, RZ01-0299XXXX-XXXX ( X can be :0~9,A~Z) Trademark: RAZER FCC ID : RWO-RZ010299 on our behalf. Date: 2020-06-15 City: San Francisco Name: Johnsen Tia Function: Senior Director Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Supplier’s Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer: U.S. Responsible Party: Razer Inc., 9 Pasteur, Suite 100, Irvine, California 92618 United States Razer Inc., 9 Pasteur, Suite 100, Irvine, California 92618 United States Contact Person: Tel.: 760 579 0180 Fax: 760 579 0182 Email: [email protected] Internet: https://www.razer.com Model: RZ01-0299, RZ01-0299XXXX-XXXX (X can be :0~9, A~Z) Classification: FCC Part 15B We hereby declare that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC rule part(s) 15B and the most accurate measurement standards. We confirm that the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commission’s requirements. Date: 2020-06-15 ----------------------------------- Johnsen Tia / Senior Director, Regulatory & Compliance [email protected] RAZER INC. 9 Pasteur, Suite 100, Irvine, California 92618 United States

Model Declaration Letter We, the undersigning company Company Name: Razer Inc. Address: 9 Pasteur, Suite 100, Irvine, CA92618, United States Hereby confirm that the following products: Product description: Wireless Mouse Type designation: RZ01-0299, RZ01-0299XXXX-XXXX (X Can be A~Z, 0~9) Trademark: RAZER That All versions of the Model RZ01-0299 and RZ01-0299XXXX-XXXX (X Can be A~Z, 0~9) are electrically equal except the following difference: It is the same as the basic model and X is used to define which country it is for under the same family series. Date: 2020-06-15 Name: Johnsen Tia Telephone: 760 579 0180 E-mail: [email protected] Signature:

Report No.: 1909C015 Page 2 of 13 Report No.: 1909C015 Page 3 of 13 Report No.: 1909C015 Page 4 of 13 Report No.: 1909C015 Page 5 of 13 Report No.: 1909C015 Page 6 of 13 Report No.: 1909C015 Page 7 of 13

Product Label Information Page 1 of 1 29 th June 2020 Product Name: Wireless Mouse Model #: RZ01-0299 Label Location (Bottom of Product)

Report No.: 1909C015 Page 8 of 13 Report No.: 1909C015 Page 9 of 13 ANT Report No.: 1909C015 Page 10 of 13 Report No.: 1909C015 Page 11 of 13 Report No.: 1909C015 Page 12 of 13 Report No.: 1909C015 Page 13 of 13

Report No.: BTL-FCCP-3-1909C015 Page 1 of 7 FCC RF EXPOSURE REPORT FCC ID: RWO-RZ010299 Project No. : 1909C015 Equipment : Wireless Mouse Brand Name : RAZER Test Model : RZ01-0299 Series Model : RZ01-0299XXXX-XXXX ( X can be :0~9,A~Z) Applicant : Razer Inc. Address : 9 Pasteur, Suite 100, Irvine, CA92618, USA. Manufacturer : Razer (Asia-Pacific) Pte.,Ltd. Address : 514 Chai Chee Lane, #07-01-06,Singapore 469029 Factory : RAZER TECHNOLOGY AND DEVELOPMENT (SHENZHEN) CO., LTD Address : East Wing, 3rd Floor, Block 2, Phase 1 of Vision Shenzhen Business Park Keji South Road, Hi-Tech Industrial Park, Shenzhen 518057, China Date of Receipt : Sep. 04, 2019 Date of Test : Sep. 10, 2019 ~ Jan. 15, 2020 Issued Date : Apr. 17, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019121173 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & KDB447498 D01 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Welly Zhou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-1909C015 Page 2 of 7 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Apr. 17, 2020 Report No.: BTL-FCCP-3-1909C015 Page 3 of 7 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Mouse Brand Name RAZER Te s t Model RZ01-0299 Series Model RZ01-0299XXXX-XXXX ( X can be :0~9,A~Z) Model Difference(s) RZ01-0299XXXX-XXXX (X Can be A~Z, 0~9) is consist of the Wireless Mouse (Model RZ01-0299) and USB Dongle (Model DGRFG6). X is use to define which country it is for under the same family series. Power Source 1# DC voltage supplied from PC USB port. 2# Supplied from battery. Model: PL383450 Power Rating 1# DC 5V 500mA 2# DC 3.8V 800mAh 3.04Wh Product Description for LE Operation Frequency 2402 MHz ~ 2480 MHz Modulation Technology GFSK Bit Rate of Transmitter 1Mbps, 2 Mbps Max. Output Power 4.30 dBm (0.0027 W) For 1Mbps 4.30 dBm (0.0027 W) For 2Mbps Product Description for 2.4G SRD Operation Frequency 2403 MHz ~ 2479 MHz Modulation Technology GFSK Bit Rate of Transmitter 2 Mbps Max. Output Power 4.13 dBm (0.0026 W) Report No.: BTL-FCCP-3-1909C015 Page 4 of 7 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the user's manual. 2. Channel List: For LE: Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 20 2442 01 2404 21 2444 02 2406 22 2446 03 2408 23 2448 04 2410 24 2450 05 2412 25 2452 06 2414 26 2454 07 2416 27 2456 08 2418 28 2458 09 2420 29 2460 10 2422 30 2462 11 2424 31 2464 12 2426 32 2466 13 2428 33 2468 14 2430 34 2470 15 2432 35 2472 16 2434 36 2474 17 2436 37 2476 18 2438 38 2478 19 2440 39 2480 Report No.: BTL-FCCP-3-1909C015 Page 5 of 7 For 2.4G SRD: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 2403 27 2429 53 2455 02 2404 28 2430 54 2456 03 2405 29 2431 55 2457 04 2406 30 2432 56 2458 05 2407 31 2433 57 2459 06 2408 32 2434 58 2460 07 2409 33 2435 59 2461 08 2410 34 2436 60 2462 09 2411 35 2437 61 2463 10 2412 36 2438 62 2464 11 2413 37 2439 63 2465 12 2414 38 2440 64 2466 13 2415 39 2441 65 2467 14 2416 40 2442 66 2468 15 2417 41 2443 67 2469 16 2418 42 2444 68 2470 17 2419 43 2445 69 2471 18 2420 44 2446 70 2472 19 2421 45 2447 71 2473 20 2422 46 2448 72 2474 21 2423 47 2449 73 2475 22 2424 48 2450 74 2476 23 2425 49 2451 75 2477 24 2426 50 2452 76 2478 25 2427 51 2453 77 2479 26 2428 52 2454 3. Table for Filed Antenna: For LE/2.4G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 YAGEO 690800012400 Chip N/A 1.67 Report No.: BTL-FCCP-3-1909C015 Page 6 of 7 2. GENERAL CONCULUSION According to FCC KDB447498 D01, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Appendix A - SAR Test Exclusion Thresholds for 100 MHz - 6 GHz and < 50 mm MHz 5 10 15 20 25 30 35 40 45 50 mm 150 39 77 116 155 194 232 271 310 349 387 SAR Test Exclusion Thresholds (mW) 300 27 55 82 110 137 164 192 219 246 274 450 22 45 67 89 112 134 157 179 201 224 835 16 33 49 66 82 98 115 131 148 164 900 16 32 47 63 79 95 111 126 142 158 1500 12 24 37 49 61 73 86 98 110 122 1900 11 22 33 44 54 65 76 87 98 109 2450 10 19 29 38 48 57 67 77 86 96 3600 8 16 24 32 40 47 55 63 71 79 5200 7 13 20 26 33 39 46 53 59 66 5400 6 13 19 26 32 39 45 52 58 65 5800 6 12 19 25 31 37 44 50 56 62 Report No.: BTL-FCCP-3-1909C015 Page 7 of 7 3. TEST RESULTS For LE: Max. Output Power (dBm) Max. Output Power (mW) Limit (mW) 4.30 2.692 10 For 2.4G SRD: Max. Output Power (dBm) Max. Output Power (mW) Limit (mW) 4.13 2.588 10 Note: The maximum measured output peak power of this EUT is 2.692mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold. End of Test Report

Report No.: BTL-FCCP-2-1909C015 Page 1 of 55 FCC Radio Test Report FCC ID: RWO-RZ010299 This report concerns: Original Grant Project No. : 1909C015 Equipment : Wireless Mouse Brand Name : RAZER Test Model : RZ01-0299 Series Model : RZ01-0299XXXX-XXXX ( X can be :0~9,A~Z) Applicant : Razer Inc. Address : 9 Pasteur, Suite 100, Irvine, CA92618, USA. Manufacturer : Razer (Asia-Pacific) Pte.,Ltd. Address : 514 Chai Chee Lane, #07-01-06,Singapore 469029 Factory : RAZER TECHNOLOGY AND DEVELOPMENT (SHENZHEN) CO., LTD Address : East Wing, 3rd Floor, Block 2, Phase 1 of Vision Shenzhen Business Park Keji South Road, Hi-Tech Industrial Park, Shenzhen 518057, China Date of Receipt : Sep. 04, 2019 Date of Test : Sep. 10, 2019 ~ Jan. 15, 2020 Issued Date : Apr. 17, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019121173 for conducted, DG2019121174 for radiated. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 FCC KDB 558074 D01 DTS Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Welly Zhou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-1909C015 Page 2 of 55 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-1909C015 Page 3 of 55 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 3.3 PARAMETERS OF TEST SOFTWARE 10 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 11 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 DEVIATION FROM TEST STANDARD 12 3.4 TEST SETUP 13 3.5 EUT OPERATING CONDITIONS 13 3.6 TEST RESULTS 13 4 . RADIATED EMISSION TEST 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 16 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULT - 9 KHZ TO 30 MHZ 17 4.7 TEST RESULT - 30 MHZ TO 1000 MHZ 17 4.8 TEST RESULT - ABOVE 1000 MHZ 17 5 . BANDWIDTH TEST 18 5.1 LIMIT 18 5.2 TEST PROCEDURE 18 5.3 DEVIATION FROM STANDARD 18 5.4 TEST SETUP 18 Report No.: BTL-FCCP-2-1909C015 Page 4 of 55 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 18 5.6 TEST RESULTS 18 6 . MAXIMUM OUTPUT POWER 19 6.1 LIMIT 19 6.2 TEST PROCEDURE 19 6.3 DEVIATION FROM STANDARD 19 6.4 TEST SETUP 19 6.5 EUT OPERATION CONDITIONS 19 6.6 TEST RESULTS 19 7 . CONDUCTED SPURIOUS EMISSION 20 7.1 LIMIT 20 7.2 TEST PROCEDURE 20 7.3 DEVIATION FROM STANDARD 20 7.4 TEST SETUP 20 7.5 EUT OPERATION CONDITIONS 20 7.6 TEST RESULTS 20 8 . POWER SPECTRAL DENSITY TEST 21 8.1 LIMIT 21 8.2 TEST PROCEDURE 21 8.3 DEVIATION FROM STANDARD 21 8.4 TEST SETUP 21 8.5 EUT OPERATION CONDITIONS 21 8.6 TEST RESULTS 21 9 . MEASUREMENT INSTRUMENTS LIST 22 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 24 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 27 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 32 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 35 APPENDIX E - BANDWIDTH 48 APPENDIX F - MAXIMUM OUTPUT POWER 50 APPENDIX G - CONDUCTED SPURIOUS EMISSION 52 APPENDIX H - POWER SPECTRAL DENSITY 54 Report No.: BTL-FCCP-2-1909C015 Page 5 of 55 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Apr. 17, 2020 Report No.: BTL-FCCP-2-1909C015 Page 6 of 55 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emission APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS -----…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1909C015 Page 1 of 68 ` FCC Radio Test Report FCC ID: RWO-RZ010299 This report concerns: Original Grant Project No. : 1909C015 Equipment : Wireless Mouse Brand Name : RAZER Test Model : RZ01-0299 Series Model : RZ01-0299XXXX-XXXX ( X can be :0~9,A~Z) Applicant : Razer Inc. Address : 9 Pasteur, Suite 100, Irvine, CA92618, USA. Manufacturer : Razer (Asia-Pacific) Pte.,Ltd. Address : 514 Chai Chee Lane, #07-01-06,Singapore 469029 Factory : RAZER TECHNOLOGY AND DEVELOPMENT (SHENZHEN) CO., LTD Address : East Wing, 3rd Floor, Block 2, Phase 1 of Vision Shenzhen Business Park Keji South Road, Hi-Tech Industrial Park, Shenzhen 518057, China Date of Receipt : Sep. 04, 2019 Date of Test : Sep. 10, 2019 ~ Jan. 15, 2020 Issued Date : Apr. 17, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019121173 for conducted, DG2019121174 for radiated. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Welly Zhou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-1909C015 Page 2 of 68 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/I EC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-1909C015 Page 3 of 68 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 PARAMETERS OF TEST SOFTWARE 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 SUPPORT UNITS 11 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 DEVIATION FROM TEST STANDARD 12 3.4 TEST SETUP 13 3.5 EUT OPERATING CONDITIONS 13 3.6 TEST RESULTS 13 4 . RADIATED EMISSION TEST 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 16 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULT - 9 KHZ TO 30 MHZ 17 4.7 TEST RESULT - 30 MHZ TO 1000 MHZ 17 4.8 TEST RESULT - ABOVE 1000 MHZ 17 5 . BANDWIDTH TEST 18 5.1 LIMIT 18 5.2 TEST PROCEDURE 18 5.3 DEVIATION FROM STANDARD 18 5.4 TEST SETUP 18 5.5 EUT OPERATION CONDITIONS 18 Report No.: BTL-FCCP-1-1909C015 Page 4 of 68 Table of Contents Page 5.6 TEST RESULTS 18 6 . MAXIMUM OUTPUT POWER 19 6.1 LIMIT 19 6.2 TEST PROCEDURE 19 6.3 DEVIATION FROM STANDARD 19 6.4 TEST SETUP 19 6.5 EUT OPERATION CONDITIONS 19 6.6 TEST RESULTS 19 7 . CONDUCTED SPURIOUS EMISSION 20 7.1 LIMIT 20 7.2 TEST PROCEDURE 20 7.3 DEVIATION FROM STANDARD 20 7.4 TEST SETUP 20 7.5 EUT OPERATION CONDITIONS 20 7.6 TEST RESULTS 20 8 . POWER SPECTRAL DENSITY TEST 21 8.1 LIMIT 21 8.2 TEST PROCEDURE 21 8.3 DEVIATION FROM STANDARD 21 8.4 TEST SETUP 21 8.5 EUT OPERATION CONDITIONS 21 8.6 TEST RESULTS 21 9 . MEASUREMENT INSTRUMENTS LIST 22 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 24 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 27 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 32 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 35 APPENDIX E - BANDWIDTH 60 APPENDIX F - MAXIMUM OUTPUT POWER 62 APPENDIX G - CONDUCTED SPURIOUS EMISSION 64 APPENDIX H - POWER SPECTRAL DENSITY 67 Report No.: BTL-FCCP-1-1909C015 Page 5 of 68 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Apr. 17, 2020 Report No.: BTL-FCCP-1-1909C015 Page 6 of 68 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emission APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS ------ 15.203 …

Text truncated - open the document above for the full version.

Report No.: 1909C015 Page 1 of 5 EUT TEST PHOTO Report No.: 1909C015 Page 2 of 5 AC Power Line Conducted Emissions Test Photos Report No.: 1909C015 Page 3 of 5 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: 1909C015 Page 4 of 5 Radiated Emissions Test Photos 30 MHz to 1000 MHz Report No.: 1909C015 Page 5 of 5 Radiated Emissions Test Photos Above 1 GHz
